3-form SimpleSpec 500.04 User manual

For more information, please visit 3-form.com or call 800.726.0126
JUNE 2020 | MANRTG50004 | REV 003 © 2020 3form, Inc. All rights reserved.
SimpleSpec 500.04tm Installation Manual
Ready To Go

Contents Overview
(1)
Fin Base Profile
122" Length
0-60-2266
(2)
Fin Cover Profile
122" Length
0-60-2267
(2)
Aluminum
Shim for Fin
0-60-2274
(1)
Chroma 15¾"  96"  ½"
(4)
M6  40mm
Std SHCS
3-15-0709
(4)
M6 Washer
3-15-3040
(4)
M6 Hexagon Nut
3-15-3060
(1)
Light Drive RGB -
DMX Wall Control
3-60-510
(1)
Fin End Cap KIT
3-60-2268-K
= +
Lightbox Heat
Sink Screw
3-15-7780
(2)
Fin End Cap
3602268
(1)
96W Dimmable
Power Supply
3-60-765
(1)
(1)
Fin End Cap with
Strain Relief Hole KIT
3-60-2271-K
= +
Lightbox Heat
Sink Screw
3-15-7780
(2)
Fin End Cap
3602271
(1)
9 Channel PWM
DMX Interface
3-60-001
(1)
2
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2020 | MANRTG50004 | REV 003 © 2020 3form, Inc. All rights reserved.
SimpleSpec 500.04tm Installation Manual
Ready To Go

Overview
96"
(2439mm)
16"
(407mm)
2⅞"
(73mm)
Fin End
Cap KIT
3602268-K
Chroma Panel
½" Gauge
Fin End Cap
with Strain Relief
Hole KIT
3602271-K
Fin Base
Profile
0602266
Fin Cover
Profile
0602267
Alumninum
Shim for Fin
0602274
+ +
Installation
Drill
Drill Bits Driving Bits
Required Tools
⁄"  1¾" (or ¼"or M6)
Wood or Concrete Anchors
3
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2020 | MANRTG50004 | REV 003 © 2020 3form, Inc. All rights reserved.
SimpleSpec 500.04tm Installation Manual
Ready To Go

0-60-2266
1Drill and Anchor
Drill ¼" holes in Fin Base Proile for anchoring with maximum of 30" spacing
and no more than 12" from edge.
a
Installation
Anchor
Anchor Fin into wall using appropriate anchors for wall surface.
Anchors to be supplied by installer.
b
4
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2020 | MANRTG50004 | REV 003 © 2020 3form, Inc. All rights reserved.
SimpleSpec 500.04tm Installation Manual
Ready To Go

Installation
2Attach Cover Proiles
0-60-2267
(×2)
5
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2020 | MANRTG50004 | REV 003 © 2020 3form, Inc. All rights reserved.
SimpleSpec 500.04tm Installation Manual
Ready To Go

3Connect Electrical
Have a qualiied electrician wire the lighting to a remote driver (in remote location) and test the lights.
Line Voltage
Black
(line)
White
(neutral)
96W
3-6-765
Power Supply
3-6-1
9-Channel PWM
DMX Interface
3-60-51
Light Drive RGB
To Additional
9-Channel Interfaces
CAT V Cable
CAT V Cable
(included w/Light Drive)
12 AWG Wire
10'max
30'Cable to Fin or Countertop
(can be extended an
additional 20' with 14/2AWG+)
DMX
INOUT
+/-
Fin or Countertop
1 2 3
PWM OUTPUT
+
DC IN
7 8 94 5 6
PWM OUTPUT PWM OUTPUT
12-48V DC
+++ +++ +++ -- - - - - - - - -
White
Black
Blue
Brown
Black
White
Blue Wire = (-) Blue LED
Brown Wire = (-) Green LED
Black Wire = (-) Red LED
White Wire = (+) 24VDC
Installation
