ABB ACH580 Series User manual

ACH580 Ultra-Low Harmonic Drives
Installation, Operation and Maintenance Manual (I, O & M)
ACH580 HVAC Drives (4…355 kW, 5…400 HP)
ACH580-BCR/BDR/ E-Clipse Bypass Drives (4…355 kW, 5…400 HP)
ACH580-PCR/PDR Packaged Drives with Disconnect (4…355 kW,
5…400 HP)

2 ACH580 Ultra-Low Harmonic Drives Installation, Operation and Maintenance Manual
Safety instructions
Safety instructions
These are the safety instructions which you
must obey when you install and operate the
drive and do maintenance on the drive. If you
ignore the safety instructions, injury, death or
damage can occur.
Use of warnings and notes in this
manual
Warnings tell you about conditions which can
cause injury or death, or damage to the
equipment. They also tell you how to prevent
the danger. Notes draw attention to a particular
condition or fact, or give information on a
subject.
The manual uses these warning symbols:
General safety in installation,
start-up and maintenance
These instructions are for all personnel that
install the drive and do maintenance work on it.
WARNING! Obey these instructions. If
you ignore them, injury or death, or
damage to the equipment can occur.
• Use safety shoes with a metal toe cap to
avoid foot injury. Wear protective gloves and
long sleeves. Some parts have sharp edges.
• Handle the drive carefully.
• Lift the drive with a lifting device. Use the
lifting eyes of the drive.
• Beware of hot surfaces. Some parts, such
as heatsinks of power semiconductors,
remain hot for a while after disconnection of
the electrical supply.
• Keep the drive in its package or protect it
otherwise from dust and burr from drilling
and grinding until you install it.
• Vacuum clean the area below the drive
before the start-up to prevent the drive
cooling fan from drawing the dust inside the
drive.
• Do not cover the air inlet and outlet when the
drive runs.
• Make sure that there is sufficient cooling.
See the ACH580-31 Hardware Manual
(3AXD50000037066) for more information.
Electricity warning tells about hazards
from electricity which can cause injury
or death, or damage to the equipment.
General warning tells about
conditions, other than those caused by
electricity, which can cause injury or death,
or damage to the equipment.
Electrostatic sensitive devices
warning tells you about the risk of
electrostatic discharge which can cause
damage to the equipment.

ACH580 Ultra-Low Harmonic Drives Installation, Operation and Maintenance Manual 3
Safety instructions
• Before you connect voltage to the drive,
make sure that the drive covers are on.
Keep the covers on during the operation.
• Before you adjust the drive operation limits,
make sure that the motor and all driven
equipment can operate throughout the
range of operation limits.
• Before you activate the automatic fault reset
or automatic restart functions of the drive
control program, make sure that no
dangerous situations can occur. These
functions reset the drive automatically and
continue operation after a fault or supply
break. If these functions are activated, the
installation must be clearly marked as
defined in IEC/EN 61800-5-1, subclause
6.5.3, for example, “THIS MACHINE
STARTS AUTOMATICALLY”.
• The maximum number of drive power-ups is
five in ten minutes. Too frequent power-ups
can damage the charging circuit of the DC
capacitors.
• If you have connected safety circuits to the
drive (for example, emergency stop and
Safe torque off), validate them at the start
up. For the validation of the Safe torque off,
see ACH580 HVAC control program
firmware manual (3AXD50000027537
[English]). For the validation of other safety
circuits, see the instructions provided with
them.
Note:
• If you select an external source for start
command and it is on, and the start
command is level-triggered, the drive will
start immediately after fault reset. See
parameters 20.02 Ext1 start trigger type and
20.07 Ext2 start trigger type in ACH580
HVAC control program firmware manual
(3AXD50000027537 [English]).
• When the control location is not set to HAND
(text Hand is not shown on the top row of the
panel and parameter 19.19 HAND/OFF
disable action has value OFF button
disabled), the OFF key on the control panel
will not stop the drive.
• Frame R3: Do not attempt to repair a
malfunctioning drive; contact your local
representative for replacement or repair by
authorized persons.
• Frames R6 and R8: Can be repaired by
authorized persons.
Electrical safety in installation,
start-up and maintenance
Precautions before electrical work
These warnings are for all personnel who do
work on the drive, motor cable or motor.
WARNING! Obey these instructions. If
you ignore them, injury or death, or
damage to the equipment can occur. If you are
not a qualified electrical professional, do not do
electrical installation or maintenance work. Go
through these steps before you begin any
installation or maintenance work.
1. Clearly identify the work location.
2. Secure a permit to work from the person in
control of the electrical installation work.
3. Disconnect all possible voltage sources.
Lock and tag.
• Open the main disconnector at the power
supply of the drive.
• Make sure that reconnection is not
possible.
• Disconnect any external power sources
from the control circuits.
• After you disconnect the drive, always
wait for 5 minutes to let the intermediate
circuit capacitors discharge before you
continue.
4. Protect any other energized parts in the
work location against contact.
5. Take special precautions when close to bare
conductors.

4 ACH580 Ultra-Low Harmonic Drives Installation, Operation and Maintenance Manual
Safety instructions
6. Measure that the installation is
de-energized.
7. Confirm the multimeter is working by testing
a known source.
• Use a multimeter with an impedance of at
least 1 Mohm.
• Make sure that the voltage between the
drive input power terminals (L1, L2, L3)
and the grounding terminal (PE) is close to
0 V.
8. Install temporary grounding as required by the
local regulations.
If the drive does not operate according to these
steps, refer to the ACH580-31 Hardware
Manual (3AXD5000037066).
Additional instructions and notes
WARNING! Obey these instructions. If you
ignore them, injury or death, or damage to
the equipment can occur.
• A drive with the EMC filter connected can be
installed to a symmetrically grounded TN-S
system. If you install the drive to another
system, check if you must disconnect the
EMC filter. See sections When to disconnect
EMC filter or ground-to-phase varistor:
TN-S, IT, Corner-grounded delta, and
Midpoint-grounded delta systems on page
15 and Guidelines for installing the drive to a
TT system on page 16.
WARNING! Do not install the drive with
the EMC filter connected to a system
that the filter is not suitable for. This can
cause danger, or damage the drive.
Note: When the internal EMC filter is
disconnected, the drive EMC compatibility is
considerably reduced. See section
Checking the compatibility of EMC filters
with IT (ungrounded), Corner-grounded
delta, Midpoint-grounded delta, and TT
systems on page 14 and Maximum
recommended motor cable length on page
17.
• A drive with the ground-to-phase varistor
connected can be installed to a
symmetrically grounded TN-S system. If you
install the drive to another system, check if
you must disconnect the varistor. See
sections When to disconnect EMC filter or
ground-to-phase varistor: TN-S, IT,
Corner-grounded delta, and
Midpoint-grounded delta systems on page
15 and Guidelines for installing the drive to a
TT system on page 16.
WARNING! Do not install the drive with
the ground-to-phase varistor
connected to a system that the varistor is
not suitable for. If you do, the varistor circuit
can be damaged.
• Use all ELV (extra low voltage) circuits
connected to the drive only within a zone of
equipotential bonding, that is, within a zone
where all simultaneously accessible
conductive parts are electrically connected
to prevent hazardous voltages appearing
between them. You can accomplish this by a
proper factory grounding, that is, make sure
that all simultaneously accessible
conductive parts are grounded to the
protective earth (PE) bus of the building.
WARNING! Do not do insulation or
voltage withstand tests on the drive or
drive modules.
Note:
• The motor cable terminals of the drive are at
a dangerous voltage when the input power
is on, regardless of whether the motor is
running or not.
• The DC terminals (UDC+, UDC-) are at a
dangerous voltage.
• External wiring can supply dangerous
voltages to the terminals of relay outputs
(RO1, RO2 and RO3).
• The Safe torque off function does not
remove the voltage from the main and
auxiliary circuits. The function is not effective
against deliberate sabotage or misuse.
WARNING! Use a grounding wrist band
when you handle the printed circuit boards.
Do not touch the boards unnecessarily. The
boards contain components sensitive to
electrostatic discharge.

ACH580 Ultra-Low Harmonic Drives Installation, Operation and Maintenance Manual 5
Safety instructions
Grounding
These instructions are for all personnel who are
responsible for the electrical installation,
including the grounding of the drive.
WARNING! Obey these instructions. If
you ignore them, injury or death, or
equipment malfunction can occur, and
electromagnetic interference can increase.
• If you are not a qualified electrical
professional, do not do grounding work.
• Always ground the drive, the motor and
adjoining equipment to the protective earth
(PE) bus of the power supply. This is
necessary for the personnel safety. Proper
grounding also reduces electromagnetic
emission and interference.
• In a multiple-drive installation, connect each
drive separately to the protective earth (PE)
bus of the power supply.
• Make sure that the conductivity of the
protective earth (PE) conductors is
sufficient. See section Power cable terminal
and lead-through data on page 16. Obey the
local regulations.
• Connect the power cable shields to the
protective earth (PE) terminals of the drive.
• Make a 360°grounding of the power and
control cable shields at the cable entries to
suppress electromagnetic disturbance.
• Standard IEC/EN 61800-5-1 (section
4.3.5.5.2.) requires that as the normal touch
current of the drive is higher than 3.5 mA AC
or 10 mA DC, you must use a fixed
protective earth (PE) connection. In addition,
• install a second protective earth
conductor of the same cross-sectional
area as the original protective earthing
conductor,
or
• install a protective earth conductor with a
cross-section of at least 10 mm2Cu or
16 mm2Al,
or
• install a device which automatically
disconnects the supply if the protective
earth conductor breaks.
Additional instructions for Safety Functions
WARNING! Bypass configurations
(ACH580-3BxR) do not support Safe
Torque Off (STO) functionality in bypass mode.
Additional instructions for
permanent magnet motor drives
Safety in installation, start-up and
maintenance
These are additional warnings concerning
permanent magnet motor drives. The other
safety instructions in this chapter are also valid.
WARNING! Obey these instructions. If
you ignore them, injury or death and
damage to the equipment can occur.
• Do not work on a drive when a rotating
permanent magnet motor is connected to it.
A rotating permanent magnet motor
energizes the drive including its power
terminals.
Before installation, start-up and maintenance
work on the drive:
• Stop the motor.
• Disconnect the motor from the drive with a
safety switch or by other means.
• If you cannot disconnect the motor, make
sure that the motor cannot rotate during
work. Make sure that no other system, like
hydraulic crawling drives, can rotate the
motor directly or through any mechanical
connection like felt, nip, rope, etc.
• Measure that the installation is
de-energized.
• Confirm the multimeter is working by
testing known source.
• Use a multimeter with an impedance of at
least 1 Mohm.

6 ACH580 Ultra-Low Harmonic Drives Installation, Operation and Maintenance Manual
Safety instructions
• Make sure that the voltage between the
drive output terminals (T1/U, T2/V, T3/W)
and the grounding (PE) busbar is close to
0 V.
• Make sure that the voltage between the
drive input power terminals (L1, L2, L3)
and the grounding (PE) busbar is close to
0 V.
• Make sure that the voltage between the
drive DC terminals (UDC+, UDC-) and
the grounding (PE) terminal is close to
0 V.
• Install temporary grounding to the drive
output terminals (T1/U, T2/V, T3/W).
Connect the output terminals together as
well as to the PE.
Start-up and operation:
• Make sure that the operator cannot run the
motor over the rated speed. Motor
overspeed causes overvoltage that can
damage or destroy the capacitors in the
intermediate circuit of the drive.
General safety in operation
These instructions are for all personnel that
operate the drive.
WARNING! Obey these instructions. If
you ignore them, injury or death, or
damage to the equipment can occur.
• Do not control the motor with the line side
disconnect at the drive power supply;
instead, use the control panel start and stop
keys or commands through the I/O terminals
of the drive.
• Give a stop command to the drive before
you reset a fault. If you have an external
source for the start command and the start is
on, the drive will start immediately after the
fault reset, unless you configure the drive for
pulse start. See the firmware manual.
• Before you activate automatic fault reset
functions of the drive control program, make
sure that no dangerous situations can occur.
These functions reset the drive
automatically and continue operation after a
fault.
Note: When the drive is not in the Hand mode,
the Off key on the control panel will not stop the
drive.
Cybersecurity disclaimer
This product is designed to be connected to
and to communicate information and data via a
network interface. It is Customer’s sole
responsibility to provide and continuously
ensure a secure connection between the
product and Customer network or any other
network (as the case may be). Customer shall
establish and maintain any appropriate
measures (such as but not limited to the
installation of firewalls, application of
authentication measures, encryption of data,
installation of anti-virus programs, etc) to
protect the product, the network, its system and
the interface against any kind of security
breaches, unauthorized access, interference,
intrusion, leakage and/or theft of data or
information. ABB and its affiliates are not liable
for damages and/or losses related to such
security breaches, any unauthorized access,
interference, intrusion, leakage and/or theft of
data or information.

ACH580 Ultra-Low Harmonic Drives Installation, Operation and Maintenance Manual 7
Contents
This manual is the Installation, Operation and Maintenance Manual for the
ACH580-31 Ultra-Low Harmonic Drives. Complete technical details are available in
the ACH580-31 Drives Hardware manual, publication number 3AXD50000037066.
Complete programming information is available in the ACH580 HVAC Control
Firmware manual, publication number 3AXD50000027537.
1. To determine the type of your drive, refer to its construction code on either:
• Serial number label attached on upper part of the
top mounting plate between the mounting holes.
• Type code label attached to the base frame – on
the side of the enclosure.
2. According to the construction code, proceed to your drive’s installation, operation,
diagnostics and maintenance information:
• 31 (Wall-Mount Drives)
• 3BCR, 3BDR (E-Clipse Bypass) – page 85.
• 3PCR, 3PDR (Packaged Drives with Disconnect) – page 120.
U1 3ph 400/480 VAC
I2 27 A
ACH580-31-027A-4
S/N * 2193303939
S/N: 1170700001
MADE IN FINLAND
FRAME
R6
IP21
UL type 1
U1 3ph 480 VAC
I1 24A
f1 60 Hz
U2 3ph 0...U1
I2 27A
f2 0...500 Hz
ABB Oy
Hiomotie 13
00380, Helsinki
Finland
IND CONT EQ.
1PD8
xxxxxxx
ACH580-31-027A-4
Air cooling
SCCR: 100 kA
Construction
code
Manufacturing
year and week

8 ACH580 Ultra-Low Harmonic Drives Installation, Operation and Maintenance Manual
ACH580 Ultra-Low Harmonic Drives Installation
ACH580 Ultra-Low Harmonic Drives Installation
Installation
Study these installation instructions carefully before proceeding. Failure to observe
the warnings and instructions may cause a malfunction or personal hazard.
WARNING! Before you begin read Safety instructions on page 3.
1. Check mounting surface and free space requirements
The drive must be installed on a vertical wall or surface. The surface construction or
support structure must be sufficient to support the weight of the connected drive(s).
Follow IBC and any local code requirements for the correct mounting and fastening
requirements. The mounting surface must be free from vibration and not exceed the
vibration specifications defined in the ACH580-31 Hardware manual, Technical data
section for Vibration (IEC 60068-2). Three acceptable mounting orientation include:
• vertically alone
• vertically side by side
• horizontally alone
Note: UL Type 1 (IP21) only meets UL “Open” type in horizontal orientation
Note: Do not install upside down.
Check that adequate clearance exists between the drive and other surfaces
including other drives.

ACH580 Ultra-Low Harmonic Drives Installation, Operation and Maintenance Manual 9
ACH580 Ultra-Low Harmonic Drives Installation
Vertical and horizontal clearances are defined in the following diagrams for each
orientation.
200 mm (8 in.)
300 mm (12 in.)
200 mm (8 in.)
200 mm (8 in.)
30 mm (1.5 in.)
300 mm (12 in.)200 mm (8 in.)
30 mm (1.5 in.)
300 mm (12 in.)200 mm (8 in.)
Allowable mounting orientations

10 ACH580 Ultra-Low Harmonic Drives Installation, Operation and Maintenance Manual
ACH580 Ultra-Low Harmonic Drives Installation
2. Prepare for installation
Lifting R3, R6 and R8
Use provided lifting points to install drive.
Transporting R3, R6 and R8
1. Use appropriate lifting equipment to move the transport package/enclosure to the
installation site.
WARNING! Frames R3, R6 and R8: Lift the drive with a lifting device. Use the lifting
eyes of the drive. The drive is heavy and its center of gravity is high. An
overturning drive can cause physical injury.
2. Use a hoist to lift the drive. (Do not place drive in final position until mounting site is
prepared.)
200 mm (8 in.)
300 mm (12 in.)
120 mm
250 mm (10 in.)
(5 in.)
120 mm
(5 in.)
Vertical installation and deflector plate
deflector
plate

ACH580 Ultra-Low Harmonic Drives Installation, Operation and Maintenance Manual 11
ACH580 Ultra-Low Harmonic Drives Installation
Unpack the drive
1. Unpack the drive.
2. Check for any damage and notify the shipper immediately if damaged components
are found.
3. Check the contents against the order and the shipping label to verify that all parts
have been received.
Tools required
To install the ACH580 Ultra-Low Harmonic Drives you need the following:
• Screwdrivers as appropriate for the mounting hardware used, including a
T20 Torx driver for drive cover removal
• Wire stripper
• Tape measure and/or provided mounting template
•Drill
• Use pallet truck and hoist
• Use the appropriate crimping tool for power cable lugs (if applicable).
• Mounting hardware: screws or nuts and bolts. The type, length and quantity of
hardware depends on the mounting surface and the frame size:
WARNING! Before installing the ACH580 Ultra-Low Harmonic Drives, ensure the
input power supply to the drive is off.
WARNING! Metal shavings or debris in the enclosure can damage electrical
equipment and create a hazardous condition. Where parts, such as conduit plates
require cutting or drilling, first remove the part. If that is not practical, cover nearby
electrical components to protect them from all shavings or debris.
Flange Mounting
Further information is in: Flange mounting kit supplement, 3AXD50000019100.
3. Install the drive
Installing the drive vertically, frames R3, R6, R8
The figures show frame R3 as an example.
1. Mark the hole locations using the mounting template included in the package.
2. Drill the mounting holes.
Frame size Kit
R3 3AXD50000255726
R6 3AXD50000179633
R8 3AXD50000164318

12 ACH580 Ultra-Low Harmonic Drives Installation, Operation and Maintenance Manual
ACH580 Ultra-Low Harmonic Drives Installation
3. Insert anchors or plugs into the holes and start the screws or bolts into the anchors
or plugs. Drive the screws or bolts long enough into the wall to make them carry the
weight of the drive.
4. Position the drive onto the bolts on the wall. For R6 and R8 with option +B056 (UL
Type 12), see also step 6.
5. Tighten the bolts in the wall securely.
6. Frames R6 and R8 with option +B056 (UL Type 12) installation: Install the hood on
top of the drive before you tighten the upper fastening bolts. Place the vertical edge
of the hood in between the wall and the drive back plate. Then, tighten the bolts to
fasten the hood on its place.
1
3
R3: M5 (#10)
R6: M8 (5/16″)
R8: M8 (5/16″)
2
4

ACH580 Ultra-Low Harmonic Drives Installation, Operation and Maintenance Manual 13
ACH580 Ultra-Low Harmonic Drives Installation
4. Install wiring
WARNING! Ensure the motor is compatible for use with the ACH580 Ultra-Low
Harmonic Drives. The ACH580 Ultra-Low Harmonic Drives must be installed by a
competent person. If in doubt, contact your local ABB sales or service office.
WARNING! If the drive will be connected on an IT (ungrounded) system, make sure
neither the EMC filter nor the ground-to-phase varistor are connected. If the drive will
be connected on a corner-grounded TN system, make sure you have not connected
the EMC filter. See Checking the compatibility with IT (ungrounded) and
corner-grounded TN systems (North America) in the ACH580-31 Drives Hardware
manual, publication number 3AXD50000037066.
Checking the insulation of the assembly
WARNING! Do not make any voltage tolerance or insulation resistance tests on any
part of the drive as testing can damage the drive. The drive has been tested at the
factory.
1. Before testing make sure the cable is not connected to the drive.
2. Check the insulation of the input cable according to local regulations. Minimum cable
temperature rating of 70 °C (158 °F) must be used.
Note: For drives rated over 100 amperes, the power cables must be rated for 75 °C
(167 °F) or higher. For UL Type 12 drives of frame R6, the power cables must be
rated for 90 °C (194 °F) minimum.
3. With the motor cable connected to the motor, but NOT to the drive output terminals
T1/U, T2/V and T3/W, measure the insulation resistance between the phase
conductors and between each phase conductor and the Protective Earth (PE)
conductor, using a measuring voltage of 1000 V DC. The insulation resistance must
exceed 100 Mohm at 25 °C (77 °F).
Ground connections
For personnel safety, proper operation and to reduce electromagnetic
emission/pick-up, the drive and the motor must be grounded at the installation site.
• Conductors must be adequately sized as required by safety regulations.
• Power cable shields must be connected to the drive PE terminal in order to meet
safety regulations.
• Power cable shields are suitable for use as equipment grounding conductors only
when the shield conductors are adequately sized as required by safety
regulations.
• In multiple drive installations, do not connect drive grounding terminals in series.

14 ACH580 Ultra-Low Harmonic Drives Installation, Operation and Maintenance Manual
ACH580 Ultra-Low Harmonic Drives Installation
Checking the compatibility of EMC filters with IT (ungrounded), Corner-grounded
delta, Midpoint-grounded delta, and TT systems
EMC filter
A drive with the EMC filter connected can be installed to a symmetrically grounded
TN-S system. If you install the drive to another system type, you may need to
disconnect the EMC filter. Refer to the following sections of the ACH580-31 Drives
Hardware manual, publication number 3AXD50000037066:
• When to disconnect EMC filter or ground-to-phase varistor: TN-S, IT,
Corner-grounded delta, and Midpoint-grounded delta systems
• Guidelines for installing the drive to a TT system
WARNING! Do not install the drive with the EMC filter connected to a system type
that the filter is not suitable for. This can cause danger, or damage the drive.
Note: When the internal EMC filter is disconnected, the drive EMC compatibility is
considerably reduced. Refer to the EMC compatibility and motor cable length section
of the ACH580-31 Drives Hardware manual, publication number
3AXD50000037066.
Ground-to-phase varistor (MOVs)
A drive with the ground-to-phase varistor connected can be installed into a
symmetrically grounded TN-S system. If you install the drive into another system,
you may need to disconnect the varistor. Refer to the following sections of the
ACH580-31 Drives Hardware manual, publication number 3AXD50000037066:
• When to disconnect EMC filter or ground-to-phase varistor: TN-S, IT,
Corner-grounded delta, and Midpoint-grounded delta systems
• Guidelines for installing the drive to a TT system
WARNING! Do not install the drive with the ground-to-phase varistor connected to a
system that the varistor is not suitable for. If you do, the varistor circuit can be
damaged.
WARNING! If the drive will be connected on an IT system (ungrounded or
high-resistance-grounded [over 30 ohms]), make sure that neither the EMC filter nor
the ground-to-phase varistor are connected, that is, the metal screws must not be
installed.
If the drive will be connected on a corner-grounded TN system, make sure that the
EMC filter is not connected, that is, the metal screws must not be installed.
Connections with metal screws in these systems can cause danger or damage.

ACH580 Ultra-Low Harmonic Drives Installation, Operation and Maintenance Manual 15
ACH580 Ultra-Low Harmonic Drives Installation
When to disconnect EMC filter or ground-to-phase varistor: TN-S, IT,
Corner-grounded delta, and Midpoint-grounded delta systems
Frame
size
Symmetrically grounded
TN-S systems 1
Corner-grounded and
Midpoint-grounded delta
systems 2
IT systems (ungrounded or
high-resistance grounded
[>30 ohms]) 3
R3 Do not disconnect EMC or
VAR screws
Do not disconnect EMC or
VAR screws
Disconnect EMC and VAR
screws.
R6 Do not disconnect EMC or
VAR screws
See Note 1 below. Disconnect EMC AC, EMC DC
and VAR screws.
R8 Do not disconnect EMC or
VAR screws
Disconnect EMC and VAR
screws
Disconnect EMC and VAR
screws.
Note 1:Frames R3 and R6 are evaluated for use on Corner-grounded and Midpoint-grounded delta
systems by UL standards. Disconnect EMC DC screw. Do not disconnect EMC AC or VAR screws.
Frames R3 and R6 are not evaluated by IEC standards for use on Corner-grounded or
Midpoint-grounded systems.
EMC and varistor screws for R3, R6, and R8 Frames
Frame Size EMC filter screws Ground-to-phase varistor screws
R3 EMC VAR
R6 EMC AC, EMC DC VAR
R8 EMC DC VAR*
* VAR screw also functions as the EMC AC screw in R8.
Drive
PE
N
L3
L2
L1
Drive Drive
PE
L3
L2
L1
L3
L2
L1
Drive
PE
L3
L2
L1
231
2

16 ACH580 Ultra-Low Harmonic Drives Installation, Operation and Maintenance Manual
ACH580 Ultra-Low Harmonic Drives Installation
Guidelines for installing the drive to a TT system
The drive can be connected to a TT system under these conditions:
1. Residual current device has been installed in the supply system.
2. These screws have been disconnected. Otherwise EMC filter and ground-to-phase
varistor capacitor leakage current will cause the residual current device to trip.
Power cable terminal and lead-through data
UL (NEC) ratings at U
N= 460 V
Input, motor and DC cable entries, maximum wire sizes (per phase) and terminal
screw sizes and tightening torques are given below.
Frame size EMC filter screws Ground-to-phase varistor screws
R3 EMC VAR
R6 EMC AC, EMC DC VAR
R8 EMC DC VAR*
*VAR screw also functions as the EMC AC screw in R8. 3AXD10000681917
Note:
• Because the EMC filter screws have been disconnected, ABB does not guarantee the EMC
category.
• ABB does not guarantee the functioning of the ground leakage detector built inside the drive.
• In large systems the residual current device can trip without a real reason.
Frame
size
Cable
entries L1, L2, L3 terminals T1/U, T2/V, T3/W, UDC+, UDC- terminals Grounding
terminals
Per
cable
type
Ø1) Min wire
size (solid/
stranded)2)
Max wire
size
(solid/
Tightening
torque
Min wire
size (solid/
stranded)2
Max wire
size (solid/
stranded)
Tightening
torque
Tightening
torque
pcs in AWG AWG lbf·ft AWG AWG lbf·ft lb-ft
R3 1 0.91 20 6 1.3 20 6 1.3 1.2
R6 1 1.77 10 2/0 4.1 10 2/0 4.1 2.1
R8 1 1.77 6 300 25 4 300 22 7.2
3AXD00000586715
1) Maximum cable diameter accepted. For the bottom plate hole diameters, see the Dimension drawings chapter in the ACH580-31
Drives Hardware manual, publication number 3AXD50000037066.
2) Minimum wire size does not necessarily have enough current capability for full load. Make sure the installation complies with local
codes and regulations.
Note: Only copper cables are allowed for drive types up to -039A-4.
Drive
N
L3
L2
L1

ACH580 Ultra-Low Harmonic Drives Installation, Operation and Maintenance Manual 17
ACH580 Ultra-Low Harmonic Drives Installation
Control cable terminal and lead-through data
Control cable entries, wire sizes and tightening torques (T) are given below.
Current and power ratings
UL (NEC) ratings at U
N= 460 V
Maximum recommended motor cable length
Frame
size
Cable entries Control cable entries and terminal sizes
Holes Max cable
size
+24V, DCOM, DGND, EXT. 24V
terminals
DI, AI/O, AGND, RO, STO terminals
Wire size TWire size T
pcs in AWG lbf·ft AWG lbf·ft
R3 3 0.67 24…14 0.4 26…14 0.4
R6 4 0.67 26…14 0.4 26…14 0.4
R8 4 0.67 26…14 0.4 26…14 0.4
3AXD00000586715
Type
ACH580
-31-
Input rating Max. current App. power Output ratings
Frame
size
Light-duty use
I1Imax SN ILd PLd
AAkVAA hp
3-phase UN= 480 V (440…480 V)
07A6-4 7.0 9.5 6.3 7.6 5.0 R3
012A-4 9.0 15.0 10.0 12.0 7.5 R3
014A-4 12.0 20.4 11.6 14.0 10.0 R3
023A-4 17.0 28.8 19.1 23.0 15.0 R3
027A-4* 24 39.1 22.4 27 20.0 R6
034A-4* 29 45.9 28.3 34 25.0 R6
044A-4* 34 57.8 36.6 44 30.0 R6
052A-4* 44 74.8 43.2 52 40.0 R6
065A-4* 54 88.4 54.0 65 50.0 R6
077A-4* 66 110.5 64.0 77 60.0 R6
3AXD00000586715
Frame Size
Maximum motor cable length, 4 kHz
Scalar control Vector control
mftmft
Standard drive, without external options
R3 200 656 200 656
R6 300 990 300 990
R8 300 990 300 990

18 ACH580 Ultra-Low Harmonic Drives Installation, Operation and Maintenance Manual
ACH580 Ultra-Low Harmonic Drives Installation
Heat dissipation and Air flow requirements
Definitions
Type
ACH580
-31-
Heat dissipation
Air flow Noise Frame
size
Main circuit
at rated
I1 at I2
Control
circuit
minimum
Control
circuit
maximum
Main and
control boards
maximum
WWW Wm
3/h ft3/
min
dB(A)
NEC ratings: 3-phase UN= 480 V (440…480 V)
07A6-4 183 4.1 36 219 361 212 57 R3
012A-4 242 4.1 36 278 361 212 57 R3
014A-4 285 4.1 36 321 361 212 57 R3
023A-4 437 4.1 36 473 361 212 57 R3
027A-4 589 4.1 36 625 550 324 65 R6
034A-4 675 4.1 36 711 550 324 65 R6
044A-4 771 4.1 36 807 550 324 65 R6
052A-4 924 4.1 36 960 550 324 65 R6
065A-4 1187 4.1 36 1223 550 324 65 R6
077A-4 1524 4.1 36 1560 550 324 65 R6
3AXD00000586715
UNOutput voltage of the drive.
IContinuous rms output current, allowing 110% overload for 1 minute every 10 minutes.
PTypical motor power valid at nominal voltage, 460V.

ACH580 Ultra-Low Harmonic Drives Installation, Operation and Maintenance Manual 19
ACH580 Ultra-Low Harmonic Drives Installation
Fuses
UL class T fuses for branch circuit protection per NEC are listed below. ABB
recommends fast acting class T or faster fuses for drives installed in North America.
Check on the fuse time-current curve to ensure the operating time of the fuse
is below 0.5 seconds for frames R3 and R6 and below 0.1 seconds for frame
R8. Comply with NFPA70 (NEC) and all local.
Note 1: See also Implementing thermal overload and short-circuit protection in
ACH580-31 Hardware Manual (3AXD5000037066).
Note 2: Fuses with higher current rating than the recommended ones must not be
used.
Note 3: Fuses from other manufacturers can be used if they meet the ratings and
the melting curve of the fuse does not exceed the melting curve of the fuse
mentioned in the table.
Note: The UL listed fuses in the table are the required branch circuit protection.
Fuses are to be provided as part of the installation.
• Fuses are not included in the purchased drive and must be provided by others.
• Fuses with higher current rating than specified must not be used.
• Fuses with lower current rating than specified may be used if they are of the same
class and voltage rating. It is the user's responsibility to verify that lower current
rated fuses are compliant with local regulations and appropriate for the
application.
• Drive fuses must be used to maintain the drive UL listing. Additional protection
can be used. Refer to local codes and regulations.
Type
ACH580
-01-
Input current UL (one fuse per phase)
Nominal current Voltage rating Bussmann type UL class
AAV
UL (NEC) ratings: 3-phase UN= 480 V (440…480 V)
07A6-4 7.0 15 600 JJS-15 T
012A-4 9.0 20 600 JJS-20 T
014A-4 12.0 25 600 JJS-25 T
023A-4 17.0 35 600 JJS-35 T
027A-4 24 40 600 JJS-40 T
034A-4 29 50 600 JJS-50 T
044A-4 34 60 600 JJS-60 T
052A-4 44 80 600 JJS-80 T
065A-4 54 90 600 JJS-90 T
077A-4 66 110 600 JJS-110 T
3AXD00000586715
1) Minimum short-circuit current of the installation

20 ACH580 Ultra-Low Harmonic Drives Installation, Operation and Maintenance Manual
ACH580 Ultra-Low Harmonic Drives Installation
Layout
The layout of the drive is shown below.
1 Lifting holes (2 pcs in frame R3, 6 pcs in
frames R6 and R8)
5 Front cover
2 Control panel 6 Control panel behind the control panel
cover
3 Heatsink 7 Hood in frames R6 and R8.
4 Mounting points (4 pieces) - -
UL Type 12 R6 IP20 (UL Open Type) option +P940, R3
1
1
1
2
3
4
4
7
IP21 (UL Type 1) R6
6
IP55 (UL Type 12) option +B056, R6
5
1
