2easy CDV17D User manual

2-Wire Intercom System

Read this manual carefully before using the product, and keep safe for future use.
CDV17DS INSTALLATION MANUAL(EN)

Unit Mounting
The location of outdoor station should keep away from snow,rain,and intensity light.
Accessory contents:
Accessories include a screwdriver T20, one M4X10 screw, two PA4X25 screws,three PA3x25
screws,three PM3x12 screws,and five screw stoppers Φ6X30.
Installation steps:
Installation height for door station usually is 145~160cm.
1. Use screws to fix the back panel and rainy cover to the wall after connect the cable correctly.
2. Attach the front panel to the back panel, then use the screw to fix it.
Wiring and Connection
Basic one-to-one connecon
1
2
3
4
7
5
6
M4*10
PM3*12
1 2 3
-
+
Monitor
Bus PL S2+ S1+ S1-
BUS(Blue&Green); S2+(Red); PL(White); S1+(Yellow); S1-(Black);
AC~
PC6
1 2 3
ON
1 2 3
123
ON
1 2 3
BUS(Blue&Green)
S2+(Red)
PL(White)
S1+(Yellow)
S1-(Black)
4P
terminal
DIP PROG
SPK adjust
Lock Control
Jumper
CALL button
please refer to DT-CAM user instructions in details.
PL(White): external lock power input, connect to the power positive(power +).
S1+(Yellow): lock power(+) output.
S1-(Black): lock power(-) output.
Parts and Function
Speaker
Unlock Indicator
Talk Indicator
Front Panel
Call Button
Microphone
1
2
3
4
5
6
Terminal Description
The audio door station is designed for the CDV 2Easy 2-wire system. The 17-D is made of
zinc alloy for protection against vandalism including the call button featuring a blue
backlight for auxiliary illumination.The door unlock and speech LED indicator show
visual verification of operation.The rain cover provides protection adverse weather.
Connection Cable
BUS(Blue&Green): connect to the bus line, no polarity.
S2+(Red): the S2+ connect with S1- to activate the relay of ERL to extend a camera
of DT-CAM, please refer to DT-CAM user instructions in details.
◆ Lock Control Jumper: For selection of lock type. Please refer to Electric Lock Connection:Pg7.
◆ DIP switch: to set ID code for door station, total 4 door stations can be supported. Please refer to
DIP Switch Settings.
◆ SPK adjust: to adjust the talk volume.
◆ PROG button: reserved.
◆ CALL button: press to call the user.
◆ 4P terminal: to update software via specified programmer.
◆ Connection cable:to connect the bus line and the electronic locks.
7Rain Cover
-1-

Parts and Function
The door station is an audio door station without camera,which is designed for DT 2-wire system.
The front panel is made of zinc alloy for better protection against vandalism & cauterization, and
the call button is also made of zinc alloy with blue backlight for auxiliary illumination, the unlock
and talking LED indicator guarantee the door station working efficiently.
With the rainy cover, the door station can be strongly protection against water.
Terminal Description
Speaker
Talk Indicator
Unlock Indicator
Call Button
Front Panel
Microphone
1
2
3
4
7
5
6
1
2
3
4
5
6
Rainy Cover
7
M4*10
PM3*12
1 2 3
-
+
Bus PL S2+ S1+ S1-
AC~
PC6
1 2 3
ON
1 2 3
123
ON
1 2 3
BUS(Blue&Green)
S2+(Red)
PL(White)
S1+(Yellow)
S1-(Black)
4P
terminal
DIP PROG
SPK adjust
Lock Control
Jumper Connection line
CALL button
PL(White): external lock power input, connect to the power positive(power +).
S1+(Yellow): lock power(+) output.
S1-(Black): lock power(-) output.
Unit Mounting
Wiring and Connection
Basic one-to-one connecton
BUS(Blue&Green); S2+(Red); PL(White); S1+(Yellow); S1-(Black);
The location of outdoor station should kept away from direct snow, rain and intense light.
Accessory contents:
Accessories include a screwdriver T20, one M4x10 screw, two PA4x25 screws, three PA3x25
screws, three PM3x12 screws and five screw stoppers 6x30.
Installation steps:
Installation height for door station usually is 145~160cm.
1. Use screws to fix the back panel and rain cover to the wall, connect the cable correctly.
2. Attach the front panel to the back panel, then use the screw to fix it.
Audio
Handset
-2-

With DBC-4S Wiring Mode
1 2 3
ON
1 2 3
ON
1 2 3
ON
1 2 3
ON
1# Camera
DIP=on,off,off
ID=00
ID=10
ID=01ID=11
2# Camera3# Camera4# Camera
DBC-4S
A B C D
OFF
ON
Impedance
Switch
Bus PL S2+ S1+ S1- Bus PL S2+ S1+ S1- Bus PL S2+ S1+ S1- Bus PL S2+ S1+ S1-
1 2 3
ON
ID=00
Code=0, DIP-6=off
1 2 3 4 5 6
ON
Code=1, DIP-6=off
1 2 3 4 5 6
ON
1 2 3456
ON
1 2 3456
ON
Code=3, DIP-6=on
Code=1, DIP-6=on
1 2 3456
ON
1 2 3456
ON
Code=2, DIP-6=on
Code=0, DIP-6=on
Code=15, DIP-6=on
Code=13, DIP-6=on
Code=14, DIP-6=on
Code=12, DIP-6=on
OFF ON
OFF ON
monitor
monitor
monitor
monitor
monitor
monitor
monitor
monitor
DBC-4S
A B C D
DBC-4S
A B C D
Impedance
switch
Impedance
switch
DIP=on,off,off
DIP=on,off,off
1 2 3
ON
ID=00
AC~
PC6
AC~
PC6
AC~
PC6
Code=14, DIP-6=off
1 2 3 4 5 6
ON
Code=15, DIP-6=on
1 2 3 4 5 6
ON
1 2 3456
ON
1 2 3456
ON
1 2 3456
ON
1 2 3456
ON
Mult Door Staton Connecton
BUS(Blue&Green); S2+(Red); PL(White); S1+(Yellow); S1-(Black);
Multi Monitors Connection Basic
IN-OUT wiring mode
Audio Handset Audio Handset Audio Handset Audio Handset
Audio Handset
-3-

Mul Door Staon Connecon
Multi Monitors Connection
Basic IN-OUT wiring mode
Monitors
1 2 3
ON
1 2 3
ON
1 2 3
ON
1 2 3
ON
1# Camera
DIP=on,off,off
ID=00
ID=10
ID=01ID=11
2# Camera3# Camera4# Camera
DBC-4S
A B C D
OFF
ON
Impedance
Switch
Bus PL S2+ S1+ S1- Bus PL S2+ S1+ S1- Bus PL S2+ S1+ S1- Bus PL S2+ S1+ S1-
BUS(Blue&Green); S2+(Red); PL(White); S1+(Yellow); S1-(Black);
1 2 3
ON
ID=00
monitor monitor monitor monitor
Code=0, DIP-6=off
1 2 3456
ON
Code=1, DIP-6=off
1 2 3456
ON
1 2 3 4 5 6
ON
1 2 3 4 5 6
ON
Code=3, DIP-6=on
Code=1, DIP-6=on
1 2 3 4 5 6
ON
1 2 3 4 5 6
ON
Code=2, DIP-6=on
Code=0, DIP-6=on
Code=15, DIP-6=on
Code=13, DIP-6=on
Code=14, DIP-6=on
Code=12, DIP-6=on
OFF ON
OFF ON
DBC-4S
A B C D
DBC-4S
A B C D
Impedance
switch
Impedance
switch
DIP=on,off,off
DIP=on,off,off
1 2 3
ON
ID=00
AC~
PC6
AC~
PC6
AC~
PC6
Code=14, DIP-6=off
1 2 3456
ON
Code=15, DIP-6=on
1 2 3456
ON
1 2 3 4 5 6
ON
1 2 3 4 5 6
ON
1 2 3 4 5 6
ON
1 2 3 4 5 6
ON
With DBC-4S Wiring Mode
Audio
Handset
Audio
Handset
Audio
Handset
Audio
Handset
Audio
Handset
Audio
Handset
Audio
Handset
Audio
Handset
-4-

Door Lock Controlled with Dry Contact
EB
*
LOCK
Jumper position in
Connect one lock
2-3
Bus PL S2+ S1+ S1-
DIP Switch Setting
The DIP switch is designed to set the code for door station and monitor, there are two states for
each DIP switch, please refer to the following sketch map.
Door station DIP setting
Indoor monitor DIP setting
Bit state Description
ON(1)
=
OFF(0)
=
ON
ON
Total 3 bits can be configured, bit-1 and bit-2 are used to assign ID code for door station, bit-3 is
used to match the video impedance.The switches can be modified either before or after installation.
There are 6 bits in total. The DIP switches are used to configure the user code for Monitors.
Bit-6 is an video impedance match switch, which have to be set to ON if match the impedance,
otherwise set to OFF.
Bit-1~Bit-5 are used to set user code, to DT595A door station, the user code should set to 0~15.
Please refer to the following settings:
Note: if the video impedance need to match, please set the bit-3 on.
123
ON
123
ON
123
ON
123
ON
ID = 0(00), set to the first door station
ID = 1(10), set to the second door station
ID = 2(01), set to the third door station
ID = 3(11), set to the fourth door station
LOCK
Take off the Jumper
POWER
SUPPLY
Bus PL S2+ S1+ S1-
1 2 3
AC~
PC6
ERL
DT595A
DT-CAM
DS IM
Bus PL S2+ S1+ S1-
OUT IN
With DT-CAM wiring mode - NOT UK
The audio door station DT595A can be extended an additional CCTV camera to be a
video door station. For more details about the camera, please refer to DT-CAM user
instructions.
Note:
1. Electronic lock of Power-on-to-unlock (fail
secure) type should be used.
2. The door lock is limited to 12V, and holding
current must be less than 250mA.
3. The door lock control is not timed from Exit
Button(EB).
4. The Unlock Mode Parameter of Monitor must
be set to 0 (by default).
Note:
1. An external power supply must be used
depending on they type of lock used.
2. The jumper must be taken off before
connecting a lock
3. Set the Unlock Mode of the Monitor for
different lock types.
* Power-on-to-unlock type: Unlock Mode=0 (by
default) * Power-off-to-unlock type: Unlock
Mode=1
Audio
Handset
Electric Lock Connecton
Door Lock Controlled with Internal Power
-5-

Use the DIP switch and PROG button to change the unlock setting.
1. Set DIP‐1=ON, DIP‐2=OFF;
2. Press the PROG (Fig 1) button and hold for 3 secs (blue LED on) to activate the setup option:
1) NO relay: press the PROG button one more time.
2) NC relay: press the PROG button and hold for 3s again.
1. Set DIP‐1=OFF, DIP‐2=ON;
2. Press the PROG (fig 1) button and hold for 3 secs (blue LED on) to activate the setup option:
3. Press the PROG (fig 1) button and hold for the number of seconds required (indicted by beeps and
red LED). The time between pressing and releasing the PRGO button is the unlock time.
Note: DIP‐1 and DIP‐2 should reset to the corresponding a ddress code after setting the above.
Fig. 1
1 2 3
Prog Button
CDV17DS PCB
Instructions for Lock Relay 1 Setting:
UNLOCK TYPE
UNLOCK TIME
-6-

With DT-CAM wiring mode
Electric Lock Connecon
Door Lock Controlled with Internal Power
Door Lock Controlled with Dry Contact
EB
*
LOCK
Jumper position in
Connect one lock
2-3
Bus PL S2+ S1+ S1-
DIP Switch Setting
Bit state Description
ON(1)
=
OFF(0)
=
ON
ON
123
ON
123
ON
123
ON
123
ON
ID = 0(00), set to the first door station
ID = 1(10), set to the second door station
ID = 2(01), set to the third door station
ID = 3(11), set to the fourth door station
LOCK
Take off the Jumper
POWER
SUPPLY
Bus PL S2+ S1+ S1-
1 2 3
AC~
PC6
ERL
DT595A
DT-CAM
DS IM
Bus PL S2+ S1+ S1-
OUT IN
Monitor
Door station DIP setting
The DIP switch is designed to set the code the for door station and the monitor, there
are two states for each DIP switch, please refer to the following:
Total 3 bits can be configured, bit-1 and bit-2 are used to assign ID code for door
station, bit-3 is used to match the video impedance.The switches can be modified either
before or after installation.
Note: for video impedance EOL: set the bit-3 on.
Indoor monitor DIP setting
There are 6 bits in total. The DIP switches are used to configure the user address for Monitors.
Note:
1. The external power supply must be used
according to the lock.
2. The jumper must be taken off before connecting.
3. Setup the Unlock Mode of Monitor for different
lock types.
* Power-on-to-unlock type:Unlock Mode=0 (by default)
* Power-off-to-unlock type:Unlock Mode=1
-7-
Bit-6 is an video impedance EOL switch, set to ON to match the impedance.
Bit-1~Bit-5 are used to set user address, the user code should set be set to
0~15. Please refer to the following settings:

When Monitor quanty < 20
When Monitor quanty >20
Bit state User code
code=0
code=1
code=2
code=3
code=4
code=6
code=7
code=8
code=9
code=10
code=11
code=12
code=13
code=14
code=15
code=5
Bit state User code Bit state User code
Cable Requirements
The maximum distance of the wiring is limited in the DT system. Using different cables may also
affect the maximum distance which the system can reach.
Cable Usage A B C
Twisted cable 2x0.75 mm260 60 30
80 80 40
Twisted cable 2x1 mm2
Cable Usage A B C
Twisted cable 2x1 mm270 30 20
70 50 30
Twisted cable 2x1.5 mm2
1 2 3 4 5 6
ON
123 4 5 6
ON
1 2 3 4 5 6
ON
1 2 3 4 5 6
ON
1 2 3 4 5 6
ON
1 2 3 4 5 6
ON
123 4 5 6
ON
1 2 3 4 5 6
ON
1 2 3 4 5 6
ON
123 4 5 6
ON
1 2 3 4 5 6
ON
123 4 5 6
ON
1 2 3 4 5 6
ON
1 2 3 4 5 6
ON
1 2 3 4 5 6
ON
1 2 3 4 5 6
ON
The farest monitor
B
A
C
DBC-4S
monitor
monitor
monitor
with two or four monitors
AC~
PC6
Note:If the monitor has been specified
the distance,refer to the parameter.
Specification
Precautions
• Power Supply:DC 24V
• Power Consumption:Standby 60mA; Working status 200mA
• Lock Power Supply:12Vdc, 300mA(Internal Power)
• Working Temperature:
-10ºC ~ +45ºC
• Wiring: 2 wires,non-polarity
• Dimension:137(H)x49(W)x28(D)mm
• Please clean the unit with soft cotton cloth, do not use a chemical cleaning agent. If
necessary, please use a little pure water or dilute soap water to clean the dust.
• The unit is weather resistant. However do not spray high pressure water on access
control keypad directly. Excessive moisture may cause problems with the unit.
• You must use the right adaptor which is supplied by the manufacture or approved by
the manufacturer.
• Pay attention to high voltage inside the products, please refer service only to a
trained and qualified professional.
-8-

When Monitor quanty < 20
When Monitor quanty >20
Bit state User code
code=0
code=1
code=2
code=3
code=4
code=6
code=7
code=8
code=9
code=10
code=11
code=12
code=13
code=14
code=15
code=5
Bit state User code Bit state User code
Specification
• Power Supply:DC 24V
• Power Consumption:Standby 60mA; Working status 200mA
• Lock Power Supply:12Vdc, 300mA(Internal Power)
• Working Temperature:
-10ºC ~ +45ºC
• Wiring: 2 wires,non-polarity
• Dimension:137(H)x49(W)x28(D)mm
Precaustions
• Please clean the unit with soft cotton cloth, don't use the organic impregnant or chemical clean agent.
If necessary, please use a little pure water or dilute soap water to clean the dust.
• The unit is weather resistant. However do not spray high pressure water on access control keypad
directly. Excessive moisture may cause problems with the unit.
• You must use the right adaptor which is supplied by the manufacture or approved by the manufacture.
• Pay attention to the high voltage inside the products, please refer service only to a trained and qualified
professional.
Cable Usage A B C
Twisted cable 2x0.75 mm260 60 30
80 80 40
Twisted cable 2x1 mm2
Cable Usage A B C
Twisted cable 2x1 mm270 30 20
70 50 30
Twisted cable 2x1.5 mm2
1 2 3456
ON
123456
ON
1 2 3456
ON
1 2 3456
ON
1 2 3456
ON
1 2 3456
ON
123456
ON
1 2 3456
ON
1 2 3456
ON
123456
ON
1 2 3456
ON
123456
ON
1 2 3456
ON
1 2 3456
ON
1 2 3456
ON
1 2 3456
ON
B
A
C
DBC-4S
AC~
PC6
Cable Requirements
The maximum wiring distance is limited in the 2Easy system. Using different
cables can also affect the maximum distance achievable.
The furthest monitor
with two to four monitors
Note: If the monitor has been specified
the distance, refer to the parameter.
Audio
Handset
Audio
Handset
Audio
Handset
-9-

Printed 2012. 09
. Right to interpret and copyright of this manual are preserved.
The design and specications can be changed without notice to the user. Right to
interpret and copyright of this manual are preserved.
