2VV ESSENSSE NEO VCES3 AC Series User manual

ESSENSSE NEO
VCES3 B-xxx-xx AC.....
16.01.2023
INSTALLATION
EN

23
2 VV. Creating innovative solutions for you and your business since 1995.
23
2 VV. Creating innovative solutions for you and your business since 1995.
1. BEFORE YOU BEGIN
Before installing, read carefully the section Safe use of the air curtains, where you will nd all the in-
structions for the safe and proper use of the product.
Symbol Meaning
CAUTION!
PLEASE NOTE!
you will need
TECHNICAL INFORMATI-
ON
Warning or Caution
Important instructions
Practical tips and information
Detailed technical information
Reference to another part of the
manual
This manual includes important instructions for the appropriate installation of the air curtains. Before installing,
read carefully all the following instructions and observe them. The manufacturer reserves the right to change, including
the technical documentation, without prior notice. Keep the manual for future use. The instructions herein are part of the
product
Declaration of conformity
Details can be found at www.2VV.cz

23
2 VV. Creating innovative solutions for you and your business since 1995.
2x
1x
1x
4x M6x20
1
1
23
4
5
7
6
6
+5 oC
+40 oC
23
2 VV. Creating innovative solutions for you and your business since 1995.
PLEASE NOTE
• If the unit was transported in temperatures lower than
0°C, after unpacking, leave it in operational conditions
for at least two hours without activating in order to com-
pensate the inner temperature.
2. UNPACKING
3. MAIN COMPONENTS
2.1 CONTROL DE DELIVERY
PLEASE NOTE
Check the product for damages immediately after delive-
ry. In case of damage to the packaging, contact the ca-
rrier. Claims not led in due time will be disregarded.
• Check that it corresponds to the type of product orde-
red. In case of discrepancy, do not unpack the product
and contact the vendor.
• After unpacking, check that the product and all the
other components are in good order. In case of doubt,
contact the vendor.
• Do not install a damaged unit!
• If you will not unpack the product immediately after de-
livery, store it indoors, in a dry place with ambient tem-
peratures between +5 °C and +40 °C.
2.2 CONTENTS
All the packaging material is environ-
mentally friendly and can be reused
or recycled. Contribute actively to the
protection of the environment and en-
sure the proper disposal or recycling
of the packaging materials.
1
2
3
4
5
6
7
Mounting brackets (2pcs)
Curtain body
Area to connect the control module
Suction cover
Connection of water exchanger (only water model)
Side cover
erminal box for main power connection.

45
2 VV. Creating innovative solutions for you and your business since 1995.
A
I
8
H
G
E
F
B
C
15
15
J
D
TYPE A B C D E F G H I
(mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm)
VCES3 B 100 916 1252 407 252 51 111 90 240 95
VCES3 B 150 1325 1660 407 252 51 111 90 240 95
VCES3 B 200 1825 2160 407 252 51 111 90 240 95
VCES3 B 250 2235 2570 407 252 51 111 90 240 95
45
2 VV. Creating innovative solutions for you and your business since 1995.
4. DIMENSIONS4. DIMENSIONS

45
2 VV. Creating innovative solutions for you and your business since 1995.
VCES3 B 100-E0 3,2 4,7 4,90 400 / 13,7 230 / 0,6 10,3
50/60
23,0
VCES3 B 150-E0 3,8 7,5 7,70 400 / 11,9 230 / 0,9 10,1 29,0
VCES3 B 200-E0 4,8 9,5 9,80 400 / 15,8 230 / 1,4 9,4 37,0
VCES3 B 250-E0 6,9 12,2 12,60 400 / 19,4 230 / 1,4 10,4 44,0
VCES3 B 100-E1 3,2 6,3 6,50 400 / 14,4 230 / 0,6 13,9 23,0
VCES3 B 150-E1 5 10 10,20 400 / 21,3 230 / 0,9 13,5 29,0
VCES3 B 200-E1 6,3 12,6 12,90 400 / 27,9 230 / 1,4 12,5 37,0
VCES3 B 250-E1 8,2 16,3 16,70 400 / 26 230 / 1,4 13,8 44,0
VCES3 B 100-E2 4,7 9,5 9,70 400 / 14,3 230 / 0,6 20,9 23,0
VCES3 B 150-E2 7,5 15 15,20 400 / 22,6 230 / 0,9 20,3 29,0
VCES3 B 200-E2 9,5 19 19,30 400 / 28,8 230 / 1,4 18,8 37,0
VCES3 B 250-E2 12,2 24,5 24,90 400 / 36,8 230 / 1,4 20,8 44,0
VCES3 B 100-V2 16,0 0,20 230 / 0,6 230 / 0,6 36,4 25,0
VCES3 B 150-V2 23,6 0,20 230 / 0,9 230 / 0,9 35,0 31,0
VCES3 B 200-V2 34,0 0,30 230 / 1,4 230 / 1,4 34,1 41,0
VCES3 B 250-V2 42,9 0,40 230 / 1,4 230 / 1,4 34,3 48,0
VCES3 B 100-S0 - - 0,10 230 / 0,6 230 / 0,6 - 22,0
VCES3 B 150-S0 - - 0,20 230 / 0,9 230 / 0,9 - 28,0
VCES3 B 200-S0 - - 0,30 230 / 1,4 230 / 1,4 - 36,0
VCES3 B 250-S0 - - 0,40 230/ 1,4 230/ 1,4 - 42,0
45
2 VV. Creating innovative solutions for you and your business since 1995.
5. TECHNICAL PARAMETERS
The other technical parameters can be found in the corresponding technical sheet of the product
Type
Heater power output [kW]
(*LPHW 90/70°C) Total power input
[kW]
Total voltage/
current [V/A]
Motor voltage/
current [V/A]
Temperature

*4
Frequency
[Hz]
Weight
[kg]
*5
1st level 2nd level

67
2 VV. Creating innovative solutions for you and your business since 1995.
min. 200 mm
min. 100 mm
min. 50 mm*
min. 200 mm
min. 100 mm
min. 50 mm*
min. 100mm
min. 200mm
67
2 VV. Creating innovative solutions for you and your business since 1995.
6. INSTALLATION
6.1 OPERATIONAL CONDITIONS:
The air curtain is designed to be used in an indoor, dry
environment, with ambient temperatures between 5°C
to +40°C, a maximum relative humidity of 80%, and to
transport air free of coarse dust, grease, chemical fumes
and other contamination. The electrical protection is IP
20 (against particles larger than 12.5 mm, not protected
against water).
Curtains with electric heater are tted with an operational
thermostat with automatic reset (located on each heater)
and an emergency thermostat with manual reset.
The water exchangers are designed for a maximum wa-
ter temperature of +100°C and maximum pressure of 1.6
MPa.
6.2 INSTALLATION CONDITIONS
The installation and assembly of the unit may be car-
ried out only by a suitably qualied person who has the
adequate tools!
2 mounting brackets and 4 bolts are supplied with the
product as standard.
If the unit is to be mounted on threaded rods, they have
to be ordered separately. The following rules should be
observed for the proper function of the unit.
PLEASE NOTE
• minimum clearances must be observed (see g. clear-
ances) with respect to the ammability of materials.
• the clearances with respect to the ammability of mate-
rials are determined by the architect with regards to the
regulations applicable at the place of installation
• the unit may be installed only in horizontal position
• there must be at least 200 mm of free space in front of
the suction cover for the proper functioning of the unit
• the exhaust should be located as near as possible to
the door or the curtain opening
• the curtain should extend beyond both sides of the
opening by at least 100 mm
• if the curtain is to be installed above a door, place it as
near as possible to the upper border of the door. See
that the intake and exhaust are not blocked and that the
air can ow freely, see g.
If there is a window above the door or another material
preventing the installation on the brackets, the unit may
be hanged from the ceiling with threaded rods, directly
onto dowels (see below).
Installation with mounting brackets
YOU WILL NEED
4x dowels (not included)
4x bolts (not included)
Measure the holes on the wall according to the dimension
chart (see “Dimensions”) (observe the installation rules)
Do not forget to choose whether the unit will be installed
according to A or B and to set the height of the opening
according to that! Insert back in the opening in the cur-
tain (and only partially in the curtain) the screws that held
the brackets and hang the curtain from them. Check that
the curtain is fastened properly to prevent it falling
6.3 SUSPENSION:

67
2 VV. Creating innovative solutions for you and your business since 1995.
10mm
30mm
4x
30mm
10mm
67
2 VV. Creating innovative solutions for you and your business since 1995.
6. INSTALLATION
Before installing, check that the ceiling can bear the
weight of the unit. Install according to the following g-
ures.
1. Fastening to the ceiling
2. Fastening to the curtain
Installation with threaded rods
YOU WILL NEED
4 6mm anchors (not included)
4 M6 threaded rods (not included)
8 M6 nuts (not included)
M10 spanner (not included)

89
2 VV. Creating innovative solutions for you and your business since 1995.
12 3
4
5
3mm
6
3mm
89
2 VV. Creating innovative solutions for you and your business since 1995.
6. INSTALLATION
6.4.2 Installing the control module
(Not included)
1) insert the module into the unit
5
Siko pliers are not included
CAUTION!
Tighten the terminal box with the help of the tool
Tensioning the terminal block using the siko tongs:
6.4 Installing the control module (de-
tailed instructions can be found in the
respective manual)
The following procedure requires the removal of the suc-
tion cover
6.4.1. remove the design sideboard fas-
tened with two M5 screws on the side
of the motor

89
2 VV. Creating innovative solutions for you and your business since 1995.
89
2 VV. Creating innovative solutions for you and your business since 1995.
6.5 Connecting the water heater
(only for the curtain with LPHW )
)
• exible hoses are recommended to connect the water
heater
• the connection and pressure tests of the heater must be
carried out by a person with qualications in plumbing
and in compliance with the applicable regulations
• the diameters of the pipes to connect the water heater
are listed in the section DIMENSIONS
• the heater is designed for water with a maximum pres-
sure of 1.6 MPa and a maximum temperature of +100°C.
When connecting the heater, hold the outlet with
pliers to prevent damages (see gure)
PLEASE NOTE
• connect the pipes in the countercurrent connection, the
hot water connection and the return heating water are
shown in the gure above
• it is advisable to install a shut-o󰀨 valve at the inlet and
the outlet of the heater to interrupt the water supply
2) Insert and fasten the regulator’s terminal box to the
curtain’s terminal box with the supplied tool or with Siko
pliers.
3) Tighten all the screws of the module.
4) Fasten the regulator with a screw, see gure below
TECHNICAL INFORMATION
The tool to install the module is supplied with the module.
6.4.3 Connecting the supply cables
• The power cable may be connected to the main ter-
minal box located on the upper part of the unit only
after having installed the control module (see gure
below).
• Pull the regulator’s communication cable.
• Pull the cables to the accessories, if applicable
CAUTION!
The supply must be determined by the relevant de-
signer, it must comply with the applicable regulations
and take into account the power an installation pa-
rameters of the air curtain
6. INSTALLATION

10 11
2 VV. Creating innovative solutions for you and your business since 1995.
15°
10 11
2 VV. Creating innovative solutions for you and your business since 1995.
CAUTION!
Before starting up the unit check that:
• No tools or other objects that may damage the unit
have been left inside.
• The power and heating water supply are well connect-
ed.
• The unit is properly covered.
• The control panel is properly connected
During the commissioning, check the proper function of
the unit (fans, heating). Check the other possible settings
and functions according to the user manual of each regu-
lator
7. COMMISSIONING
7.1 SETTING THE DIRECTION OF THE
EXHAUST AIR
CAUTION!
Deect the exhaust in the desired direction during the in-
stallation of the unit The exhausts of the Essensse air cur-
tain can blow air at a maximum angle of 15°

10 11
2 VV. Creating innovative solutions for you and your business since 1995.
10 11
2 VV. Creating innovative solutions for you and your business since 1995.
8. CLEANING AND MAINTENANCE
8.1 CLEANING
ATTENTION!
Before carrying out any work inside the air curtain, the main power input must be disconnected. The air curtain
must be
allowed to cool down!
• It is forbidden to use compressed air, aggressive chemicals, solvents or water for cleaning.
• Clean using a damp cloth, ne brush or vacuum cleaner.
• Clean the surface of the air curtain including the suction inlet part.
• Clean as necessary, it is recommended that cleaning should be performed at least once every 3 months.
• Adhere to workplace safety and use protective aids.
9. SERVIS
9.1 WHEN YOU AREN‘T ABLE TO REMOVE DEFECT BY YOURSELF
If you are unable to resolve the problem, contact the supplier.
For the fast removal of defects please provide the following information:
- product reference number
- serial number
- running time
- used accessories
- installation location
- installation condition (including electrical)
- detailed description of the problem and the steps that you have taken for its removal
Warranty and post-warranty service is performed by the manufacturer, supplier or authorized service orga-
nization. When ordering service intervention it is necessary to describe the defect, product type designation
indicated on its label, and the location of installation.
9.2 PUTTING THE PRODUCT OUT OF OPERATION - DISPOSAL
Before disposing of the product, make the product unusable. Even old products contain raw materials that can be reused.
Take them to a collection point of secondary raw materials.
The product is good to dispose at the place, which is specialized for it, and thus it will be possible to recycle materials. Store
unusable parts of the product at a controlled dump.
When disposing of materials, it is necessary to observe the relevant national regulations on waste disposal.

12 13
2 VV. Creating innovative solutions for you and your business since 1995.
12 13
2 VV. Creating innovative solutions for you and your business since 1995.
8. SERVIS CLEANING AND MAINTENANCE

󰀨
be allowed to cool down!
• Check of emergency thermostats and subsequent reset.
• Visual inspection of curtain, heat exchanger and connection.
• Clean the surface and inside of the air curtain, including the suction part.

12 13
2 VV. Creating innovative solutions for you and your business since 1995.
VCES3 B 100-E0
VCES3 B XXX-V2
VCES3 B XXX-S0
12 13
2 VV. Creating innovative solutions for you and your business since 1995.
10. WIRING DIAGRAMS

14 15
2 VV. Creating innovative solutions for you and your business since 1995.
VCES3 B 100-E2
VCES3 B 100-E1
14 15
2 VV. Creating innovative solutions for you and your business since 1995.

14 15
2 VV. Creating innovative solutions for you and your business since 1995.
VCES3 B 150-E0
VCES3 B 150-E0
14 15
2 VV. Creating innovative solutions for you and your business since 1995.

16 17
2 VV. Creating innovative solutions for you and your business since 1995.
VCES3 B 150-E1
VCES3 B 150-E2
16 17
2 VV. Creating innovative solutions for you and your business since 1995.

16 17
2 VV. Creating innovative solutions for you and your business since 1995.
VCES3 B 200-E0
VCES3 B 200-E1
16 17
2 VV. Creating innovative solutions for you and your business since 1995.

18 19
2 VV. Creating innovative solutions for you and your business since 1995.
VCES3 B 200-E2
VCES3 B 250-E0
18 19
2 VV. Creating innovative solutions for you and your business since 1995.

18 19
2 VV. Creating innovative solutions for you and your business since 1995.
VCES3 B 250-E1
VCES3 B 250-E2
18 19
2 VV. Creating innovative solutions for you and your business since 1995.

CONTACT
Adresse
2VV, s.r.o.,
Fáblovka 568,
533 52 Pardubice,
Česká republika
Internet :
http://www.2vv.cz/
2 VV. Creating innovative solutions for you and your business since 1995.
After installing the air curtain, read carefully the Manual for the appropriate regulator. In case of any doubt or query, do
not hesitate to contact our sales or technical support departments.
11. CONCLUSION
CONTACT
Adresse
2VV, s.r.o.,
Fáblovka 568,
533 52 Pardubice,
Česká republika
Internet :
http://www.2vv.cz/
2 VV. Creating innovative solutions for you and your business since 1995.
