3-form SimpleSpec 200.52 User manual
For more information, please visit 3-form.com or call 800.726.0126
MARCH 2021 | MANRTG20052 | REV 002 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.52tm
Installation Manual
Ready To Go
Contents Overview
(1)
Base Profile 96½"
3-15-1886
(2)
Clamp Profile 48"
3-15-1887
(1)
Cover Profile 96½"
3-15-1888
(4) =
Insert Block KIT
3151890K
+ + ++
M1 x M5
Track Set Screw
315189
(4)
Top Support
Hole Spacer
3151893
(4)
Top Support
Insert Block
3151896
(4)
M5 Button Head
Cap Screw
3151899
(4)
M10 Hex Nut
315-87
(4)
(1)
⅜"Varia
Panel
(6)
⁄" 1¾" WH
Fastener
3151607
(2) =
Top Support Edge
Stiener for ⅜"KIT
3152010-K
+
Top Support
Edge Stiener
3152007
(2)
Top Support 3/8"
Glazing Channel
3152010
(2)
For Each Additional Panel
(×1) ⅜" Varia Panel
(×6) ⁄" 1¾" WH Fastener 3151607
(×4) Insert Block KIT 3151890K
(1) Base Proile 96½" 3-15-1886
(2) Clamp Proile 48" 3151887
(1) Cover Proile 96½" 3-15-1888
+ +
Plasitc Base
Extrusion for ⅜"
3151997
(1)
Top Support
Panel to Panel
3152008
(2)
Plastic Cover
Extrusion
for ½" and ⅜"
3152011
(1)
(1) Top Support
Panel to Panel KIT
3152008K
=
2
For more information, please visit 3-form.com or call 800.726.0126
MARCH 2021 | MANRTG20052 | REV 002 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.52tm
Installation Manual
Ready To Go
Overview
200.52 is a minimalist hardware system made to work with ⅜" Varia. It is a loor and ceiling attached system meant to give a
minimal hardware reveal. Light scale vertical extrusions provide increased rigidity to the resin panels. Using the insert block,
200.52 hangs Varia from the ceiling.
48"
(1226mm)
98¼"
(2496mm)
2¾"
(70mm)
1⁄"
(49mm)
½"
(13mm)
Base Proile
3151886
Cover Proile
3151888
Clamp Profile
3151887
+
+
Insert Block KIT
315189-K
Varia Panel
⅜" Gauge
Top Support Edge
Stiener for
⅜" KIT
3152010K
3
For more information, please visit 3-form.com or call 800.726.0126
MARCH 2021 | MANRTG20052 | REV 002 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.52tm
Installation Manual
Ready To Go
Installation
Required Tools
Drill Chop Saw
Install Base Proiles into Floor and Ceiling
aCut proiles (3151886 and 3151888)
Single Panels:
Length to Cut = Panel Width – ¾"
Multiple Panels:
Length to Cut = Total Width of Panels – ¾"
+ ¼" for each addtional
panel beyond the first
*3-15-1887 comes cut to size.
3-15-1886
3-15-1886
16"
(407mm)
16"
(407mm)
16"
(407mm)
16"
(407mm)
b*For wall-to-wall installation insert blocks will need to be
inserted prior to anchoring tracks (see Steps 23).
#3 Square
Head Bit
⁄"Bit
Level Flat Head Screwdriver
Metric Allen
Wrenches
Rubber MalletMeasuring Tape
4
For more information, please visit 3-form.com or call 800.726.0126
MARCH 2021 | MANRTG20052 | REV 002 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.52tm
Installation Manual
Ready To Go
Installation
Install Base Proiles into Floor and Ceiling cont...
c
3-15-1886
3-15-1886
3-15-167
(6)
16"
(407mm)
16"
(407mm)
16"
(407mm)
16"
(407mm)
47¼" max
(1200mm)
*Showing
installation
for 1 Panel
Loosely Assemble Insert Blocks
3-15-1896
3-15-1893
3-15-1890
3-15-0807
3-15-1896
3-15-1893 3-15-1890 3-15-0807
Top Insert Block
aBottom Insert Block
b
Shim within ¼" of level.
5
For more information, please visit 3-form.com or call 800.726.0126
MARCH 2021 | MANRTG20052 | REV 002 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.52tm
Installation Manual
Ready To Go
Installation
3-15-1890-K
Top Insert Block
3-15-1890-K
Bottom Insert Block
Slide Insert Blocks into Base Proiles
6
For more information, please visit 3-form.com or call 800.726.0126
MARCH 2021 | MANRTG20052 | REV 002 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.52tm
Installation Manual
Ready To Go
Installation
Hang Panel
a
7
For more information, please visit 3-form.com or call 800.726.0126
MARCH 2021 | MANRTG20052 | REV 002 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.52tm
Installation Manual
Ready To Go
0"
Flush
Adjust top
bushings to be flush
with front face of panel
Adjust bottom bushings
to be flush with front
face of panel
Flush
Tighten in place
Tighten in place
⅜" max
overhang
Installation
Hang Panel cont...
b
8
For more information, please visit 3-form.com or call 800.726.0126
MARCH 2021 | MANRTG20052 | REV 002 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.52tm
Installation Manual
Ready To Go
Installation
Attach Clamp Proiles
0-15-1887
3-15-1899
0-15-1887
3-15-1899
3-15-1899
9
For more information, please visit 3-form.com or call 800.726.0126
MARCH 2021 | MANRTG20052 | REV 002 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.52tm
Installation Manual
Ready To Go
Installation
Attach Cover Proiles
3-15-1886
3-15-1886
10
For more information, please visit 3-form.com or call 800.726.0126
MARCH 2021 | MANRTG20052 | REV 002 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.52tm
Installation Manual
Ready To Go
Installation
Attach Vertical Edge Stieners
Insert gasket.
aCut vertical gasket/extrusion assembly to system height.
c
3-15-2010
3-15-2007
Floor-to-Ceiling Height
Floor-to-Ceiling Height
3-15-2010-K
(3-15-2007 + 3-15-2010)
d
Measure height on all sides where support extrusion
will be installed.
b
3-15-2010-K
(3-15-2007 + 3-15-2010)
11
For more information, please visit 3-form.com or call 800.726.0126
MARCH 2021 | MANRTG20052 | REV 002 © 2021 3form, Inc. All rights reserved.
SimpleSpec 200.52tm
Installation Manual
Ready To Go
Installation
Attach Panel-to-Panel Extrusions to System (Add a Panel Only)
Insert base and cover plastic extrusions.
aEnsure a ¼"
panel-to-panel
distance.
b
3-15-1997
3-15-2008
3-15-2011
3-15-2008
¼"
¼"
Distance Between Horizontal Extrusions
Measure distance between horizontal
extrusions and cut panel-to-panel extrusion to
that length.
c
1
2
Rear View
Front View
3-15-2008
&
3-15-1997
3-15-2008
&
3-15-2011
Top
View
1Remove VHB tape cover from female end (3151997) and
insert between panels, adhering at edge.
2Snap in male assembly (3152011)
d
12
