3-form Divy SimpleSpec 200.51 User manual

For more information, please visit 3-form.com or call 800.726.0126
OCTOBER 2019 | MANRTG20051 | REV 005 © 2019 3form, Inc. All rights reserved.
Installation Manual
Ready To Go
SimpleSpec -Divytm

Contents Overview
= +
1" Shelf Holder
SS: 315-754
BO: 3-15-2018
(2)
M6  12mm
Set Screw
315-776
(2)
(2)
1" Shelf Holder KIT
Stainless Steel: 315-754K
Black Oxide: 3152018
+
Cable Coupler
with Cover Plate
SS: 3151639
BO: 3-15-2004
(2)
M8 Thread
Rod, 25mm
3151754
(2)
=
(2)
Cable Coupler KIT
Stainless Steel: 3-15-1639-K
Black Oxide: 3-15-2004-K
(2) = +
Cable Tensioner with Cover Plate
SS: 3151636
BO: 3152005
(2)
M8 Thread
Rod, 25mm
3151754
(2)
Cable Tensioner KIT
Stainless Steel: 3151636K
Black Oxide: 3152005K
(1)
36"72"
Divy Felt Baffle
(2)
3mm Cable
Stainless Steel: 315-723
Black Oxide: 3-15-2006
(4)
Single Panel Side
Bracket For Felt KIT
Stainless Steel: 3152012-K
Black Oxide: 3-15-2013-K
+
Single Panel Side
Bracket for Felt
SS: 3152012
BO: 3152013
(4)
Hex Drive Flanged Rounded
Head Screw, M650mm
SS: 3152017
BO: 3152016
(4)
=
For more information, please visit 3-form.com or call 800.726.0126
OCTOBER 2019 | MANRTG20051 | REV 005 © 2019 3form, Inc. All rights reserved.
Installation Manual
2
Ready To Go
SimpleSpec -Divytm

For Each Additional Panel
Contents Overview cont...
(×1) 36"72" Divy Felt Bale
(×1) 3mm Cable
SS: 3-15-0723
BO: 3-15-2006
(×2) Suspend Anchoring KIT
3157000K
(×1) 1"Shelf Holder KIT
SS: 3150754K
BO: 3152018
(×1) Cable Coupler KIT
SS: 3-15-1639-K
BO: 3-15-2004-K
(×1) Cable Tensioner with Cover Plate KIT
SS: 3151636K
BO: 3152005K
(×2) Double Panel Side Bracket For Felt KIT
Stainless Steel: 3152014K
Black Oxide: 3152015K
= +
Double Panel Side
Bracket for Felt
Stainless Steel: 3152014
Black Oxide: 3152015
Hex Drive Flanged Rounded
Head Screw, M650mm
Stainless Steel: 3152017
Black Oxide: 3152016
(4)(2)
(2) =
Suspend Anchoring KIT
3-15-7000-K
+ +
M8 Threaded
Wood Insert
3150791
(2)
M8 Concrete
Anchor
3153011A
(2)
M8 Threaded
Rod, 50mm
3153032A
(2) +
M8 Thread
Rod, 25mm
3151754
(2)
M8 Toggle
Bolt Anchor
3150734
(2) +
Required Tools
Drill Metric Allen
Wrenches
Concrete or
Wood Bit
Cable Cutters Plumb-bobSuper Glue
For more information, please visit 3-form.com or call 800.726.0126
OCTOBER 2019 | MANRTG20051 | REV 005 © 2019 3form, Inc. All rights reserved.
Installation Manual
3
Ready To Go
SimpleSpec -Divytm

Overview
/"
mm
Panel Width
"
mm
Panel Height
max '
floor-to-ceiling
/"
mm
Hardware Outside
"
mm
Cable Centerline
3mm Cable
SS: 3150723
BO: 3152006
Cable Coupler KIT
SS: 3151639-K
BO: 3-15-2004-K
Cable Tensioner
with Cover Plate KIT
SS: 3151636K
BO: 3152005K
1" Shelf Holder KIT
SS: 3150754-K
BO: 3-15-2018
Single Panel Side
Bracket For Felt KIT
SS: 3152012K
BO: 3152013K
36 3/8’’x 72 3/8’’
Divy Felt Panel
SimpleSpec 200.51 provides a robust partition with the added quality of acoustical absorption. The 3form Sola Patterned Felt is
complimented by a beautiful Birch Plywood Edge.
For more information, please visit 3-form.com or call 800.726.0126
OCTOBER 2019 | MANRTG20051 | REV 005 © 2019 3form, Inc. All rights reserved.
Installation Manual
4
Ready To Go
SimpleSpec -Divytm

Installation
Drill Ø10mm hole, minimum 65mm
deep.
Remove drilling debris with a blowout
bulb or with compressed air.
With screw in anchor (315311A), use a
hammer to insert anchor.
Install Ceiling Anchor for the First Cable Assembly
*If anchoring in concrete follow Steps 1a-f, if anchoring in drywall follow Steps 1g-l. if anchoring in wood follow Steps 1m-n.
b ca Concrete Installation
e fd
Place a washer under the screw head. Torque the screw to 15 Nm. Remove screw.
For more information, please visit 3-form.com or call 800.726.0126
OCTOBER 2019 | MANRTG20051 | REV 005 © 2019 3form, Inc. All rights reserved.
Installation Manual
5
Ready To Go
SimpleSpec -Divytm

Installation
Install Ceiling Anchor for the First Cable Assembly cont...
Metal
Studs
Metal
Studs
h ig
Drill ؾ" (19mm) hole. Minimum
clearance behind wall = 1⅞" (48mm)
Position the metal channel parallel
with the plastic legs. Insert the metal
channel through the drilled hole into
the wall cavity.
Pull the metal channel irmly against the
inner wall cavity by tugging the plastic
pull ring.
Hollow Substrate Installation
k lj
Slide the plastic cap forward along the
legs until it is seated lush to the work
surface.
Snap the plastic legs o lush at the
plastic cap by pushing outward.
Note: Maximum torque on screw or rod
is 5 ft-lb.
For more information, please visit 3-form.com or call 800.726.0126
OCTOBER 2019 | MANRTG20051 | REV 005 © 2019 3form, Inc. All rights reserved.
Installation Manual
6
Ready To Go
SimpleSpec -Divytm

Installation
Install Ceiling Anchor for the First Cable Assembly cont...
Install Floor Anchor for the First Cable Assembly
b
c
3-15-1754
3-15-3011A
SS: 3-15-1636
BO: 3-15-2005
Attach the Cable Tensioner
(SS: 3151636; BO: 3152005)
to the loor anchor with the
included M8 Threaded Rod
(3151754).

aHang plumb-bob
to mark anchoring
point on loor.
If anchoring in concrete follow Steps 1a-f, if anchoring in
wood follow Steps 1g-h.
3-15-1754
3-15-0791
SS: 3-15-1639
BO: 3-15-2004
n om
Drill Ø⁄" (Ø11.1mm) hole, minimum
20mm deep.
Use an Allen wrench to install the M8
Threaded Insert (315-791).
Wood Installation
For more information, please visit 3-form.com or call 800.726.0126
OCTOBER 2019 | MANRTG20051 | REV 005 © 2019 3form, Inc. All rights reserved.
Installation Manual
7
Ready To Go
SimpleSpec -Divytm

Installation
Attach First Cable Assembly
a b
e
c
fd
SS: 3-15-0723
BO: 3-15-2006
SS: 3-15-1639
BO: 3-15-2004
SS: 3-15-1639
BO: 3-15-2004
2-3x
SS: 3-15-0723
BO: 3-15-2006
Do not tighten yet!
Pull excess cable through the side
exit on the tensioner.
Unscrew the cap.
150-200 lbs
225 + lbs
max weight
per cable
Maximum Weight = 225 lbs
Maximum Tension = 400 lbs
Hollow Substrate:
Max Tension + Weight < 70lbs
For more information, please visit 3-form.com or call 800.726.0126
OCTOBER 2019 | MANRTG20051 | REV 005 © 2019 3form, Inc. All rights reserved.
Installation Manual
8
Ready To Go
SimpleSpec -Divytm

Dry-Fit Panel and Measure
Installation
aDo not tighten set screw! bDo not tighten set screws!
SS: 3-15-2012
BO: 3-15-2013
 Set Screws
SS: 3-15-2017
BO: 3-15-2016
For more information, please visit 3-form.com or call 800.726.0126
OCTOBER 2019 | MANRTG20051 | REV 005 © 2019 3form, Inc. All rights reserved.
Installation Manual
9
Ready To Go
SimpleSpec -Divytm

dc
Dry-Fit Panel and Measure cont...
Installation
Do not tighten set screws!
(2×) Set Screws
SS: 3-15-2017
BO: 3-15-2016
For more information, please visit 3-form.com or call 800.726.0126
OCTOBER 2019 | MANRTG20051 | REV 005 © 2019 3form, Inc. All rights reserved.
Installation Manual
10
Ready To Go
SimpleSpec -Divytm

e
Dry-Fit Panel and Measure cont...
Installation
Remove Panel
SS: 3-15-2017
BO: 3-15-2016
For more information, please visit 3-form.com or call 800.726.0126
OCTOBER 2019 | MANRTG20051 | REV 005 © 2019 3form, Inc. All rights reserved.
Installation Manual
11
Ready To Go
SimpleSpec -Divytm

Installation
Anchor Second Cable Assembly
ba Repeat Steps 13 for the Second Cable Assembly. Repeat Step 4 and then Steps 13
for each additional panel.
Attach the Panel
aPosition the top single side brackets for felt
(SS: 3152012; BO: 3152013) 1½" below desired location
of the top of the panel. Tighten set screws to the cable
(top side brackets only).
bPosition the panel to desired location and ensure
it is level. Tighten set screws to the panel on top side
brackets only.
69⅜"
(1762mm)
1" (25mm)
SS: 3-15-2017
BO: 3-15-2016
For more information, please visit 3-form.com or call 800.726.0126
OCTOBER 2019 | MANRTG20051 | REV 005 © 2019 3form, Inc. All rights reserved.
Installation Manual
12
Ready To Go
SimpleSpec -Divytm

Installation
Attach the Panel cont..
dc Critical Tensioning Step!
Wait to re-tension the cables as weight of the panel is
applied. Re-tension the cables, pulling excess cable
through the tensioner, and tighten using Allen wrench
through tensioner as shown in 6c.
SS: 3-15-2017
BO: 3-15-2016

Set Screws
1" (25mm)
Tighten set screws on lower side brackets once cables
have been tensioned. This will prevent gapping in
tension on the cables.
For more information, please visit 3-form.com or call 800.726.0126
OCTOBER 2019 | MANRTG20051 | REV 005 © 2019 3form, Inc. All rights reserved.
Installation Manual
13
Ready To Go
SimpleSpec -Divytm

Finish Tensioner Assembly
Installation
Cut cable and put a drop of super glue at end of cut cable to keep from fraying.
1
2
For more information, please visit 3-form.com or call 800.726.0126
OCTOBER 2019 | MANRTG20051 | REV 005 © 2019 3form, Inc. All rights reserved.
Installation Manual
14
Ready To Go
SimpleSpec -Divytm

Available Patterns
Accord Margin Net
Plane Quint Vim
Product Description and Speciications
Features and Beneits
• 15 color options
• 6 base patterns
• Noise Reduction Coeicient
(NRC) up to 0.75
• Cost-eective decorative feature
• Easy to specify
• Easy to install
Cleaning Instructions
Divy Panels should be cleaned periodically. A regular, seasonal cleaning
program will dramatically help prevent noticeable weathering and dirt
build-up.
To remove airborne debris and dust, it is recommended to periodically
vacuum Divy Panels. Please note the slight shedding of ibers from the Felt
is normal and not indicative of any defect.
To treat liquid stains, remove spills immediately using a clean damp cotton
cloth or with detergent soap and warm water. Carpet and fabric cleaners can
usually be used; always test an inconspicuous area before the actual stain.
vvv
• Vacuum or use a soft brush to clean Divy Panels.
Do not:
• Use strong solvents, highly alkaline or abrasive cleaning agents.
• Do not completely saturate module with cleaning solution or water.
Divy Panels can be speciied in any of 3form’s 15
Sola Felt options.
AriesAdmiral Burnt UmberArmor Cashmere
CitrineCast Ebony Hunter Mineral
RubyOxfordNickelMoon Zinc
Available Finishes
For more information, please visit 3-form.com or call 800.726.0126
OCTOBER 2019 | MANRTG20051 | REV 005 © 2019 3form, Inc. All rights reserved.
SimpleSpec -Divytm Spec Sheet
15
Ready To Go
Sound Absorption Test Results
SOLUTION TEST  ASTM C42309 RESULT
Divy NRC (Noise Reduction Coeficient) 0.75
Divy SAA (Sound Absorption Average) 0.76
Divy Alpha-w 0.70H
Flammability/Smoke Test Results
Sola Felt panels have been independently tested
and meet the criteria for approved interior inishes
as described in the 2018 International Building
Code®.
TEST SOLA FELT 38” 9.5MM RESULT
ASTM E84
Flame Spread
Smoke generated
30
450
Class B: 2675
<450
CAN/ULC 102.2
Flame Spread
Smoke generated
75
200
See Building Code of
Canada
Panel Weight
SOLUTION THICKNESS WEIGHT
Divy Partition 1.5” (38.1mm) 36 lb (16.3 kg)
