ABB Relion RER615 User manual

Relion® product family
Grid Automation
Recloser Protection and Control RER615
IEC 60870-5-101/104 Point List Manual

Document ID: 1MRS757824
Issued: 2015-03-06
Revision: C
Product version: 1.1
© Copyright 2015 ABB. All rights reserved

Copyright
This document and parts thereof must not be reproduced or copied without written
permission from ABB, and the contents thereof must not be imparted to a third
party, nor used for any unauthorized purpose.
The software or hardware described in this document is furnished under a license
and may be used, copied, or disclosed only in accordance with the terms of such
license.
Trademarks
ABB and Relion are registered trademarks of the ABB Group. All other brand or
product names mentioned in this document may be trademarks or registered
trademarks of their respective holders.
Warranty
Please inquire about the terms of warranty from your nearest ABB representative.
http://www.abb.com/substationautomation

Disclaimer
The data, examples and diagrams in this manual are included solely for the concept
or product description and are not to be deemed as a statement of guaranteed
properties. All persons responsible for applying the equipment addressed in this
manual must satisfy themselves that each intended application is suitable and
acceptable, including that any applicable safety or other operational requirements
are complied with. In particular, any risks in applications where a system failure and/
or product failure would create a risk for harm to property or persons (including but
not limited to personal injuries or death) shall be the sole responsibility of the
person or entity applying the equipment, and those so responsible are hereby
requested to ensure that all measures are taken to exclude or mitigate such risks.
This product has been designed to be connected and communicate data and
information via a network interface which should be connected to a secure
network. It is the sole responsibility of the person or entity responsible for network
administration to ensure a secure connection to the network and to take the
necessary measures (such as, but not limited to, installation of firewalls, application
of authentication measures, encryption of data, installation of anti virus programs,
etc.) to protect the product and the network, its system and interface included,
against any kind of security breaches, unauthorized access, interference, intrusion,
leakage and/or theft of data or information. ABB is not liable for any such damages
and/or losses.
This document has been carefully checked by ABB but deviations cannot be
completely ruled out. In case any errors are detected, the reader is kindly requested
to notify the manufacturer. Other than under explicit contractual commitments, in
no event shall ABB be responsible or liable for any loss or damage resulting from
the use of this manual or the application of the equipment.

Conformity
This product complies with the directive of the Council of the European
Communities on the approximation of the laws of the Member States relating to
electromagnetic compatibility (EMC Directive 2004/108/EC) and concerning
electrical equipment for use within specified voltage limits (Low-voltage directive
2006/95/EC). This conformity is the result of tests conducted by ABB in
accordance with the product standards EN 50263 and EN 60255-26 for the EMC
directive, and with the product standards EN 60255-1 and EN 60255-27 for the low
voltage directive. The product is designed in accordance with the international
standards of the IEC 60255 series.

Table of contents
Section 1 Introduction.......................................................................5
This manual........................................................................................5
Intended audience..............................................................................5
Product documentation.......................................................................6
Product documentation set............................................................6
Document revision history.............................................................6
Related documentation..................................................................7
Symbols and conventions...................................................................7
Symbols.........................................................................................7
Document conventions..................................................................7
Functions, codes and symbols......................................................8
Section 2 IEC 60850-5-101/104 data mappings............................13
Overview...........................................................................................13
Supported functions in RER615.......................................................13
Indications........................................................................................15
Supported ASDU types...............................................................15
General device data....................................................................16
LD0.FPHLPTOC1 FA - Phase overcurrent protection, low
stage (1)......................................................................................16
LD0.PHHPTOC1 Phase overcurrent protection, high stage
(1)................................................................................................17
LD0.PHIPTOC1 Phase overcurrent protection,
instantaneous stage (1)...............................................................17
LD0.FDPHLPDOC1 FA - Directional phase overcurrent
protection, low stage (1)..............................................................17
LD0.FDPHLPDOC2 FA - Directional phase overcurrent
protection, low stage (2)..............................................................18
LD0.DPHHPDOC1 Three-phase directional overcurrent
protection, high stage (1).............................................................18
LD0.FEFLPTOC1 FA - Earth-fault protection, low stage (1).......19
LD0.EFHPTOC1 Non-directional earth-fault protection, high
stage (1)......................................................................................19
LD0.EFIPTOC1 Non-directional earth-fault protection,
instantaneous stage (1)...............................................................19
LD0.FDEFLPDEF1 FA - Directional earth-fault protection,
low stage (1)................................................................................19
LD0.FDEFLPDEF2 FA - Directional earth-fault protection,
low stage (2)................................................................................20
LD0.DEFHPDEF1 Directional earth-fault protection, high
stage (1)......................................................................................20
Table of contents
Recloser Protection and Control RER615 1
Point List Manual

LD0.INTRPTEF1 Intermittent earth-fault protection (1)...............20
LD0.EFPADM1 Admittance-based earth-fault protection
(1)................................................................................................20
LD0.EFPADM2 Admittance-based earth-fault protection
(2)................................................................................................21
LD0.EFPADM3 Admittance-based earth-fault protection
(3)................................................................................................21
LD0.WPWDE1 Wattmetric-based earth-fault protection (1)........21
LD0.WPWDE2 Wattmetric-based earth-fault protection (2)........21
LD0.WPWDE3 Wattmetric-based earth-fault protection (3)........21
LD0.HAEFPTOC1 Harmonics-based earth-fault protection
(1)................................................................................................22
LD0.NSPTOC1 Negative-sequence overcurrent protection
(1)................................................................................................22
LD0.NSPTOC2 Negative-sequence overcurrent protection
(2)................................................................................................22
LD0.PDNSPTOC1 Phase discontinuity protection (1).................22
LD0.ROVPTOV1 Residual overvoltage protection (1).................23
LD0.ROVPTOV2 Residual overvoltage protection (2).................23
LD0.PHPTUV1 Phase undervoltage protection (1).....................23
LD0.PHPTUV2 Phase undervoltage protection (2).....................23
LD0.PHPTUV3 Phase undervoltage protection (3).....................24
LD0.PHPTOV1 Phase overvoltage protection (1).......................24
LD0.PHPTOV2 Phase overvoltage protection (2).......................25
LD0.PHPTOV3 Phase overvoltage protection (3).......................25
LD0.PSPTUV1 Positive-sequence undervoltage protection
(1)................................................................................................25
LD0.NSPTOV1 Negative-sequence overvoltage protection
(1)................................................................................................26
LD0.FRPFRQ1 Frequency protection (1)....................................26
LD0.FRPFRQ2 Frequency protection (2)....................................26
LD0.T1PTTR1 Thermal overload protection (1)..........................27
CTRL.Cxxxxx1 Circuit breaker - CB object and failure
protection (1)...............................................................................27
LD0.INRPHAR1 Three-phase inrush detection (1)......................27
LD0.TRPPTRC1 Protection trip conditioning (1).........................28
LD0.TRPPTRC2 Protection trip conditioning (2).........................28
LD0.MAPGAPC1 Multipurpose protection signals (1).................28
LD0.MAPGAPC2 Multipurpose protection signals (2).................28
LD0.MAPGAPC3 Multipurpose protection signals (3).................28
LD0.MAPGAPC4 Multipurpose protection signals (4).................29
LD0.MAPGAPC5 Multipurpose protection signals (5).................29
LD0.MAPGAPC6 Multipurpose protection signals (6).................29
LD0.CMHAI1 Current total demand distortion (1)........................29
Table of contents
2Recloser Protection and Control RER615
Point List Manual

LD0.VMHAI1 Voltage total demand distortion (1)........................29
LD0.PHQVVR1 PQ - Voltage variation signals (1)......................30
LD0.VSQVUB1 PQ - Voltage unbalance detection (1)................30
CTRL.DCSXSWI1 Disconnector position indication (1)..............30
CTRL.DCSXSWI1 Disconnector position indication (2)..............30
CTRL.ESSXSWI1 Earthing switch indication (1).........................30
CTRL.ESSXSWI2 Earthing switch indication (2).........................31
LD0.DARREC1 Autorecloser (1).................................................31
LD0.SECRSYN1 Synchrocheck (1).............................................31
LD0.SSCBR1 Circuit breaker condition monitoring (1)................32
LD0.TCSSCBR1 Trip circuit supervision (1)................................32
LD0.TCSSCBR2 Trip circuit supervision (2)................................32
LD0.SEQRFUF1 Fuse failure protection (1)................................32
LD0.MDSOPT1 Generic operation time supervision (1)..............33
LD0.PHSVPR1 Voltage presence supervision (1).......................33
LD0.CMMXU1 Phase current limit supervision (1)......................33
LD0.RESCMMXU1 Residual current limit supervision (1)...........33
LD0.VMMXU1 Phase voltage limit supervision (1)......................34
LD0.VMMXU2 Phase voltage limit supervision (2)......................34
LD0.MVGAPC1 Multipurpose binary inputs (1)...........................34
LD0.MVGAPC2 Multipurpose binary inputs (2)...........................35
LD0.SPCGGIO1 Multipurpose binary output states (1)...............35
LD0.SPCGGIO2 Multipurpose binary output states (2)...............36
LD0.SPCRGGIO1 Multipurpose binary output states (1)............36
LD0.SPCLGGIO1 Multipurpose binary output states (1).............37
LD0.XGGIO100 Physical I/O states............................................37
LD0.XGGIO110 Physical I/O states............................................38
LD0.XGGIO120 Physical I/O states............................................38
LD0.LEDPTRC1 Global protection signals..................................38
Measurands......................................................................................39
Supported ASDU types...............................................................39
General device data....................................................................39
LD0.T1PTTR1 Thermal overload values (1)................................40
LD0.DARREC1 Autorecloser (1).................................................40
LD0.SECRSYN1 Synchrocheck (1).............................................40
LD0.SSCBR1 Circuit breaker condition monitoring (1)................41
LD0.MDSOPT1 Generic operation time supervision (1) .............41
LD0.CMMXU1 Phase current measurement (1)..........................41
LD0.CSMSQI1 Sequence of current measurements (1).............42
LD0.RESCMMXU1 Residual current measurement (1)..............42
LD0.VMMXU1 Phase voltage measurements (1)........................42
LD0.VMMXU2 Phase voltage measurements (2)........................42
LD0.VSMSQI1 Sequence of voltage measurements (1).............43
Table of contents
Recloser Protection and Control RER615 3
Point List Manual

LD0.VSMSQI2 Sequence of voltage measurements (2).............43
LD0.PEMMXU1 Three-phase power measurements (1).............43
LD0.FMMXU1 Frequency measurement (1)...............................43
LD0.LEDGGIO1 LED states (1)...................................................44
LD0.FLTMSTA1 Fault record data (1).........................................44
Integrated totals................................................................................45
Supported ASDU types...............................................................45
CTRL.CBCSWI1 Operation counter............................................46
LD0.PEMMTR1 Three-phase energy values (1).........................46
Controls............................................................................................46
Supported ASDU types...............................................................46
General device data....................................................................47
CTRL.Cxxxxx1 Circuit breaker control (1)...................................47
LD0.DARREC1 Autoreclosing reset signals (1)..........................47
LD0.SSCBR1 Circuit breaker condition monitoring (1)................48
DR.RDRE1 Disturbance recorder (1)..........................................48
LD0.SRGAPC1 Multipurpose binary output flipflop resets
(1)................................................................................................48
LD0.SRGAPC2 Multipurpose binary output flipflop resets
(2)................................................................................................48
LD0.SPCGGIO1 Multipurpose binary output controls (1)............49
LD0.SPCGGIO2 Multipurpose binary output controls (2)............49
LD0.SPCRGGIO1 Multipurpose binary output controls (1).........50
Section 3 IEC 60870-5-101/104 protocol implementation..............51
Overview...........................................................................................51
Interoperability IEC 60870-5-101......................................................51
System or device..............................................................................52
Network configuration.......................................................................52
Physical layer...................................................................................52
Link layer..........................................................................................53
Application layer...............................................................................54
Basic application functions...............................................................61
Section 4 Glossary.........................................................................67
Table of contents
4Recloser Protection and Control RER615
Point List Manual

Section 1 Introduction
1.1 This manual
The point list manual describes the outlook and properties of the data points
specific to the IED. The manual should be used in conjunction with the
corresponding communication protocol manual.
1.2 Intended audience
This manual addresses the communication system engineer or system integrator
responsible for pre-engineering and engineering for communication setup in a
substation from an IED perspective.
The system engineer or system integrator must have a basic knowledge of
communication in protection and control systems and thorough knowledge of the
specific communication protocol.
1MRS757824 C Section 1
Introduction
Recloser Protection and Control RER615 5
Point List Manual

1.3 Product documentation
1.3.1 Product documentation set
Planning & purchase Engineering Installation Commissioning Operation Maintenance Decommissioning, deinstallation & disposal
Quick start guide
Quick installation guide
Brochure
Product guide
Operation manual
Installation manual
Connection diagram
Engineering manual
Technical manual
Application Engineering Guide
Communication protocol manual
IEC 61850 Engineering guide
Point list manual
GUID-7414985D-2433-46E4-B77B-CCE64F6FC8D0 V1 EN
Figure 1: The intended use of documents during the product life cycle
Product series- and product-specific manuals can be downloaded
from the ABB Website http://www.abb.com/relion.
1.3.2 Document revision history
Document revision/date Product version History
A/2013-09-17 1.0 First release
B/2014-06-13 1.0 Content updated
C/2015-03-06 1.1 Content updated to correspond to the
product version
Download the latest documents from the ABB Website
http://www.abb.com/substationautomation.
Section 1 1MRS757824 C
Introduction
6Recloser Protection and Control RER615
Point List Manual

1.3.3 Related documentation
Name of the document Document ID
IEC 60870-5-101/104 Communication Protocol Manual 1MRS757821
1.4 Symbols and conventions
1.4.1 Symbols
The caution icon indicates important information or warning related
to the concept discussed in the text. It might indicate the presence
of a hazard which could result in corruption of software or damage
to equipment or property.
The information icon alerts the reader of important facts and
conditions.
The tip icon indicates advice on, for example, how to design your
project or how to use a certain function.
Although warning hazards are related to personal injury, it is necessary to
understand that under certain operational conditions, operation of damaged
equipment may result in degraded process performance leading to personal injury
or death. Therefore, comply fully with all warning and caution notices.
1.4.2 Document conventions
A particular convention may not be used in this manual.
• Abbreviations and acronyms are spelled out in the glossary. The glossary also
contains definitions of important terms.
• The example figures illustrate the IEC display variant.
• Menu paths are presented in bold.
Select Main menu/Settings.
• LHMI messages are shown in Courier font.
To save the changes in non-volatile memory, select Yes and press .
• Parameter names are shown in italics.
The function can be enabled and disabled with the Operation setting.
• Parameter values are indicated with quotation marks.
The corresponding parameter values are "On" and "Off".
• IED input/output messages and monitored data names are shown in Courier font.
When the function starts, the START output is set to TRUE.
1MRS757824 C Section 1
Introduction
Recloser Protection and Control RER615 7
Point List Manual

1.4.3 Functions, codes and symbols
All available functions are listed in the table. All of them may not be applicable to
all products.
Table 1: Functions included in the relay
Function IEC 61850 IEC 60617 IEC-ANSI
Protection
Three-phase non-directional
overcurrent protection, low stage,
instance 1
FPHLPTOC1 3I> (1) 51P-1 (1)
Three-phase non-directional
overcurrent protection, high stage,
instance 1
PHHPTOC1 3I>> (1) 51P-2 (1)
Three-phase non-directional
overcurrent protection,
instantaneous stage, instance 1
PHIPTOC1 3I>>> (1) 50P/51P (1)
Three-phase directional overcurrent
protection, low stage, instance 1 FDPHLPDOC1 3I> -> (1) 67-1 (1)
Three-phase directional overcurrent
protection, low stage, instance 2 FDPHLPDOC2 3I> -> (2) 67-1 (2)
Three-phase directional overcurrent
protection, high stage, instance 1 DPHHPDOC1 3I>> -> (1) 67-2 (1)
Non-directional earth-fault
protection, low stage, instance 1 FEFLPTOC1 Io> (1) 51N-1 (1)
Non-directional earth-fault
protection, high stage, instance 1 EFHPTOC1 Io>> (1) 51N-2 (1)
Non-directional earth-fault
protection, instantaneous stage,
instance 1
EFIPTOC1 Io>>> (1) 50N/51N (1)
Directional earth-fault protection, low
stage, instance 1 FDEFLPDEF1 Io> -> (1) 67N-1 (1)
Directional earth-fault protection, low
stage, instance 2 FDEFLPDEF2 Io> -> (2) 67N-1 (2)
Directional earth-fault protection,
high stage, instance 1 DEFHPDEF1 Io>> -> (1) 67N-2 (1)
Transient/intermittent earth-fault
protection, instance 1 INTRPTEF1 Io> -> IEF (1) 67NIEF (1)
Admittance based earth-fault
protection, instance 1 EFPADM1 Yo> -> (1) 21YN (1)
Admittance based earth-fault
protection, instance 2 EFPADM2 Yo> -> (2) 21YN (2)
Admittance based earth-fault
protection, instance 3 EFPADM3 Yo> -> (3) 21YN (3)
Wattmetric based earth-fault
protection, instance 1 WPWDE1 Po> -> (1) 32N (1)
Wattmetric based earth-fault
protection, instance 2 WPWDE2 Po> -> (2) 32N (2)
Wattmetric based earth-fault
protection, instance 3 WPWDE3 Po> -> (3) 32N (3)
Table continues on next page
Section 1 1MRS757824 C
Introduction
8Recloser Protection and Control RER615
Point List Manual

Function IEC 61850 IEC 60617 IEC-ANSI
Harmonics based earth-fault
protection, instance 1 HAEFPTOC1 Io>HA (1) 51NHA (1)
Negative-sequence overcurrent
protection, instance 1 NSPTOC1 I2> (1) 46 (1)
Negative-sequence overcurrent
protection, instance 2 NSPTOC2 I2> (2) 46 (2)
Phase discontinuity protection,
instance 1 PDNSPTOC1 I2/I1> (1) 46PD (1)
Residual overvoltage protection,
instance 1 ROVPTOV1 Uo> (1) 59G (1)
Residual overvoltage protection,
instance 2 ROVPTOV2 Uo> (2) 59G (2)
Three-phase undervoltage
protection, instance 1 PHPTUV1 3U< (1) 27 (1)
Three-phase undervoltage
protection, instance 2 PHPTUV2 3U< (2) 27 (2)
Three-phase undervoltage
protection, instance 3 PHPTUV3 3U< (3) 27 (3)
Three-phase overvoltage protection,
instance 1 PHPTOV1 3U> (1) 59 (1)
Three-phase overvoltage protection,
instance 2 PHPTOV2 3U> (2) 59 (2)
Three-phase overvoltage protection,
instance 3 PHPTOV3 3U> (3) 59 (3)
Positive-sequence undervoltage
protection, instance 1 PSPTUV1 U1< (1) 47U+ (1)
Negative-sequence overvoltage
protection, instance 1 NSPTOV1 U2> (1) 47O- (1)
Frequency protection, instance 1 FRPFRQ1 f>/f<,df/dt (1) 81 (1)
Frequency protection, instance 2 FRPFRQ2 f>/f<,df/dt (2) 81 (2)
Three-phase thermal protection for
feeders, cables and distribution
transformers, instance 1
T1PTTR1 3Ith>F (1) 49F (1)
Circuit breaker failure protection,
instance 1 CCBRBRF1 3I>/Io>BF (1) 51BF/51NBF (1)
Three-phase inrush detector,
instance 1 INRPHAR1 3I2f> (1) 68 (1)
Master trip, instance 1 TRPPTRC1 Master Trip (1) 94/86 (1)
Master trip, instance 2 TRPPTRC2 Master Trip (2) 94/86 (2)
Multi-purpose protection, instance 1 MAPGAPC1 MAP (1) MAP (1)
Multi-purpose protection, instance 2 MAPGAPC2 MAP (2) MAP (2)
Multi-purpose protection, instance 3 MAPGAPC3 MAP (3) MAP (3)
Multi-purpose protection, instance 4 MAPGAPC4 MAP (4) MAP (4)
Multi-purpose protection, instance 5 MAPGAPC5 MAP (5) MAP (5)
Multi-purpose protection, instance 6 MAPGAPC6 MAP (6) MAP (6)
Fault locator, instance 1 SCEFRFLO1 FLOC (1) 21FL (1)
Table continues on next page
1MRS757824 C Section 1
Introduction
Recloser Protection and Control RER615 9
Point List Manual

Function IEC 61850 IEC 60617 IEC-ANSI
Power quality
Current total demand distortion,
instance 1 CMHAI1 PQM3I (1) PQM3I (1)
Voltage total harmonic distortion,
instance 1 VMHAI1 PQM3U (1) PQM3V (1)
Voltage variation, instance 1 PHQVVR1 PQMU (1) PQMV (1)
Voltage unbalance, instance 1 VSQVUB1 PQUUB (1) PQVUB (1)
Control
Circuit-breaker control, instance 1 CBXCBR1 I <-> O CB (1) I <-> O CB (1)
Disconnector position indication,
instance 1 DCSXSWI1 I <-> O DC (1) I <-> O DC (1)
Disconnector position indication,
instance 2 DCSXSWI2 I <-> O DC (2) I <-> O DC (2)
Earthing switch indication, instance 1 ESSXSWI1 I <-> O ES (1) I <-> O ES (1)
Earthing switch indication, instance 2 ESSXSWI2 I <-> O ES (2) I <-> O ES (2)
Autoreclosing, instance 1 DARREC1 O -> I (1) 79 (1)
Synchronism and energizing check,
instance 1 SECRSYN1 SYNC (1) 25 (1)
Condition monitoring and supervision
Circuit-breaker condition monitoring,
instance 1 SSCBR1 CBCM (1) CBCM (1)
Trip circuit supervision, instance 1 TCSSCBR1 TCS (1) TCM (1)
Trip circuit supervision, instance 2 TCSSCBR2 TCS (2) TCM (2)
Fuse failure supervision, instance 1 SEQRFUF1 FUSEF (1) 60 (1)
Runtime counter for machines and
devices, instance 1 MDSOPT1 OPTS (1) OPTM (1)
Voltage presence, instance 1 PHSVPR1 PHSVPR(1) PHSVPR(1)
Measurement
Disturbance recorder, instance 1 RDRE1 DR (1) DFR (1)
Three-phase current measurement,
instance 1 CMMXU1 3I (1) 3I (1)
Sequence current measurement,
instance 1 CSMSQI1 I1, I2, I0 (1) I1, I2, I0 (1)
Residual current measurement,
instance 1 RESCMMXU1 Io (1) In (1)
Three-phase voltage measurement,
instance 1 VMMXU1 3U (1) 3V (1)
Three-phase voltage measurement,
instance 2 VMMXU2 3U (B) (1) 3V (B) (1)
Sequence voltage measurement,
instance 1 VSMSQI1 U1, U2, U0 (1) V1, V2, V0 (1)
Sequence voltage measurement,
instance 2 VSMSQI2 U1, U2, U0 (B) (1) V1, V2, V0 (B) (1)
Three-phase power and energy
measurement, instance 1 PEMMXU1 P, E (1) P, E (1)
Table continues on next page
Section 1 1MRS757824 C
Introduction
10 Recloser Protection and Control RER615
Point List Manual

Function IEC 61850 IEC 60617 IEC-ANSI
Frequency measurement, instance 1 FMMXU1 f (1) f (1)
Load profile, instance 1 LDPMSTA1 LOADPROF (1) LOADPROF (1)
Other
Minimum pulse timer (2 pcs),
instance 1 TPGAPC1 TP (1) TP (1)
Minimum pulse timer (2 pcs),
instance 2 TPGAPC2 TP (2) TP (2)
Minimum pulse timer (2 pcs, second
resolution), instance 1 TPSGAPC1 TPS (1) TPS (1)
Minimum pulse timer (2 pcs, minute
resolution), instance 1 TPMGAPC1 TPM (1) TPM (1)
Pulse timer (8 pcs), instance 1 PTGAPC1 PT (1) PT (1)
Pulse timer (8 pcs), instance 2 PTGAPC2 PT (2) PT (2)
Time delay off (8 pcs), instance 1 TOFGAPC1 TOF (1) TOF (1)
Time delay off (8 pcs), instance 2 TOFGAPC2 TOF (2) TOF (2)
Time delay on (8 pcs), instance 1 TONGAPC1 TON (1) TON (1)
Time delay on (8 pcs), instance 2 TONGAPC2 TON (2) TON (2)
Set reset (8 pcs), instance 1 SRGAPC1 SR (1) SR (1)
Set reset (8 pcs), instance 2 SRGAPC2 SR (2) SR (2)
Move (8 pcs), instance 1 MVGAPC1 MV (1) MV (1)
Move (8 pcs), instance 2 MVGAPC2 MV (2) MV (2)
Generic control point (16 pcs),
instance 1 SPCGGIO1 SPCGGIO (1) SPCGGIO (1)
Generic control point (16 pcs),
instance 2 SPCGGIO2 SPCGGIO (2) SPCGGIO (2)
Remote generic control points,
instance 1 SPCRGGIO1 SPCRGGIO (1) SPCRGGIO (1)
Local generic control points,
instance 1 SPCLGGIO1 SPCLGGIO (1) SPCLGGIO (1)
Generic up-down counters, instance 1 UDFCNT1 UDCNT (1) UDCNT (1)
Generic up-down counters, instance 2 UDFCNT2 UDCNT (2) UDCNT (2)
Generic up-down counters, instance 3 UDFCNT3 UDCNT (3) UDCNT (3)
1MRS757824 C Section 1
Introduction
Recloser Protection and Control RER615 11
Point List Manual

12

Section 2 IEC 60850-5-101/104 data mappings
2.1 Overview
This document describes the IEC 60870-5-101/IEC 60870-5-104 data points and
structures available in the IED. The point lists describe a superset of all data
available through the standard configuration/s. The tables show the default point
definitions. All these data can be freely remapped in which case PCM600 can
provide an updated point list export of the new outlook.
2.2 Supported functions in RER615
Table 2: Supported functions
Function IEC 61850 A D
RE01 RE02
Protection1)2)
Three-phase non-directional overcurrent protection, low stage FPHLPTOC (1)3) (1)3)
Three-phase non-directional overcurrent protection, high stage PHHPTOC (1)3) (1)3)
Three-phase non-directional overcurrent protection, instantaneous stage PHIPTOC 1 1
Three-phase directional overcurrent protection, low stage FDPHLPDOC (2)3) (2)3)
Three-phase directional overcurrent protection, high stage DPHHPDOC (1)3) (1)3)
Non-directional earth-fault protection, low stage FEFLPTOC (1)4)5) (1)4)5)
Non-directional earth-fault protection, high stage EFHPTOC (1)4)5) (1)4)5)
Non-directional earth-fault protection, instantaneous stage EFIPTOC 15) 15)
Directional earth-fault protection, low stage FDEFLPDEF (2)5)6)7) (2)5)6)7)
Directional earth-fault protection, high stage DEFHPDEF (1)5)6)7) (1)5)6)7)
Transient / intermittent earth-fault protection INTRPTEF (1)5)6)7) (1)5)6)7)
Admittance based earth-fault protection EFPADM (3)5)7)8) (3)5)7)8)
Wattmetric based earth-fault protection WPWDE (3)5)7)8) (3)5)7)8)
Harmonics based earth-fault protection HAEFPTOC (1)5)8) (1)5)8)
Negative-sequence overcurrent protection NSPTOC 2 2
Phase discontinuity protection PDNSPTOC 1 1
Residual overvoltage protection ROVPTOV (1)7) (2)9)10)
Three-phase undervoltage protection PHPTUV (3) (3)11)
Three-phase overvoltage protection PHPTOV (3) (3)11)
Positive-sequence undervoltage protection PSPTUV (1) (1)
Table continues on next page
1MRS757824 C Section 2
IEC 60850-5-101/104 data mappings
Recloser Protection and Control RER615 13
Point List Manual

Function IEC 61850 A D
RE01 RE02
Negative-sequence overvoltage protection NSPTOV (1) (1)
Frequency protection FRPFRQ (2) (2)
Three-phase thermal protection for feeders, cables and distribution transformers T1PTTR 1 1
Circuit breaker failure protection CCBRBRF 1 1
Three-phase inrush detector INRPHAR 1 1
Master trip TRPPTRC 2 2
Multi-purpose protection MAPGAPC 6 6
Fault locator SCEFRFLO (1) (1)
Power quality
Current total demand distortion CMHAI (1) (1)
Voltage total harmonic distortion VMHAI (1) (1)
Voltage variation PHQVVR (1) (1)
Voltage unbalance VSQVUB (1) (1)
Control
Circuit-breaker control CBXCBR 1 1
Disconnector position indication DCSXSWI 2 2
Earthing switch indication ESSXSWI 2 2
Autoreclosing DARREC 1 1
Synchronism and energizing check SECRSYN 1
Condition monitoring and supervision
Circuit-breaker condition monitoring SSCBR 1 1
Trip circuit supervision TCSSCBR 2 2
Fuse failure supervision SEQRFUF 1 1
Runtime counter for machines and devices MDSOPT 1 1
Voltage presence PHSVPR 1 1
Measurement
Disturbance recorder RDRE 1 1
Three-phase current measurement CMMXU 1 1
Sequence current measurement CSMSQI 1 1
Residual current measurement RESCMMXU 1 1
Three-phase voltage measurement VMMXU 1 1(2)12)
Sequence voltage measurement VSMSQI 1 1(2)12)
Three-phase power and energy measurement PEMMXU 1 1
Frequency measurement FMMXU 1 1
Load profile LDPMSTA 1 1
Other
Minimum pulse timer (2 pcs) TPGAPC 2 2
Minimum pulse timer (2 pcs, second resolution) TPSGAPC 1 1
Minimum pulse timer (2 pcs, minute resolution) TPMGAPC 1 1
Table continues on next page
Section 2 1MRS757824 C
IEC 60850-5-101/104 data mappings
14 Recloser Protection and Control RER615
Point List Manual
