ZyXEL Communications DIMENSION ES-1124 User manual

www.zyxel.com
ES-1124
Ethernet Switch
User’s Guide
Version 1.00
10/2006
Edition 2

About This User's Guide
ES-1124 User’s Guide 3
About This User's Guide
Intended Audience
This manual is intended for people who want to install the switch on their network. You
should have at least a basic knowledge of TCP/IP networking concepts and topology.
Related Documentation
• Quick Start Guide
The Quick Start Guide is designed to help you get up and running right away. It contains
information on installing your switch.
• Supporting Disk
Refer to the included CD for support documents.
• ZyXEL Web Site
Please refer to www.zyxel.com for additional support documentation and product
certifications.
User Guide Feedback
Help us help you. Send all User Guide-related comments, questions or suggestions for
improvement to the following address, or use e-mail instead. Thank you!
The Technical Writing Team,
ZyXEL Communications Corp.,
6 Innovation Road II,
Science-Based Industrial Park,
Hsinchu, 300, Taiwan.
E-mail: [email protected]

Document Conventions
ES-1124 User’s Guide
4
Document Conventions
Warnings and Notes
These are how warnings and notes are shown in this User’s Guide.
1Warnings tell you about things that could harm you or your device.
"Notes tell you other important information (for example, other things you may
need to configure or helpful tips) or recommendations.
Syntax Conventions
• The ES-1124 may be referred to as the “switch”, the “device” or the “system” in this
User’s Guide.
• Product labels are all in bold font.
• Units of measurement may denote the “metric” value or the “scientific” value. For
example, “k” for kilo may denote “1000” or “1024”, “M” for mega may denote “1000000”
or “1048576” and so on.
• “e.g.,” is a shorthand for “for instance”, and “i.e.,” means “that is” or “in other words”.
Icons Used in Figures
Figures in this User’s Guide may use the following generic icons. The ES-1124 icon is not an
exact representation of your device.
the ES-1124 Computer Server
Printer Switch Internetl

Safety Warnings
ES-1124 User’s Guide 5
Safety Warnings
1For your safety, be sure to read and follow all warning notices and instructions.
• Do NOT use this product near water, for example, in a wet basement or near a swimming
pool.
• Do NOT expose your device to dampness, dust or corrosive liquids.
• Do NOT store things on the device.
• Do NOT install, use, or service this device during a thunderstorm. There is a remote risk
of electric shock from lightning.
• Connect ONLY suitable accessories to the device.
• Do NOT open the device or unit. Opening or removing covers can expose you to
dangerous high voltage points or other risks. ONLY qualified service personnel should
service or disassemble this device. Please contact your vendor for further information.
• Make sure to connect the cables to the correct ports.
• Place connecting cables carefully so that no one will step on them or stumble over them.
• Always disconnect all cables from this device before servicing or disassembling.
• Use ONLY an appropriate power adaptor or cord for your device.
• Connect the power adaptor or cord to the right supply voltage (for example, 110V AC in
North America or 230V AC in Europe).
• Do NOT allow anything to rest on the power adaptor or cord and do NOT place the
product where anyone can walk on the power adaptor or cord.
• Do NOT use the device if the power adaptor or cord is damaged as it might cause
electrocution.
• If the power adaptor or cord is damaged, remove it from the power outlet.
• Do NOT attempt to repair the power adaptor or cord. Contact your local vendor to order a
new one.
• Do not use the device outside, and make sure all the connections are indoors. There is a
remote risk of electric shock from lightning.
• Do NOT obstruct the device ventilation slots, as insufficient airflow may harm your
device.

Safety Warnings
ES-1124 User’s Guide
6
This product is recyclable. Dispose of it properly.

Table of Contents
ES-1124 User’s Guide 7
Table of Contents
About This User's Guide .......................................................................................................... 3
Document Conventions............................................................................................................4
Safety Warnings........................................................................................................................ 5
Table of Contents...................................................................................................................... 7
List of Figures ........................................................................................................................... 9
List of Tables........................................................................................................................... 11
Part I: Introduction, Hardware Installation and Troubleshooting ...... 13
Chapter 1
Getting to Know Your Switch................................................................................................. 15
1.1 Introduction .......................................................................................................................... 15
1.1.1 Backbone Application ................................................................................................. 15
1.1.2 Bridging Example ....................................................................................................... 15
Chapter 2
Hardware Installation and Connection ................................................................................. 17
2.1 Freestanding Installation ..................................................................................................... 17
2.2 Mounting the Switch on a Rack .......................................................................................... 18
2.2.1 Rack-mounted Installation Requirements .................................................................. 18
2.2.2 Attaching the Mounting Brackets to the Switch .......................................................... 18
2.2.3 Mounting the Switch on a Rack .................................................................................. 19
Chapter 3
Hardware Overview................................................................................................................. 21
3.1 Panel Connections ............................................................................................................. 21
3.1.1 Ethernet Ports ............................................................................................................ 21
3.1.2 Dual Personality GbE Interfaces ................................................................................ 22
3.1.3 Mini-GBIC Slots .........................................................................................................22
3.2 Rear Panel ........................................................................................................................... 24
3.2.1 Power Connector ....................................................................................................... 24
3.3 LEDs ................................................................................................................................ 24

Table of Contents
ES-1124 User’s Guide
8
Chapter 4
Troubleshooting...................................................................................................................... 25
Part II: Appendices and Index............................................................... 27
Appendix A Product Specifications ................................................................................... 29
Appendix B IP Addresses and Subnetting ........................................................................ 31
Appendix C Legal Information........................................................................................... 39
Appendix D Customer Support ......................................................................................... 43
Index......................................................................................................................................... 47

List of Figures
ES-1124 User’s Guide 9
List of Figures
Figure 1 Backbone Application .............................................................................................................. 15
Figure 2 Bridging Application ................................................................................................................ 16
Figure 3 Attaching Rubber Feet ............................................................................................................ 17
Figure 4 Attaching the Mounting Brackets ............................................................................................. 18
Figure 5 Mounting the Switch on a Rack .............................................................................................. 19
Figure 6 Front Panel ............................................................................................................................. 21
Figure 7 Transceiver Installation Example ............................................................................................. 23
Figure 8 Installed Transceiver .............................................................................................................. 23
Figure 9 Opening the Transceiver’s Latch Example ..............................................................................23
Figure 10 Transceiver Removal Example .............................................................................................. 23
Figure 11 Rear Panel ............................................................................................................................. 24
Figure 12 Network Number and Host ID ................................................................................................ 32
Figure 13 Subnetting Example: Before Subnetting ................................................................................34
Figure 14 Subnetting Example: After Subnetting ................................................................................... 35

List of Figures
ES-1124 User’s Guide
10

List of Tables
ES-1124 User’s Guide 11
List of Tables
Table 1 Panel Connections .................................................................................................................... 21
Table 2 LEDs ......................................................................................................................................... 24
Table 3 Hardware Specifications ........................................................................................................... 29
Table 4 Firmware Specifications ............................................................................................................ 29
Table 5 .................................................................................................................................................. 32
Table 6 Subnet Masks ........................................................................................................................... 33
Table 7 Maximum Host Numbers .......................................................................................................... 33
Table 8 Alternative Subnet Mask Notation ............................................................................................. 33
Table 9 Subnet 1 .................................................................................................................................... 35
Table 10 Subnet 2 .................................................................................................................................. 36
Table 11 Subnet 3 .................................................................................................................................. 36
Table 12 Subnet 4 .................................................................................................................................. 36
Table 13 Eight Subnets .......................................................................................................................... 36
Table 14 24-bit Network Number Subnet Planning ................................................................................37
Table 15 16-bit Network Number Subnet Planning ................................................................................37

List of Tables
ES-1124 User’s Guide
12

13
PART I
Introduction,
Hardware
Installation and
Troubleshooting
This part contains the following:
Getting to Know Your Switch (15)
Hardware Installation and Connection (17)
Hardware Overview (21)
Troubleshooting (25)

14

ES-1124 User’s Guide 15
CHAPTER 1
Getting to Know Your Switch
This chapter introduces the main features and applications of the switch.
1.1 Introduction
The ES-1124 is an Ethernet switch with 24 10/100Mbps ports and 2 GbE dual personality
interfaces for uplink. A dual personality interface includes one Gigabit port and one slot for a
mini-GBIC transceiver (SFP module) with one port active at a time.
See Appendix A on page 29 for a full list of features available on the switch.
1.1.1 Backbone Application
The switch is an ideal solution for small networks where rapid growth can be expected in the
near future. The switch can be used standalone for a group of heavy traffic users. You can
connect computers and servers directly to the switch’s port or connect other switches to the
switch.
In this example, all computers can share high-speed applications on the server. To expand the
network, simply add more networking devices such as switches, routers, computers, print
servers etc.
Figure 1 Backbone Application
1.1.2 Bridging Example
In this example application the switch connects different company departments (RD and
Sales) to the corporate backbone. It can alleviate bandwidth contention and eliminate server
and network bottlenecks. All users that need high bandwidth can connect to high-speed
department servers via the switch. You can provide a super-fast uplink connection by using a
Gigabit Ethernet/mini-GBIC port on the switch.

Chapter 1 Getting to Know Your Switch
ES-1124 User’s Guide
16
Moreover, the switch eases supervision and maintenance by allowing network managers to
centralize multiple servers at a single location.
Figure 2 Bridging Application

ES-1124 User’s Guide 17
CHAPTER 2
Hardware Installation and
Connection
This chapter shows you how to install and connect the switch.
2.1 Freestanding Installation
1Make sure the switch is clean and dry.
2Set the switch on a smooth, level surface strong enough to support the weight of the
switch and the connected cables. Make sure there is a power outlet nearby.
3Make sure there is enough clearance around the switch to allow air circulation and the
attachment of cables and the power cord.
4Remove the adhesive backing from the rubber feet.
5Attach the rubber feet to each corner on the bottom of the switch. These rubber feet help
protect the switch from shock or vibration and ensure space between devices when
stacking.
Figure 3 Attaching Rubber Feet

Chapter 2 Hardware Installation and Connection
ES-1124 User’s Guide
18
"Do NOT block the ventilation holes. Leave space between devices when
stacking.
For proper ventilation, allow at least 4 inches (10 cm) of clearance at the front
and 3.4 inches (8 cm) at the back of the switch. This is especially important for
enclosed rack installations.
2.2 Mounting the Switch on a Rack
This section lists the rack mounting requirements and precautions and describes the
installation steps.
2.2.1 Rack-mounted Installation Requirements
• Two mounting brackets.
• Eight M3 flat head screws and a #2 Philips screwdriver.
• Four M5 flat head screws and a #2 Philips screwdriver.
"Failure to use the proper screws may damage the unit.
2.2.1.1 Precautions
• Make sure the rack will safely support the combined weight of all the equipment it
contains.
• Make sure the position of the switch does not make the rack unstable or top-heavy. Take
all necessary precautions to anchor the rack securely before installing the unit.
2.2.2 Attaching the Mounting Brackets to the Switch
1Position a mounting bracket on one side of the switch, lining up the four screw holes on
the bracket with the screw holes on the side of the switch.
Figure 4 Attaching the Mounting Brackets
2Using a #2 Philips screwdriver, install the M3 flat head screws through the mounting
bracket holes into the switch.

Chapter 2 Hardware Installation and Connection
ES-1124 User’s Guide 19
3Repeat steps 1and 2to install the second mounting bracket on the other side of the
switch.
4You may now mount the switch on a rack. Proceed to the next section.
2.2.3 Mounting the Switch on a Rack
1Position a mounting bracket (that is already attached to the switch) on one side of the
rack, lining up the two screw holes on the bracket with the screw holes on the side of the
rack.
Figure 5 Mounting the Switch on a Rack
2Using a #2 Philips screwdriver, install the M5 flat head screws through the mounting
bracket holes into the rack.
3Repeat steps 1and 2to attach the second mounting bracket on the other side of the rack.

Chapter 2 Hardware Installation and Connection
ES-1124 User’s Guide
20
