A.O. Smith waterclinic LTS 75 Series User manual

Innovation has a name.
LTS 75 SERİSİ
SU ARITMA SİSTEMLERİ
KULLANIM KILAVUZU
LTS 75 SERIES
WATER TREATMENT SYSTEMS
USER MANUAL

Contents
General Information 06
What is REVERSE OSMOSIS? 06
Reverse osmosis practices 06
Ion Removal In Reverse Osmosis 07
Working Principle 07
Points to be Considered Before Installation of the Device 08
Water Flow Diagram 08
Box Contents And Assembly Parts 09
Device Properties 10
Electrical Diagram - LTS 75 SX 10
Manual Installation And Assembly 11
How to Assemble 11
RO Faucet Installation 11
Membrane Installation 12
Hose Connection Scheme 12
Start-Up After Installation 13
Maintenance and Cleaning 13
Maintenance 16
Troubleshooting Guide 17
Frequently Asked Questions 18
İçindekiler
Genel Bilgiler 22
Ters Osmoz (Reverse Osmosis) nedir? 22
 TersOsmoz(ReverseOsmosis)uygulamaları 22
TersOsmozSistemindeİyonGiderimi 23
ÇalışmaPrensibi 23
CihazKurulumuÖncesiDikkatEdilmesiGerekenNoktalar 24
ArıtmaCihazıAkışŞeması 24
KutuİçeriğiveMontajParçaları 23
SistemÖzellikleri 26
ElektrikŞeması 26
CihazKurulumuveMontajAşaması 27
 MontajAşamasındaYapılmasıGerekenler 27
 FiltrelerinYerleştirilmesi 28
 HortumBağlantıŞeması 28
 MontajSonrasıCihazınÇalıştırılması 29
CihazınBakım,OnarımveTemizliği 29
ArızaGidermeKılavuzu 33
SıkçaSorulanSorular 34
Garanti Belgesi 35
GarantiKapsamıveKoşulları 36

4

5
Dearcustomer,
Thankyouforpurchasinga“WaterclinicbyA.O.Smith”brandedwaterpurier!
Youarenowtheownerofwatertreatmentequipmentproducedbytheworld’sleading
manufacturer of water treatment systems. This equipment produces pure water that
canbeconsumeddirectly,providingyouwithacleanerandhealthiersourceofdrinking
water.
Please read this user manual carefully before you install and operate your “Waterclinic
byA.O.Smith”brandedwaterpurier.Toachievemaximumeciencythisusermanual
providesdetailedinstructionsregardingtheinstallationofyourwaterpurieraswellas
informationrelatedtotheproperoperationandmaintenanceofyourwaterpurier.
The installation should only be handled by professionals authorized by A. O. Smith Su
TeknolojileriA.Ş.
Spare parts used for maintenance and replacement lter should be approved by
A.O.SmithSuTeknolojileriA.Ş.beforetheyareinstalled.
Anydegradationofperformancecausedbytheuseofsparepartsorltersthathave
not been approved by A. O. Smith Su Teknolojileri A.Ş. will not be covered by our
warranty.
Ifyouexperienceanydicultiesduringinstallationoroperation,pleasecontactyour
local distributor to have them carry out repairs or maintenance on your equipment.

6
What is REVERSE OSMOSIS?
Osmosis is a process in which water passes through a semi-permeable membrane from a less
concentratedsolutionintoamoreconcentratedone.Innaturallyoccurringosmosisprocess,reverse
osmosis is achieved by pressurizing tohigher concentrated environment. Ifhigher concentrated
environmentispressurized,waterpassesthroughlowerconcentreatedoneSemi-permeablemembranes
used in reverse osmosis systems are in pore diameter of 8-12angstroms. Water molecules are smaller
than8-12angstromsandhaveaneutralelectriccharge.Forthisreason,watermoleculescaneasilypass
throughthemembranes.However,positivelyandnegativelychargedionsandmoleculesinthewater,
bacteria and viruses cannot pass through the membranes because they are bigger than 12 angstroms
andowtothedrainage.
Asasummary,reverseosmosisisthemostidealwatertreatmentmethodforionremovalbyadvanced
ltration.Reverseosmosismethodisoneoftherapidlyprogressingtechnologies.
Design of the reverse osmosis systemrequires various technical knowledge and experience such as
productwaterquality,rawwateranalysis,typeofmembraneetc.
Reverse osmosis practices
A. O. Smith water treatment device is designed to work with minimum water pressure. It does not require
chemical use and produces quality water. It is manufactured as a compact device that can easily be
installed anywhere thanks to minimum dimensions.
RO treatment device enhances taste andquality of your water. It decreases odor and sediment whilst
minimizingchlorineupto99%.Reverseosmosisdevicealsodecreasescontaminantssuchaslead,
copper,barium,chromium,mercury,sodium,cad-mium,uoride,nitrite,nitrateandseleniumwhichmay
be present in water.
Watertreatmentdeviceswillserveyouformanyyearseconomicallyandecientlyaslongastheyare
usedaccordingtotheinstallationandassemblyinstructionsandtechnicalspecicationsdescribedinthis
manual.
Thisdeviceshallonlybeusedinaccordancewiththedesignpurposeandtechnicalspecications
described in brochure and theusers manual. Maintenance and repair must be performed in accordance
with the instructions inthe users manual and original parts supplied byan authorized service must be used.
GENERALINFORMATION

7
STAGES OF CLEAN WATER PRODUCTION IN REVERSE OSMOSIS SYSTEM
Feed water pressure must be minimum 3 bar for reverse osmosis system to work. If the feed water pressure
isnotsucient,thesystemcanbereinforcedwithapump.feedwaterpassesthroughthefollowingltrations
respectively;
• 1stStage:5micronppsedimentlter.Thepre-sedimentlterretainssuspendedmaterialsandparticlesin
thewaterandprotectssuccessiveltrations,especiallythemembranelter.(1mm=1000micron).
• 2ndStage:Activatedcarbonlterremovespollutants,whichareharmfultohumanhealthandmembrane
lter,byretainingorganicsubstancesandhighamountsofcancerogenicchlorineandchlorinecompounds.
• 3rdstage:Blockcarbonlterisusedformoresensitiveparticleltrationtoretainthesuspendedmaterialsin
the water.
• 4thstage:Membranelter.Thesemi-permeablemembranewith8-12angstromporesretainsbacteria,
viruses and heavy metals in the water at 95-98% and pollutant runs to the drainage through wastewater part
of membrane.
• 5thstage:Lastcarbonlter(postcarbon).Waterrunsthroughthecarbonlteratthelaststagetoprovide
clean and extremely safe drinking water.
IONREMOVALINREVERSEOSMOSIS
WORKINGPRINCIPLE
ION AND ORG.
PESTICIDE REMOVAL ( % ) ION AND ORG. PES- TICIDE REMOVAL ( % )
Aluminum 97-98 Nickel 97-99
Ammonium 85-95 Nitrate 93-96
Arsenic 94-96 Phosphate 99+
Magnesium 96-98 Potassium 92
Bicarbonate 95-96 Radioactivity 95-98
Bromide 93-96 Radium 97
Cadmium 96-98 Selenium 97
Calcium 96-98 Silica 85-90
Chloride 94-95 Silver 95-97
Chromate 90-98 Sodium 92-98
Chromium 96-98 Sulfate 99+
Copper 97-99 Zinc 98-99
Cyanide 90-95 Boron 50-70
Fluoride 94-96 Borate 30-50
Iron 98-99 Mercury 96-98
Lead 96-98 Bacteria 99+
Mangan 96-98 Virus 99+

8
POINTSTOBECONSIDEREDBEFORE
INSTALLATIONOFTHEDEVICE
WATER FLOW DIAGRAM
A.O.Smithwatertreatmentsystem’soperatingwatertemperatureisbetweenminimum5˚C(41˚F)andmaximum
40˚C(104˚F).Ithasriskoffreezingtooperatethedevicebelow5˚Casitcarriesriskofdamagetolterswhen
operatedatabove40˚C.
ItisnecessarytoselectasuitablelocationrstforinstallationofA.O.Smithwatertreatmentdevice.Itmustbe
considered during selection that installation place should be close to cold water line of the RO device and to the
drainageandsucientspaceshouldbeleftforworkingincaseofmalfunctionandlterreplacement.
Watertreatmentdeviceisdesignedforwaterwithspecicationsclosetotapwater,whoseinletconductivity
ismax.600ppmandtheturbidityismax3NTU.Ifrawwatersourceandspecicationsareunknown,theraw
water should be sent for analysis before installation of the device in order to check the suitability.
“Ifthedeviceisusedbeyondthelimitvaluesmentionedintechnicalspecicationpartoftheusers’manual,
the requested quality will not be achieved for product water. Usage of such feed water will cause variation in
replacementperiodsofltersandmembrane.
Inlet pressure is between 3 - 6 bar for water treatment devices without pump and between 1 - 6 bar for water
treatment devices with pump. The optimum working pressure is 3 bar. In case the inlet pressure is above 4
bar,itisrecommendedtoinstallapressurereducertopreventmorewastewa-terdischarge.Donotconnect
the device to power socket before it is installed.Our company will not be liable for any problems caused by
nonobservance of the above warnings.
1. Sediment Filter
2. Granule Active Carbon Filter
3. Block Carbon Filter
4. R.O. Membrane (75 GPD)
5. Inline Post Carbon Filter
6. Inlet Raw Water
7. Pump (only for LTS 75 SX)
8. Waste Water
9. 2.2G Storage Tank
10. Pressure Reducer
11. Faucet
12. Low Pressure Switch
(only for LTS 75 SX)
13. High Pressure Switch
(only for LTS 75 SX)
7
8
10
6
12
13
11
4
9
WATER SUPPLY
WARNING:
ThisdiagramshowsLTS75SXwaterowwithpump.
LTS 75 LX model does not have pump.

9
BOXCONTENTSANDASSEMBLYPARTS
1. Reverse Osmosis Device
2. Faucet
3. 12” Inline Block Carbon Cartridge Filter (CTO)
4. 12” Gac Carbon Cartridge Filter (UDF)
5. 10” Inline Coconut Post Carbon Filter
6. 12” 5 Micron Spun (Sediment) Filter
7. 75 GPD Membrane
8. 2.2 Gallon Storage Tank
9. Metal Ball Valve 1/4”
10. 75 GPD Dynamic Pump
(available in LTS 75 SX)
11.24Volt1,5AmperAdapter
(available in LTS 75 SX)
12. Feed water connection part
13.Automaticshut-ovalve
14. Tube
15.UsersManualandWarrantyCerticate
TOOLSREQUIREDFORINSTALLATION
(not included in the box)
*Drillbits,steelordiamonddrillbitsset12and
13mmtipandherringboneles(rasp).Youmust
use the tools according to the installation place or
ground.
*Teontape.
* Wrench (frog key or required open mouth key set).
* A sharp knife or craft knife.
1
5
9
2
6
10
14 1513
11
12
3
7
4
8
LTS 75 LX (no pump)
LTS 75 SX (with pump)

10
DEVICE PROPERTIES
ELECTRICAL DIAGRAM - LTS 75 SX
Model Code 5006535 5006536
ModelName LTS 75 LX LTS 75 SX
Max. R.O. Membrane Capacity 75 GPD (280 Lt./day)
Storage Tank Capacity 2.2G (8.3 Lt)
Inlet Water Pressure 1-5 Bars 3-6 Bars
Inlet Water Temperature 5-38 °C
Voltage / Frequency Noelectricityrequired 230V AC 50 Hz
Total Power Noelectricityrequired 24 V DC
Dimensions (HxWxD) 405x280x420 mm
NetWeight(kg) 10 11
NOTE: Products without pressure reducer are not covered by the warranty.

11
MANUALINSTALLATIONANDASSEMBLY
HOW TO ASSEMBLE
1. Beforetheinstallation,turnothevalveofmainfeedwaterlineortheinlet
valve.
2. Afterdrainingtheremainingwaterinthepipes,installfeedwater
connectionadapter(3-wayadapter)byfasteningwithteonband
(Figure A- 2)
3. Install1/4’’metalballvalveonthefeedwaterconnectionadapter
(3-wayadapter)bymeansofteonbandsoastoturnon/oeasily(Figure
A –3).
4. Install6mmwaterinlettubetothe1/4“metalballvalve.Notethattheball
valve is closed.
5. Then,turnonthevalveofmainfeedwaterlineortheinletvalveandcheck
whether there is any leakage.
1. Incaseofdrillingcountertoporsink,faucetforcleanwatermustbe
installedcarefullyintermsofusageandaesthetics.Youcanstarttodrill
countertoporsinkafterleavingenoughspaceforinstallationofseal,nut
andunionatthebottomofcountertoporsink.Otherwise,youmaydrillthe
wrong place.
2. Ifyoudrillmarble,graniteceramic,laminateorsheetmetalsink,rstyou
shoulduse5mmdrillingbitandthen12mmdrillingbit,respectively.The
drill must be operated at low speed and without impact. If the counter is
coveredwithtile-coatedcastconcrete,itmustbedrilledwithadiamond
bit. (Figure A- 4)
3. Outerlengthofthefaucetis7cm.Ifthecounteristhickerthan7cm,
you’llneedtousettingsasmanyasrequired.Finally,placethefaucetinto
thehole,adjustitsjointsandtightenthenuts.
4. Filters should be washed before use to run out residues on them
(check washing procedures page).
RO FAUCET INSTALLATION
FIGURE A-2
FIGURE A-3
FIGURE A-4
FIGURE A-5
3-way adapter
3-way adapter
Closed
3/8 Ball Valve
Open
WATER INTAKE IN UNDER COUNTERDOUBLE BATTERY WATER INTAKE
3-way adapter
1/4 Ball Valve
NOTE: If you do not want to drill the under counter sink and washbasin, you can also install it by using a single faucet. Contact your
authorizedservice forreplacementofthefaucetadapter,which youhave used,withthe three-wayonethroughwhich hot,cold andpuried
water ow (Extra charge for the faucet) .
The images in the manual may not be identical to each other.
SINGLE BATTERY WATER INTAKE
3-way adapter
Extension
1/4 Ball Valve

12
MEMBRANE INSTALLATION
12” Inline 5 Micron Spun (Sediment) Filter
12” Inline Gac Carbon Cartridge Filter (UDF)
12” Inline Block Carbon Cartridge Filter (CTO)
75 GPD Membran
10” Inline Coconut Post Carbon Filter
• Afterintallingthelters,unscrewmembranehou
sing cap. Insert the membrane into the housing
 untilitstops.Then,screwthehousingcap.
• Cut the tube to a length that will allow to connect
 thepostcarbonlteroutlettothefaucetafter
mounting the faucet and drain line.
• Loosen and pull out stem-nut on outlet of
 thepostcarbonlter.Putthenutontubeand
 tightenrmly.Inserttheothersideofthetube
into respectively yellow nut and collet placed
under the faucet. Push the tube to the faucet
 andtightenthenutrmly.
Yellow nut
Ring
Hose
Faucet
embodiments
Hose
connection
HOSE CONNECTION SCHEME
Asshowningure;
A: Water inlet
B: Product water tube is connected to RO faucet.
C: The tube at the outlet of post carbon is
connected to product water line.
D: The drain tube is connected to wastewater
outowline.
RO FAUCET
WASTE
WATER
WATER INLET A
B
D

13
Once you have assembled and installed all the
components,turnonthewatersupplyrsttocheck
forleaks.Then,turnonthefaucetslowly.
Attherststage,waterwillrunfromthefaucet
slowly. Let it run in this way for 10 minutes. If
the waterstarts to drip and do not reach normal
owrate,itprobablymeansthatthewaterpressure
isso low that the device cannot perform with 100 %
eciency.Ifyouareexperiencingsuchaproblem,
see Troubleshooting on page 17.
Nowyourdeviceisreadyforusage,youcanenjoy
quality water safely.
START-UP AFTER INSTALLATION
!! IMPORTANT !!
*During the rst few days after installation,
airbubbles may be seen in the water.
*Water treatment device will work better andl longer
when it is used more often. For this reason, we
recommend you use the puried water for cooking,
preparing tea, coee etc.
*In case of water leaks, broken lters tc., turn o the
valve of water supply and correct the faults
REPLACEMENT PERIODS OF CARTRIDGE FILTERS
MAINTENANCEANDCLEANING
Spun (Sediment) Filter:
It should be replaced approximately every 6
months depending on the water contamination.
GAC Carbon Cartridge Filter (UDF):
If the water is clear and the total amount of chlorine is
low,thecartridgelifeis6monthsonaverage.
Block Carbon Cartridge Filtre (CTO):
The cartridge life is approximately 6 months
depending on the amount of chlorine in the water
andreplecamentperiodsofpre-lters.
Membrane Filter:
The membrane life is approximately 2 years
depending on the regular maintenance.
Coconut Post Carbon Filter:
The cartridge life is approximately 12 months.
Iffeedingtubeisdamaged,itshouldbereplacedwith
a specially prepared tube or tube set supplied by the
manufacturer or authorised service.

14
INSTALLATION AND REPLACEMENT OF MEMBRANE
1. Disconnect the plug from the socket.
2. Turnothewatersupplyvalve.
3. TurntheJacottingsclockwise.
4. Unscrewmembranehousing’scapbyturningit
clockwise.
5. Grasp the membrane with a clamp and pull out.
6. Push new membrane carefully into the housing until
it stops.
 Afterinstallingthemembrane,screwthecapand
reinsert the tube in the same way. Open RO tap to
cleanthenewlyinstalledmembranelter.Letthe
systemrunfor2hoursandthewaterrunout.Then,
youcandrinkthepuriedwater.
Do not forget to connect the power plug to the
socket in models with pump.
You’rekindlyrequestedtofollowwashingprocedure
written below for operating your system at the
highest performance.
1. Shutothetankvalveandturnonthepuried
water faucet. Insert the plug in the socket and
turnontheballvalve(page4,partnumber9).
The wastewater should be drained throughout a
wastewater pipeline (it is proper to install to the
drain pipe of the sink).
2. Sediment Filter and Activated Carbon Filter (1st
and2ndlter)arewashedtogether.Thefoulwater
should be drained out before reaching Block
Carbon(3rdlter).Onceclearwaterisobtained,
Block Carbon (3rd Filter) is washed with the water
comingthrough1stand2ndltersandblackwater
coming through block carbon should be drained
out(4thand5th,and6thlterifavailableshould
notbefedwiththiswater).BlockCarbon(3rdlter)
is washed for 10 minutes.
3. PostCarbon(5thlter)iswashedwiththewater
comingthroughtherstthreelters[before
installationofmembrane(4thlter)]andthe
water should be drained out. Once clear water is
obtained,mineralofpHlter(6thlter),ifavailable,
is washed and this process is repeated until clear
water gets.
4. Themembrane(4thlter)isinsertedinto
membrane housing in a way that the gaskets will
be underneath (These gaskets should be placed in
by getting wet and turning rightward) and the cap
of housing is closed. The membrane is fed with
water. This water should be drained out before
reachingtank,postcarbonandminerallterif
available. Until 8 litres of water is obtained from
themembrane,thewatershouldbedrainedout
directly (It takes around 45 minutes).
5. Turnontankvalveandshutothecleanwater
faucet.Thepuriedwatershouldllinthetank
anditwilltake45minutes.Attheendof45min.,
thetankshouldbelledandthewatershouldbe
drainedonceatleastbyturningonpuriedwater
faucet.
6. Youcandrinksafeandcleanwaterattheendof
these processes.
FLUSHING PROCEDURES

15
MAINTENANCE AND CLEANING
Membrane replacement and housing sanitisation as
seeningures;
Open drinking water faucet.
Loose the union of the membrane housing on the
water inlet side and disconnect tubing from the
housing.
Unscrew the membrane housing from the cap
(with pliers) and displace the used membrane.-
Clean the membrane housing with disinfectant
(bleach solution) and rinse the housing.Wet or wipe
the O-ring at the bottom of thenew membrane
element for being seated properly. Push the
membraneintothehousingwitho-ringsiderst.
Ensurethemembranetintothehousingproperly.
Screw the cap back onto the membrane housing
and tighten with hand or the supplied wrench.
Finally,placetheunionatthewaterinletsideofthe
membraneproperlyandtightenrmly.
Do not forget to connect the power plug to the socket in models
with pump.
The treatment device must not be supplied with hot water.
Otherwise, all lters will be damaged and the device will be out
of warranty.
The water rst-supplied to the device should be discharged
after passing through the lters. It should denitely not con-
tact the tank and post carbon
!! ATTENTION !!
Turnothewatersupplyandopendrinkingwater
faucet.
Loose tubing unions at inlet and outlet and discard
the used post-carbon.
Disconnect the union placed at the outlet of the
lter. To prevent leaks, apply teon tape to the
T-connectoronwatersupplyandinstallthelter.
Tighten the tube unions.
REPLACEMENT OF POST CARBON FILTER
Water Treatment Device is designed for easy
installation and maintenance. It is essential not to
exceed the recommended replacement periods
ofcartridgeltersandtousethedeviceproperly.
When the required maintenance and repair is not
provided,thelifespanofthedeviceisshortenedand
theeciencyofthemembranesisreduced.Such
situationsmaycausecerticateofwarrantytobe
void.
SANITISING DEVICE
The water treatment device should be disinfected at
least once a year as follows;
Turnothewatersupply.
Drain all of the water from the tank by opening the
faucet (for the models with tanks).
Addateaspoonofchlorinetothelterhousing
and screw back onto the cap.
Turn on the water supply.
Repeat this process for 2 times and replace all
cartridgelters(forthemodelswithtanks).
WARNING: FLOW marking on the lter shows thedirection of
the water outlet. Ensure not to insert it backwards and do not
over-tighten T-connector and the union on the other side.
Water outlet direction Water inlet direction
T Connector

16
MAINTENANCE
Maintenanceofyourltersrequiresverylittletimeoreortbutitisessential.Regularmaintenancewillensure
manyyearsofecientandtroublefreeoperation.
Standard Care
Toretaintheattractiveappearanceofyournewwaterlter,cleanoccasionallywithamildsoapsolution.DONOT
useabrasivecleaners,ammoniaorsolvents.Neversubjectyourltertofreezing
Theltermediawillonlyrequirereplacementonceithasreachedthelimitsofitsdesignatedlife.Referto
theproductinformationoftheparticularltermediaused.
WARNING:
Disconnect all electrical power prior to performing system maintenance.
START-UP AFTER MAINTENANCE
TRANSPORTATION AND HANDLING
Atrst,followtheoccupationalsafetyrules.
Drain the water in the tank before transportation
and handling.
Close the water supply of the tank and if the
devicemodeliswithpump,disconnecttheplug
from the socket carefully.
Demount the device carefully.
Do not leave your device hanging from a higher
place.
Pay attention to keep the parts in the same place
to avoid losing them.
Keepthedeviceinadryandclosedplace.
Payattentionnottodrop,break,shake,crushthe
device during transportation and handling. Ensure
thatitdoesnotgetdamagedduetoheat,humidity
ordust.Keepitoutofsunexposure.
Youcangetsupportfromourauthorized
services to avoid unexpected damages during
transportation and handling.
Supply of Spare Parts Under/Out of Warranty:
Warranty period is 2 (two) years from the date of your
invoice.Youcansupplysparepartsofthisproduct
for 10 (ten) years from the delivery date. The warranty
is applicable only to defects in the device and we
arenotresponsibleforanyothercost.Noclaimof
indemnity can be made under any other name.
Turn on the mini valve
of the water supply as
showninthegure.
Afterturningonthevalves,turnonthewatersupply.
Open RO faucet and check the entire system for
leaks.
Nowyoucanenjoythequalitywatersafely.
PRECAUTIONS TO USE YOUR DEVICE LONGER;
To ensure that your device functions properly and to
prolongthelifeofthedevice,thefollowingpointsmust
betakenintoconsideration.Otherwise,thewarranty
will be voided.
Do not use with water that has temperature above
40˚C.
Placeorxthedeviceonaatsurface.
Do not touch the valves on the device except
when necessary.
It is recommended to install pressure reducer on
water inlet of RO device when installation pressure
is high. -Ensure that periodical maintenance is
performed on time and by the authorized service.
Incaseoflongperiodsofnon-use,turnowater
supply. Follow start-up procedure when you want
to re-operate.
Keepyourdevicecleanbywipingwithawetcloth
periodically and avoid using harsh and corrosive
cleaners.

17
Troubleshooting Guide
FAILURE EXPERIENCED REASON RESOLUTION METHOD
•The power source is not connected
•Low inlet water pressure or no water
•Low-pressure switch failure, cannot connect the power
source
•High-pressure switch cannot be restored
•Switch Mode Power Supply is burned out
•High-pressure pump has lost pressure
•Inlet water solenoid valve is faulty, no water can get in
(no pure water)
• A pre-lter is blocked
• Check valve is blocked (waste water, no pure water)
•The RO Membrane is plugged
• Check valve has lost pressure
•High-pressure switch failure
•System is exhibiting a loss of pressure
• Pre-lter is plugged
•RO membrane is plugged
•Inlet solenoid valve failure
• Check valve is plugged
• Post-carbon lter is plugged
•High pressure pump pressure is not enough
• Storage tank doesn’t have enough pressure
• Post-activated carbon lter is plugged
•Inlet solenoid valve failed, cannot effectively
cut off the water supply
• Check valve has lost pressure (small W.W. ow rate)
• Check the power source or the power source plug
• Check the inlet water pressure
• After connecting the inlet water, measure the
resistance, replace
• After letting off the pressure, measure the resistance,
replace
• Measure the output voltage, replace
• Replace the pre-lter
• Wash or replace the RO membrane
•Replace the inlet solenoid valve
• Replace the check valve
• Replace the post-carbon lter
•Measure the high pressure pump water pressure,
replace
•Measure the water pump pressure, replace
•Replace the solenoid valve
•Observe the pure water and waste water,
replace the pre-lter
• Replace the check valve
•Clean or replace the RO membrane
• Replace the check valve
•Replace the high pressure switch
• After checking the non return valve, check whether
there is water leakage in the pipelines
• Inate the storage bucket, empty tank pressure
should be between 0.05 and 0.07MPa
• Replace the post-activated carbon lter
•Observe the waste water, replace the inlet solenoid
valve
• Observe the waste water, replace the check valve
The machine will not
start
The high pressure pump
is working properly,
but no water is being
produced
The storage tank is full
but no pure
water is owing out
The machine is turned off
but waste water has not
stopped
After the machine is
lled with water, the
machine starts repeatedly
The pure water ow is
small or not owing

18
FREQUENTLYASKEDQUESTIONS
“How often should lters be replaced?”
Itdependsonproperties,qualityofwater supplyandusagefrequencyofthesystem. It isrecommendedto
replacelterseverysixmonths.Werecommendthatyoureplacepostcarbonltercartridgeonceayearand
membrane every three years.
“I have replaced the cartridges newly and the water is cloudy. Is it normal?”
Afteryouhavereplacedthelters,youshoulddrainthewaterforafewminutes.Becausecarbonltersaremade
ofnaturalmaterials,cloudyblackwatermayowforawhile(10-15minutes),Keepyourfaucetopenandturno
the tank valve. Allow the water to run out until the water is clear.
“I do not often use the system, does it change life span of lters and membrane?”
Replacementdatesoftherstthreeltersdonotchange;livingorganisms(microbes,bacteria)aresettledinthe
ltersduringltration.Therefore,rstcontactwithwaterisdeemedasbeginningofreplacementperiod.Less
usageofthesystemaectsonlyreplacementperiodofmembrane.
“Can I assemble the device and replace ltersmyself ?”
Yes,youcan.However,anyotherpractisenotperformedbyaserviceproviderwillcausethewarrantytobe
voided.Iftheserviceisprovidedbyanauthorisedpersonnel,thedevicewillcontinuetobeunderwarrantytillthe
expiration date of warranty.

19

20
