3-form SimpleSpec 200.47 User manual

For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20047 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.47tm Installation Manual
Ready To Go

Contents Overview
For Each Additional Panel
(1)
Gray Single Sided
Foam Tape – ¼" ×⅛"
3151968
(9)
⁄" × 1¾" Fastener
315-842
(8)
#8 × 2.5" - #2
Drive Wood Screw
3151961
(14)
#6 × 1" Black
Trim Head Screw
3151962
(6)
Scribe Profile
3-15-1947
(3)
Edge Clamp Profile
3-15-1946
(1)
Varia Panel ⅜"
(3)
Edge Seat Profile
3-15-1945
(×1) Varia Panel ⅜"
(×1) Edge Seat Proile 3151945
(×1) Edge Clamp Proile 3151946
(×2) Scribe Proile 3151947
(×1) #8  2.5" -#2 Drive Wood Screw 3151961
(×14) #6  1" Black Trim Head Screw 3151962
(×9) ⁄"  1¾" Fastener 315-842
(1)
Mullion Seat Profile
3-15-1943
(1)
Mullion Clamp Profile
3-15-1944
2
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20047 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.47tm Installation Manual
Ready To Go

The Wood Frame hardware system ensures a perfect it on every installation. Wood Proiles are sent in 10'lengths to be cut and
fastened on site. The design of the proiles ensures the minimal amount of joints. Variations in the ceiling and loor are taken up
by ⅜" scribes at the top and bottom. Screws fastening the vertical proiles in place are hidden through the top and bottom of the
system.
Overview
Mullion
Condition 3
Edge to Surface
Condition 1
Open Edge
Condition 2
94"
(2388mm)
96"
(2439mm)
4"
(102mm)
3
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20047 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.47tm Installation Manual
Ready To Go

Overview: Profile Conditions
Condition 1: Edge to Surface
Condition 2: Open Edge
Condition 3: Mullion
Occurs when the system meets loor, ceiling, and walls. The Scribe proiles are attached spaced ¹/"o of either edge of the Edge
Seat proile.
This is similar to Condition 1 except that Scribe proiles are not needed along this edge since it is not mounting to a surface. The
open edge will occur on Vertical proiles only.
Used for any panel to panel intersection. They are fastened top and bottom through the Edge proiles for loor to ceiling
conditions. For horizontal mullions or vertical mullions that are not full loor to ceiling, you must fasten using either pocket screws
or dowels to conceal the hardware.
Foam Tape
Edge Seat Edge Clamp
+ + + + =
PanelScribe
(×2)
Wall, Floor or
Ceiling
Foam TapeEdge Seat Edge Clamp
+ + + =
Panel
Foam Tape
+ + + =
Edge Seat Edge Clamp Panel
(×2)
4
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20047 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.47tm Installation Manual
Ready To Go

Installation
Required Tools
Drill Countersink Bit
Miter Saw
Nail Gun
3/16" Masonry Bit
Level
Hammer Drill
Router for Panel Trimming
Bits
Hand Planer
Finishing Nails Wood Putty
5
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20047 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.47tm Installation Manual
Ready To Go

Installation
Measure installation space. Account for variation in the wall, ceiling and loor.
⅜"
10mm
⅜"
10mm
3-15-1945
3-15-1947 (×2)
3-15-1945
3-15-1947 (×2)
1Measure the Installation Space
2Attach Scribe Proiles
Using a inishing nail gun, attach Scribe Proiles to Edge Seat Proiles for wherever the system will meet a ceiling, loor, or
wall. Scribe Proiles are not required for an open edge on the system.
6
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20047 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.47tm Installation Manual
Ready To Go

Installation
3Cut Horizontal Proiles
4Cut Vertical Proiles
3-15-1945 + 3-15-1947 (×2)
3-15-1945
3-15-1943
3-15-1945 + 3-15-1947 (×2)
3-15-1945 + 3-15-1947 (×2)
Miter the ends if connecting with a vertical Edge Seat Proile. Use a plain cut if butting into another horizontal proile.
7
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20047 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.47tm Installation Manual
Ready To Go

Installation
5Assemble Module
3-15-1961 (×12)
3-15-1945 + 3-15-1947 (×2)
3-15-1945 + 3-15-1947 (×2)
3-15-1945 + 3-15-1947 (×2)
3-15-1945
3-15-1943
8
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20047 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.47tm Installation Manual
Ready To Go

Installation
6Scribe for Custom Fit
Using a hand planar, scribe at loor, walls, and ceiling to ensure a perfect it for the module.
9
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20047 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.47tm Installation Manual
Ready To Go

Installation
7Install Module
Panel Zone
3-15-1962
Slide module into place and anchor through the “panel zone” face of the Edge Seat Proile.
10
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20047 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.47tm Installation Manual
Ready To Go

Installation
8Cut Clamp Proiles
Cut Edge Clamp ( 3151946) and Mullion Clamp (3151944) Proiles to size and pay attention to joint conditions.
3-15-1946
3-15-1946
3-15-1946
3-15-1946
3-15-1944
11
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20047 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.47tm Installation Manual
Ready To Go

3-15-1968
Installation
9Apply Foam Tape
12
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20047 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.47tm Installation Manual
Ready To Go

Installation
10 Install Panels and Clamp Proiles
Varia
Panel
Varia
Panel
3-15-1944
3-15-1946
3-15-1946
3-15-1946
3-15-1946
a
13
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20047 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.47tm Installation Manual
Ready To Go

Installation
10 Install Panels and Clamp Proiles cont...
18" max
(458mm)
3-15-1962
Clamp Profile
Varia Panel
1
2
Cover holes with
wood putty.
b
14
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20047 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.47tm Installation Manual
Ready To Go
