Abode Storm Slimline AB2427 User manual

Important Technical Data:
Minimum water pressure: AB2427 = 0.4 bar ( o flow limiter) 0.5 bar (With flow limiter)
Maximum operating pressure 5 bar*
Maximum recommended hot water temperature 70°C
* ote: If these pressures or temperatures are exceeded, even for short periods, damage can result.
In these instances a pressure reducing valve or TMV should be installed.
For manual mixing products we recommend the installation of a separate TMV2 product to reduce
the risk of accidental scalding.
All thermostatic products should be tested and cleaned at least once a year.
When drilling or preparing walls take care not to disturb existing water or electrical supplies that may
be buried within the wall.
Supply pipes should maintain the maximum diameter until immediately before the fitting.
Hot and cold supply pressures should be as closely balanced as possible for best results. The
differential between the hot and cold water supply temperatures should be sufficient to allow correct
mixing function.
Where hot and cold supply pressures are greatly imbalanced flow restricting valves or pressure
reducing valves should be installed on the supply with the greater incoming pressure.
Abode products are either WRAS approved or manufactured in accordance with recognised
European standards. Please ensure that your Abode product is fitted in accordance with Local
Water Byelaws. Where hot and cold water mix within any product, then suitable non return valves
should be installed to the hot and cold supplies to prevent backflow.
Whilst assembling this product take care not to accidentally loosen any screwed assemblies. PTFE
tape can be used to ensure watertight joins on threaded connections, do not over tighten
connections or allow pipes to be twisted or folded.
The installation should be periodically checked for damage, if the property is left unattended for a
prolonged period we recommend isolating water supplies.
Manufacturers Reference
©Abode 09/2017
Unit L, Zenith Park, Whaley Road, Barnsley,S75 1HT.
Tel: [phone] Fax: [phone]
www.abodedesigns.co.uk
Storm Slimline 3mm Wall Mounted Showerhead
5 Year Warranty Terms & Conditions:
In the unlikely event that you should
experience any defect in the materials or
workmanship of your new Abode product within
FIVE years of purchase, the purchaser’s sole
remedy shall be the replacement (at the
manufacturer’s discretion) of all or any part of
the product that is defective. Valves are
guaranteed for a period of FIVE years from
purchase. Decorative surface finishes and O-
rings are guaranteed for O E year from the
date of purchase provided that our advice
concerning care has been observed and no
scouring agents have been used.
This is provided that the product has been
used for normal domestic purposes in the UK
and that the care, installation and maintenance
instructions have been observed. The warranty
extends to the original purchaser only. You
should retain a copy of your dated invoice as
proof of purchase to validate any claims under
this warranty.
Marks and scratches caused by improper
installation or accidental damage are not
covered by this guarantee. either are shade
variations or any damage or defect caused by
incorrect installation or abuse of the fitting.
As we are continuously improving and
developing our products range, finishes &
colours, in the event of a valid claim, we may
not be able to provide an identical replacement
for the defective product throughout the
warranty period. Where an identical product is
no longer available, we will supply the nearest
equivalent from our then current product range.
In assessing your claim, we must be given the
opportunity to inspect the product as installed
prior to removal. Any product returns must be
packaged carefully as received and complete.
o other warranties, express or implied, are
made, including merchantability or fitness for a
particular purpose. Under no circumstances
shall the manufacturer be liable for any loss or
damage arising from the purchase, use or
inability to use this product, or for any special,
indirect, incidental or consequential damages.
o liability is accepted for consequential
damage to other household fixtures, fittings or
furnishings arising from this claim, even if
attached to the product. o installer, dealer,
agent or employee of Abode has the authority
to modify the obligations or limitations of this
warranty.
Product Care Instructions:
To maintain the appearance of this product, ensure that it is regularly cleaned only using a clean, soft
damp cloth. A solution of warm water and a mild liquid detergent may be used where necessary, and
then the fitting rinsed thoroughly and wiped dry. Any other cleaning action or cleaning products will
invalidate your warranty.
Abrasive cleaners, scouring cleaners, limescale cleaners and acidic cleaners must not be used
under any circumstances. Avoid contact with all solvents (including chlorinated solvents, ketones or
acetones as these may result in surface deterioration or etching). Also avoid contact with any harsh
household chemicals such as bleach cleaners, drain cleaners, rust removers, paint strippers and
toilet bowl cleaners, toothpaste, mouthwash, bar keepers friend or Brasso.
If the product has a spout aerator it can be unscrewed and cleaned periodically in warm water to
maintain flow. Sprayheads have ‘rub clean’ nozzles to reduce any limescale build up.
Please leave these instructions for your customer.

Installation Pre aration:
All parts should be removed from their packaging and inspected for any transport damage and completeness prior to
installation; you should read these instructions throughout before commencing installation.
We do not accept responsibility for problems that may occur through improper installation. Always ensure you have
sufficient hot and cold water pressure available to allow correct function before specifying or installing this product.
We strongly recommend installing particle filters and isolation valves to both the hot and cold supply pipes in an
accessible position. This will help to prevent premature failure of the any product valves and ease any future
maintenance. All serviceable parts should be given suitable access to allow easy future maintenance.
Shut off your water heating system and ensure that your mains stopcock is closed. Ensure both the hot and cold water
supplies are isolated before commencing installation.
You should ensure that both the product and required fittings will fit into the depth and area of the mounting surface
available before installation. Roughly assemble the product and plumbing connections to establish the required sizes.
Before installing the new fitting it is essential that you thoroughly flush through the su ly i es in order to remove
any remaining solder, swarf or impurities from your system. Failure to carry out this simple procedure could cause
problems or damage to the workings of the fitting and invalidate the warranty.
Prepare the installation hole(s) required to mount the product the hole diameter(s) should be smaller than the product
base and sealing gasket and larger than the size required for the fixings and plumbing connections.
Installation Guidance:
Key
Descri tion
Qty.
Key
Descri tion
Qty.
A Shower body 1 G Rain shower feed pipe 1
B Spread bolt 2 H Flow limiting washer (as supplied) or
mesh filter washer
1
C Small metal washer 2 I ½” Union 1
D Large metal washer 2 J ½” Female 90° backplate elbow 0
E Split washer 2 K 15mm inlet pipe 0
F ut 2 L Wall fixing 0
Note: A red 12 litre flow limiter is fitted between arts (G & H). This can be removed to im rove the flow
rate of the shower at lower ressures.
Installation Instructions:
1. Open the wall out to the required width and depth for supply pipe (K) and elbow (L).
• All serviceable parts should be given suitable access to allow easy future maintenance.
• You should ensure that both the product and required fittings will fit into the depth and area of the
mounting surface available before installation. Roughly assemble the product and plumbing connections
(example ½” union (J) to establish the required sizes ‘A-C’ to allow the ½” union (J) to project from the
finished wall surface.
‘A’ Distance from finished
surface to fixed connector
‘B’ Cavity depth for supply
pipes and fixings
‘C’ Finished hole diameter
2. Fix elbow (J) inlet pipe (K) securely to the wall using appropriate fixings (L). ote these fixings should be secure
enough to allow the attached product to be removed if required.
• Before installing this new connection it is essential that you thoroughly flush through the su ly
i es in order to remove any remaining solder, swarf or impurities from your system. Failure to carry out
this simple procedure could cause problems or damage to the workings of any attached product and
invalidate the warranty.
3. Screw an appropriate sized ½” Union (I) into ½” elbow (J) to suit the fitting depth for shower body (A) connection
size using PTFE tape or sealing compound to ensure a water tight connection.
4. Make good the finished surface using tiles or similar. Ensure back of shower body (A) will cover the finished hole
diameters ‘C’.
5. Mark out two 14mm diameter drill holes (adjust according to surface and fixing type used) for fixing shower body
(A) to tiled wall using spread bolts (B). ote: Use a spirit level to adjust the shower body (A) to ensure it is fixed
horizontally.
6. Screw the shower body (A) to the tiled wall using fittings (B – F) in order shown.
7. Connect shower feed (G) to ½” Union (I) ensuring that flow limiting washer (H) or rubber washer (H) is in place as
shown.
8. Silicone seal around the back section of shower body (A).
After installation:
Once you have visually checked the installation of the new product and all connections, ensure that all other fittings are
closed except the new product which should be left open.
Turn on your water heating system and ensure that your mains stopcock is open. Reconnect both the hot and cold water
supplies to this fitting.
Check the function of flow and function of hot, cold and mixed water though all outlets. If the product has thermostatic
function test the maximum output temperature.
Turn off the product and check carefully for any leaks around all connections on the fitting and adjoining plumbing. If
possible return to the installation after a longer period to double check for slower leaks. If pressure testing equipment is
available check the installation to the maximum recommended pressure.
Clean the product to remove any marks created during installation as instructed, then place a bag over the product to
protect the product finish until it is ready for use.
Check that the product is sealed against water ingress to the mounting surface.
