Installation ManualSimpleSpec tm
Clario Cloud Circle

Contents Overview
Clario Cloud Cable KIT
3151989K
+ + + (8)
Wood Lag Screw
with Eye Bolt
3158895
(2)
Concrete Screw
with Eye Bolt
3158811
(2)
3/64" Ø, 8' Cable
with Hook
3151677
(2) + +
3/64" Ø, 48" Cable
with Terminal End
3151933
(8)
4 Point Sputnik
Cable Connector
3152411
(2)
=
Clario Cloud 4 Point
Sputnik KIT
3151933K
(2)
72"Clario Cloud
48"Clario Cloud
=+ + + (3)
Wood Lag Screw
with Eye Bolt
3158895
(3)
Concrete Screw
with Eye Bolt
3158811
(3)
3/64" Ø, 8' Cable
with Hook
3151677
(3)
(3)
Pre-assembled 48"
Clario Cloud Bale
(1)
Eye Bolt Lag Bit
3158812
(1)
Pre-assembled 72"
Clario Cloud Bale
(1)
Eye Bolt Lag Bit
3158812
(1)
Ring Gripper
3151989
Ring Gripper
3151989
2
For more information, please visit 3-form.com/Elements or call 800.726.0126
AUGUST 2021 | MANRTG40047 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Circle

Overview: 48"Clario Cloud
8' max cable
length (2438mm)
⁄" Ø, 8' Cable
with Hook
3-15-1677
or
Concrete Screw
with Eye Bolt
3-15-8811
Wood Lag Screw
with Eye Bolt
3-15-8895
Pre-assembled 48"
Clario Cloud Bale
Ring Gripper
3-15-1989
3
For more information, please visit 3-form.com/Elements or call 800.726.0126
AUGUST 2021 | MANRTG40047 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Circle

Overview: 72"Clario Cloud
or
Concrete Screw
with Eye Bolt
3-15-8811
Wood Lag Screw
with Eye Bolt
3-15-8895
⁄" Ø, 8' Cable
with Hook
3-15-1677
4 Point Sputnik
Cable Connector
3-15-2411
⁄" Ø, 48" Cable
with Terminal End
3-15-1933
+ +
8' max cable to
Sputnik (2438mm)
Unassembled 72" Clario Cloud Bale Fins
Cable length from
Sputnik to Clario
4' maximum
30" recommended
20" minimum
Ring Gripper
3-15-1989
4
For more information, please visit 3-form.com/Elements or call 800.726.0126
AUGUST 2021 | MANRTG40047 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Circle

Required Tools
Drill Drill Bits Cable Cutters GlueLevel Laser Level
Installation: 48"Clario Cloud
1Position Clario Clouds and Mark Mounting Location
3form recommends creating a square template based
on the outside dimension of the Clario Cloud, using
something like a thin piece of wood or cardboard. Then
using the dimensions provided here mark the pick
points for your installation as needed. Multiple templates
may be helpful with a larger installation of clouds. The
pre-installed Clario Cloud Hooks can be used with a laser
level to help determine the best anchoring locations for
the site conditions.
Ø48"
14.5"
48"×48"
Template
14.1"
20.85"
13.7"
11.25"
19"
5
For more information, please visit 3-form.com/Elements or call 800.726.0126
AUGUST 2021 | MANRTG40047 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Circle

Installation: 48"Clario Cloud
2
a
3-15-8895
or
3-15-8811
Install Cables and Eye Bolts into Mounting Surface (3)
b
3-15-1677
3Attach Cable to Clario Cloud
Thread cables through Ring
Grippers (3151989), pull through
until Ring Gripper hits your mark.
a
b
Mark lengths of the cables (depending on the chosen height) using a permanent marker.
Hook Ring Gripper to the Clario
Cloud Hooks (attachment points
on the cloud).
c
6
For more information, please visit 3-form.com/Elements or call 800.726.0126
AUGUST 2021 | MANRTG40047 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Circle

5Trim Cables and Glue Ends
Installation: 48"Clario Cloud
4Level the Clario Cloud
Make sure cloud is level
from all sides. Make micro
adjustments at each ring
gripper if needed.
a b
7
For more information, please visit 3-form.com/Elements or call 800.726.0126
AUGUST 2021 | MANRTG40047 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Circle

Installation: 72"Clario Cloud
1Position Clario Cloud and Mark Mounting Locations
3form recommends creating a square template
based on the outside dimension of the Clario
Cloud, using something like a thin piece of wood
or cardboard. Then using the dimensions provided
here mark the pick points for your installation as
needed. Multiple templates may be helpful with a
larger installation of clouds. See top diagram for
location of where the cables attach to the 4 Point
Sputniks above the Clario Cloud to determine
mounting location. For installations without
Sputniks see lower diagram for hook locations.
72"×72"
Template
20.85"
Ø72"
25.66" 25.67"
36.54"
35.57"
20.60"
Ø72"
35.52"
25.67" 25.73"
36.48"
*
= Location where hooks are located
72"
13.63"
43.52"
14.85"
72"
11.91" 20.64" 6.87" 20.64" 11.94"
8
For more information, please visit 3-form.com/Elements or call 800.726.0126
AUGUST 2021 | MANRTG40047 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Circle

Installation: 72"Clario Cloud
30"
3Assemble 4 Point Sputnik Hanging Anchor
3form recommends installing
Sputnik with 30" from top
of Clario Cloud to bottom of
Sputnik, minimum distance of
20". If using a distance below
the recommended 30" height
the installer should plan on
more time for installation and
leveling of the system.
Top of Clario Cloud
to Bottom of Sputnik
A
" recommended
B
"
Cable Length*
Perpendicular to
Pattern Direction
C
"
Cable Length*
Parallel to
Pattern Direction
" minimum " "
A
C
C
B
B
Pattern Direction
C
C
B
B
A
*Cable lengths are measured from the far end of the ring-side of
the Ring Gripper (3151989) to where the cable enters the Sputnik.
2
a
3-15-8895
or
3-15-8811
Install Cables and Eye Bolt into Mounting Surface.
b
3-15-1677
9
For more information, please visit 3-form.com/Elements or call 800.726.0126
AUGUST 2021 | MANRTG40047 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Circle

Installation: 72"Clario Cloud
3-15-1933 (×4) 3-15-2411
Insert ⁄" cables (3151933) into base and attach base.
a
3-15-1677
3-15-2411
Insert cable (3151677) hanging from the ceiling.
b
4Attach Cable to Clario Cloud
Thread cables through Ring
Grippers (3151989), pull through
until Ring Gripper hits your mark.
a
b
Mark lengths of the cables (depending on the chosen height) using a permanent marker.
Hook Ring Gripper to the Clario
Cloud Hooks (attachment points
on the cloud).
c
3Assemble 4 Point Sputnik Hanging Anchor cont...
10
For more information, please visit 3-form.com/Elements or call 800.726.0126
AUGUST 2021 | MANRTG40047 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Circle

Installation: 72"Clario Cloud
6Trim Cables and Glue Ends
a b
5Level the Clario Cloud
Make sure cloud is level
from all sides. Make micro
adjustments at each ring
gripper if needed.
11
For more information, please visit 3-form.com/Elements or call 800.726.0126
AUGUST 2021 | MANRTG40047 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Circle

Design Options
48" Clario Cloud
72"Clario Cloud
Clario Cloud is a felt ceiling system that adds textures, color and acoustic performance to your space. The system is made from 16
or 24 individual ins that are assembled to create a beautiful aesthetic. Available in a variety of Sola Felt colors.
Product Description
Available Finishes
Clario can be speciied in a variety of color options.
See 3form’s Sola Felt colors at:
https://www.3-form.com/materials/sola-felt
Panel Weight
Panel Size
"
"
 lbs/module
 lbs/module
Panel Weight
89%21.5%
Openness of Clario Cloud Modules
Sound Absorption Test Results
Material
Sola Felt
Sola Felt
Sola Felt
Noise Reduction Coeicient
Alpha-W
Sound Absorption Average
Test - ASTM C-

MH

Result
Clario Cloud Modules have been independently tested and meet
the criteria for approved interior inishes as described in the
2018 International Building Code®.
Flammability and Smoke Test Results -
Building Code Approvals
ASTM E
Flame Spread
Smoke Generated
Test
CAN/ULC 
Flame Spread
Smoke Generated


Clario Cloud


Class B: -

Result
See Building Code
of Canada
