REF542plus
Multifunction Protection and Switchgear Control Unit
Operator's manual

3
Contents
1. Introduction.... ..................................................................... 7
1.1. This manual.................................................................... ...... 7
1.2. Use of symbols.... .......................................................... ...... 7
1.3. Intended audience.......................................................... ...... 8
1.4. Product documentation.... .............................................. ...... 8
1.5. Revision history.... .......................................................... ...... 8
2. Safety information.... .......................................................... 9
3. HMI features.... .................................................................. 11
3.1. Control area.................................................................... .... 11
3.2. Info and Menu area........................................................ .... 13
3.3. REF542plus status information area.... ......................... .... 15
4. Behavior at power up....................................................... 17
5. Control modes.... .............................................................. 19
5.1. Available control modes................................................. .... 19
5.2. Changing the control modes.......................................... .... 19
6. Operating the primary objects........................................ 21
7. Viewing and resetting alarms.... ..................................... 23
7.1. Viewing alarms.... ........................................................... .... 23
7.2. Resetting alarms.... ........................................................ .... 23
8. Viewing measurements.................................................... 25
9. Viewing events.................................................................. 27
10. Viewing and changing the protection settings.... ........ 29
10.1. Viewing the protection settings...................................... .... 29
10.2. Changing the protection settings................................... .... 29
10.2.1. Changing the protection key mode................. .... 29
10.2.2. Changing the protection parameters.... .......... .... 30
10.2.3. Changing the active parameter set.... ............ .... 32
10.2.4. Viewing and changing control parameters.... . .... 33
11. Setting the time and date.... ............................................ 35
12. Command page................................................................. 37
13. REF542plus commissioning mode.... ............................ 39
13.1. Binary input commissioning page.................................. .... 40
13.2. Binary output commissioning page.... ........................... .... 41
13.3. Analog input commissioning page................................. .... 42
13.4. Analog output 4- 20 mA commissioning page.............. .... 44
13.5. Analog input 4-20 mA commissioning page.... ............. .... 46
13.6. Optical inputs commissioning page............................... .... 47
Multifunction Protection and Switchgear Control
Unit
Operator's manual
REF542plus
1MRS755869
Issued: 01.11.2002
Version: A/28.02.2006

13.7. Optical output commissioning page.... .......................... .... 47
14. Connection to PC.... ......................................................... 49
14.1. Optical to RS232 converter cable.... ............................. .... 49
14.2. Downloading a configuration.... ..................................... .... 49
14.2.1. Serial port settings.... ...................................... .... 50
14.3. Uploading the configuration.... ....................................... .... 52
14.4. Uploading other information........................................... .... 53
15. Troubleshooting................................................................ 55
15.1. Error messages.... .......................................................... .... 55
15.2. Clearing the configuration inside the unit...................... .... 60
15.3. Primary objects incorrect visualization.... ...................... .... 60
16. Terminology.... ................................................................... 63
17. Abbreviations.... ................................................................ 65
18. Appendix A: Connection diagrams................................ 67
18.1. Analog Inputs.... ............................................................. .... 69
18.2. Binary inputs and outputs.... .......................................... .... 72
18.2.1. Static.... ............................................................ .... 72
18.2.2. Electromechanical.... ....................................... .... 73
18.2.2.1. BIO3.... ............................................ .... 73
18.3. Other connections.... ...................................................... .... 75
18.3.1. Analog outputs 0/4-20 mA.... .......................... .... 75
18.3.2. Analog inputs 4-20 mA.... ............................... .... 75
18.3.3. Communication module................................... .... 76
18.3.4. Power supply.... ............................................... .... 76
18.3.5. Time synchronization.... .................................. .... 77
18.3.6. HMI.... .............................................................. .... 77
19. Appendix B: Menu structure........................................... 79
19.1. Reset page.... ................................................................. .... 80
19.2. Service page.... .............................................................. .... 82
19.3. Test page........................................................................ .... 98
19.3.1. Test HMI........................................................... .... 98
19.3.2. Test primary object.... ...................................... .... 99
20. Appendix C: Tripping time indication.... ...................... 101
4
REF542plus Multifunction Protection and Switchgear Control
Unit
Operator's manual
1MRS755869

5
Copyrights
The information in this document is subject to change without notice and
should not be construed as a commitment by ABB Oy. ABB Oy assumes no
responsibility for any errors that may appear in this document.
In no event shall ABB Oy be liable for direct, indirect, special, incidental or
consequential damages of any nature or kind arising from the use of this
document, nor shall ABB Oy be liable for incidental or consequential
damages arising from use of any software or hardware described in this
document.
This document and parts thereof must not be reproduced or copied without
written permission from ABB Oy, and the contents thereof must not be
imparted to a third party nor used for any unauthorized purpose.
The software or hardware described in this document is furnished under a
license and may be used, copied, or disclosed only in accordance with the
terms of such license.
Copyright © 2006 ABB Oy
All rights reserved.
Trademarks
ABB is a registered trademark of ABB Group. All other brand or product
names mentioned in this document may be trademarks or registered
trademarks of their respective holders.
Guarantee
Please inquire about the terms of guarantee from your nearest ABB
representative.
1MRS755869
Multifunction Protection and Switchgear Control
Unit
Operator's manual
REF542plus

6

7
1. Introduction
1.1. This manual
Before attempting any operation with REF542plus, read this manual carefully
first.
This manual describes how to use the interface of REF542plus (LD HMI,
Local Detached Human Machine Interface). Note that HMI views and
pictures are to be considered exemplary.
Do not make any changes to the REF542plus configuration
unless you are authorized to do it and familiar with REF542plus
and its Operating Tool. This might result in malfunction and loss
of warranty.
1.2. Use of symbols
This publication includes the following icons that point out safety-related
conditions or other important information:
The electrical warning icon indicates the presence of a hazard
which could result in electrical shock.
The warning icon indicates the presence of a hazard which could
result in personal injury.
The caution icon indicates important information or warning
related to the concept discussed in the text. It might indicate the
presence of a hazard which could result in corruption of software
or damage to equipment or property.
The information icon alerts the reader to relevant facts and
conditions.
It should be understood that operation of damaged equipment could, under
certain operational conditions, result in degraded process performance
leading to information or property loss. Therefore, comply fully with all
notices.
1MRS755869
Multifunction Protection and Switchgear Control
Unit
Operator's manual
REF542plus

1.3. Intended audience
This manual is intended for operators, supervisors and administrators to
support normal use of the product.
1.4. Product documentation
Name of the Manual Document ID
Application Notes 1MRS755870
CAN Manual 1VTA100189-Rev 1, en
Configuration Manual 1MRS755871
iButton Programmer User Manual 1MRS755863
Manual Part 3, Installation and Commission 1 VTA100004
Manual Part 4, Communication 1VTA100005
Motor Protection with ATEX Certification, Manual 1MRS755862
Operator’s Manual 1MRS755869
Protection Manual 1MRS755860
Technical Catalogue 1MRS755859
Technical Reference Modbus RTU 1MRS755868
Web Manual, Installation 1MRS755865
Web Manual, Operation 1MRS755864
1.5. Revision history
Version Date History
1VTA100172-Rev 1, en 01.11.2002 First release
1VTA100172-Rev 2, en 22.10.2003 Updated to version 4D02
1VTA100172-Rev 3, en 03.05.2004 Updated
1VTA100172-Rev 4, en 04.04.2005 Updated
A 28.02..2006 Document updated
*language
*layout
Applicability
This manual is applicable to REF542plus Release 2.0, software version
V4D02.
8
REF542plus Multifunction Protection and Switchgear Control
Unit
Operator's manual
1MRS755869

9
2. Safety information
Dangerous voltages can occur on the connectors, even though
the auxiliary voltage has been disconnected.
Non-observance can result in death, personal injury or
substantial property damage.
Only a competent electrician is allowed to carry out the electrical
installation.
National and local electrical safety regulations must always be
followed.
The frame of the device has to be carefully earthed.
The device contains components which are sensitive to
electrostatic discharge. Unnecessary touching of electronic
components must therefore be avoided.
1MRS755869
Multifunction Protection and Switchgear Control
Unit
Operator's manual
REF542plus

10

11
3. HMI features
The REF542plus HMI is shown in Fig. 3.-1. The HMI features a back
illuminated LCD, 8 push buttons, several LEDs and an electronic key sensor.
The language of the display, when available, can be selected via the
Operating Tool. The default language is English.
A051327
Fig. 3.-1 REF542plus HMI
The LCD in the SLD view provides a graphical representation of the primary
objects controlled or monitored by REF542plus in the switchgear. The right
half of the LCD is for plain text visualization such as measurements and
protection events. The contrast level is automatically controlled for an
optimum reading, it can also be adjusted as wanted.
The HMI panel is organized in three main areas.
3.1. Control area
The left side of the HMI panel is for primary objects control. The command
buttons and the information related to the switchgear control are placed on
this area
1MRS755869
Multifunction Protection and Switchgear Control
Unit
Operator's manual
REF542plus

A051328
Fig. 3.1.-1 HMI control area
1 E-Key sensor
This section of the LCD display shows the Single Line Diagram (SLD) of the
controlled panel and the measurement bars. Text can be added in this section
to improve the understanding of SLD.
*Command buttons
The Primary Object Control can be performed with the following push
buttons to allow operating the primary objects if configured as “selectable”.
The command push buttons for local operation of the switching devices are:
Open: to open the selected object.
Close: to close the selected object.
Select: to select the object. The selected object appears highlighted.
CB Fast Opening: to allow opening of the circuit breaker independently
from the selected control mode. When pressed simultaneously with the
normal open button, this button allows opening the circuit breaker
independently from the selected control mode. This feature must be
enabled in the unit with the Operating Tool.
*E-Keys Sensor: this is the sensor for the electronic keys. The sensor
automatically detects which key has been inserted. The two keys are
usually labelled “Protect”and “Control”to distinguish them.
*Protection key: is specialized to the protection environment allowing
changing of parameters and other functions related to the protection.
*Control Key: this is dedicated to the control modes. It allows changing the
operating mode of REF542plus. The different operating modes discipline
the access to the primary objects by the different REF542plus interfaces
(HMI and SCADA). When required, a Super User key to access both
12
REF542plus Multifunction Protection and Switchgear Control
Unit
Operator's manual
1MRS755869

13
modes can be provided. The Super User key is also needed to access the
commissioning test mode. The password codes stored in the key can be
customized in each REF542plus for access restriction purposes.
*SLD view: this is the graphical part of the LCD. This part shows the single
line diagram of the switchgear. The status of the primary objects is
dynamically updated after every operation. If for example the circuit
breaker has been opened, its representation will reflect it.
3.2. Info and Menu area
The right side of the HMI LCD is for information and menu browsing. The
buttons to navigate through the menus and to change items are placed on this
area.
A051333
Fig. 3.2.-1 Info and Menu area
*Menu Navigation: these push buttons allow navigation trough the
REF542plus menus.
Pressing this button, the unit goes back to the former menu.
The up direction push button.
The down direction push button.
The enter push button to enter into the selected menu or to select
the highlighted submenu.
The following menus are available in the main window:
*Commands: this menu shows the configured FUPLA commands.
*E-Key status: to display and change the unit modes with the electronic
keys.
*Alarms: it displays the indication LED’s status.
1MRS755869
Multifunction Protection and Switchgear Control
Unit
Operator's manual
REF542plus

*Measurements: it displays the available measurements.
*Resets: to acknowledge alarms and other quantities.
*Events: to display protection starts and trips events.
*Protection: it displays the protection functions installed in the unit, and
allows displaying and changing their settings.
*Control: it displays the control functions list installed in the unit and
allows displaying and changing their settings.
*Service: relevant information on the HW and SW configurations and basic
setting of REF542plus.
*Tests: to access the test mode for the HMI and the primary objects.
Access to a few submenus is allowed only in some modes.
*LED bars: The three LED bars are available to show the most relevant
measurements acquired by REF542plus for a quick inspection of the
switchgear load situation. The three bars are marked M1, M2, and M3.
Each bar is composed of twelve LEDs, ten green and two red ones. The
ten green LEDs are normally dedicated to display between 0% and 100%
of the nominal value of the configured measurement. Each LED
corresponding then to 10% of the nominal value. The two red LEDs
indicate an overload condition of 20%. The measurements displayed by
the bars are set with the Operating Tool.
*Indication LEDs: 8 freely programmable, three-color LEDs are available
for indications. There are 4 pages of these LEDs. As a result, a total of 32
indication options can be programmed for events and status regarding
protection, control, monitoring, binary inputs and so on. The assignment
of the LED to a specific condition is done with the Operating Tool.
*Optical interface: This is the optical serial interface port to connect
REF542plus to a personal computer. By using the appropriate cable and
the Operating Tool, the following actions are possible:
*Download a configuration into the unit.
*Upload the current configuration from the unit.
*After a fault, upload the fault recorder data. This is possible only if the
fault recorder has been previously enabled with the Operating Tool.
Upload other information (measurements, binary inputs status, binary output
status).
Do not make any changes to the REF542plus configuration
unless you are familiar with REF542plus and the Operating
Tool. This might result in malfunction and loss of warranty.
14
REF542plus Multifunction Protection and Switchgear Control
Unit
Operator's manual
1MRS755869

15
3.3. REF542plus status information area
A051338
Fig. 3.3.-1 Status Information area
1 Unit status
2 Network Communication status
3 Alarm
4 Interlocking Error
The HMI shows the following status information:
*Ready. This green LED is turned on when the unit is in the operational
state. The LED is switched off when the auxiliary power is not present or
when the unit is not operational (FUPLA is not running).
*Network Communication. This LED is meaningful only when the
REF542plus is equipped with a communication module. When a
communication module is detected the LED turns on to green. If the
module is not detected or fails, the LED turns red. When a Modbus
communication module is installed, the LED becomes orange if the
communication error rate increases. It becomes red when the
communication error rate prevents good communication. The LED
comes back to green when no communication errors occur or by
resetting the module status registers (see the Modbus technical reference).
When there is no communication module, the LED is always switched off.
*Alarm: this LED turns to red when the user defined alarms become
true. Several arbitrary alarm conditions can be defined and configured
with the Operating Tool. Alarm conditions could be the trip of a
protection function, loss of SF6 in the circuit breaker and so on. When
this LED is on, it is not possible to close the circuit breaker or to
download a new configuration. The alarm must be acknowledged first.
*Interlocking Error: this LED is usually green. It turns temporarily to
red when the user attempts an operation that would violate the
programmed interlocking conditions; for example switching a
disconnector with the circuit breaker in closed position.
1MRS755869
Multifunction Protection and Switchgear Control
Unit
Operator's manual
REF542plus

16

17
4. Behavior at power up
Before energizing the switchgear, verify that the REF542plus
protection functions are properly set and that the unit is properly
working (READY LED green).
At power up, the HMI unit shows on the LCD for a few seconds the
following:
A051339
Fig. 4.-1 REF542plus LCD during power up
After that, the LCD left part shows the switchgear single diagram while the
right part shows the default menu. When the initialization is completed and
the unit is operational, the ready LED is on.
1MRS755869
Multifunction Protection and Switchgear Control
Unit
Operator's manual
REF542plus

18

19
5. Control modes
5.1. Available control modes
Local Control
It is possible to control the circuit breaker and other primary objects from the
HMI using the object control buttons. Open and close operations are possible
only if the interlocking logic programmed into the unit allow them. Remote
control from the SCADA is inhibited. Uploading and downloading the
configuration via the optical interface is possible.
Remote Control
The control of the circuit breaker and other primary objects from the HMI is
inhibited. The control is possible only remotely. Uploading and downloading
the configuration via the optical interface is possible.
No Control
It is not possible to control the circuit breaker and other primary objects both
from the HMI and remotely. Any kind of operation apart from the protection
trip is inhibited. Uploading and downloading the configuration via the optical
interface is possible.
Local and Remote Control
Both the local control and remote control from HMI are possible. Uploading
and downloading the configuration via the optical interface is possible.
The selection of this control mode requires caution, because
operations are allowed both from the HMI and remotely.
5.2. Changing the control modes
The next figure shows how to change the control mode. At first the menu E-
Key must be selected. Then the control key must be placed in the electronic
key sensor.
Select then the desired control mode by using UP and DOWN until it
is highlighted. Confirm the selection by pressing ENTER . After pressing
ENTER , the E-key status menu will appear again. Verify that the required
control mode has been properly set in the unit looking in the lower left corner
of the HMI. A text string there indicates the currently selected control and
protection mode.
1MRS755869
Multifunction Protection and Switchgear Control
Unit
Operator's manual
REF542plus

A051340
Fig. 5.2.-1 Changing the control mode by using the control key
20
REF542plus Multifunction Protection and Switchgear Control
Unit
Operator's manual
1MRS755869
