3-form Ready to go simplespec 200.39 User manual

For more information, please visit 3-form.com or call 800.726.0126

SimpleSpec 200.39tm

Installation Manual

Ready To Go

Contents Overview

(8) =

2-Piece Clamping

Bracket KIT

3-15-1752-K

M6 TNut

315-825

(16) + +

M5  14mm

CSK Screw

315-794

(16)

M6  12mm Button

Head Screw

(16)

Clamping Side

Bracket

3151752

(8)

(6)

Slot Cover

3-15-1732

(1)

Varia Panel

(2)

Beam Profiles 96"

-15-126

(2) =

Top Cap KIT

3-15-139-K

Beam Top Cap

315-139

(2)

12  1 FH SQ

SMS

315-868

(2)

(2) =

Beam Base Cover KIT

3151939K

(2)

Cover Plates

3151939

(4)

M5 TNut

315-86

+(4)

M5  6mm

Set Screw

315-86

For more information, please visit 3-form.com or call 800.726.0126

SimpleSpec 200.39tm

Installation Manual

Ready To Go

Contents Overview cont...

(2) =

Versa 6" Dia. 2Part

Baseplate for Concrete KIT

3151941K

For Each Additional Panel

(×1) Varia Panel

(×1) Beam Proile – 96" -15-126

(×1) Top Cap KIT 3-15-139-K

(×1) Versa 6" Dia. 2Part Baseplate for Concrete KIT 3151941K

(×1) Beam Base Cover KIT 3151939K

(×8) 2Piece Clamping Bracket KIT 3151752K

(×2) Slot Cover 3151732

+ +

188 SS LHSC M8,

20mm 1.25

315-999

(8)

SHCS M12  1.75,

30mm 316 SS

3151938

(2)

M8  50mm

Concrete Anchors

315311A

(8)

+ +

188 SS FHSC M8,

10mm 1.25

3-15-15

(8)

Top Plate

3-15-1941

(2)

Bottom Plate

3-15-1942

(2)

12  1 FH SQ SMS

315-868

(8)

For more information, please visit 3-form.com or call 800.726.0126

SimpleSpec 200.39tm

Installation Manual

Ready To Go

Overview

Versa is a popular system that uses aluminum extrusions to add rigidity to panels. With the 200.39 installation, the base is bolted

to loor and covered using the base covers. Slot covers are used to conceal exposed slots. The material is then suspended using

the 2 piece clamping brackets.

51" max

(1296mm)

48"

(1219mm)

95"

(2413mm)

96" max

(2439mm)

(153mm)

Varia Panel

⅜" Gauge

Versa 6" Dia. 2-Part

Baseplate

for Concrete KIT

3151941K

Beam Top

Cap Kit

315- 139-K

Clamping Side

Bracket KIT

3151752-K

Bottom Plate

Cover KIT

3151939-K

Slot Cover

3151732

Beam Extrusion 96"

-15-126

Center Line to Center Line

49.8" (1265mm)

Panel Width

48" (1220mm)

Overall Width

55.9" (1420mm)

For more information, please visit 3-form.com or call 800.726.0126

SimpleSpec 200.39tm

Installation Manual

Ready To Go

Installation

Required Tools

Drill

Hammer Drill Masonry Bits Metric Allen Wrenches#3 Square Head Bit

11/64"Bit Saw Rubber Mallet

For more information, please visit 3-form.com or call 800.726.0126

SimpleSpec 200.39tm

Installation Manual

Ready To Go

3-15-0999

(×4)

3-15-1938

3-15-1941

0-15-0126

1Attach Baseplate to Extrusion (Tapped at Center End)

* Complete this step for each extrusion.

3-15-1005

(×4)

3-15-1942

b* Complete this step for each extrusion.

For more information, please visit 3-form.com or call 800.726.0126

SimpleSpec 200.39tm

Installation Manual

Ready To Go

3-15-825 (×8)

3-15-1939

3-15-86 (2)

Installation

2Slide on Cover Plate and Attach Side Clamping Brackets

* Complete this step for each extrusion.

M6  12mm (×2)

3-15-1752

3-15-825 (2)

For more information, please visit 3-form.com or call 800.726.0126

SimpleSpec 200.39tm

Installation Manual

Ready To Go

Installation

3Install Panel

3-15-0794 (×2)

3-15-1752

For more information, please visit 3-form.com or call 800.726.0126

SimpleSpec 200.39tm

Installation Manual

Ready To Go

4Dry-Fit and Measure

Installation

3-15-1942

3-15-1941

3-15-1005

(×4)

Position the assembly and then remove the panel

For more information, please visit 3-form.com or call 800.726.0126

SimpleSpec 200.39tm

Installation Manual

Ready To Go

5Install Concrete Anchors

Installation

b ca

e fd

Drill Ø10mm hole, minimum 65mm

deep.

Remove drilling debris with a blowout

bulb or with compressed air.

With screw in anchor (315311A), use

a hammer to insert anchor.

Place a washer under the screw head. Torque the screw to 15 Nm. Remove screw.

For more information, please visit 3-form.com or call 800.726.0126

SimpleSpec 200.39tm

Installation Manual

Ready To Go

6Anchor to Floor

Installation

3-15-0999

(×4)

3-15-1942

3-15-3011A

(×4)

3-15-1005

(×4)

3-15-1942

3-15-1941

For more information, please visit 3-form.com or call 800.726.0126

SimpleSpec 200.39tm

Installation Manual

Ready To Go

7Reinstall Panels

Installation

3-15-0794 (×2)

3-15-1752

For more information, please visit 3-form.com or call 800.726.0126

SimpleSpec 200.39tm

Installation Manual

Ready To Go

Installation

8Attach Extrusion Top Caps

3-15-0868

(×2)

3-15-0139

For more information, please visit 3-form.com or call 800.726.0126

SimpleSpec 200.39tm

Installation Manual

Ready To Go

Installation

9Attach Slot Covers

3-15-1732

Cut slot covers to size.

Attach slot covers on outer edges of assembly.
