Abode Tubist Single Lever Pull Out AT2131 User manual

Important Technical Data
Minimum operating pressure 1.0 bar
Maximum operating pressure 5.5 bar*
Maximum hot water temperature 70°C*
Recommended hot water temperature 46°C
ote: If these temperatures or pressures are
exceeded, even for short periods, damage can
result. In these instances a thermostatic mixing
or pressure reducing valve should be installed.
All Abode taps are either WRAS approved or
manufactured in accordance with recognised
European standards. Please ensure that your
Abode Kitchen mixer is fitted in accordance with
Local Water Byelaws.
These installation guidelines have been prepared for your
direction and you must exercise due care at all times. We do not
accept responsibility for problems that may occur through
improper installation. Whilst assembling the tap take care not to
accidentally loosen any screwed assemblies.
Abode is a registered trademark of Abode.
Manufacturers Product Reference
©Abode
12/2019
Unit L, Zenith Park, Whaley Road, Barnsley,S75 1HT.
Tel: [phone] Fax: [phone] www.abodedesigns.co.uk
All errors and omissions excepted.
AT2131
AT2132
Tubist Single Lever Pull Out
5 Year warranty
Terms and Conditions
In the unlikely event that you should experience any
defect in the materials or workmanship of your new
Abode mixer within 5 years of purchase, the purchaser’s
sole remedy shall be the replacement (at the
manufacturer’s discretion) of all or any part of the
product that is defective. All working parts and valves are
guaranteed for a period of 5 years from purchase.
Decorative surface finishes and O-rings are guaranteed
for 1 year from the date of purchase provided that our
advice concerning care has been observed and no
scouring agents have been used. This is provided that the
mixer or tap has been used for normal domestic
purposes and that the care, installation and maintenance
instructions have been observed. The warranty extends
to the original purchaser only.
Marks, scuffs and scratches caused by improper
installation or accidental damage are not covered by this
guarantee. either are shade variations or any damage
or defect caused by incorrect installation or abuse of the
fitting.
As we are continuously improving and developing our
range of products, finishes & colours, in the event of a
valid claim, we may not be able to provide an identical
replacement for the defective product throughout the
guarantee period. Where an identical product is no
longer available, we will supply the nearest equivalent
from our then current product range. In assessing your
claim, we must be given the opportunity to inspect the
product as installed prior to removal. Any product
returns must be packaged as received and complete.
o other warranties, express or implied, are made,
including merchantability or fitness for a particular
purpose. Under no circumstances shall the manufacturer
be liable for any loss or damage arising from the
purchase, use or inability to use this product, or for any
special, indirect, incidental or consequential damages.
o liability is accepted for consequential damage to
other household fixtures, fittings or furnishings arising
from this claim, even if attached to the product. o
installer, dealer, agent or employee of Abode has the
authority to modify the obligations or limitations of this
warranty.
Care Instructions for your Kitchen Sink tap
To maintain the appearance of this product ensure that it is regularly cleaned only using a clean soft damp cloth. A solution
of warm water and a mild liquid detergent may be used where necessary and then the fitting rinsed thoroughly and wiped
dry. Any other cleaning action will invalidate your warranty.
If the mixertap has a diffuser it should be unscrewed and cleaned periodically in warm water.
Abrasive cleaners, scouring cleaners and acidic cleaners must not be used under any circumstances. Avoid contact with all
solvents (including chlorinated solvents, ketones or acetones as these may result in surface deterioration or etching). Also
avoid contact with any harsh household chemicals such as oven cleaners, drain cleaners, rust removers, paint strippers and
toilet bowl cleaners, bar keepers friend or Brasso.
Please leave these instructions for your customer.

Parts and Contents
Key Description Qty
A Mixer body 1
B Base plinth 1
C Upper seal 1
D Fixing column 1
E Triangular stabilising bracket 1
F Lower gasket 1
G Metal spacer 1
H Metal fixing nut 1
I Hot Flexible tail
(with integral RV) 1
J Cold Flexible tail
(with integral RV) 1
K Mixed water outlet extension 1
L Rubber seal 1
M Pull out horse 1
Hose weight 1
O Hose weight screws 2
Figure 1
Installation Instructions:
Preparation
Before installing the new mixer it is essential that you thoroughly flush through the supply pipes in order to remove any
remaining solder, swarf or impurities from your system. Failure to carry out this simple procedure could cause problems or
damage to the workings of the mixertap.
We strongly recommend installing particle filters and isolation valves to both the hot and cold feed pipes in an accessible
position. This will help to prevent premature failure of the valves and ease any future maintenance.
All parts should be removed from their packaging and inspected for any transport damage prior to installation.
Shut off your water heating system and ensure that your mains stopcock is closed. Open the lowest hot and cold taps in the
house and allow the water to run until the cold-water storage tank and pipes are fully empty. Please note, the hot water
storage cylinder (if applicable) will always remain full.
This mixertap requires a 35mm tap hole, if replacing an existing tap, remove the tap & clean the end of the feed pipes using
wire wool the tap hole area should be free from dirt and sealant.
Loosely position the tap and tail pipes to check if any alteration to the existing pipework is required, if this is the case do this
now.
The installation of this product should respect requirement IR R090.
Installation
1. Place upper seal (C) under the base plinth (B).
2. Locate base plinth (B) onto the fine threaded side located on top of fixing column (D).
3. Then screw both the base plinth (B), upper seal (C) and fixing column (D) onto the mixer body (A).
4. Screw the hot tail pipe (I) on the top of mixer body (A), the cold tail pipe (J) on the middle right hole then screw
the mixed water outlet (K) on the bottom hole. When the tap is facing forwards. (see Fig.1)
5. Place the mixer tap (A), with base plinth (B), upper seal (C) and fixing column (D) onto the sink/worktop, passing
the tail pipes (I&J), mixed water outlet (K) and the pull out horse through the tap hole.
6. Pass the lower gasket (F) and the metal spacer (G) over the fixing column (D) around the mixed water outlet (K),
flexible tail pipes (I & J). If fitting the tap to a stainless steel sink, the white triangular stabiliser (E) can be placed
where shown to help stabilise the weight of the tap.
7. Fasten fixing nut (H) securely onto the fixing column (D) to fix the tap (A) into its correct location.
8. Screw the pull out pipe horse (M) onto the mixer water outlet extension (K) ensuring the rubber seal (L) is In place.
9. Fix the horse weight ( ) with screws (O) as shown.
10. Connect the hot and cold tail pipes (I & J) to the water mains using ½” BSPx15mm compression fittings. ote: on-
return valves will be pre-inserted into tail pipes (I & J).
After installation
Once you have visually checked the new fittings and connections, ensure that all taps are closed except the new mixer tap
which should be left open. Turn on the water supply at the mains stop cock. As the system starts to refill, check carefully for
leaks. Once you are fully satisfied that there are no leaks, turn on the water heating.
Clean the tap to remove any marks created during installation as instructed then place the cloth bag that has been provided to
protect the tap until it is ready for use.
