2GOability Boost User manual

UserManual

1
BEFORE USING YOUR NEW 2GOABILITY BOOST SCOOTER YOUMUST READ
AND FULLY UNDERSTAND THIS MANUAL
General information
You have just purchased an 2GOability Boost scooter and we want to thank you for
the confidence in our 2GOability products. The Boost scooter is a quality product.
The policy of 2GOability is to continually improve the quality and reliability of our
products. We reserve the right, therefore without prior notification, to alter this guide.
It is important that your guide for the use of the Boost scooter is read carefully. The
manual contains important information about the safe use and maintenance of your
Boost scooter. We recommend that you keep this guide, it is also your proof of
warranty and you will find it useful for referring to it at a later date.
The safety instructions in this guide are general guidelines that must be seen as broad
guidelines.
Your new 2GOability Boost scooter requires frequent maintenance, much of which
you can do yourself.
Caution!
In this guide you will find information and warnings. These are clearly identified by the
symbols below and the appearance of the text:
Tip
Information
Warning
To avoid personal injury, warnings must be followed

2
Fill out the information on your authorized dealer below:
Company: …………………………………………………………………
Address: …………………………………………………………………
…………………………………………………………………
Telephone number: …………………………………………………………………
Fax number: …………………………………………………………………
Email address: …………………………………………………………………
Website: …………………………………………………………………

3
1 IDENTIFICATION....................................................................................... 4
2 GENERAL EXPLANATION CONCERNING YOUR SCOOTER ........................ 5
2.1 COMPONENTS OF THE SCOOTER .............................................................................5
2.2 GENERAL EXPLANATION OF THE FUNCTION AND POSSIBILITIES OF YOUR BOOST SCOOTER.........6
3 SAFETY REGULATIONS .............................................................................. 6
3.1 GENERAL SAFETY REGULATIONS.............................................................................6
3.2 WARNINGS FOR SAFE USE ....................................................................................6
4 INSTRUCTIONS FOR USE .......................................................................... 7
4.1 TILLER CONTROL PANEL ......................................................................................8
4.2 GETTING ON AND OFF ........................................................................................9
4.3 SET UP ........................................................................................................10
4.4 BASIC DRIVING ..............................................................................................11
4.5 STEERING ....................................................................................................11
4.6 CONTROL THROUGH TIGHT SPOTS ........................................................................12
4.7 GOING UP AN INCLINE /DOWN A DECLINE...............................................................13
4.8 EMI /RFI ...................................................................................................15
5 INSTRUCTIONS FOR USE AND MOUNTING OPTIONS ............................ 16
5.1 TECHNICAL INFORMATION..................................................................................16
5.2ARMREST ADJUSTMENTS....................................................................................17
5.3 SEAT ADJUSTMENTS.........................................................................................18
5.4 TILLER ........................................................................................................19
5.5 DISASSEMBLY ................................................................................................19
5.6 ASSEMBLY ....................................................................................................22
6 TRANSPORT AND TRANSIT IN CAR ........................................................ 23
7 CARE AND MAINTAINANCE..................................................................... 24
8 PROBLEM ANALYSIS AND SOLUTIONS................................................... 25
9 WARRANTY .............................................................................................. 26
9.1 WARRANTY APPLICATION ..................................................................................26
9.2 WARRANTY DEFINITION ....................................................................................26
10 GENERAL MAINTENANCE INSTRUCTIONS.......................................... 27

4
1 IDENTIFICATION
Your Boost scooter is equipped with a unique serial number. You can find this number
on the frame of your Boost scooter. Below is an example of the frame label on which
you can find the identification number. Furthermore you will find the explanation of the
various data stored on the frame label listed below.
1. Production date Production date of the Boost scooter
2. Serial number The unique serial number. You must have this
number when making technical requests or if
warranty parts are required.
3. Maximum user weight The largest occupant weight allowed for protection
of both the Boost scooter and the user.
4. Type number This number indicates which model of Boost
scooter you have, again this is always required
when making technical calls.
5. Model name The model name of your Boost scooter.
6. Description Description of the design of your scooter.
7. Warranty This is the warranty period. Chapter 9 describes
your warranty terms and conditions in more detail.
1
2
5
6
3
4
7

5
2 GENERAL EXPLANATION CONCERNING YOUR SCOOTER
2.1 Components of the scooter
1
Seat
7
Tiller lock knob
2
Armrest
8
Tiller adjustment knob
3
Seat tube
9
Basket
4
Battery pack
10
Handgrip
5
Rear wheel
11
Control panel
6
Front wheel
Your Boost scooter is equipped with a number of elements and parts. You should know
these before continue reading this manual. Designs and specifications may change
without prior notice.
1
2
3
4
5
6
7
8
9
10
11

6
2.2 General explanation of the function and possibilities of your Boost
scooter
The Boost scooter is equipped with multifunction brakes and stable wheels which roll
easily. The Boost scooter is especially developed so that it can be adjust to every
individual user. Your Boost scooter is a medical equipment product and is not a
standard consumer product. You must follow this manual completely to ensure good,
optimal and safe use of your Boost scooter.
3 SAFETY REGULATIONS
2GOability specifically disclaims responsibility for any body injury or property damage
which may occur during any use which does not comply with laws or ordinances. If
used correctly, the 2GOability Boost scooter is an utmost safe and stable product, if
the instructions for use as described in this manual are followed. However, it is
possible when the 2GOability Boost scooter is not used correctly, dangerous
situations may occur.
3.1 General safety regulations
Protect your 2GOability Boost scooter by checking it regularly. When a part of your
Boost scooter is not functioning properly, a dangerous situation could occur.
 Warning:
You must keep your Boost scooter in a good state to guarantee safe use.
3.2 Warnings for safe use
 Warnings :
Failure to follow all the instructions in this manual may result in damage to the
scooter or serious injury;
Always operate your scooter with thought, care and safety;
Do not drive into curbs;
Never connect anything to the wheels;
The maximum weight capacity has been indicated on your scooter frame label;
Unauthorized modification and or use of parts not supplied by 2GOability will
invalidate the warranty of this scooter and may lead to injury to the user and or
damage to the scooter;
Before using your scooter, always check if the brakes are working perfectly;
Do not let children play with or on your scooter;
Do not use the scooter when the brakes are not working;

7
All wheels must be in contact with the floor at all times during use. This will
ensure the scooter is properly balanced;
Do not turn your scooter suddenly at full speed;
Do not use your scooter when it is damaged or has any malfunction;
Do not attempt to use your scooter on an escalator. Always use an elevator;
Do not carry passengers under any circumstances;
Do not mount or dismount your scooter unless the brake is engaged;
Always make sure that the key switch is set to “Off” before mounting or
dismounting your scooter;
Do not drive backwards with your scooter on an incline or across an uneven
surface;
Always make sure the seat is locked forward before operating your scooter;
Always come to a full stop before changing direction from forward to reverse or
from reverse to forward;
Do not operate your scooter where you could not safely or legally walk;
Do not climb ramps or curbs that exceed your scooters capacity;
Always approach inclines straight on;
Always be aware of and careful near mechanical pinch points especially when
assembling and disassembling your scooter;
Never sit on your scooter when it is being transported;
Always fasten down your scooter securely with an approved tie-down system
while transporting your scooter;
Never operate your scooter if it is not functioning properly;
Always use caution when driving on soft or uneven surfaces such as grass and
gravel. Also use caution on decks where there is no railing;
Always cross streets at intersections and use crosswalks or the most direct
route, making sure that your path is clear and that you are visible to motor
traffic;
Never back up or down a step or curb;
Never drive your scooter up or down a step or curb that is higher than 4cm;
Never drive your scooter over a gap greater than 7.5 cm;
Do not drive your scooter in icy of salted conditions;
Never drive on the roadway, except when you must cross the street;
Never operate your scooter while you are under the influence of alcohol;
Always check with your physician to determine if any of the medications you are
taking may affect your judgment and/or your ability to operate your scooter.
Also check with your physician concerning your physical ability to operate a
scooter.
4 INSTRUCTIONS FOR USE
Your 2GOability Boost scooter is a battery-operated personal mobility vehicle. Please
exercise caution and consideration when you are operating it. Driving your scooter
carefully and thoughtfully will help ensure your personal safety and the safety of other
people.

8
4.1 Tiller control panel
Control panel:
Key Switch
This switch turns the power on and off to your scooter.
Insert the key into the key switch;
Turn the key 90 degrees clockwise to turn on your scooter´s power;
Turn the key back to the vertical position to turn off your scooter's power.
Tip
Always make certain that the key is removed from the key switch before getting
on or off your scooter or before lowering the tiller completely.
Speed Control
The speed adjustment dial allows you to preselect the maximum top speed of your
scooter;
Turn the dial counterclockwise to operate your scooter at the lowest speed level;
Turn the dial clockwise to increase the operational speed of your scooter;
We recommend that you select a speed setting at which you feel comfortable, safe,
and in control of your scooter.
Forward / Reverse
To move forward push the lever on the right side;
To move backwards push the lever on the left side.
Horn
Speed Control
Key Switch
Forward
lever
Battery indicator
Power Eye
Reverse lever

9
Battery indicator
This meter shows the amount of voltage in your scooter’s batteries.
Green indicates a full charge on the batteries;
Yellow indicates caution and approximately a one-half charge of the batteries;
Red indicates that the batteries have less than one-half of a charge remaining.
Horn Button
Press this button to sound the horn.
Power Eye
When the scooter is on, and all conditions are normal, the Power Eye will be on. When
there is some special situation that needs attention, the light will flash. See chapter 8
for the trouble shooting table.
Brakes and throttle lever
Whenever the speed engager lever is moved out of the neutral position, the
electromagnetic brake will automatically release and your scooter will move. When the
speed engager lever is released, it will return to the neutral position and the scooter
will decelerate and come to a complete stop. The parking brake will then engage
preventing further movement of your scooter.
4.2 Getting on and off
Before getting on your scooter:
Check to be certain that the power is turned off. This will eliminate the possibility
of accidentally activating the paddle controls and causing injury to yourself or to
others;
Check to be certain that your scooter’s brake handle is in the engaged position;
Flip up the armrests.
 Warning:
When getting on or off your scooter, keep your weight toward the middle of the
deck. Putting most or all of your weight on the edge of the deck may cause an
unstable condition!

10
Getting on your scooter:
Position the seat for safe and easy mounting;
Return tiller to full upright position;
Carefully place one foot on the approximate center of the deck and seat yourself
comfortably and securely on the seat;
Fasten the seatbelt, if your scooter is so equipped;
Flip down or replace the armrests.
Getting off your scooter:
Make certain that the power is turned off and the key is removed;
Return tiller to full upright position;
Flip up or remove the armrests;
Unfasten the seatbelt;
Carefully place one foot on the ground, transfer your weight to that leg, and
slowly come to a standing position;
Step away from the scooter.
4.3 Set up
Tip
For your first driving session, make certain that your scooter starts out on a level
surface and that you will continue driving on a level surface.
To get on your scooter:
Stand behind your scooter;
Place the scooter in Drive, see picture 1;
Make certain that the seat is positioned for safe and easy use;
Position yourself in the seat;
Use the seat rotate lever to position the seat so that it is locked in the fully
forward direction;
Fasten your seat belt, if your scooter is so equipped;
Place the key into the key switch;
Rotate the key to the on position.

11
 Warning:
Pushing the scooter too quickly in freewheel (picture 1) will cause the motor to
act as a generator causing the scooter to become difficult to push;
Never set your scooter in freewheel mode when it is on an incline;
Never disengage the park brake while you are operating your scooter;
Always make certain that your scooter park brake is engaged before inserting
the key into the key switch and turning it to the on position.
4.4 Basic driving
Make certain that you are seated safely and properly on your scooter;
Turn the speed control dial fully counterclockwise to its slowest setting;
Insert the key into the key switch;
Turn the key clockwise to the “On”position;
Place your hand on the handgrips;
oIf you wish to drive forward, pull back on the right side of the throttle control
lever;
oIf you wish to drive in reverse, pull back the left side of the throttle control
lever;
Pull on the throttle control lever to gently accelerate your scooter;
Release the throttle control lever to allow your scooter to come gently to a full
stop;
Practice these two basic functions until you feel that you have control of your
scooter.
4.5 Steering
Place both hands on the handgrips of the tiller, turn the tiller to the right to travel
to the right;
Turn the tiller to the left to travel to the left;
Make certain to maintain sufficient clearance when turning your scooter so that
the rear wheels will clear any obstacle.
Picture 1

12
Warning:
Turning your scooter too sharply at a too high speed will create a situation
where one of the rear wheels will leave the ground and the scooter will tip over.
Avoid this at any time by decelerating and steering a wide arc around corners
and obstacles.
Steering in a tight spot
If you must steer in a tight spot, such as entering or leaving a doorway or when you
are turning around;
1. Bring your scooter to a full stop;
2. Set speed at the lowest setting;
3. Turn the tiller to the direction in which you wish to drive.
Steering in reverse
Please be extra careful when you are driving in reverse.
1. Use your right fingers to push the throttle control lever or use your left fingers to
pull back on the throttle control lever;
2. Turn the tiller to the left to drive in reverse to the left;
3. Turn the tiller to the right to drive in reverse to the right.
4.6 Control through tight spots
As you use your scooter to greatly increase your mobility, you will undoubtedly
encounter some obstacles that will require practice to manoeuvre smoothly and safely.
Below are some common obstacles that you may meet during the daily use of your
scooter. Listed with those obstacles are some driving tips that should help you conquer
those obstacles. Learn and follow those tips, and with surprising ease you will soon be
in control of your scooter as you manoeuvre it through doors, up and down ramps, up
and over curbs, through grass and gravel, and up and down inclines.
Ramps
When proceeding up any ramp, curb, or incline:
Lean forward in your seat to move your centre of gravity forward for maximum
stability and safety.
If the ramp has a switchback, good cornering ability is required:
Manoeuvre your scooter so that the front wheels take wide swings around the
corners of the ramp.
Doing this will allow your scooter's back wheels to follow a wide arc around the
corner, staying clear of obstacles.

13
If you must stop your scooter while driving up a ramp:
Starting up again simply requires that you apply gentle and steady forward power
pressure to the throttle control lever.
Accelerate gently after stopping on any incline.
Driving down a ramp
Keep your scooter’s speed control dial set fully counter clockwise at the slowest
speed setting.
If you must come to a stop, release the throttle control lever slowly and
smoothly.
Curbs
Do not go up or down a curb that is higher than 4 cm;
Always use caution when descending any curb;
Approach the curb so that both back wheels of your scooter go over the curb at
the same time;
Never go down on curbs by traversing them. Doing this will cause the scooter to
tip over;
Go down a curb slowly to avoid a jarring bump. Use as little power as possible.
Grass and Gravel
Your scooter performs admirably on grass, gravel, and hills, but you must follow the
operational parameters presented in this manual, see chapter 3. If you are unsure
about any situation, avoid it.
Feel free to use your scooter on lawns or in park areas;
Avoid long or high grass, which may wrap around your scooter's axles;
Avoid loose gravel.
4.7 Going up an incline / down a decline
Driving on inclines
For maximum stability, lean forward in your scooters seat while
proceeding up ramps, inclines, curbs, or any low rise;
Drive with caution when attempting to drive up to any incline, even handicap
access ramps;
Always climb or descend an incline by driving straight up or straight down the
face of the slope;
Do not traverse or drive across the face of an incline in any direction;
Do not attempt to descend an incline that is covered with snow, ice, cut or wet
grass, leaves, or any other potentially hazardous material;
Do not back down an incline;
Try to keep your scooter moving when climbing an incline. If you do come
to a stop, restart and accelerate slowly and carefully;
Do not try to descend or climb a slope whose gradient is greater than
recommended. The recommended incline is 8°.

14
 Warning:
If, while you are driving down a slope, your scooter starts to move faster than
you feel is safe, release the throttle control lever and allow your scooter to come
to a stop. When you feel that you again have control of your scooter, push the
throttle control lever forward and continue safely down the remainder of the
slope.
Driving down a decline
Lower speed setting
Whenever it is safely possible, drive forward down any ramp, low rise, or incline.
2GOability does not recommend that you drive your scooter in reverse down any
incline, ramp, curb, or low rise. Backing down any slope may create a very hazardous
situation.
If it is necessary to back down a slope follow one of two procedures.
Tip
When using either of the following procedures to back down a slope,
2GOability strongly advises that you have the assistance of another person.
Procedure 1: Under power
Set the key switch to the “Off position”;
Dismount your scooter;
Set the key switch to the “On position”;
While standing next to your scooter, carefully operate the controls at the lowest
speed setting;
Slowly and carefully back your scooter down the incline;
Carefully remount your scooter and resume normal operation.
Procedure 2: Emergency (No power)
Set the key switch to the “Off position”;
Dismount your scooter;
Set the freewheel lever to “Disengaged”;
While standing next to the scooter, carefully manually maneuver it down the
slope;
When you have reached a level surface at the bottom of the slope, position the
freewheel lever in the engaged position;
See chapter 7 to restore power.

15
 Warning:
When your scooter is in freewheel mode, the park brake is released. The weight
of the scooter on a slope may cause you to lose control of the scooter. If you do
not feel capable of manually controlling your scooter down the slope, request
assistance or do not attempt to use this procedure.
4.8 EMI / RFI
The rapid development of electronics, especially in the area of communications, has
saturated our environment with electromagnetic (radio) waves that are emitted by
television transmitters, cellular phones, citizen’s band radios (CBs), amateur radios
(ham radios), wireless computer links, microwave transmitters, paging transmitters,
etc. These electromagnetic (EM) waves are invisible and increase in strength the closer
one gets to the source of transmission. When these energy waves act upon electrical
devices and cause them to malfunction or to function in an erratic or uncontrolled
manner, they are referred to as Electromagnetic Interference (EMI) of Radio
Frequency Interference (RFI).
EMI / RFI and your scooter
All electrically powered vehicles, including scooters are susceptible to Electromagnetic
Interference / Radio Frequency Interference (EMI / RFI). This interference could result
in abnormal, unintended movement of your scooter.
 Warning:
Unintended movement or brake release could cause an accident or injury.
The FDA has determined that each make and model of scooter can resist EMI/ RFI to a
certain level. The higher the lever of resistance, the greater the degree of protection
from EMI/ RFI –measured in volts per meter (V/m). The FDA has also determined that
current technology is capable of providing 20 V/m of resistance to EMI/ RFI, which
would provide useful protection against common sources of interference. This product
has been tested and has passed an immunity lever of 20 V/m.

16
EMI / RFI recommendations
Do not turn on or use hand-held personal electronic communication devices such
as cellular phones, walkie-talkies, and CB radios while your scooter is turned on;
Be aware of any nearby transmitters (radio, television, microwave, etc.) on your
intended route and avoid operating your scooter close to any of those
transmitters;
Turn off the power if your scooter is going to be in a stationary position for any
length of time;
Be aware that adding accessories or components or modifying your scooter may
make it more susceptible to EMI/ RFI;
If unintended movement or park brake release occurs, turn your scooter off as
soon as it is safe to do so.
Warning:
Turn off your scooter as soon as it is safely possible if unintended or
uncontrollable motion occurs or if unintended park brake release occurs.
MAKING ADJUSTMENTS TO YOUR SCOOTER CAN CAUSE BIG RISKS FOR
YOUR SAFETY AND THE FUNCTION OF YOUR SCOOTER. ADJUSTMENTS
MADE BY YOURSELF ARE STRONGLY ADVISED AGAINST AND CARRIED OUT
AT YOUR OWN RISK.
5 INSTRUCTIONS FOR USE AND MOUNTING OPTIONS
5.1 Technical information
Length 102 cm
Width 54 cm
Front wheels 7”
Rear wheels 8”
Weight capacity 115 kg
Ground clearance 6,4 cm
Maximum speed 7,2 km/h
Maximum range 17 km
Battery pack weight 13 kg
Batteries 2 x 18 Ah
Weight 45,5 kg
Weight seat 7 kg

17
5.2 Armrest adjustments
Armrest width adjustment
To adjust the armrest width:
Loosen the adjustment knobs at the rear of the seat see picture 2;
Slide the armrests in or out to the desired width;
Tighten the adjustment knobs.
Flip-up the armrests
Pull up on the end of either armrest to flip it up for easy transfer on and off your
scooter.
Armrest angle
To increase the armrest angle, turn the armrest angle screw clockwise, see picture 3.
To decrease the armrest angle, turn the armrest angle screw counter clockwise.
Picture 3
Picture 2

18
5.3 Seat adjustments
Seat rotation lever
The seat swivel lever (on the side of the seat) allows the seat to rotate in 45º.
Pull up on the seat rotation lever up (see picture 4) and rotate the seat to the
desired position;
Release the handle to lock the seat.
Backrest angle
To adjust the backrest angle:
Grab the backrest at the top;
Move the backrest to the desired angle.
Tip
Fold the back rest down (picture 5) when you’re taking the seat of or when you
want to transport your scooter.
Picture 4
Picture 5

19
5.4 Tiller
Tiller position adaption
You can adjust the position of the tiller:
Loosen the tiller adjustment knob;
Hold with one hand the tiller while loosening the knob, picture 6;
Place the tiller into the desired position;
Tighten the knob firmly;
Check if the tiller is correctly tightened by moving it back and forth. If it doesn’t
move it is correctly tightened.
5.5 Disassembly
This scooter can be separated into five parts, the front frame, rear frame, basket,
battery pack and the seat (picture 7). Each part weighs less than 14 kg. Follow the
procedures below to disassemble your scooter and transport it with care.
Picture 7
Picture 6
