Abode GR10 User manual

Important Technical Data
Whilst every effort has been made to make these instructions comprehensive they may not be exhaustive, and
we strongly recommend that this product is installed by a skilled professional. This will ensure the best possible
finished installation.
This product is made from a mixture of acrylic resin and aggregate particles for the greatest possible durability,
after the end of the lifecycle of this product it should be disposed of responsibly.
Earth bonding: under current IEE regulations there is no statutory re uirement to earth bond sinks as most new
wiring installations are protected with an RCD. If you are unsure whether your wiring is protected by an RCD,
contact a ualified electrician.
Maximum temperature 280°C* Note: If this temperature is exceeded, even for short periods, damage to the
finish can result.
Waste disposers should be mounted in such a way that the weight of the unit is supported by the kitchen
cabinet carcass, not just the sink. Faulty or damaged waste disposal units can cause vibration – this will
damage the sink and can loosen connecting pipework or fixings causing water leaks.
All Abode products are designed in accordance with recognised European or global standards. Please ensure
that your Abode product is fitted in accordance with localised legislation.
The installation should be periodically checked for damage to water sealing parts as described in the
instructions to avoid accidental water damage.
Abode is a registered trademark of Abode Home Products Limited. All errors and omissions excepted.
A full technical specification and copies of these instructions are available for this product on our website.
www.abode.eu
Manufacturers Product Reference
©Abode
AX4014 v1 – 06/2013
Abode Home Products Limited, Unit L, Zenith Park, Whaley Road, Barnsley, S75 1HT.
Tel: [phone] Fax: [phone]
www.abode.eu
All errors and omissions excepted.
Please retain these instructions with the sink for future reference
Abode Home Products Ltd.
Sovereign House, 51 High
Street, Wetherby, LS22 6LR
EN13310:2003 (13)
Domestic kitchen sink made of
Granite & Acrylic composite
Cleanability: pass
Load
resistance:
NPD / NA
(applies to wall
hung sinks only)
Durability: pass
Composite Inset/ Undermount Sink
10 Year Warranty
Terms and Conditions
In the unlikely event that you should experience any defect in
the materials or workmanship of your new Abode sink within 10
years of purchase, the manufacturer will repair or replace all or
any part of the product that is defective, at their discretion. The
manufacturer will not be responsible for any other conse uential
costs such as labour, removal or reinstallation of the sink or any
other connected or related products.
This is provided that the product has been used for normal
domestic purposes in the UK & Eire, and that the care,
installation and maintenance instructions have been observed.
The warranty extends to the original purchaser only. You should
retain a copy of your dated invoice as proof of purchase to
validate any claims under this guarantee.
Please note that this product is manufactured using natural
materials so slight shade variations can occur. Marks, scuffs and
scratches caused during installation or accidental damage are
not covered by this guarantee. Neither are stains, discolouration or
corrosion or any damage or defect caused by incorrect installation
or abuse of the product.
We are continuously improving and developing our range of
products, finishes & colours. Therefore, in the event of a valid claim,
we may not be able to provide an identical replacement for the
defective product throughout the guarantee period. Where an
identical product is no longer available, we will supply the nearest
e uivalent from our then current product range. In assessing your
claim, we must be given the opportunity to inspect the product as
installed prior to removal. Any product returned to us must be
securely packaged and ade uately insured. We will not accept
responsibility for any damage caused during transportation.
No installer, dealer, agent or employee of Abode Home Products
Limited has the authority to modify the obligations or limitations of this
warranty. This warranty does not affect your statutory rights.
Care Instructions for your itchen Sink
To maintain the appearance of this product, ensure that it is regularly cleaned using only a clean, soft damp cloth. A solution of warm
water and a mild liquid non-antibacterial detergent may be used where necessary, and then the product rinsed thoroughly and wiped dry.
Any other cleaning action will invalidate your warranty.
No household or industrial chemicals should come into contact with this product to prevent damage.
To prevent staining or discolouration of the product always rinse the sink with water after use, if you live in a hard water area we suggest
you also wipe the sink dry.
Do not cut, slice or chop directly onto the sink as you may mark the surface finish. Avoid the use of plastic washing up bowls as engrained
grit on the bowl underside may mark the surface finish. Avoid impacting the product with sharp or heavy objects, such as knives, pans or
cooking pots and also avoid contact with abrasives. No hot objects should be placed directly onto the sink surface. Avoid contact with
cycles of very hot and cold substances.
For further care and maintenance advice on removing stubborn marks and more examples of objects or actions likely to artificially shorten
the life of this product please visit our website.
Parts and Contents
ey Description Qty
A Sink (may differ from
model shown) 1
B Overflow pipework 1
C Care & fitting
instructions 1
D Undermount Clips 8
N/A Basket strainer
waste(s) dependant on model
N/A Connecting pipework 1

Installation Instructions
Preparation
1. Take great care when handling this sink, whilst every effort has been taken to remove sharp edges, the
material by nature may be sharp. We recommend wearing gloves accordingly.
2. Check the package for completeness, possible defects or any transport damage before installation
commences. Installed faulty product will not be honoured by the warranty.
3. Check that the supporting carcass and worktop is level left to right and front to back to ensure correct
drainage of water.
4. Check that the surrounding furniture is the correct size and shape to accept this product and that no
plumbing or wiring may foul the installation.
5. If replacing an existing sink, remove this product and clean the surrounding area, ensure the new sink
will suit the existing cut out size and position.
6. Collect the tools you will need to complete this installation. Typically this might include a sprit level,
pencil, straight edge, jigsaw, crosshead screwdriver and small adjustable spanner.
Installation - Inset
5. Install the basket strainer waste kit(s) and overflow according to the manufacturer’s instructions.
6. Clean the cut out perimeter of the worktop underside and the upper perimeter of the sink with a
degreasing cleaning solvent and allow to dry.
7. Apply a continuous generous bead of good uality silicone
onto the rim around the lower perimeter of the sink (fig1).
Fig 1.
8. Gently lay the worksurface onto the sink, carefully align the sink
rim with the cut out shape with e ual spacing on all sides (fig 2).
Where possible apply a 2
nd
bead of silicone around the outside of
the adjoining sink and worktop. Any excess silicone can be cleaned
away using a proprietary silicone cleaner.
Allow the silicone to dry.
Fig 2.
9. Attach the sink connecting pipework to the waste kit(s) according to the manufacturer’s instructions.
1. Before creating the cut out in the worktop, carefully plan the positioning of the sink. Ensure that the
position of the bowl(s), tap and overflows will not interfere with surrounding units or appliances. The cut out
details are published on the included specification sheet and on www.abode.eu to ensure perfect
positioning of this product.
2. Carefully mark out the cut out using the provided technical drawing. Create the sink cut out in the worktop
using a router or CNC cutter, follow the manufacturer’s instructions taking care not to chip, crack or
scratch the worktop. If preparing the cut out in situ cover any open pipework to avoid any debris
contaminating the water supply feeds.
3. Choose the tap-hole position(s) based on the bowl and drainer orientation. Drill the re uired part scored
top-hole(s) completely through the sink using a power drill and 35mm (1 3/8”) hole saw. Support around
the tap hole area whilst drilling slowly and carefully from the underside of the sink, do not use a hammer
setting. Note: Our recommendation would be to use a diamond tipped hole or dusted saw due to the
toughness of the material.
4. Install the tap to the worktop or sink according to the manufacturer’s instructions. Ensure the tap is secure
as later access may be obstructed by the sink or plumbing. We recommend using long flexible tap
connectors to help.
Installation – Undermount (Tap deck exposed or hidden)
1. Follow steps 1 – 6 on the Inset instructions
2. Drill holes under work surface according to the technical
drawings provided. A wooden surface re uires an 8 diameter
hole, and a granite surface re uires a 10 diameter hole.
3. Use a proxy two part resin to fill the hole for the granite
surface. Push in insert when wet. Avoid glue on insert internal
thread. For the wooden surface just screw the threaded
inserts straight in.
4. Apply a generous continuous bead of silicone into the
channel around the top perimeter of the sink
5. Fix the sink to the worktop by tightening the screw on the
fixing clips clockwise using a crosshead screwdriver, the sink
frame will pull up tight and flat to the bottom surface to the
worktop.
Tighten the clips fully in an order similar to (fig 3). to ensure the
sink does not skew or rotate whilst it is fixed. Position the sink with
the clips loosely tight, and then finely adjust the position of the
sink before tightening them fully.
Do not use an electric screwdriver, this will over tighten the
screws and could damage the clips or sink.
Fig 3.
After installation
1. Clean the sink using the attached care advice ready for use.
2. Check the sink is flat to the worktop, straight and level; pour a small amount of water onto the drainer (if
applicable) to check for drainage.
3. Close the plug(s) in all bowls, fill the sink with water below the overflow and check the water does not leak through
or around the waste(s).
4. Close the plug(s) in all bowls fill the sink with water above the overflow, check the water exits though the overflow
and does not leak from the overflow system.
5. Open the plug(s) and let water drain from the bowls, check the connecting pipework does not leak.
6. If the sink is not to be used for a period after installation, cover the sink and tap to protect them from accidental
damage during further surrounding installation work.
7. We recommend once fully set, the silicone seal should be checked for water tightness and rechecked periodically.
