SimpleSpec -Seeyondtm Installation Manual
Ready To Go

Contents Overview
Seeyond Tiles (Back Side)
The back side of the partition will mainly be in clusters of 4, but for features with odd amounts of rows and columns there will be
single and double tiles. The tiles will be labeled with a Tile ID referencing location and the letter "B" (e.g. A1-B, B1-B).
Seeyond Tiles (Front Side)
The front side tiles (labeled with an “F” after the Tile ID, e.g.
A1F, B1F) will be as individual tiles.
Baseplates
A ¾" thick melamine baseplate will be provided for the
partition. This baseplate will be anchored to the ground
and then the tiles attached to the baseplate. The baseplate
footprint is ¾" less on each open side (1½" overall less than
length and width). The baseplates are not undersized on
sides that are adjacent to other baseplates.
Hardware
Outside Face of
Back Tiles
Inside Face of
Back Tiles
Outside Face of
Front Tiles
Inside Face of
Front Tiles
⁄"  1¾" Fastener
315-842
Screw
38515
Washer
38516
Zip Tie
3-85-12
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG20048 | REV 002 © 2018 3form, Inc. All rights reserved.
Installation Manual
2
Ready To Go
SimpleSpec -Seeyondtm

Overview
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG20048 | REV 002 © 2018 3form, Inc. All rights reserved.
Installation Manual
3
Ready To Go
SimpleSpec -Seeyondtm

Installation
Required Tools
1Arrange Seeyond Tiles
Arrange the Seeyond Tiles in order. Tiles are arranged with columns designated by letters and rows designated by numbers.
Start with A1 which will be the irst tile (irst row, irst column). There will be a front set of tiles designated by "F" and a back
set of tiles designated by "B" (e.g. A1F, A1B).
Drill Hammer Drill Bit
for ⁄"Fastener
(for Concrete Floor)
⁄" Drill Bit
(for Wood Floor)
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG20048 | REV 002 © 2018 3form, Inc. All rights reserved.
Installation Manual
4
Ready To Go
SimpleSpec -Seeyondtm

Installation
2Attach Baseplate to Floor
Using a mortar bit for ⁄" fastener and hammer drill
(or ⁄" drill bit for wood), pre-drill holes into the loor.
a
Hole
Depth
Hole Depth = Screw Length + 1/2"
A1-B
B2-B
B1-B
A2-B
C1-B D1-B
C2-B D2-B
3Attach Bottom Row of Back Tiles to
Baseplate
Position the bottom row of back tiles (A1B, B1B) then
(C1B, D1B) on the baseplate. The magnets should
help you align these properly.
a
bNext install the baseplates using the included screws
(315-842).
c
Optional: You can also mount the baseplate to the
loor by using 3M VHB tape 0.060" or thicker. We
recommend using VHB 4991 or VHB 4624. Apply tape
every 12" as shown in diagram below.
Mark the loor where you intend to install the Seeyond
Partition. Once the position is marked, position the
baseplate. The actual partition overlaps the baseplate
on all sides by ¾" (except where adjacent to another
baseplate) so keep that in mind when positioning the
baseplate. If using anchors follow Steps 2a-b, if using
VHB Tape follow Step 2c.
Attach with Anchors
Attach with VHB Tape
12" 12" 12"12"12"
* When mounting with VHB Tape, the partition can tip.
It is recommended to use anchors (Steps 2a-b) for
permanent installation.
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG20048 | REV 002 © 2018 3form, Inc. All rights reserved.
Installation Manual
5
Ready To Go
SimpleSpec -Seeyondtm

Installation
A1-B
B2-B
B1-B
A2-B
C1-B
D1-B
C2-B D2-B
bFirst, using zip ties, connect each of these clusters
together through the holes between the panels. Pull
each zip tie snug. There should be 6 zip ties per tile.
When the whole bottom row has been joined together
with zip ties anchor the clusters to the baseplate.
3Attach Bottom Row of Back Tiles to
Baseplate cont...
4
a
A3-B
A4-B B4-B
B3-B
C4-B
C3-B
D4-B
D3-B
A1-B
B2-B
B1-B
A2-B
C1-B D1-B
C2-B D2-B
Connect Clusters Together
Using the screws (385-15) with the washers
(385-16), screw through the inside of the bottom
Seeyond Tiles and into the melamine baseplate until
snug. Be careful not to over tighten as this will strip
out the melamine and provide a poor anchor point.
This will be the anchor point between the melamine
base and the structure. There should be 4 anchors per
tile.
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG20048 | REV 002 © 2018 3form, Inc. All rights reserved.
Installation Manual
6
Ready To Go
SimpleSpec -Seeyondtm

Installation
4Connect Clusters Together cont...
Using zip ties, connect tile clusters together both
along the vertical and horizontal seams to complete
the back side of the partition.
Next attach the front tiles to the partition. Pre-installed
magnets will attach the front tiles to the back wall of
tiles. Start on the bottom left (A1F) and work your way
across the row before building upwards.
5Attach Front Tiles
ab
A3-B
A4-B B4-B
B3-B
C4-B
C3-B
D4-B
D3-B
A1-B
B2-B
B1-B
A2-B
C1-B
D1-B
C2-B D2-B
A3-B
A4-B B4-B
B3-B
C4-B
C3-B
D4-B
D3-B
A1-B
B2-B
A1-F
A2-B
C1-B D1-B
C2-B D2-B
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG20048 | REV 002 © 2018 3form, Inc. All rights reserved.
Installation Manual
7
Ready To Go
SimpleSpec -Seeyondtm

5Attach Front Tiles cont...
cb
Installation
A3-B
A4-B B4-B
B3-B
C4-B
C3-B
D4-B
D3-B
A2-F
A1-F
B2-F
B1-F
C1-F
D1-F
C2-F D2-F
A3-F
A4-F B4-F
B3-F
C4-F
C3-F
D4-F
D3-F
A2-F
A1-F
B2-F
B1-F
C1-F D1-F
C2-F D2-F
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG20048 | REV 002 © 2018 3form, Inc. All rights reserved.
Installation Manual
8
Ready To Go
SimpleSpec -Seeyondtm

Product Description and Speciications
Features and Beneits
• 15 color options
• 5 base patterns
• Noise Reduction Coeicient
(NRC) up to 1.10
• Easy to specify
• Easy to install
• Cost-eective decorative
feature
Available Patterns
Billow
Court
Kink
Tilt
Cusp
Cleaning Instructions
Seeyond Tiles should be cleaned periodically. A regular, seasonal
cleaning program will dramatically help prevent noticeable weathering
and dirt build-up.
To remove airborne debris and dust, it is recommended to periodically
vacuum Seeyond Tiles. Please note the slight shedding of ibers from
the Felt is normal and not indicative of any defect.
To treat liquid stains, remove spills immediately using a clean damp
cotton cloth or with detergent soap and warm water. Carpet and fabric
Panel Sizes and Tolerances
Seeyond Tiles are oered in various sizes. All dimensions and
squareness are subject to a 2% tolerance.
Panel Weight
 lb/ft kg/m
Material
Sola Felt /" mm
Thickness Weight Flux
Sound Absorption Test Results
Sola Felt Noise Reduction Coeicient
Material Test - ASTM C Result
Seeyond Tiles have been independently tested and meet
the criteria for approved interior inishes as described in the
2015 International Building Code®.
Flammability and Smoke Test Results
- Building Code Approvals
Material


Class A: -

Sola Felt Flame Spread
Smoke Generated
Test - ASTM E Seeyond Result
cleaners can usually be used; always test an inconspicuous area
before the actual stain.
Available Finishes
Seeyond can be speciied in any of 3form’s 15 Sola Felt options.
Ruby Aries Citrine Admiral Oxford
Hunter Burnt Umber Nickel Armor Mineral
Cast Ebony Cashmere Moon Zinc
Create a private space, contain sound, and build a more comfortable environment with this absorptive, modular tile system.
Seeyond is a series of lightweight dimensional tiles made from Acoustic Felt and boasts an NRC rating of 1.10. When combined
with Acoustic Foam, Seeyond has an NRC of 1.10. Use Seeyond to build walls, divide a space, or create unique features that will
leave a lasting impression.
Do:
• Vacuum or use a
soft brush to clean
Seeyond Tiles.
Do not:
• Use strong solvents, highly alkaline
or abrasive cleaning agents.
• Do not completely saturate module
with cleaning solution or water.
Sabine Absorption Coeicients






















































⅓ Octave Center
Frequency, HZ
Absorption
Coeicient Sabins/ft
Total
Absorption
