Aaeon SBC-676 User manual

SBC-676
Pentium / Celeron CPU Card with Rage
Mobility VGA interface, Dual LAN, Dual
USB & SSD

Copyright Notice
This document is copyrighted, 2001. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, nor for
any infringements upon the rights of third parties which may result
from its use.
Acknowledgements
AMD is a trademark of Advanced Micro Devices, Inc.
AMI is a trademark of American Megatrends, Inc.
Award is a trademark of Award Software International, Inc.
CyrixisatrademarkofCyrixCorporation.
IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
Intel and Pentium II are trademarks of Intel Corporation.
Microsoft Windows® is a registered trademark of Microsoft Corp.
SMC is a trademark of Standard Microsystems Corporation.
RTLis a trademark of Realtek Semi-ConductorCo.,Ltd.
C&T is a trademark of Chips and Technologies, Inc.
UMC is a trademark of United Microelectronics Corporation.
ITE is a trademark of Integrated Technology Express, Inc.
SiS is a trademark of Silicon Integrated Systems Corp.
VIA is a trademark of VIA Technology, Inc.
All other product names or trademarks are properties of their
respective owners.
PartNo. 2047676000 SBC-676 2nd Edition
Printed in Taiwan Dec, 2001

A Message to the Customer
AAEON Customer Services
Each and every AAEON product is built to the most exacting
specifications to ensure reliable performance in the harsh and
demanding conditions typical of industrial environments. Whether
your new AAEON equipment is destined for the laboratory or the
factory floor, you can be assured that your product will provide the
reliability and ease of operation for which the name AAEON has
come to be known.
Your satisfaction is our primary concern. Here is a guide to
AAEON's customer services. To ensure you get the full benefit of
our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products.
So if you run into technical difficulties, we are here to help. For the
most frequently asked questions, you can easily find answers in
your product documentation. These answers are normally a lot
more detailed than the ones we can give over the phone.
So please consult this manual first. If you still cannot find the
answer, gather all the information or questions that apply to your
problem, and with the product close at hand, call your dealer. Our
dealers are well trained and ready to give you the support you need
to get the most from your AAEON products. In fact, most problems
reported are minor and are able to be easily solved over the phone.
In addition, free technical support is available from AAEON
engineers every business day. We are always ready to give advice
on application requirements or specific information on the installa-
tion and operation of any of our products.

Product Warranty
AAEON warrants to you, the original purchaser, that each of its
products will be free from defects in materials and workmanship for
one year from the date of purchase.
This warranty does not apply to any products which have been
repaired or altered by persons other than repair personnel autho-
rized by AAEON, or which have been subject to misuse, abuse,
accident or improper installation. AAEON assumes no liability
under the terms of this warranty as a consequence of such events.
Because of AAEON's high quality-control standards and rigorous
testing, most of our customers never need to use our repair service.
If an AAEON product is defective, it will be repaired or replaced at
no charge during the warranty period. For out-of-warranty repairs,
you will be billed according to the cost of replacement materials,
service time, and freight. Please consult your dealer for more
details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For
example, CPU type and speed, AAEON products used, other
hardware and software used, etc.) Note anything abnormal and
list any on-screen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your
manual, product, and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA
(return material authorization) number from your dealer. This
allows us to process your return more quickly.
4. Carefully pack the defective product, a fully-completed Repair
and Replacement Order Card and a photocopy proof of pur-
chase date (such as your sales receipt) in a shippable container.
A product returned without proof of the purchase date is not
eligible for warranty service.
5. Write the RMA number visibly on the outside of the package
and ship it prepaid to your dealer.

Packing list
Before you begin installing your card, please make sure that the
following materials have been shipped:
• 1SBC-676All-in-OneSingleBoardComputer
• 1Quick Installation Guide
• 1 Supporting CD-ROM contains the followings:
-- User's Manual (this manual in PDF file)
-- Drivers and utilities
--VGA drivers and utilities
--BIOSfiles
• 1Hard disk drive(IDE) interface cable
• 1 Floppy disk drive interface cable
• 1 6-pin mini-DIN dual outlet adapter for keyboard and PS/2
mouse
• 1 mounting bracket contains 1 Parallel port adapter (26 pins) and
COM2adapter(forRS-232/422/485)
If any of these items are missing or damaged, contact your distribu-
tor or sales representative immediately.

http://www.aaeon.com
Notice
DearCustomer,
Thank you for purchasing the SBC-676 board. This user's
manual is designed to help you to get the most out of the
SBC-676, please read it thoroughly before you install and use the
board. The product that you have purchased comes with a two-
year limited warranty, but AAEON will not be responsible for
misuse of the product. Therefore, we strongly urge you to first
read the manual before using the product.
To receive the lastest version of the user manual, please visit our
Web site at:

Contents
Chapter 1: General Information.........................................1
Introduction ........................................................................... 2
Features.................................................................................. 3
Specifications ......................................................................... 4
Chapter 2: Installation ......................................................7
Safety precautions.............................................................8
Removing CPU.................................................................8
Installing CPU...................................................................9
Installing DRAM............................................................10
Jumpers and connectors.................................................... 11
Locating connectors ........................................................... 12
Board layout....................................................................13
Board dimensions...........................................................14
LVDS panel voltage setting (J1).....................................15
CPU frequency ratio select (J4).....................................16
Clear CMOS (J5)............................................................16
COM2 RS-232/422/485 Select (J7, J8)..........................17
DOC address select (J9)................................................18
Buzzer setting (JP1).......................................................18
Power Connector(PWR1,CN17 ).......................................19
Power LED and keylock (CN1)......................................20
IDE hard drive connector (CN2, CN8)..........................21
Floppy drive connector (CN3)........................................23
USB connector (CN6).....................................................24
Parallel port connector (CN9)........................................25
IrDA connector (CN11)..................................................26
Display Connector(CN21)......................................27
Serial ports (CN14, CN16).............................................28
Keyboard & PS/2 mouse connector (CN15, CN18, CN23)..29
ATX power connector (CN20).......................................30

Front panel (CN24).......................................................30
LVDS connector channel 1 (CN27)............................31
LVDS connector channel 2 (CN29)..............................32
DiskOnChip socket (U16)..........................................33
DiskOnChip 2000 installation.........................................34
Chapter 3: Award BIOS Setup..................................... 35
Starting setup....................................................................... 36
Setup keys............................................................................ 37
Getting help ......................................................................... 38
In case of problem...................................................................38
Main setup menu ................................................................ 39
Standard CMOS setup ....................................................... 41
Advanced BIOS features ................................................... 46
Advanced chipset features ............................................51
Integrated Peripherals..........................................55
Power management setup.................................................. 60
PNP/PCI congfiguration setup .......................................... 64
PC health status.............................................................66
Frequency/Voltage control..............................................67
Load fail-safe defaults......................................................... 68
Load optimized defaults ..................................................... 69
Set supervisor password.................................................... 70
Set user password ............................................................... 71
Save to CMOS and exit...................................................... 72
Exit without saving.........................................................73

Notice .............................................................................75
Software Drivers.................................................................. 76
VGA Driver .......................................................................... 77
Ethernet Driver.........................................................78
Chapter 4: Software Driver Installation ..................... 74
Appendix A: Watch Dog Timer .........................................81

Chapter 1 General Information 1
1
GeneralGeneral
GeneralGeneral
General
InformationInformation
InformationInformation
Information
This chapter gives background
informationon SBC 676.
Sections include:
• Board specifications
• Layout and dimensions
CHAPTER

2SBC-676 User Manual
IntroductionIntroduction
IntroductionIntroduction
Introduction
The SBC-676 is an all-in-one Celeron and Pentium III processor
based single board computer (SBC) with a ATI Rage Mobility Flat
Panel controller. When using an Intel Celeron processor, the SBC-
676 achieves outstanding performance that surpasses any other
SBCinits class. Dual Intel 82559GD 10/100 Base-TEthernet
controller ensures quality throughput and connectivity. In
addition, the onboard SSD interface supports M-systems DiskOn-
Chip2000 series, memory capacity from 2MB to 288 MB.
Onboard features include two serial ports (one RS-232, one RS-232/
422/485),onemulti-modeparallel(ECP/EPP/SPP)port,connectorfor
two USB (Universal Serial Bus) ports, a floppy drive controller, and
a keyboard/PS/2 mouse interface. The built-in high speed PCI IDE
controller supports Ultra DMA/33 mode. Up to four IDE devices
can be connected, including large hard disks, CD-ROM drives, and
tape backup drives, etc.
TheSBC-676 also features powermanagement to minimize power
consumption. It complies with the APM standard and supports
three types of power saving features: Doze mode, Standby mode,
and Suspend mode. In addition, the board's watchdog timer can be
programmed to reset the system or generate an interrupt in case the
system stops due to a program bug or EMI.
Highly integrated SBC
The SBC-676 is a highly integrated SBC that combines video and
network functions on a single computer board. It provides up to
8MB SDRAM display memory. Major onboard devices adopt PCI
technology to achieve outstanding computing performance when
used with Intel Celeron level processors, making the SBC-676 one
of the world's best and most powerful all-in-one Single Board
Computers.

Chapter 1 General Information 3
FeaturesFeatures
FeaturesFeatures
Features
• Supports Intel Celeron up to 766 MHz and Pentium III CPUs up to
850MHz
• Supports DiskOnChip (SSD) up to 288MB
• ATI Rage Mobility Flat Panel Interface
• Supports H/W status monitoring
• Dual Ethernet Intel 82559GD 10/100Base-TFast Ethernet
• Supports AT/ATX power connector

4SBC-676 User Manual
SpecificationsSpecifications
SpecificationsSpecifications
Specifications
Standard SBC functions
•CPU: Intel Celeron 300~800MHz (With system bus frequencies of
66 MHz) and Pentium III 500-850 MHz (With system bus frequencies of
100MHz)
•Businterface: PICMG 2.0 standard
•ISAdriving capacity: Built-in Address/Data buffer supports driving
capacity up to 64mA
•CPUsocket: 370-pinsocket
•BIOS:Award256KBFlashBIOS
•Chipset:Intel440BX
•I/Ochipset: WinbondW83977EF with fully 16-bit I/O decoded
• Memory : Onboard three 168-pin DIMM sockets support up to
768 Mbytes SDRAM
•EnhancedIDE: Supports up to four IDE devices. Supports Ultra DMA/
33 mode with data transfer rate 33MB/Sec.
•FDDinterface: Supports up to two floppy disk drives, 5.25" (360KB and
1.2MB) and/or 3.5" (720KB, 1.44MB, and2.88MB)
•Parallelport: One bi-directional parallel port. Supports SPP, ECP, and
EPP modes
•Serialport: One RS-232 and one RS-232/422/485 serial port. Ports can be
configured as COM1, COM2, COM3, COM4, or disabled individually.
(16C550equivalent)
•IRinterface: Supports one IrDA Tx/Rx header
•KB/Mouseconnector : 6-pin mini-DIN connector supports PC/AT
keyboard and PS/2 mouse. Additional 5-pin header supports PC/AT
keyboard for IPC applications. Additional 4-pin header supports PS/2

Chapter 1 General Information 5
mouse for IPC applications.
• USB connectors: 5 x 2 header onboard supports dual USB ports
•Battery: Lithium battery for data retention
•Watchdog timer: Can generate a system reset. Software selectable time-
out interval (2 sec. ~ 255 sec., 1 sec./step)
• DMA:7 DMA channels (8237 equivalent)
•Interrupt: 15interruptlevels (8259 equivalent)
• Power management: Supports ATX and AT power supply. Supports
Wake on LAN, modem ring and keyboard wake-up functions.
• H/Wstatusmonitoring: Winbond88W83781D H/W status monitoring
IC supports power supply voltages, fan speed, and temperatures
monitoring
Flat Panel/CRT Interface
•Chipset: ATIRAGE Mobility-M1 AGP-2X
•Displaymemory:Built-in8MBSDRAM
• Displaytype: Supports non-interlaced CRT and LVDS panel only. Can
display both CRT and Flat Panel simultaneously
•Resolution:LVDSpanelresolution 1600x1200
LVDS Interface ( 2 Channel)
• Chipset: ATI Rage Mobility
• Display type: Can support 24-bit display capability, single channel
SSD Interface
• One 32-pin DIP socket supports M-Systems DiskOnChip 2000 series up
to 288MB

6SBC-676 User Manual
Ethernet Interface (Dual Ethernet)
• Intel82559GD10/100Base-TFast Ethernet Controller
• Onboard 10/100 Base-T RJ-45 connector. Optional Remote boot ROM
function.
Mechanical and environmental
•Powersupplyvoltage:+5V(4.75Vto5.25V),
+12V (11.4V to 12.6V)
-5V (-4.75 to -5.25V)
-12V(-11.4to-12.6V)
•Typicalpowerrequirement:+5V@4A
•Operatingtemperature: 32 to 140o F (0 to 60oC)
•Boardsize:13.3"(L)x4.8"(W)(338mmx122mm)
•Weight:1.2lb. (0.5 Kg)

Chapter 2 Installation 7
SBC-675B
2
Installation
This chapter describes how to set up the
main board hardware, including instruc-
tions on setting jumpers and connecting
peripherals, switches, and indicators. Be
sure to read all the safety precautions
before you begin the installation proce-
dure.
CHAPTER

8 SBC-676 User Manual
SBC-676
Safety precautions
Warning! Always completely disconnect the power cord
from your chassis whenever you are working on it.
Do not make connections while the power is on
because sensitive electronic components can be
damagedby thesudden rushof power. Only
experiencedelectronicspersonnel shouldopen
the PC chassis.
Caution! Alwaysgroundyourself toremoveany
static charge before touching the CPU card.
Modernelectronic devicesarevery sensitiveto
static electric charges. Use a grounding wrist
strap at all times. Place all electronic components
on a static-dissipative surface or in a static-
shielded bag when they are not in the chassis.
Removing the CPU
The SBC-676 all-in-one CPU module supports most Pentium III and
Celeron CPUs. The system's performance depends on the CPU you
choose. You can install or upgrade the CPU in the board's PGA
socket by following the procedures outlined below. If your system
has an existing CPU, you need to remove it before installing the
newCPU.
Removing a CPU
1. Disconnect power from the chassis, and unplug all connections
to the CPU card. Then, remove the CPU card from the chassis
by following the instructions in the user's manual for your
chassis.
2. Lift the CPU out of the PGA socket. The old chip may be
difficult to remove. You may find spray chip lubricant, designed
for pin-grid-array (PGA) devices, and a chip puller helpful.
These are available at electronics hobbyists' supply stores.

Chapter 2 Installation 9
SBC-675B
Installing A CPU
To install the CPU, follow the instructions that came with it. If no
documentation was provided, the general procedures for installing
a CPU are outlined below:
1. Lubricate the pins on the CPU with lubricant for PGA devices.
This makes the CPU slide in much easier and greatly reduces
the chance of damaging the pins and other components.
2. Carefully align the CPU so that it is parallel to the socket. Make
sure that the notch on the corner of the CPU matches the notch
on the inside of the socket.
3. Gently push the CPU into the socket. There will probably be a
small gap between the CPU and the socket even when it is fully
seated.DONOTUSEEXCESSIVEFORCE!
When you install a new CPU, you may have to adjust other
settings on the board, such as CPU type, CPU clock, and PCI
speed, to accommodate it. Make sure that the settings are correct
foryour CPU.ImpropersettingsmaydamagetheCPU.

10 SBC-676 User Manual
SBC-676
Installing DRAM (DIMMs)
System Memory
The SBC-676 contains three sockets for 168-pin dual inline memory
module (DIMM). The socket uses 3.3 V unbuffered synchronous
DRAM(SDRAM). DIMM is available incapacities of 16, 32, 64,128
or 256 MB. The socket can be filled in the DIMM of any size,
giving your SBC-676 single board computer between 16 and 512
MBof memory.
Supplementary information about DIMM
SBC-676canaccept PC-133 SDRAM DIMM Module(with or
without parity).
Single-sided modules are typically 16 or 64 MB; double-sided
modulesare usually 32, 128 or 256 MB.
Memory Installation Procedures
To install DIMM, first make sure the two handles of the DIMM
socket are in the "open" position. i.e. The handles remain outward.
Slowly slide the DIMM module along the plastic guides on both
ends of the socket. Then press the DIMM module right down into
the socket, until you hear a click. This is when the two handles
have automatically locked the memory module into the correct
position of the DIMM socket. (See Figure below) To remove the
memory module, just push both handles outward, and the memory
module will be ejected by the mechanism in the socket.

Chapter 2 Installation 11
SBC-675B
Jumpers and connectors
Connectors on the board link it to external devices such as hard
disk drives, a keyboard, or floppy drives. In addition, the board
has a number of jumpers that allow you to configure your system
to suit your application.
The following tables list the function of each of the board's jumpers
and connectors.
Jumpers
Label Function
J1 LVDS Voltage Setting
J4 CPU Core Frequency
J5 CMOS Setting
J7 COM2 Setting
J8 COM2 Setting
J9 DOC 2000 Address Setting
JP1 Buzzer Setting
