3-form SimpleSpec 400.48 User manual

For more information, please visit 3-form.com/Elements or call 800.726.0126
JUNE 2021 | MANRTG40048 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Square

Contents Overview
Clario Cloud Cable KIT
(S Pattern)
3151989K
=
(4)
Pre-assembled
Clario Cloud Bale
(1)
Eye Bolt Lag Bit
3158812
(1)
*Quantities shown are for one (1) module. The hardware kit provided depends on whether the module is connected to another
module or on it’s own.
S
The pattern direction
arrow indicates the
visible direction through
the cloud, in plan view.
+ + + (4)
Wood Lag Screw
with Eye Bolt
3158895
(1)
Concrete Screw
with Eye Bolt
3158811
(1)
3/64" Ø, 8' Cable
with Hook
3151677
(1) + +
3/64" Ø, 48" Cable
with Terminal End
3151933
(4)
4 Point Sputnik
Cable Connector
3152411
(1)
=
Clario Cloud 4 Point Sputnik KIT
(A,B,C,D,E,F,G,H,J,K,L,M,N,P,R)
3152411K
(1)
K
Connector
Large U
Connector
Small U
Connector
Ring Gripper
3151989
+ + +
Ring Gripper
3151989
(4)
Wood Lag Screw
with Eye Bolt
3158895
(4)
Concrete Screw
with Eye Bolt
3158811
(4)
3/64" Ø, 8' Cable
with Hook
3151677
(4)
2
For more information, please visit 3-form.com/Elements or call 800.726.0126
JUNE 2021 | MANRTG40048 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Square

Overview: S Pattern
48"
48"
4"
8' max cable
length (2438mm)
⁄" Ø, 8' Cable
with Hook
3-15-1677
or
Concrete Screw
with Eye Bolt
3-15-8811
Wood Lag Screw
with Eye Bolt
3-15-8895
Pre-assembled
Clario Cloud Bale
Ring Gripper
3-15-1989
3
For more information, please visit 3-form.com/Elements or call 800.726.0126
JUNE 2021 | MANRTG40048 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Square

Overview: K,L,M Hallway
4'
8' max cable to
Sputnik (2438mm)
4'
4'
4'
12'
4"
Cable length from
Sputnik to Clario
4' maximum
30" recommended
20" minimum
or
Concrete Screw
with Eye Bolt
3-15-8811
Wood Lag Screw
with Eye Bolt
3-15-8895
⁄" Ø, 8' Cable
with Hook
3-15-1677
4 Point Sputnik
Cable Connector
3-15-2411
⁄" Ø, 48" Cable
with Terminal End
3-15-1933
+ +
Pre-assembled
Clario Cloud Bale
Ring Gripper
3-15-1989
4
For more information, please visit 3-form.com/Elements or call 800.726.0126
JUNE 2021 | MANRTG40048 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Square

Overview: Available Modules
K
L
M
S
N P R
A
D
G
B
E
H
C
F
J
48"
48"
144"
144"
144"
144" 48"
48"
144"×48" Plan View
48"×48" Plan View48"×144" Plan View
144"×144" Plan View
*S pattern uses the Cable Loop Kit (3-15-1989-K).
The 4 Point Sputnik Kit (3-15-1933-K) is used on patterns A, B, C, D, E, F, G, H, J, K, L, M, N, P, R.
5
For more information, please visit 3-form.com/Elements or call 800.726.0126
JUNE 2021 | MANRTG40048 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Square

Required Tools
Drill Drill Bits Cable Cutters GlueLevel Laser Level
Installation: S Pattern
1Position Clario Clouds and Mark Mounting Location
3form recommends creating a square template based
on the outside dimension of the Clario Cloud, using
something like a thin piece of wood or cardboard. Then
using the dimensions provided here mark the pick
points for your installation as needed. Multiple templates
may be helpful with a larger installation of clouds. The
pre-installed Clario Cloud Hooks can be used with a laser
level to help determine the best anchoring locations for
the site conditions.
24"
6.2"
25.25"
6.05"
6.05"
22.75"
3.6"
24"
48"×48"
Template
6
For more information, please visit 3-form.com/Elements or call 800.726.0126
JUNE 2021 | MANRTG40048 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Square

Installation: S Pattern
2
a
3-15-8895
or
3-15-8811
Install Cables and Eye Bolts (4) into Mounting Surface
b
3-15-1677
3Attach Cable to Clario Cloud
Thread cables through Ring
Grippers (3151989), pull through
until Ring Gripper hits your mark.
a
b
Mark lengths of the cables (depending on the chosen height) using a permanent marker.
Hook Ring Gripper to the Clario
Cloud Hooks (attachment points
on the cloud).
c
7
For more information, please visit 3-form.com/Elements or call 800.726.0126
JUNE 2021 | MANRTG40048 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Square

Installation: S Pattern
5Trim Cables and Glue Ends
4Level the Clario Cloud
Make sure cloud is level
from all sides. Make micro
adjustments at each ring
gripper if needed.
a b
8
For more information, please visit 3-form.com/Elements or call 800.726.0126
JUNE 2021 | MANRTG40048 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Square

Installation: A,B,C,D,E,F,G,H,J,K,L,M,N,P,R Patterns
1Position Clario Clouds and Mark Mounting Location
3form recommends creating a square
template based on the outside dimension
of the Clario Cloud, using something like a
thin piece of wood or cardboard. Then using
the dimensions provided here mark the
pick points for your installation as needed.
Multiple templates may be helpful with a
larger installation of clouds. The pre-installed
Clario Cloud Hooks can be used with a laser
level to help determine the best anchoring
locations for the site conditions.
*When connecting multiple modules, the
connection to the ceiling is 48"on center.
The center location on the packaging is for
reference only.
48"×48"
Template
24"
24"
2
a
3-15-8895
or
3-15-8811
Install Cable and Eye Bolt into Mounting Surface
b
3-15-1677
9
For more information, please visit 3-form.com/Elements or call 800.726.0126
JUNE 2021 | MANRTG40048 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Square

3Assemble 4 Point Sputnik Hanging Anchor
3-15-1933 (×4) 3-15-2411
Insert ⁄" cables (3151933) into base and attach base.
a
3-15-1677
3-15-2411
Insert cable (3151677) hanging from the ceiling.
b
3form recommends installing
Sputnik with 30" from top
of Clario Cloud to bottom of
Sputnik, minimum distance of
20". If using a distance below
the recommended 30" height
the installer should plan on
more time for installation and
leveling of the system.
Installation: A,B,C,D,E,F,G,H,J,K,L,M,N,P,R Patterns
Top of Clario Cloud
to Bottom of Sputnik
A
" recommended
B
"
Cable Length*
Perpendicular to
Pattern Direction
C
"
Cable Length*
Parallel to
Pattern Direction
" minimum " "
A
C
C
B
B
Pattern Direction
30"
*Cable lengths are measured from the far end of the ring-side of
the Ring Gripper (3151989) to where the cable enters the Sputnik.
10
For more information, please visit 3-form.com/Elements or call 800.726.0126
JUNE 2021 | MANRTG40048 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Square

Installation: A,B,C,D,E,F,G,H,J,K,L,M,N,P,R Patterns
4Attach Cable to Clario Cloud
Thread cables through Ring
Grippers (3151989), pull through
until Ring Gripper hits your mark.
a
b
Mark lengths of the cables (depending on the chosen height) using a permanent marker.
Hook Ring Gripper to the Clario
Cloud Hooks (attachment points
on the cloud).
c
11
For more information, please visit 3-form.com/Elements or call 800.726.0126
JUNE 2021 | MANRTG40048 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Square

5Attach Additional Modules
K Connector
Large U
Connector
a
Installation: A,B,C,D,E,F,G,H,J,K,L,M,N,P,R Patterns
K Connectors and Large U Connectors are used to connect modules at the locations indicated below.
K
L
M
A
D
G
B
E
H
C
F
J
12
For more information, please visit 3-form.com/Elements or call 800.726.0126
JUNE 2021 | MANRTG40048 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Square

5Attach Additional Modules cont...
b
Installation: A,B,C,D,E,F,G,H,J,K,L,M,N,P,R Patterns
Small U Connectors are used to connect modules at the locations indicated below.
A
D
G
B
E
H
C
F
J
N P R Small U
Connectors
6Level the Clario Cloud
Make sure cloud is level
from all sides. Make micro
adjustments at each ring
gripper if needed.
13
For more information, please visit 3-form.com/Elements or call 800.726.0126
JUNE 2021 | MANRTG40048 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Square

Installation: A,B,C,D,E,F,G,H,J,K,L,M,N,P,R Patterns
7Trim Cables and Glue Ends
a b
14
For more information, please visit 3-form.com/Elements or call 800.726.0126
JUNE 2021 | MANRTG40048 | REV 005 © 2021 3form, Inc. All rights reserved.
Installation ManualSimpleSpec tm
Clario Cloud Square
