Aaeon IMBM-H81B User manual

Industrial Motherboard
IMBM-H81B

ii
E12033
First Edition
September 2016
Copyright Notice
This document is copyrighted, 2016. All rights are reserved. The original
manufacturer reserves the right to make improvements to the products described
in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or transmitted
in any form or by any means without the prior written permission of the original
manufacturer. Information provided in this manual is intended to be accurate and
reliable. However, the original manufacturer assumes no responsibility for its use,
or for any infringements upon the rights of third parties that may result from its use.
The material in this document is for product information only and is subject to
change without notice. While reasonable efforts have been made in the preparation
of this document to assure its accuracy, the original manufacturer assumes no
liabilities resulting from errors or omissions in this document, or from the use of the
information contained herein.
The original manufacturer reserves the right to make changes in the product
design without notice to its users.
Acknowledgments
All other products’ name or trademarks are properties of their respective owners.
• AMI is a trademark of American Megatrends Inc.
• Intel®, Core™ are trademarks of Intel® Corporation.
• Microsoft Windows®is a registered trademark of Microsoft Corp.
• IBM, PC/AT, PS/2, and VGA are trademarks of International Business
Machines Corporation.
The original manufacturer reserves the right to make changes in the product
design without notice to its users.
All other product names or trademarks are properties of their respective owners.

iii
Contents
Chapter 1 Product overview 1-1
1.1 Package contents......................................................................... 1-1
1.2 Features ........................................................................................ 1-1
1.3 Specifications............................................................................... 1-2
Chapter 2 Motherboard information 2-1
2.1 Before you proceed ..................................................................... 2-1
2.2 Motherboard layout...................................................................... 2-2
2.3 Screw size..................................................................................... 2-4
2.3.1 Component side.............................................................. 2-4
2.3.2 Solder side ...................................................................... 2-5
2.4 Central Processing Unit (CPU) ................................................... 2-6
2.4.1 Installing the CPU ........................................................... 2-7
2.4.2 CPU heatsink and fan assembly installation................... 2-9
2.5 System memory ......................................................................... 2-11
2.5.1 Installing a DIMM .......................................................... 2-12
2.6 Jumpers ...................................................................................... 2-13
2.7 Onboard LEDs ............................................................................ 2-15
2.8 Connectors ................................................................................. 2-16
2.8.1 Rear panel connectors.................................................. 2-16
2.8.2 Internal connectors ....................................................... 2-18
Chapter 3 BIOS setup 3-1
3.1 BIOS setup program .................................................................... 3-1
3.1.1 BIOS menu screen.......................................................... 3-2
3.1.2 Menu bar......................................................................... 3-2
3.2 Main menu .................................................................................... 3-2
3.2.1 System Date [Day MM/DD/YYYY] .................................. 3-2
3.2.2 System Time [HH:MM:SS] .............................................. 3-2
3.3 Advanced menu ........................................................................... 3-3
3.3.1 ACPI Settings.................................................................. 3-3
3.3.2 CPUConguration .......................................................... 3-3
3.3.3 Dynamic Digital IO .......................................................... 3-4
3.3.4 Watch Dog Timer Setting................................................ 3-4
3.3.5 SATAConguration ........................................................ 3-4

iv
3.3.6 PCH-FWConguration ................................................... 3-5
3.3.7 USBConguration .......................................................... 3-5
3.3.8 F81216SecondSuperIOConguration......................... 3-6
3.3.9 F81866SuperIOConguration ...................................... 3-6
3.3.10 H/W Monitor .................................................................... 3-7
3.3.11 S5 RTC Wake Settings ................................................. 3-10
3.4 Chipset menu ............................................................................. 3-11
3.4.1 PCH-IOConguration ................................................... 3-11
3.4.2 SystemAgent(SA)Conguration ................................. 3-12
3.5 Boot menu .................................................................................. 3-12
3.5.1 BootConguration ........................................................ 3-12
3.5.2 Boot Option Priorities .................................................... 3-12
3.6 Security menu ............................................................................ 3-13
3.6.1 Administrator Password ................................................ 3-13
3.6.2 User Password.............................................................. 3-13
3.7 Save & Exit menu....................................................................... 3-14
Appendix A-1
Notices.......................................................................................................A-1

1-1
Chapter 1: General information
1.1 Package contents
Check your industrial motherboard package for the following items.
1 x Industrial Motherboard 1 x SATA 6.0 Gb/s cable (2 in 1 pack)
1 x I/O Shield 1 x Support DVD
If any of the above items is damaged or missing, contact your distributor or
sales representative immediately.
1.2 Features
• Intel®Socket 1150 for 4th Generation Core™ i7 / Core™ i5 / Core™ i3,
Pentium®, CeleronTM 22nm LGA 1150 socket Processor
• Two DIMMs support 288-pin Dual Channel DDR3 1333/1600MHz Non-ECC,
Un-buffered memory up to 16GB
• 2 x Realtek PCIe Gb LAN 8111G, RJ45 x 2
• 2 x SATA 6.0 Gb/s ports (7P, 180 degree connecotor)
• 1 x PCIe 3.0 [x16] Slot, 2 x PCIe 2.0 [x1] Slots
Chapter 1
Product overview

IMBM-H81B
1-2
1.3 Specifications
SYSTEM
Form factor
micro ATX
CPU
Intel® 4th Generation Core™ i7/i5/i3, Pentium®/Celeron™ 22nm
LGA 1150 socket Processor
Supports Intel®22nm CPU
Memory
2 x DIMMs, DDR3 1333/1600 MHz, Max. 16GB
non-ECC, un-buffered memory
Dual-channel memory architecture
Chipset
Intel®H81 Express Chipset
I/O Chipset
Fintek F81866D (RS 232 COM1~6 & others)
Fintek F81216HD (RS232-COM7~10)
Ethernet
2 x Realtek PCIe Gb LAN 8111G, RJ45 x 2
BIOS
1 x 64Mbit Flash ROM, AMI BIOS
Wake on LAN
Yes (WOL/PXE)
Watchdog Timer
1~255 steps by software program
TPM
Yes
H/W Status Monitor
Monitors CPU/Chassis temperature
Monitors Vcore/5V/3.3V/12V voltages
Monitors CPU/Chassis fan speed
Smart Fan Control
CPU Fan / Chassis Fan (3.3V colay 5V)
Power State
S3, S4, S5
Expansion slot
1 x PCIe 3.0 [x16] slot
2 x PCIe 2.0 [x1] slots
Battery
Lithium battery
Power requirement
1 x 24-pin ATX connector
1 x 4-pin (2 x 2) ATX 12V power connector
Form factor
Micro-ATX Form Factor, 9.6”x9.6” (244mmx244mm)
Gross weight
1.76 lb (0.8 Kg)
Operating
temperature
32oF~140oF (0oC~60oC)
Storage temperature
-40oF~185oF (-40oC~85oC)
Operating humidity
0%~90% relative humidity, non-condensing
Certificate
CE/FCC
(continued on the next page)

1-3
Chapter 1: General information
DISPLAY
Chipset
Intel®Graphics Media Accelerator
Resolution
Up to 1920 x 1200 @60Hz for VGA
Up to 1920 x 1200 @60Hz for DVI-D
Output interface
VGA+DVI-D, VGA+VGA
I/O
Storage
2 x SATA 6.0 Gb/s ports (7P, 180 degree connector)
2 x SATA 3.0 Gb/s ports (7P, 180 degree connector)
Serial port
1 x RS-232/422/485 (COM1, supports 5V/12V/RI optional)
1 x RS-232 header (COM2)
2 x RS-232 header (COM3~6, COM7~10)
USB
6 x USB 3.0/2.0 ports, (4 port via ASM1042A, 2 port via H81)
8 x USB 2.0 ports (Via H81)
Fan
1 x CPU Fan connector(s) (4-pin)
2 x Chassis Fan connectors (4-pin)
RTC
Internal RTC
Keyboard/Mouse
1 x PS/2 Keyboard / mouse combo connector
Audio
Realtek ALC887, Mic-in/Line-in/Line-out
Ethernet
2 x RJ-45 ports
Display
1 x DVI-I
1 x VGA
Others
1 x Front panel header
1 x Clear CMOS jumper

IMBM-H81B
1-4

2-1
Chapter 2: Motherboard information
Chapter 2
Motherboard information
2.1 Before you proceed
Take note of the following precautions before you install motherboard components
or change any motherboard settings.
CAUTION!
• Unplugthepowercordfromthewallsocketbeforetouchingany
component.
• Beforehandlingcomponents,useagroundedwriststraportouchasafely
groundedobjectorametalobject,suchasthepowersupplycase,toavoid
damaging them due to static electricity.
• HoldcomponentsbytheedgestoavoidtouchingtheICsonthem.
• Wheneveryouuninstallanycomponent,placeitonagroundedantistatic
pad or in the bag that came with the component.
• Beforeyouinstallorremoveanycomponent,ensurethattheATXpower
supply is switched off or the power cord is detached from the power
supply.Failuretodosomaycauseseveredamagetothemotherboard,
peripherals,orcomponents.

IMBM-H81B
2-2
IMBM-H81B
PCIEX16_1
DIO1
AAFP1
PCIEX1_1
PCIEX1_2
EATX_PWR1
CPU_FAN
CHA_FAN2
CHA_FAN1 BATTERY
Super
I/O
Super
I/O
LAN
8111G
LAN
8111G
RTD
2168
ASM
1442K
ASM
1042A
ASM
1042A
BZ1
ALC
887
ATMODE
CLRTC
DIS_ME
CHASSIS
24.4cm(9.6in)
24.4cm(9.6in)
Intel®
H81
DDR3 DIMM_A1 (64bit, 240-pin module) DDR3 DIMM_A2 (64bit, 240-pin module)
SATA6G_2 SATA3G_4 SATA6G_1 SATA3G_3
AUDIO
LAN1_USB2_12
LAN2_USB2_34
SPI_1
DVI
VGA
USB3_3456
USB2_5678
KBMS
_USB3
_12
LGA1150
F_PANEL
COM2 COM1
COM1_VSETCOM2_VSET
COM3456COM78910
EATX_PWR2
21 13 4 2
14 131516
17
5
12
10
11
8
9
6
7
1
18
2.2 Motherboard layout
Place this side
towards the rear
of the chassis
NOTE: Place eight screws into the holes indicated by circles to secure the
motherboard to the chassis.
CAUTION!Donotovertightenthescrews!Doingsocandamagethe
motherboard.

2-3
Chapter 2: Motherboard information
Connectors/Jumpers/LEDs Page
1. CPUandsystemfanconnectors(4-pinCPU_FAN1,4-pinCHA_FAN1~2)
2. ATXpowerconnectors(24-pinEATXPWR1,4-pinEATX_PWR2)
3. Intel® LGA1150CPUsocket
4. DIMMmemoryslots
5. AT/ATXmodejumper(3-pinATMODE)
6. Chassisintrusionconnector(4-1pinCHASSIS)
7. Systempanelconnector(10-pinF_PANEL)
8. Intel®MEJumper(3-pinDIS_ME)
9. ClearRTCRAM(CLRTC)
10. BIOSprogrammableconnector(8-pinSPI_1)
11. COM1/2Ring/+5V/+12Vselection(COM1/2_Vset)
12. SerialATA3.0Gb/sconnectors(7-pinSATA3G_3~4)
13. SerialATA6.0Gb/sconnectors(7-pinSATA6G_1~2)
14. Serialportconnectors(10-1pinCOM1~10)
15. DigitalI/Oconnector(10-pinDIO1)
16. Frontpanelaudioconnector(10-1pinAAFP)

IMBM-H81B
2-4
2.3 Screw size
2.3.1 Component side
243.84
243.84
12.39 26.24 48.42 66.42 84.42
110.42
35.81
132.42 147.92 150.62
11.62
161.01 201.65 221.97 241.66 240.52 240.28
83.03 4.70 21.49 78.73 95.63 110.24 124.46 141.99 152.53 176.40 195.96 211.22 203.31 228.24 220.33 228.73 240.28
0.00
132.42
8.50
18.74
10.49
11.84
14.56
7.06
19.50
31.69
45.45
47.88
107.19
120.69
94.23
170.82
181.23
185.67
195.45
203.45
217.83
238.48
235.08
237.62
59.94
51.18
69.43
125.54
138.56
176.98
187.65
230.80
236.35
237.62
0.00
236.35
35.52
21.92 51.92 69.92 87.92
106.92 128.92 147.92 243.84
0.00
35.52

2-5
Chapter 2: Motherboard information
2.3.2 Solder side
243.84
243.84
6.35
163.83 209.55
46.14 57.22
121.15
57.22 46.14 6.35 163.83 229.87 121.15 118.24 174.34 217.58
33.02
88.04
107.54
125.54
143.54
163.04
165.10
237.49
10.16
155.57
165.10
186.06
237.49
0.00
0.00

IMBM-H81B
2-6
IMPORTANT:UnplugallpowercablesbeforeinstallingtheCPU.
CAUTION!
• Uponpurchaseofthemotherboard,ensurethatthePnPcapison
thesocketandthesocketcontactsarenotbent.Contactyourretailer
immediatelyifthePnPcapismissing,orifyouseeanydamagetothe
PnPcap/socketcontacts/motherboardcomponents.Themanufacturerwill
shoulderthecostofrepaironlyifthedamageisshipment/transit-related.
• Keepthecapafterinstallingthemotherboard.Themanufacturerwill
processReturnMerchandiseAuthorization(RMA)requestsonlyifthe
motherboardcomeswiththecapontheLGA1150socket.
• Theproductwarrantydoesnotcoverdamagetothesocketcontacts
resultingfromincorrectCPUinstallation/removal,ormisplacement/loss/
incorrectremovalofthePnPcap.
2.4 Central Processing Unit (CPU)
ThemotherboardcomeswithasurfacemountLGA1150socketdesignedforthe
Intel®4thGenerationCore™i7/Core™i5/Core™i3,Pentium®andCeleron®
22nm processors.
IMBM-H81B
IMBM-H81B CPU socket LGA1150

2-7
Chapter 2: Motherboard information
2.4.1 Installing the CPU
1
A
B
2 3
CAUTION! EnsurethatyouinstallthecorrectCPUdesignedforLGA1150
only.DONOTinstallaCPUdesignedforLGA1155andLGA1156socketson
theLGA1150socket.

IMBM-H81B
2-8
A
B
C
4
5

2-9
Chapter 2: Motherboard information
2.4.2 CPU heatsink and fan assembly installation
CAUTION!ApplytheThermal
InterfaceMaterialtotheCPU
heatsinkandCPUbeforeyou
install the heatsink and fan if
necessary.
To install the CPU heatsink and fan assembly
B
A
A
B
1
2
3 4

IMBM-H81B
2-10
A
B
B
A
To uninstall the CPU heatsink and fan assembly
2
1

2-11
Chapter 2: Motherboard information
2.5 System memory
ThismotherboardcomeswithtwoDoubleDataRate3(DDR3)DualInlineMemoryModule
(DIMM)sockets.ADDR3modulehasthesamephysicaldimensionsasaDDR2DIMMbut
isnotcheddifferentlytopreventinstallationonaDDR2DIMMsocket.DDR3modulesare
developedforbetterperformancewithlesspowerconsumption.
AccordingtoIntel®CPUspec,DIMMvoltagebelow1.2Visrecommendedtoprotectthe
CPU.
IMBM-H81B
IMBM-H81B 240-pin DDR3 DIMM sockets
DIMM_A1 DIMM_B1

IMBM-H81B
2-12
2.5.1 Installing a DIMM
To remove a DIMM
A
B
1
2
3
