3SIXT 3S-0966 User manual

USER GUIDE
ALUMINIUM DUAL 15W
QI WIRELESS CHARGE PAD
3S-0966

IMPORTANT SAFETY INFORMATION
• Read all instructions and warnings before using the 3SIXT
Aluminium Dual 15W Qi Wireless Charge Pad. Improper use of
this product may result in product damage, excessive heat,
toxic fumes, fire or explosion, for which damages you
(“Purchaser”) and not 3SIXT (“Manufacturer”) are responsible.
• Do not store the accessory in a high-temperature
environment, including heat caused by intense sunlight or
other forms of heat (heaters etc.).
• Do not place any parts of the device in fire or other extremely
hot environments.
• Do not disassemble or modify the accessory in any manner.
• Do not attempt to replace any part of the 3SIXT Aluminium
Dual 15W Qi Wireless Charge Pad.
• Do not attempt to power this device using any other method
than as instructed explicitly in this user guide.
• The 3SIXT Aluminium Dual 15W Qi Wireless Charge Pad
accessory is intended for adults, not minors or pets.
• All 3SIXT items undergo quality testing. If you find that your
device is excessively hot (Qi charging heat generation is
normal), is emitting foul odour, is deformed or is experiencing
or demonstrating abnormal phenomenon, immediately unplug
it from its power source, halt all use and contact 3SIXT
(Manufacturer).

3
Welcome
Thank you for purchasing the
3SIXT Aluminium Dual 15W Qi
Wireless Charge Pad. The 3SIXT
Aluminium Dual 15W Qi Wireless
Charge Pad will wirelessly charge
Apple, Samsung and other devices
with Qi wireless technology. This
guide will allow you understanding
around how to operate them
safely.
For more information and support,
visit www.3sixtgear.com

4
PACKAGE CONTENTS
3SIXT Aluminium Dual 15W Qi
Wireless Charge Pad
12V Wall Charger
User Guide

5
THE BASICS
Name Parts
1. Silicone Feet
2. Power Input Port
3. LED Indicator #1
4. Silicon Charge Pad
5. LED Indicator #2
6. 12V Wall Charger
6
4
5
1
2
3

6
Turning on the device
1. Plug the 12V Wall Charger (6) into
your wall socket.
2. Turn it on at the wall.
3. 3SIXT Aluminium Dual 15W
Qi Wireless Charge Pad LED
indicator (3 or 5) will turn on for
4 seconds and turn off. You are
now ready to charge.
Foreign Object Detection
1. If a foreign object is detected the
LED (3 or 5) indicator will flash red.
OPERATION INSTRUCTIONS

7
Placing your device
ü
ü
û
OPERATION INSTRUCTIONS

8
Charging your Device
1. When successful charging has been
established the LED indicator (3 or
5) will continually flash green.
2. Once fully charged the LED indicator
(3 or 5) will remain on.
3. If an error occurs during charging
the LED indicator (3 or 5) will
continually flash red. Simply
remove the device and reapply it to
recommence charging.
OPERATION INSTRUCTIONS

9
Power input 12V | 3.5A DC 3.5mm
Power output 30W (15W+15W)
Launch distance ≤ 8mm
Additional notes
Qi Licensed Technology - Qi EPP 15W
Over Voltage Protection
Foreign Object Detection
Over Temperature Protection
5W Support
7.5W Apple Fast Charge Support
10W Samsung Quick Charge Support
15WExtended Power Support
Dimensions H - 73mm x W - 178mm x D - 15mm
TECH SPECS

10
LIABILITY NOTICE
LIABILITY NOTICE
We reserve the right to printing errors and changes to product,
packaging or product documentation.
• See our terms of the warranty. These are available in their
current form by the importer of record in each region where
the item is sold.
DISPOSAL
Parts of this unit contain materials that are recyclable. Certain
waste companies specialise in recycling these parts. Dispose
of the components in compliance with all applicable regions
regulations. Contact your local waste management authority for
more detailed information about recycling this product.
DISPOSAL (Applicable for EU countries)
This symbol on the product, or in the operating
instructions, or on the packaging indicates that the
product must not be included as general household
waste.
According to the European WEEE directive, electrical and
electronic equipment must not be disposed of with consumers
waste. Its components must be recycled or disposed separately
of general household waste. Otherwise, contaminative and
hazardous substances can pollute the environment and adversely
aect human health.
As a consumer, you are commied by law to dispose of electrical
and electronic devices to the producer, the dealer, or public
collecting points at the end of the devices lifetime. This kind of
waste separation, application, and recycling of materials help with
conserving natural resources critical to environmental protection.
WEEE No: 82898622
EU DECLARATION OF CONFORMITY
With the CE sign, 3SIXT, an imported brand of Wentronic
GmbH ensures, that the product is conformed to the
basic European standards and directives.

11
WARRANTY
AUSTRALIA & NEW ZEALAND TWO YEAR WARRANTY
3SIXT will replace the faulty product at no cost to the consumer. The warranty
does not extend to any consequential damages or costs that may be incurred
and is valid for TWO YEARS from date of purchase. The consumer must return
the faulty product to the retail store it was purchased from together with
proof of purchase. The benefits to the consumer under this warranty are in
addition to other rights and remedies of the consumer under Australian and
New Zealand laws in relation to the goods to which the warranty relates. Our
goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for major failure
and for compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail
to be of acceptable quality and the failure does not amount to a major failure.
The warranty is provided by: Cellnet Limited (in Australia): 59-61 Qantas Drive,
Eagle Farm, Queensland 4009. Ph: 1300 CELLNET (1300 235 563). Email: info@
cellnet.com.au. Cellnet Limited (in New Zealand): 10a Orbit Drive, Rosedale,
Auckland 0632. Ph: 0800 CELLNET (0800 235 563), Email: [e-mail]
For more detailed warranty information, please visit:
www.3sixtgear.com/warranty-policy
EUROPE WARRANTY
This warranty is by Wentronic GmbH. Wentronic GmbH oer the manufacturer’s
warranty in addition to the legal guarantee of this 3SIXT product. This warranty
applies to products in the following countries: Germany, France, Ireland, Italy,
Luxembourg, Austria, Switzerland, or United Kingdom. The warranty does not
extend to any consequential damages or costs that may be incurred. Defects
and damages resulting from misuse, wear parts and consumables are excluded
from the warranty. Damage which is not caused to the product itself, is also
not covered under the warranty. Claims due to the neglect of duties, misuse on
manipulations and claims for reimbursement of expenses are excluded against us
or our agents under the warranty; This also applies to claims for compensation
of consequential damages. The restrictions, mentioned above, do not apply to
statutory rights of the consumer of a purchase of consumer goods or claims
of damages resulting from injury to life, body or health, intentionally or by
gross negligence, or under the Product Liability Act (ProdHaG Germany). The
warranty is void for improper use of the product. The warranty does not extend
the guarantee period or initiate a new guarantee. The statutory guarantee rights
are not aected by this warranty but are available fully unchanged to the buyer
in addition. The warranty is provided by: Wentronic GmbH: Pillmannstraße
12, 38112 Braunschweig, Hotline: [phone] (0.14€ per minute within
Germany. Max 0.42€ per minute from mobiles), Email: o[email protected],
Web: www.wentronic.de
For more detailed warranty information, please visit:
www.3sixtgear.com/warranty-policy-eu

EN
DE
FR
ES
IT
EU PRODUCT SUPPORT
3SIXT PRODUCT SUPPORT
For more information, visit www.3sixtgear.com/support
3SIXT PRODUKT-SUPPORT
Bie besuchen Sie www.3sixtgear.com/support
ASSISTANCE PRODUIT 3SIXT
Veuillez consulter www.3sixtgear.com/support
ASISTENCIA TÉCNICA DEL PRODUCTO 3SIXT
Visite www.3sixtgear.com/support
ASSISTENZA TECNICA 3SIXT
Si prega di visitare www.3sixtgear.com/support

Copyright © 2018.
3SIXT and its logo are trademarks of Cellnet Group Limited
in Australia & New Zealand. All Rights Reserved.
CELLNET GROUP LIMITED
59-61 Qantas Drive, Eagle Farm, QLD 4009 Australia.
MADE IN CHINA.
3SIXTgear.com

For more information, visit
www.3sixtgear.com
or visit www.3sixtgear.com/support
3SIXTgear
3S-0966
