ABB Relion REB500 User manual

RELION® REB500
Distributed busbar protection REB500
Version 8.3 IEC
Communication protocol manual
IEC60870-5-103



 

  
a

=
I
;
D


e






-
  

 




 

  
a

=
I
;
D


e






-
  

 
Document ID: 1MRK 511 451-UEN
Issued: May 2019
Revision: B
Product version: 8.3
© Copyright 2019 ABB. All rights reserved

Copyright
This document and parts thereof must not be reproduced or copied without written
permission from ABB, and the contents thereof must not be imparted to a third party, nor
used for any unauthorized purpose.
The software and hardware described in this document is furnished under a license and may
be used or disclosed only in accordance with the terms of such license.
This product includes software developed by the OpenSSL Project for use in theOpenSSL
Toolkit. (http://www.openssl.org/) This product includes cryptographicsoftware written/
developed by: Eric Young ([email protected]) and Tim Hudson([email protected]).
Trademarks
ABB and Relion are registered trademarks of the ABB Group. All other brand or product names
mentioned in this document may be trademarks or registered trademarks of their respective
holders.
Warranty
Please inquire about the terms of warranty from your nearest ABB representative.

Disclaimer
The data, examples and diagrams in this manual are included solely for the concept or product
description and are not to be deemed as a statement of guaranteed properties. All persons
responsible for applying the equipment addressed in this manual must satisfy themselves that
each intended application is suitable and acceptable, including that any applicable safety or
other operational requirements are complied with. In particular, any risks in applications where
a system failure and /or product failure would create a risk for harm to property or persons
(including but not limited to personal injuries or death) shall be the sole responsibility of the
person or entity applying the equipment, and those so responsible are hereby requested to
ensure that all measures are taken to exclude or mitigate such risks.
This document has been carefully checked by ABB but deviations cannot be completely ruled
out. In case any errors are detected, the reader is kindly requested to notify the manufacturer.
Other than under explicit contractual commitments, in no event shall ABB be responsible or
liable for any loss or damage resulting from the use of this manual or the application of the
equipment.

Conformity
This product complies with the directive of the Council of the European Communities on the
approximation of the laws of the Member States relating to electromagnetic compatibility
(EMC Directive 2004/108/EC) and concerning electrical equipment for use within specified
voltage limits (Low-voltage directive 2006/95/EC). This conformity is the result of tests
conducted by ABB in accordance with the product standards EN 50263 and EN 60255-26 for
the EMC directive, and with the product standards EN 60255-1 and EN 60255-27 for the low
voltage directive. The product is designed in accordance with the international standards of
the IEC 60255 series.

Table of contents
Section 1 Introduction.................................................................................................... 3
1.1 This manual....................................................................................................................................3
1.2 Intended audience........................................................................................................................3
1.3 Product documentation.............................................................................................................. 3
1.4 Symbols and conventions........................................................................................................... 3
1.4.1 Symbols........................................................................................................................................ 3
1.4.2 Document conventions............................................................................................................. 4
Section 2 Safety information.........................................................................................5
Section 3 Interbay bus functions...................................................................................7
3.1 Introduction................................................................................................................................... 7
3.2 Basic configuration...................................................................................................................... 7
3.3 Configuring IEC 60870-5-103 IBB............................................................................................ 10
3.4 Transfer of differential current values....................................................................................11
3.4.1 The delta/dead band algorithm.............................................................................................11
3.4.2 Configuring the SCS differential current parameter.........................................................12
Section 4 IEC60870-5-103.............................................................................................15
4.1 Introduction................................................................................................................................. 15
4.2 General functions........................................................................................................................15
4.3 Disturbance recorder................................................................................................................. 17
4.4 ACC actual channel..................................................................................................................... 18
4.5 Generic REB500 functions........................................................................................................ 19
4.5.1 Diagnostic information........................................................................................................... 19
4.5.2 Status information................................................................................................................... 21
4.5.3 Entries for single-point indications......................................................................................22
4.5.4 Entries for double-point indications ................................................................................... 23
4.5.5 Display of busbar differential currents................................................................................24
4.6 Special information and instructions for configuring the control system.....................26
Table of contents
Distributed busbar protection REB500 1
Communication protocol manual IEC60870-5-103
© Copyright 2019 ABB. All rights reserved

2

Section 1 Introduction
1.1 This manual
GUID-FD38FA69-DDD6-40C9-9185-7AC9C894B6C6 v1
The communication protocol manual describes a communication protocol supported by the
IED. The manual concentrates on vendor-specific implementations.
1.2 Intended audience
GUID-ACC7A898-5907-41E1-8DDD-DD8591298668 v1
This manual addresses the communication system engineer or system integrator responsible
for pre-engineering and engineering for communication setup in a substation from an IED
perspective.
The system engineer or system integrator must have a basic knowledge of communication in
protection and control systems and thorough knowledge of the specific communication
protocol.
1.3 Product documentation
GUID-91F0A03F-D1AF-4695-A239-1FC87E7459EE v2
REB500 manuals Document numbers
Product guide 1MRK 505 402-BEN
Application manual 1MRK 505 399-UEN
Technical manual 1MRK 505 400-UEN
Operation manual 1MRK 500 132-UEN
Engineering manual 1MRK 511 452-UEN
Commissioning manual 1MRK 505 401-UEN
Application manual for bay protection functions 1MRK 505 403-UEN
Technical manual for bay protection functions 1MRK 505 406-UEN
Cyber security deployment guideline 1MRK 511 453-UEN
Communication protocol manual IEC61850 1MRK 511 450-UEN
Communication protocol manual IEC60870-5-103 1MRK 511 451-UEN
Getting started guide 1MRK 505 404-UEN
1.4 Symbols and conventions
1.4.1 Symbols GUID-4F7DD10A-DEE5-4297-8697-B8AAB5E3262F v2
The electrical warning icon indicates the presence of a hazard which could
result in electrical shock.
1MRK 511 451-UEN B Section 1
Introduction
Distributed busbar protection REB500 3
Communication protocol manual IEC60870-5-103
© Copyright 2019 ABB. All rights reserved

The warning icon indicates the presence of a hazard which could result in
personal injury.
The caution icon indicates important information or warning related to the
concept discussed in the text. It might indicate the presence of a hazard which
could result in corruption of software or damage to equipment or property.
The information icon alerts the reader of important facts and conditions.
The tip icon indicates advice on, for example, how to design your project or
how to use a certain function.
Although warning hazards are related to personal injury, it is necessary to understand that
under certain operational conditions, operation of damaged equipment may result in
degraded process performance leading to personal injury or death. Therefore, comply fully
with all warning and caution notices.
1.4.2 Document conventions GUID-37C3ACF4-BD79-43C6-B37E-24B38EE69301 v2
A particular convention may not be used in this manual.
• Abbreviations and acronyms in this manual are spelled out in the glossary. The glossary
also contains definitions of important terms.
• Push button navigation in the LHMI menu structure is presented by using the push button
icons.
For example, to navigate the options, use and .
• HMI menu paths are presented in bold.
For example, select Main menu/Settings.
• Signal names are presented in bold.
The signal 21120_EXT_TEST_TRIP can be set and reset via the LHMI Test Trip menu.
• Parameter names and parameter values are presented in italics.
For example, the default value of the
Operation setting is Not inverted .
• Section references are presented with the respective section numbers.
For example, see Section 1.4.2 for more details about document conventions.
Section 1 1MRK 511 451-UEN B
Introduction
4Distributed busbar protection REB500
Communication protocol manual IEC60870-5-103
© Copyright 2019 ABB. All rights reserved

Section 2 Safety information
GUID-7CDA9FB7-5CD6-4BD5-A1D2-AAB8E7BF87A3 v2
Dangerous voltages can occur on the connectors, even though the auxiliary
voltage has been disconnected.
Non-observance can result in death, personal injury or substantial property
damage.
Only a competent electrician is allowed to carry out the electrical installation.
National and local electrical safety regulations must always be followed.
The frame of the IEDs has to be carefully earthed.
Whenever changes are made in the IEDs, measures should be taken to avoid
inadvertent tripping.
The IEDs contain components which are sensitive to electrostatic discharge.
Unnecessary touching of electronic components must therefore be avoided.
1MRK 511 451-UEN B Section 2
Safety information
Distributed busbar protection REB500 5
Communication protocol manual IEC60870-5-103
© Copyright 2019 ABB. All rights reserved

6

Section 3 Interbay bus functions
GUID-FC8C1289-F943-4E92-A50E-BDA7281A5337 v1
3.1 Introduction
GUID-7A41F2A2-F366-4D30-9D76-BB6279380110 v2
An interface is available for connecting the numerical busbar protection to a station
automation system or station monitoring system (SCS/SMS).
For an overview of REB500’s communication interfaces, see the Operation manual .
In contrast to feeder control and protection bay units, REB500 is equipped with only a single
interbay bus interface via which all the REB500 bay units in the entire station communicate.
This has to be taken into account by the various bus protocols.
This document applies for IEC60870-5-103. However, Section 3 of this
document also contains information of a second IBB using IEC61850-8-1 if
configured.
3.2 Basic configuration
GUID-A112B99B-E8BF-4750-8E26-D9C9BD9F6048 v2
The fourth octet in the Data Unit Identification field of an ASDU determines the common
address of ASDU. It normally has to be the same as the station address on the link layer.
Exceptions are permitted where additional common ASDU addresses are needed because of
multiple instances of functions.
In case of REB500, this exception allowed in the IEC recommendation is used to be able to
address the Central Unit and the Bay Units via a single physical connection.
Common Address of ASDU – CAA
Basic setting:
0 Central Unit
1-60 Bay Units
255 Global address
The dialog for configuring the communication is accessed by selecting HMI500
Configuration/Communication/SCS Configuration.
1MRK 511 451-UEN B Section 3
Interbay bus functions
Distributed busbar protection REB500 7
Communication protocol manual IEC60870-5-103
© Copyright 2019 ABB. All rights reserved

14000051-IEC18000623-1-en.vsdx
IEC18000623 V1 EN-US
Figure 1: Dialog box for configuring the communication
If Common Link Layer Address of the SCS Configuration is selected:
The link address can be setup in this dialog box. The Common Address of ASDU (CAA) for all
units is setup in the CAA Setting dialog box by pressing the Addr. Setting button.
Table 1: Configuration of IEC60870-5-103
Setting Description Default setting
Common Link layer
address
Link layer address used for all Units in
common
1
Baud Rate Baud rate 9600
Addr. Setting Individual Common Address of ASDU for
each Bay Unit
0 Central Unit
1-60 Bay Units
Section 3 1MRK 511 451-UEN B
Interbay bus functions
8Distributed busbar protection REB500
Communication protocol manual IEC60870-5-103
© Copyright 2019 ABB. All rights reserved

15000029-IEC18000624-1-en.vsdx
IEC18000624 V1 EN-US
Figure 2: Dialog box for configuring CAA
Table 2: Configuration of IEC60870-5-103
Setting Description Default setting
CAA Individual Common Address of ASDU for
each Bay Unit
0 Central Unit
1-60 Bay Units
If Common Link Layer Address of the SCS Configuration is not selected:
The link address and the Common Address of ASDU (CAA) for all units is setup in the CAA
Setting dialog box by pressing the Addr. Setting button.
1MRK 511 451-UEN B Section 3
Interbay bus functions
Distributed busbar protection REB500 9
Communication protocol manual IEC60870-5-103
© Copyright 2019 ABB. All rights reserved

15000030-IEC18000625-1-en.vsdx
IEC18000625 V1 EN-US
Figure 3: Dialog box for configuring CAA and LLA
Table 3: Configuration of IEC 870-5-103
Setting Description Default setting
CAA Individual Common Address of ASDU for
each Bay Unit
0 Central Unit
1-60 Bay Units
LLA Individual Link Address for each Bay Unit 0 Central Unit
1-60 Bay Units
3.3 Configuring IEC 60870-5-103 IBB
GUID-605B1ACD-79EB-4C0A-8839-331FD573E41B v1
For changes in status generated by REB500 to be transferred as events to an SCS/SMS, the
corresponding signals must be configured by selecting them in HMI500 Configuration/Binary
module and making the settings in the Event configuration section of the Details dialog box.
To which IBB an event is sent is determined by selecting the appropriate check box IBB 1 or IBB
2 when configuring the signal.
As the 61850 model is implemented as defined by the standard, no custom assignments can
be made for the IBB associated with 61850.
Section 3 1MRK 511 451-UEN B
Interbay bus functions
10 Distributed busbar protection REB500
Communication protocol manual IEC60870-5-103
© Copyright 2019 ABB. All rights reserved

13000024-IEC18000608-1-en.vsdx
IEC18000608 V1 EN-US
Figure 4: Configuring signals as events
Diagnostic and system events are always available for transfer whichever protocol is in use
and cannot be configured.
The IEC 60870-5-103 section only appears when the protocol is configured.
3.4 Transfer of differential current values
3.4.1 The delta/dead band algorithm GUID-85BE2C1A-DD67-4564-99E1-CF504CBD06D7 v1
To keep the load on the IBB as low as possible, the bus zone differential currents are checked
cyclically, but only actually transferred via the bus if the value has changed.
Diff.
Current
Values transferred
to the SCS
Zero limit
0100 200
12000189-IEC18000308-1-en.vsd
IEC18000308 V1 EN-US
Figure 5: Transmitted values and the zero limit
To stabilize the display during normal operation, differential currents below the zero limit
(dead band) count as zero and are transferred as such.
1MRK 511 451-UEN B Section 3
Interbay bus functions
Distributed busbar protection REB500 11
Communication protocol manual IEC60870-5-103
© Copyright 2019 ABB. All rights reserved

Providing the condition for transmitting a current value is fulfilled, all the differential currents
belonging to the respective zone are sent to the SCS/SMS.
sum = sum + |current – last|
if sum > delta then
sum = 0
if current < deadband then
current = 0
endif
send current
endif
last = current
The system continuously performs the above algorithm: It adds up the absolute difference
between the last two measurements (current and last) since the last status update was sent
(sum).
As soon as sum is greater than the threshold delta a new event will be sent with the current
value. If this value is below the deadband threshold, the value 0 will be sent instead.
3.4.2 Configuring the SCS differential current parameter
GUID-DF29CA42-6DDD-459D-A610-175B597D83C9 v2
The precise conditions for sending differential currents to the SCS can be set by selecting
HMI500 Settings/Communication/SCS Diff. Current Parameters.
12000190-IEC18000536-1-en.vsdx
IEC18000536 V1 EN-US
Figure 6: Settings/Communication/SCS Diff. Current Parameters
Settings in this dialog box are made for each busbar section (bus zone) and can be changed
after activating the respective field. The differential current parameters are as follows:
Table 4: SCS differential current parameters
Item Description Min. Max. Default Step Unit
Update
period
Determines how often the differential
current measurement has to be
updated.
0 1000 60 100 s
Enabled Enables polling of the bus zone
differential currents.
yes no Yes
Delta
L1_L2_L3
Applies to all bus zones. Delta per bus
zone for phases L1, L2 and L3.
0 65535 10 1 A
Table continues on next page
Section 3 1MRK 511 451-UEN B
Interbay bus functions
12 Distributed busbar protection REB500
Communication protocol manual IEC60870-5-103
© Copyright 2019 ABB. All rights reserved

Item Description Min. Max. Default Step Unit
Dead band
L1_L2_L3
Dead band per bus zone for phases
L1, L2 and L3.
0 65535 5 1 A
Delta L0 Delta per bus zone for the neutral
current L0.
0 65535 10 1 A
Dead band L0 Dead Band per bus zone for the
neutral current L0
0 65535 5 1 A
Delta and Dead band settings that are too low, result in a high data load on the
bus. For this reason, care should be taken to set reasonable values.
1MRK 511 451-UEN B Section 3
Interbay bus functions
Distributed busbar protection REB500 13
Communication protocol manual IEC60870-5-103
© Copyright 2019 ABB. All rights reserved

14
