AAXA Technologies LEDandroid User manual

aaxa
User Guide
TECHNOLOGIES

Quick Start Guide
Step 4: Settings Button
Step 2: Power Button
Step 3: Adjust Focus
Step 1: Power Adapter Port
Step 1: Connect the power adapter
Step 2: Press the Power button once, the fan should start
spinning and the projector engine shoud light up
Step 3: Adjust the focus as needed
Step 4: Enter the “OSD” Menu to change brightness or to
select inputs. The OSD Menu can be accessed via the“Set -
tings”button on the projector or the “Menu” button on the
remote control

Caution!
WARNING: Please use this product as instructed. Misuse may cause
injury or death.
DO NOT expose to water or wet
surfaces. Electric shock may occur.
DO NOT expose the projected LED
image to your eyes or the eyes of
others
DO NOT block or restrict airow
from ventilation holes as this may
cause the projector to overheat
Keep the projector charger away
from any heat sources
Caution for Headphone Use
• Prolonged use at high volume may
impair your hearing.

Table of Contents
Chapter 1: Projector at a glance
Main Unit Front/Back
Remote & Keypad
Accessories
Chapter 2: Getting Started
Powering On / Off
Focus Adjustment / Throw
Distance
Accessing OSD Menu
Adjusting the Brightness
Picture Settings & Mode
Connecting to Projector
Enabling Video Output
(on a laptop)
Connecting to Composite Video
Connecting to VGA
Connecting to HDMI
Connecting to USB
Connecting to Speakers &
Headphones
Chapter 3: File Playback
Playing Videos
Viewing Pictures
Music Playback
Video Playback FAQ
Chapter 4: Android System
Connecting to Wireless
Quick Launch Buttons
Apps Menu
Ofce Files
1
2
3
4
5
6
7
8
10
13
17
15
16
17
18
20
22
24
26
28
30
31
33

Table of Contents (Cont)
Wireless Display (Screen Mirror)
Connecting to Bluetooth
Display Settings
Chapter 5: Settings
Picture Conguration
Keystone Adjustment
Chapter 6: Technical Details
Trouble Shooting
Specications
34
38
39
40
44
47
49

1
LED Android at a Glance
Chapter 1
HDMI Input
USB Port
3.5 mm Audio Jack
VGA Input
3.5 mm Composite Jack
Settings Button
Navigation Pad
Back Button
Power Button
Focus Wheel
Lens
Power Adapter Receptacle
Mini USB Port

Remote & Keypad
2
Both the keypad and remote can be used to control the projector. The Main Menu Navigation on the
remote functions similarly to the keypad on the projector but with additional features that include:
1. Mouse Pointer - The Mouse icon opens a mouse pointer on the screen. To enter “mouse mode” press
the mouse icon on the remote control and press the left or right arrow key. The mouse pointer should
begin to move. To exit “mouse mode” double-click the mouse icon. (Press Right / Left if it does not work im-
mediately)
2. Volume Control - Use the volume keys to adjust the speaker volume
3. Keystone - Adjust the keystone manually with the remote control (vertical only)

Accessories
3
*Under various circumstances, the actual accessories may be different from
those shown in the pictures above.
Power Adapter A/V Cable
Remote

Getting Started
4
Chapter 2
1. Connect the power cord to the Projector
2. Connect the opposite end of the power cord into a wall outlet.
3. Press the POWER button on the top of the projector to start the projector or press
the POWER button on the remote control to start the projector.
Powering ON the projector
Powering OFF the projector
* The POWER button’s blue LED light will turn on when the projector is on.
1. Press the button on the keypad or remote twice to turn the projector off. The optical
engine should power off and the fan should stop spinning. The projector can be
turned on using the remote control.
Power Socket

Focus Adjusment / Throw Distance
5
Focus Adjustment
DIAGONAL SCREEN SIZE
16:9 Aspect Ratio
Throw Distance Chart
Throw Ratio 1.22
*minimum throw distance: 20 inches
Located on top of the projector, turn the
focus ring to the left or right until the image
becomes clear.
19
28
38
47
56
66
75
150
20
30
40
50
60
70
80
157
Min
Max
Diagonal inch (“) Distance from
Lens to Screen (“)

Accessing the OSD Menu
6
To Access the OSD Menu
The OSD Menu allows the user to
control 3 primary functions of the pro-
jector. (1) Input Selection (2) Bright-
ness Settings (3) Picture Settings
Simply press the “settings” button ( )
on the projector or the “menu” button
on the remote control. The OSD
Menu will pop up.
The OSD Menu

Brightness Settings
7
Boost Mode delivers 550Lm of brightness. The Pro -
jector is designed to run in boost mode for 60 minutes
each time. Excessive use of Boost Mode will decrease
light-source lifespan. To toggle “on” boost mode, simply
select “Boost Mode” in the OSD menu. The fan will spin
faster and the projected image become brighter.
The Projector operates at 450Lm in
standard mode. Standard bright -
ness is designed for a wide range of
altitudes and ambient temperatures
and preserves light-source life
Boost Mode
Standard Mode

Picture Settings
8
Picture Mode
The picture mode allows the user to select between different picture
modes Dynamic, Standard, Mild, and Custom. The differences in
each mode is a combination of changes in Contrast, Brightness, Color,
Sharpness, and Tint. A fth mode, “User” allows the user to manually
adjust these settings.
Color Mode
The color mode allows the user to pick between Warm, Medium, and
Cool color temperatures. The differences in each mode is changes to
the Red, Green, Blue color-mix. A forth mode “user” allows the user to
manually adjust the color-mix.

Picture Settings (Cont)
9
Keystone allows vertical keystone adjustment. Please see
Keystone Adjustments page for more information. Horizontal
Keystone is not supported.
The Projector allows 4 different display modes which accomodate for
rear-projection and reverse (up-side down) mounting and is accomplished
through vertical or horizontal ip .
Keystone
Display Mode
Aspect Ratio
The Aspect ratio can be set to 6 different settings. The rst is an “auto”
setting. The next few settings forces between 4:3 or 16:9 (native) aspect
ratio, while Zoom 1 and Zoom 2 will zoom the image. “Just Scan” can
switch the image to wide screen / cinema mode.

Connecting to the Projector
10
HDMI - VGA - AV
The Input Selection menu can be found
by accessing the OSD menu. The
OSD menu is accessed by pressing the
“Settings” ( ) button on the projector or
the remote control.
The Projector offers 6 different input
sources.
This section will focus on HDMI,
VGA, and AV (Composite) input.
Selecting Inputs

Connecting to the Projector (Cont)
To connect a device to the Projector rst connect the appropriate source cable. HDMI is
a full sized HDMI cable. VGA is a standard 25 pin VGA cable. Composite Video is the
included 3.5mm AV cable. After connecting the cable open the OSD menu and select
the appropriate format. For example to enable an HDMI connection rst connect the
HDMI cable then select “HDMI” in the OSD menu.
11

Connecting to the Projector (Cont)
12
HDMI ConneCtIon
When connecting to HDMI remember to set the output resolution to match the projec-
tor. The native resolution of the projector is 1280x800. Not all resolutions will match,
please try a few different resolution settings to obtain the desired display. On systems
like the Playstation 4, a safe-mode boot (on the PS4) may be needed to change the
output resolution to match.
VGA ConneCtIon
VGA connections are analog connections without “autodetection”. To connect a laptop
to the LED Projector rst set the resolution. We recommend resolutions at or near
1280x800. Depending on your device, sometimes toggling the VGA output to “ON” is
needed. Each laptop conguration is different, for example Function+F5 is sometimes
used to toggle the VGA output On / Off on laptops. Please check your device owners
manual for more detailed instructions.
RCA ConneCtIon
To connect Composite Video (RCA) connections simply connect the red, white, and yel-
low RCA cables to the included 3.5mm RCA cable. The 3.5mm port should then plug
into the 3.5mm AV port of the LED Android Projector.

Tips: Enabling Video Output
Step 1:
To enable VGA or HDMI output on your computer most computers require “turning on” the video
output feature. Each computer is different. Please consult your owner’s manual for instructions to
enable VGA or HDMI output. Below are standard instructions for a Windows XP computer – not all
systems are the same.
Press function & “F5” to instruct
the computer to enable multiple
displays.
You can also press Windows+P to
toggle through display settings.
*NOTE: different operating systems may differ
Step 2:
1. Right click on computer desk-
top and select “Properties”
2. Display Properties window
will pop up
3. Click on the “Settings” Tab
4. If a secondary monitor is
grayed out, click on it and
check “Extend my Windows
Desktop onto this monitor”
5. If the image is blurry or the
text is not legible, adjust
the screen resolution. We
recommend 1280x800.
Step 3:
13

Tips: Connecting to Composite
14
Connect the 3.5mm A/V Cable to the
back of the Projector.
Connect the composite end of
the AV Cable (Red, White,Yellow)
to your device.
Step 1:
Step 2:

15
Step 1:
Connect one end of the VGA Cable to the back fo the
projector and the other end to the source device
Select “VGA Input” in the OSD Menu of the Projector
Step 2:
Connecting to VGA
Step 3:
Enable the video output of your source device. Frequently this is done with
the function F5 key or by enabling “video output” in the “display settings”.
Please see your device’s owners manual
