3-form Ready To Go SimpleSpec 400.18 User manual

For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG40018 | REV 002 © 2018 3form, Inc. All rights reserved.
SimpleSpec 400.18tm Installation Manual
Ready To Go

Contents Overview
(1) = + +
Large
12"  3¾"  33"
(2)
Medium
12"  5½"  58"
(2)
Small
12"  5½"  96"
(2)
Varia Shapes
¼"Gauge
=
(14)
Smooth Surface
Bracket KIT
3151781K
+ + +
Set Screw
M6  8mm
Cup Point
315-774
(28)
Set Screw
M6  1mm
Cup Point
315-775
(28)
M6  4mmL
STD SHCS
315-79
(14)
Smooth Surface
Bracket
3151781
(14) (14)
M6  14mm
SS STD Head
Socket Cap Screw
3157777
+
(14)
M6 Universal
Anchoring KIT
3156-K
= + +
M6 SS Concrete
Anchor
31531
(14)
M6 Threaded
Rod, 5 mm
31533
(14)
M6 Toggle Bolt
315-7
(14) (14)
M6  25mm
Rampa Screw
315-762
+
2
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG40018 | REV 002 © 2018 3form, Inc. All rights reserved.
SimpleSpec 400.18tm Installation Manual
Ready To Go

Overview
The SimpleSpec 400.18 solution adds texture to any ceiling by adding the beauty of heat formed 3form Varia. The surface bracket
hardware allow for lush mounting with ease.
96"
(2439mm)
12"
(305mm)
12"
(305mm)
12"
(305mm)
33"
(839mm)
58"
(1474mm)
Varia Shapes
¼" Gauge
Smooth Surface
Bracket KIT
3-15-1781-K
M6 Universal
Anchoring KIT
3-15-6000-K
+
3
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG40018 | REV 002 © 2018 3form, Inc. All rights reserved.
SimpleSpec 400.18tm Installation Manual
Ready To Go

Installation
1Mark Locations for Drilling
Position shapes on loor in desired orientation, then set brackets on top of shapes.
a
Required Tools
Drill Drill Bits Laser Level Allen Wrenches
4
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG40018 | REV 002 © 2018 3form, Inc. All rights reserved.
SimpleSpec 400.18tm Installation Manual
Ready To Go

Installation
1Mark Locations for Drilling cont...
Mark the location of the brackets on the loor.
b
cUse laser level to translate
shape orientations to ceiling
and mark ceiling location.
5
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG40018 | REV 002 © 2018 3form, Inc. All rights reserved.
SimpleSpec 400.18tm Installation Manual
Ready To Go

Installation
2Drill and Attach Anchors
*If anchoring in concrete follow Steps 2a-f, for a hollow substrate follow Steps 2g-l, for wood follow Steps 2m-n.
Drill Ø8mm hole, minimum 6mm deep. Remove drilling debris with a blowout
bulb or with compressed air.
With screw in anchor (31531), use a
hammer to insert anchor.
b ca Concrete Installation
e fd
Place a washer under the screw head. Torque the screw to 7 Nm. Remove screw.
6
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG40018 | REV 002 © 2018 3form, Inc. All rights reserved.
SimpleSpec 400.18tm Installation Manual
Ready To Go

Installation
2Drill and Attach Anchors cont...
Metal
Studs
Metal
Studs
h ig
Drill ؽ” (13mm) hole. Minimum
clearance behind wall = 1⅞” (48mm).
Position the metal channel parallel
with the plastic legs. Insert the metal
channel through the drilled hole into
the wall cavity.
Pull the metal channel irmly against the
inner wall cavity by tugging the plastic
pull ring.
Hollow Substrate Installation
k lj
Slide the plastic cap forward along the
legs until it is seated lush to the work
surface.
Snap the plastic legs o lush at the
plastic cap by pushing outward.
Note: Maximum torque on screw or rod
is 5 ft-lb.
7
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG40018 | REV 002 © 2018 3form, Inc. All rights reserved.
SimpleSpec 400.18tm Installation Manual
Ready To Go

3-15-0709
3-15-1781
Anchor
Installation
2Drill and Attach Anchors cont...
3Mount Surface Brackets into Ceiling
nm
Drill Ø.4” (Ø1.4mm) hole, minimum
25mm deep.
Use an Allen wrench to install the
M625mm Rampa Screw (315-762).
Wood Installation
8
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG40018 | REV 002 © 2018 3form, Inc. All rights reserved.
SimpleSpec 400.18tm Installation Manual
Ready To Go

Installation
4Install Shapes into Surface Brackets and Fix Panels with Set Screws
3-15-0774
or
3-15-0775
9
