3-form Velo Ceiling Tiles User manual

For more information, please visit 3-form.com or call 800.726.0126
JUNE 2020 | VELO | REV 009 © 2020 3form, Inc. All rights reserved.
Velo Ceiling Tilestm Solution Document

Overview
Velo tiles are available in Sola Felt colors in a concave or convex shape. Use the on-line coniguration tool to mix and match colors
and shapes to create a unique cloud installation.
3⁄64" Ø,
8' Cable with Hook
3-15-1677
Wood Lag Screw
with Eye Bolt
3-15-8895
+or
Concrete Screw
with Eye Bolt
3-15-8811
Velo Tile
Sola Felt
Self-tapping
Screw
3-85-105
+
Double Ended
Cable Gripper
3-15-1990
Cantilever
Attachment Bracket
3-85-120
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2020 | VELO | REV 009 © 2020 3form, Inc. All rights reserved.
Velo Ceiling Tilestm Solution Document
2

Contents Overview
=
Cable Loop KIT
3151677K
+ + +
Double Ended
Cable Gripper
3151990
(1)
Wood Lag Screw
with Eye Bolt
3158895
(1)
Concrete Screw
with Eye Bolt
3158811
(1)
3/64" Ø, 8' Cable
with Hook
3151677
(1)
Self-tapping Screw
385105
Eye Bolt Lag Bit
3158812
Required Tools
Drill Drill Bits Phillips & Torx Bits Cable Cutters Glue
Level
Laser Level
=
Cantilevered
Attachment KIT
385120K
+++
Double
Ended
Cable
Gripper
3151990
(1)
Wood Lag
Screw with
Eye Bolt
3158895
(1)
Concrete
Screw with
Eye Bolt
3158811
(1)
3/64" Ø, 8' Cable
with Hook
3151677
(1) +
Cantilever
Attachment
Bracket
385120
(1)
#6 Screw
3/16"
3152412
(1)
+
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2020 | VELO | REV 009 © 2020 3form, Inc. All rights reserved.
Velo Ceiling Tilestm Solution Document
3

1.25" 1.25"
15.95"
405mm
12.6"
320mm
12.6"
320mm
12.6"
320mm
12.6"
320mm
Concave Velo Tile Convex Velo Tile
Overview
Looped Attachment
Attachment Types
Uses 3151677K for locations internal to the layout. Can
be used at cantilevered edges if cable splay is ≥  10° is
required.
Cantilevered Attachment
Uses 385120K for locations at cantilevered edges that
need support. Typically at locations with ≤ 2 adjacent shaped
tile edges. Uses VHB tape and a screw (3152412) to attach
tiles. Cable splay must be within  10° of vertical. Provides a
blind connection detail at edges of installation where more
support is needed for cantilever.
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2020 | VELO | REV 009 © 2020 3form, Inc. All rights reserved.
Velo Ceiling Tilestm Solution Document
4

Installation
Layout Velo tiles on the ground in
speciied or desired pattern. Make note
of which tiles are concave vs. convex
and their placement within the pattern.
a
1Preparation
CV
CC CC
CV
CV
CC CC
CV
CC
CV
CC
CV
CC = Concave
CV = Convex
* Note that this coniguration is
for illustration purposes only
Assemble the tiles into manageable sized clusters for assembly.
Clusters should not be larger than 4 tiles.
a
Cluster TilesCluster Tiles
2
3-85-105
bUse self-tapping screws (385105) to conncect tiles (3 per side).
Don’t over-run/over tighten screw.
¼"
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2020 | VELO | REV 009 © 2020 3form, Inc. All rights reserved.
Velo Ceiling Tilestm Solution Document
5

Installation
3
Identify the Eye Bolt location in the ceiling for each cable location. This can be done with a laser
level, using the shape on the loor as a reference for cable location.
*Ensure that there are holes for the
cable to loop through the Velo tiles at
the seams indicated on the diagram.
CV
CC CC
CV
CV
CC CC
CV
CC
CV
CC
CV
*
*
*
*
*
*
*
*
*
*
*
°
°
Position and Mark Mounting Locations
Cables can be splayed out at various angles to reduce seismic
and airlow movement.
±10°
±10°
±10°
±10°
Cables can be hung perpendicular to the ceiling.
or
Red *= Looped Attachment (3151677K)
Blue °= Cantilevered Attachment (385120K)
If there are ≤2 shared edges, this will require a cantilevered attachment.
See additional examples on the following page.
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2020 | VELO | REV 009 © 2020 3form, Inc. All rights reserved.
Velo Ceiling Tilestm Solution Document
6

*
*
°
**
** *
*
*
*
**
°
°
°
*
**
*
*
° °
°
* * *
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
°
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
* *
*
*
*
*
*
*
*
*
* **
*
*
*
*
*
*
*
*
*
* *
Installation
Position and Mark Mounting Locations cont...
*
° ° °
° °
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*°
*
°
°*
*
**
*
*
3
Red *= Looped Attachment (3151677K)
Blue °= Cantilevered Attachment (385120K)
If there are ≤2 shared edges, this will require a cantilevered attachment.
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2020 | VELO | REV 009 © 2020 3form, Inc. All rights reserved.
Velo Ceiling Tilestm Solution Document
7

While supporting
the feature, as to
not place excess
strain on any
connected
joint, lift the
feature o the
ground and
thread the
cable through
the pre-drilled
holes.
a b
3-15-8895
or
3-15-8811
3-15-1677
4Install Cables and Eye Bolt into Mounting Surface.
a b Thread the loose end of cable
back through the double
ended gripper. This loop
can be adjusted by
releasing the cable,
pushing the plunger
down or pulling on the
loose end of the cable
to tighten the loop. Make
sure the gripper doesn’t
have any weight hanging
while making these adjustments.
Installation
5Attach Velo Tiles to the Cables with Looped Attachment Only
Thread the double ended gripper onto the cable.
This component will create the adjustable loop
that the Velo feature will hang from (the position
can be adjusted after hanging; but consider for
larger installations, leveling your inner sections
and moving outward).
The double ended gripper can be adjusted
by easily sliding in one direction and then by
compressing down the plunger and sliding the
gripper along the cable when moving it ‘up’ the
cable.
c
3-15-1990
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2020 | VELO | REV 009 © 2020 3form, Inc. All rights reserved.
Velo Ceiling Tilestm Solution Document
8

Hang remaining clusters next to the irst
cluster in the same manner, connecting
with appropriate fasteners, then leveling.
3-85-105
Installation
6Level the Cluster
With the irst cluster hung in place,
level it with the gripper (either
adjusting the gripper placement
on the cable or the loop side).
Pull to raise
the cluster and
to increase the
loop size
Pull to
tighten loop
7Hang Additional Clusters
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2020 | VELO | REV 009 © 2020 3form, Inc. All rights reserved.
Velo Ceiling Tilestm Solution Document
9

Wipe tile clean before applying bracket.
Firmly press for 810 seconds to engage
adhesive to Velo Tiles. It is best to wait
12 hours before
hanging weight on
this connection to
ensure the best
bond strength
(and 24 hours for
optimal strength).
Installation
9Cut Cables and Glue Ends
8Attach Cantilevered Attachment Brackets
aRemove
adhesive
backing.
b c Use a screw (3152412) to attach for a better
connection. Screw through adhesive into felt.
Hand tighten and do not strip!
d
Pull to
raise the
cluster and
increase the
loop size
Pull to
tighten
loop
eLevel tiles at edges.
Loop cable through bracket, with the cable position  10° of vertical. If the
cable can’t be set within this range, omit adhesive bracket and drill a hole in
the edge of the tile to create a looped connection.
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2020 | VELO | REV 009 © 2020 3form, Inc. All rights reserved.
Velo Ceiling Tilestm Solution Document
10

Product Description and Speciications
Available Colors
Velo is available in any of 3forms’s 15 Sola Felt colors.
Admiral
Driftwood
Jasper
Aries
Dune
Mineral
Cast
Ebony
Nightfall
Armor
Dusk
Nickel
Citrine
Emerald
Zinc
Sola Felt has been independently tested and meet the criteria
for approved interior inishes as described in the 2018
International Building Code®.
Flammability and Smoke Test Results
Building Code Approvals


Sola Felt


Class A: -

Result
See Building
Code of Canada
ASTM E
Flame Spread, /" thickness
Smoke Generated
Test
CAN/ULC  TRIPLICATE
Rounded Flame Spread FSR
Rounded Smoke Developed SDC
Panel Weight
 lbs/tile
Weight
Sound Absorption Test Results
Felt Noise Reduction Coeicient
Material Test - ASTM C  Result
Felt Alpha - W
Cleaning Instructions
Velo Tiles should be cleaned periodically. A regular, seasonal
cleaning program will dramatically help prevent noticeable
weathering and dirt build-up.
To remove airborne debris and dust, it is recommended to
periodically vacuum Velo Tiles. Please note the slight
shedding of ibers from the Felt is normal and not indicative of
any defect.
To treat liquid stains, remove spills immediately using a clean
damp cotton cloth or with detergent soap and warm water.
Carpet and fabric cleaners can usually be used; always test an
inconspicuous area before the actual stain.
Do:
• Vacuum or use a soft brush to clean Velo Tiles
Do not:
• Use strong solvents, highly alkaline or abrasive cleaning
agents.
• Do not completely saturate module with cleaning solution
or water.
Features and Beneits
• 15 color options
• Noise Reduction Coeicient (NRC) of 0.85
• Cost-eective decorative feature
• Easy to specify
• Easy to install
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2020 | VELO | REV 009 © 2020 3form, Inc. All rights reserved. 11
Velo Ceiling Tilestm Spec Sheet
