ZyXEL Communications P-660RU-Tx v3 SERIES User manual

Benefits
ˍġADSL2+ Internet Access
ˍġSOHO Firewall Security with
DoS Prevention
ˍġWeb Based User Interface
ˍġUSB and Ethernet Dual Interface
ˍġPowerful Remote Management
Support (TR-069)*
High Speed Internet Access
ZyXEL P-660RU-Tx v3 Series is an ADSL/ADSL2/ADSL2+ router,which supports downstream transmission
of up to 12 Mbps (ADSL2) or 24 Mbps (ADSL2+). For ISP/Telco’s need, the P-660RU-Tx v3 Series also has the
capability to support rate and line status monitor management. Users can enjoy not only high-speed
ADSL services but also broadband multimedia applications such as interactive gaming, video streaming
and real-time audio much easier than ever.
SOHO Firewall Security
Along with the built-in NAT firewall feature, the router also provides advanced hacker packet filtering
protection. It can automatically detect and block Denial of Service (DoS) attacks.
Automatic Remote Configuration
The P-660RU-Tx v3 Series comply with TR-069. Most configurations, diagnosis and FW upgrades can be
performed via remote ACS without user involvement. In other words, users get better service with less
manual configuration.
MAP Express for Easy Installation
Setting up such a powerful device would be complex.With ZyXEL’s MAP Express Install 1-2-3 installation
guide, the configuration can be done in a snap,and its rich audio and visual aids even fun to use.
Multi-NAT Technology
NAT provides system administrators an easy solution to create private IP networks with better security
and IP management. Powered by the ZyNOS NAT technology,the P-660RU-Tx v3 Series supports most
popular Internet multimedia applications such as NetMeeting, CuSeeMe, IP TV, QuickTime, Real Player
(RSP/RTSP) and Xbox, etc.
H
ig
h-Speed ADSL2+ Ethernet/USB
Router
f
or SOHO Network
s
ADSL2+ Ethernet/USB
Router
P-660RU-Tx v3
SERIES
Note:The feature with * needs local ISP support.

Specifications
Application Diagram
System Specifications
ADSL Compliance
• Support Multi-Mode standard (ANSI T1.413,
Issue 2; G.dmt (G.992.1); G.lite (G992.2))
• EOC specified in ITU-T G.992.1
• ADSL2 G.dmt.bis (G.992.3)
• ADSL2 G.lite.bis (G.992.4)
• ADSL2+ (G.992.5)
• Reach Extended ADSL (RE ADSL)
ATM Protocol
• ADSL physical connection ATM AAL5 (ATM
Adaptation Layer type 5)
• Support multi-protocol over AAL5
(RFC1483/2684)
• Support VC-based and LLC-based
multiplexing
• Support up to 8 PVCs
• Support PPP over ATM AAL5 (RFC2364)
• PPP over Ethernet support for DSL connection
(RFC 2516)
• I.610 F4/F5 OAM loop-back
Network Protocols
• IP routing
• 802.1d transparent bridging
• IGMP v1&v2
• RIP-1/RIP-2
• ICMP
• TCP/UDP
IP Management
• DHCP client/server/relay
• DNS proxy
• Dynamic DNS (www.dyndns.org)
• UPnP support
• SUA/Multi-NAT Internet sharing
Network Management
• FTP for firmware and configuration
upgrade/backup
• Remote management control:
Telnet, FTP, Web
• SNMP support
• Built-in diagnostic tools
Firewall Security
• Stateful packet inspection
• Prevent DoS/ping of death
• Application filter
• IP & MAC filter
Advanced Feature
• CPE WAN management (TR-069 support)
• CPE LAN management (TR-064 support)
Hardware Specifications
• ADSL port: RJ-11 port
• LAN port: RJ-45 port
• USB port: USB 1.1 port
• Power: 5 V DC & 1 A switching
• Power consumption: 5 watt
Physical Specifications
• Item weight: 165 g (0.36 lb)
• Item dimensions:
110 (W) x 107 (D) x 36 (H) mm
(4.33 (W) x 4.21 (D) x 1.42 (H) inch)
• Packing weight: 450 g (0.99 lb)
• Packing dimensions:
229 (W) x 148 (D) x 42 (H) mm
(9.01 (W) x 5.83 (D) x 1.65 (H) inch)
Environmental Specifications
• Operating temperature: 0°C ~ 40°C
• Storage temperature: -20°C ~ 60°C
• Operating humidity: 20% ~ 85%
(non-condensing)
• Storage humidity: 20% ~ 90%
(non-condensing)
Certification
• CE
Product Description
P-660RU-T1 v3 ADSL2+ Ethernet/USB Router
over POTS
P-660RU-T3 v3 ADSL2+ Ethernet/USB Router
over ISDN/U-R2
65-100-060606B 01/09
Copyright © 2009 ZyXEL Communications Corp. All rights reserved. ZyXEL,ZyXEL logo are registered trademarks of ZyXEL Communications Corp.All other brands,
product names, or trademarks mentioned are the property of their respective owners.All specifications are subject to change without notice.
For more product information, visit us on the web at www.ZyXEL.com
P
-660RU-Tx v3 Ser
i
e
s
A
DSL2+ Et
h
ernet/USB Route
r
I
nternet
ZyAIR
Wire
l
ess
Ca
r
d
B
us
Ca
r
d
W
ire
l
e
ss
USB A
d
a
p
ter
ZyAIR
ZyAIR
W
ire
l
ess A
P
W
irele
ss
A
P
Network Cable
USB Cable
ADSL Line
Prestige600series
PWR/SYS10/100MDSLPPPUSB
