3SIXT 3S-0570 User manual

USER GUIDE
LAPTOP CHARGER
& ADAPTER
3S-0570 : 65W
For more information visit
www.3sixtgear.com/support
COMPATIBILITY TABLE
16B
IBM, Lenovo
K3
HP, Compaq
E
Sony Vaio
M
Acer, Asus, Clevo, Compaq,
Fujitsu, Hitachi, HP, IBM,
Lenovo, NEC,
Panasonic, Sharp, Toshiba
I
Samsung
U
Acer
K1
Dell
T
HP, Compaq
PLEASE NOTE: Some tips may not be compatible with all
models of the laptops shown. Some of the tips are very similar
to each other. Look carefully at the number or letter on the tip.
Brand names and trademarks are the property of their respective owners.
SPECIFICATIONS
Input 100-240V~, 1.7A, 50/60Hz
Output 19V DC, 3.42A, 65W
SAFE DISPOSAL
This power adapter contains items that are harmful to
the environment. To preserve our environment, dispose
of unused power adapters according to your local laws or
regulations. Do not dispose of the power adapter with
normal household waste. For more information, please
contact the local authority.
This symbol on the product indicates that this
product must not be disposed of with your
other household waste. Instead, it is your
responsibility to dispose of your waste equipment by
handing it over to a designated collection point for the
recycling of waste electrical and electronic equipment.
The separate collection and recycling of your waste
equipment at the time of disposal will help conserve
natural resources and ensure that it is recycled in a
manner that protects human health and the
environment. For more information about where you can
drop off your waste for recycling, please contact your
local authority.

For more information and support visit www.3sixtgear.com/support
READ FIRST SAFETY INFORMATION
• Your adapter is not a toy. Keep it away from children. Make sure that all
persons who operate your adapter read and follow this guide.
• Using your adapter with non-approved accessories may result in serious fatal
injury and/or property damage.
• Never attempt to use your adapter to power any devices that require more
than the output power of this adapter (for example, the voltage setting
matches, but your laptop requires more amperage).
• Your adapter is suitable for use only with laptop computers. Do not use your
adapter with other electronic devices. It may result in serious injury and/or
property damage.
• For energy saving and safety, disconnect the input power to your adapter
when it is not in use.
• Your adapter may become hot during operation. Ensure to provide ventilation
and refrain from placing items on or around your adapter during operation.
Maintain at least 5cm around the top and sides of your adapter. Never
operate your adapter inside a closed or confined space such as a glove
compartment, console or airline seat pocket.
• When operating your adapter, regularly check that all connections are firmly
connected. Loose connections can generate harmful heat that can damage
your adapter or attached laptop computer.
• Do not operate your adapter near a heat source, heat vent, or in direct
sunlight. Your adapter should be used in temperatures between 0-40°C.
• Before use, make sure that your laptop’s input voltage is compatible with the
input voltage of this adapter.
• Keep your adapter dry. Direct contact of your adapter to moisture may lead to
electrical shock, causing serious fatal injury and/or property damage. Consult
a qualified technician for a complete safety evaluation before resuming use of
your adapter when it has come into direct contact with moisture.
• Inspect your adapter and cables for damage and wear before use. Do not use
or attempt to repair your adapter and/or cables. Consult a qualified technician
for a complete safety evaluation if in doubt.
1. Confirm the brand, voltage and output wattage of your
laptop. You can sometimes find this information on the
bottom or back of you laptop. The voltage of your laptop
MUST be between 18-20V, and the output wattage is less
than 65W.
2. Find the tip (
4
) that should be used for the brand of
your laptop by checking the Compatibility Table
(following page).
3. Connect the correct tip (
4
) to the adapter DC cable
connector (
a
). Ensure the tip (
4
) is pushed all the way
onto the DC cable connector (
a
). Ensure the tip is not
loose and is fitted correctly (do not force the tip). Using
an incorrect tip for your laptop computer may damage
your computer or cause it to malfunction.
4. Connect the mains cable (
3
) to the power adapter
socket (
b
) first, then connect it to a wall power outlet.
5. Connect the DC cable (
2
) fitted with the correct tip (
4
)
to the power socket on your laptop. Do not use excessive
force to insert the tip into your laptop computer. If your
laptop does not start to charge you may have selected
the wrong tip. Please check Compatibility Table for
correct tip.
Please note: If your laptop is completely discharged,
allow at least 5 minutes for the laptop to charge before use.
GETTING TO KNOW YOUR
ADAPTER, CABLES AND TIPS
CONNECTING THE POWER ADAPTER
TO YOUR LAPTOP
a
Power
Adapter
DC Cable
Mains Cable
Connector
Tip
Mains Adapter
Socket
2
1
b
4Tips
3
SEE COMPATIBILITY TABLE
