3-form SimpleSpec 200.29 User manual

For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20029 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.29tm Installation Manual
Ready To Go

(1)
(1)
Silicone
3-5-69
Glass Pony Wall
Contents Overview
=
+
(1)
Glass
(1)
Wood Base
+
(1)
Floor Plate
2
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20029 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.29tm Installation Manual
Ready To Go

Overview
Large
9' 7"
(2759mm)
3'
(915mm)
1'
(305mm)
10'
(3048mm)
10"
(254mm)
⁄" or ½" Gauge Glass
(11 or 12.5mm)
Medium
7' 7"
(2149mm)
3'
(915mm)
1'
(305mm)
8'
(2439mm)
10"
(254mm)
⁄" or ½" Gauge Glass
(11 or 12.5mm)
Small
5' 7"
(1539mm)
2'
(610mm)
1'
(305mm)
6'
(1829mm)
10"
(254mm)
⁄" or ½" Gauge Glass
(11 or 12.5mm)
3
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20029 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.29tm Installation Manual
Ready To Go

Installation
Required Tools
1Attach Floor Plate to Floor
a3form requires the 200.29 system be attached to the loor so that it will not tip when leaned on or against.
Remove loor plate from the bottom of the wood base.
b
Masking Tape
Anchor Screws
(Substrate Dependent)
Drill and Assorted Bits Construction
Adhesive
Shims LevelCaulking Gun
4
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20029 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.29tm Installation Manual
Ready To Go

Installation
2Attach Wooden Base to Floor Plate
1Attach Floor Plate to Floor
Anchors
Floor Plate
cAnchor plate to loor in desired location. Anchor with screws or bolts.
Apply construction adhesive (not included) on the top of the loor plate then place the wooden base over the loor
plate.
5
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20029 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.29tm Installation Manual
Ready To Go

a
bInstall 3form Glass into wooden slot in base unit.
Install 3form Glass in Wooden Base
Installation
3
Apply silicone to bottom edge of 3form Glass.
6
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20029 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.29tm Installation Manual
Ready To Go

Installation
Install 3form Glass in Wooden Base cont...
3
dWith shims in place, mask o the wood base and glass to protect it when applying silicone.
cShim around the perimeter until it is plumb. Make sure spacing is equal around the glass.
7
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG20029 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 200.29tm Installation Manual
Ready To Go

Installation
Install 3form Glass in Wooden Base cont...
3
Let silicone dry at least 4 hours, remove shims then remask areas where shims were and then apply silicone.
Tool and let dry.
f
eApply silicone around perimeter to ensure an even bead. Remove tape immediately.
4 Hrs
