3-form SimpleSpec 200.25 User manual

For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20025 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.25tm Installation Manual
Ready To Go

Contents Overview
(1)
Base Profile 96½"
3-15-1886
(2)
Clamp Profile 48"
3-15-1887
(1)
Cover Profile 96½"
3-15-1888
=
(4)
Top Support
End Cap KIT
3151897K
+ + +
(4)
Top Support End
Cap Assembly
3151897
(4)
Top Support
Cap Attachment
3151898
M6 x 8
SET Screw
315-774
(8)
Lightbox Heat
Sink Screw
3157780
(8)
(4) =
Insert Block KIT
315189-K
++ + +
M1 x M5
Track Set Screw
315189
(4)
Top Support
Hole Spacer
3151893
(4)
Top Support
Insert Block
3151896
(4)
M5 Button Head
Cap Screw
3151899
(4)
M10 Hex Nut
315-87
(4)
(1)
Varia Panel
(6)
⁄"  1¾" WH Fastener
315167
2
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20025 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.25tm Installation Manual
Ready To Go

Overview
200.25 is a minimalist hardware system made to work with 1/2" Varia. It is a loor and ceiling attached system meant to give a
minimal hardware reveal. Using the insert block, 200.25 hangs Varia from the ceiling.
48"
(1220mm)
98¼"
(2496mm)
1¾"
(45mm)
2¾"
(70mm)
Panel
47½"96"
(12072439mm)
End Cap KIT
3151632
Insert Block
KIT
315189-K
Varia Panel
½" Gauge
Base Proile
3151886
Cover Proile
3151888
Clamp Profile
3151887
+
+
3
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20025 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.25tm Installation Manual
Ready To Go

Installation
Required Tools
Drill Metric Allen
Wrenches
#3 Square
Head Bit
3-15-1886
3-15-1886
16"
(407mm)
16"
(407mm)
16"
(407mm)
16"
(407mm)
1Install Base Proiles into Floor and Ceiling
a
Chop Saw
Cut proiles (3151886 and 3151888) in to ½" more than the panel width.
*3-15-1887 comes cut to size.
b
11/64"Bit
Level
Rubber Mallet
*For wall-to-wall installation
insert blocks will need to be
inserted prior to anchoring
tracks (see Steps 23).
Flat Head Screwdriver
4
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20025 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.25tm Installation Manual
Ready To Go

3-15-1896
3-15-1893 3-15-1890
3-15-0807
3-15-1896
3-15-1893
3-15-1890
3-15-0807
Installation
Top Insert Block
2Loosely Assemble Insert Blocks
aBottom Insert Block b
1Install Base Proiles into Floor and Ceiling cont...
c
3-15-1886
3-15-1886
3-15-167
(6)
16"
(407mm)
16"
(407mm)
16"
(407mm)
16"
(407mm)
5
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20025 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.25tm Installation Manual
Ready To Go

3-15-1890-K
3-15-1890-K
Top Insert Block
Bottom Insert Block
Installation
3Slide Insert Blocks into Base Proiles
6
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20025 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.25tm Installation Manual
Ready To Go

4Install End Cap Blocks
Installation
3-15-1898
3-15-0774
(x2)
3-15-1898
3-15-0774
(x2)
Flush
1
1
2
*End Cap Blocks are not necessary for wall-to-wall installation.
7
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20025 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.25tm Installation Manual
Ready To Go

Installation
5Hang Panel
a
8
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20025 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.25tm Installation Manual
Ready To Go

0"
Flush
5Hang Panel cont...
Installation
Adjust top bushings to be lush
with front face of panel,
then tighten in place.
Adjust bottom bushings until
they touch the base of the
panel, then tighten in place.
b
9
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20025 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.25tm Installation Manual
Ready To Go

Installation
6Attach Clamp Proiles
0-15-1887
3-15-1899
0-15-1887
3-15-1899
10
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20025 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.25tm Installation Manual
Ready To Go

Installation
7Attach Cover Proiles
3-15-1886
3-15-1886
11
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20025 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.25tm Installation Manual
Ready To Go

Installation
8Attach End Caps
3-15-1897
3-15-7780
(x2)
3-15-1897
3-15-7780
(x2)
*End Caps are not necessary for wall-to-wall installation.
12
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20025 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.25tm Installation Manual
Ready To Go
