AAF AstroPure 550C User manual

THE WOR L D LEADER IN CLE A N AIR S O LUTION S
AstroPure™550C
AIR PURIFIER
•
•
•
•
H14 True HEPA Filter
Effectively removes up to 99.995% of
ultra fine particles
Wi-Fi Smart Control
Control your unit anywhere and anytime
through our AAF Connect mobile app
UV-C Light
Ultraviolet light feature to provide
additional protection against airborne
infection
PM & TVOC Display
Visualise your current indoor air quality
(IAQ) through real-time monitoring
•
•
•
•
•
•
360° Cylindrical 3-in-1 filter (Prefilter,
H14 HEPA, Carbon)
Aerodynamic Design (3 inlets & 3
outlets)
Disinfects and diminishes bad smells in
the room
Touch Panel OLED Display
Easy to operate and Maintenance
Mobility - 4 x Caster Wheels
Product Overview
More Features
Remote Air Purification
Remotely control and monitor the air quality in your home, offices or any rooms with
AstroPure™550C using your mobile devices anywhere and anytime. You can even
turn ON the unit using your mobile app to ensure the indoor air is clean before
entering the room.
Intelligent Sensor
Equipped with the advance sensors to monitor the indoor air quality accurately and
to ensure that the air you breathe is safe and clean. User friendly, just switch it ON
and it will automatically adjust its fan speed accordingly to the indoor air quality by
the sensors.
Cylindrical 3-in-1 Filter
Cylindrical filter designed to trap and remove airborne pollutants. It has a prefilter
that collects dust, dirt, hair, and pet dander, an advanced high efficiency grade H14
HEPA filter that provides the highest fine particle efficiency up to 99.995%,
incorporating with an activated carbon filter leaving the occupants with lower
chance to expose with the formaldehyde, odours, and smoke.
Powerful Purifying Performance
AstroPure™ 550C provides safer and cleaner air, as
the system is designed to operate with 4 stages of air
filtration that is effective in purifying the polluted air, such
as pollen, haze, fine dust harmful gases & odours, and
even the health threatening microorganisms. It detects,
filters and gets rid of PM1 around you in real-time.

Center Indicator Ring
The display brightness can vary with ambient light.
Press the Wi-Fi button to switch the display contents:
PM10 -> PM2.5 -> PM1.0 -> TVOC. When switching to the
corresponding display value, air quality is judged according to the
corresponding sensor value.
AstroPure™550C
Touch Panel with LED Display
Night Mode
Turns off all lights on the control panel and
silences the fan to an almost inaudible
whisper. Fan speed will automatically be set
to 1.
Smart Sleep
The unit will automatically enter Night Mode
when there is low ambient light for 20
seconds. In turn, the unit will also
automatically exit Night Mode when ambient
light brightens up for more than 20 seconds.
Auto Mode
Unit determines the best environment needs
and adjusts the settings accordingly.
Wi-Fi
Use this icon in 2 ways:
To pair with your Mobile phone.
Press the Wi-Fi button for 3 seconds to initiate
the pairing. When the Wi-Fi icon is blinking,
indicate that the unit has not yet been paired
successfully.
To check real-time air quality reading
•PM 10 - Press once
•PM 2.5 - Press twice
•PM 1 - Press thrice
•TVOC - Press 4 times
Fan Speed
Select desired fan speed from 1-5 with 5
being the highest and 1 being the lowest.
UV-C
Press to enable or disable the UV-C.
Replace Filter
Filter change indicator. LED light blinks when
it is time to replace the filter. After replacing
the filter, press and hold the button for 5
seconds to reset.
Air Quality Indicator (Multicolor Ring)
Blue (Good)
PM2.5 : < 16 µg/m3
TVOC : < 56 ppb
Green (Moderate)
PM2.5 : 16 - 65 µg/m3
TVOC : 56 - 222 ppb
Orange (Bad)
PM2.5 : 66 - 150 µg/m3
TVOC : 223 - 667 ppb
Red (Poor)
PM2.5 : > 150 µg/m3
TVOC : > 667 ppb Child Lock
Press this button for 3 seconds to
enable or disable Child Lock.
* PM2.5 value reference to EPA guidelines.
** TVOC value reference to WHO guidelines.
Child Lock
Press this button for 3 seconds to
enable or disable Child Lock

AstroPure™550C
667 mm
370 mm 370 mm
Air Outlet 3 Sides
Air Inlet 3 Sides
AP550C Cylindrical
3-in-1 H14 HEPA
Hidden wheels
Location Requirements
Place on a level surface at least 10 inches away from
any heat sources such as stoves or ovens, dryers, or
heaters.
Position the unit where its air inlet and vents are
unobstructed.
Never place the unit on uneven or unstable surface.
Only for indoors use.
•
•
•
•
Safety Switch
When the filter cover is opened, the air purifier would be shut down automatically.
Energy Savings
Automatically reduces fan speed when the air is clean.
Multiple Working Modes
Select your preferred working mode from Auto, Manual, Sleep, or
7 Days Schedule Timer.

AstroPure™550C
For enquiries email us at
[email protected]
MAFP-1-0013B 08/21
AAF has a policy of continuous product research and
improvement and reserves the right to change
design and specifications without notice.
©2021 AAF Malaysia
Asia Sales Office
American Air Filter Manufacturing Sdn. Bhd.
(HQ - Malaysia)
(Penang - Malaysia)
AAF Australia Pty. Ltd.
(NSW HQ Sales Office)
(VIC Sales Office)
AAF International (Thailand) Co., Ltd.
AAF Singapore Pte. Ltd.
PT. AAF International Indonesia
Tel : [phone]
Tel : [phone]
Tel : [phone]
Tel : [phone]
Tel : [phone]
Tel : [phone]
Tel : [phone]
Applications
Homes & Residential
Buildings Offices & Buildings Cinemas Schools
Salons &
Spas
Hotels &
Resorts
Malls, Stores
& Commercial
Space
Clinics & Hospitals
Specification
550 - 700 CMH
3-sides Linear Air Grille
5 Levels of Speed
HIPS
Matte White
3-in-1 Cylindrical filter (Prefilter + H14 HEPA + Carbon)
1Ph/50/60Hz/220-240VAC
182 m2
24 - 55.9 dBA
CADR1
Air Outlet
Controller
Housing Material
Housing Color
Filter Configuration2
Power Supply
Applicable Coverage Area3
Sound Pressure Level
1The CADR varies based on E12, H13 and H14 filters.
2Unit comes with preinstalled filter. Spare filter and alternative filters in E12 and H13 grades are also available.
3The coverage area calculation is based on CADR of 700CMH according to NRCC-54013 standard.
Please contact your sales representative for more information.
