acaia lunar User manual

Acaia Lunar
User Manual
FW 2.6.005

In the Box
Introduction
Scale overview
Getting Started
Placement
Power on/off
Tare weight
Switch mode
Product Care Information
Battery charge
Calibration
Mode Introduction
Mode 1 - Weighing Mode
Mode 2 - Dual Display Mode
Mode 3 - Timer Starts with Flow Mode ( )
Mode 4 - Auto Tare Timer Starts with Flow Mode ( )
Mode 5 - Auto-Tare Auto-Start Timer Mode ( )
Mode 6 - Auto-Tare Mode ( )
Conguration
Appendix
Buttons
LED indicators
Error codes
Other
Specications
3
3
3
4
4
4
4
4
5
5
5
6
6
6
7
8
9
10
12
16
15
17
18
18
19
Contents

Next, follow the instructions in Getting Started to begin using your scale. To take full advan-
tage of the Lunar’s many features, carefully read through the manual, which contains step-
by-step procedures, examples, and other information.
Warning: Incorrect handling of this product could result in personal injury or physical damage.
Thank you for choosing our scale. The Acaia Lunar is designed and manufactured to the
most rigorous standard to give you the best coffee brewing experience. Start by checking
that your Acaia Lunar box contains all the parts listed below:
*Note: For the best performance, place the weight in the center of the weighing pan.
In the Box
Introduction
Scale overview
Weighing Pan
LED Display
Power Tare
Acaia Lunar Heat Resistant Pad Micro USB Cable Acaia Calibration
Weight 100 g
3

Getting Started
Placement
Power on/off
Tare weight
Switch mode
Select a work place that is stable, vibration-free and, if possible,
a horizontal location for the weighing platform.
4
[Press] to turn on the scale.
[Double tap] to turn off the scale.
[Short press] to tare/zero the weight.
[Press and hold] to switch modes.
* Please see the “Mode Introduction” section for more details.

• You can charge the battery by plugging the USB cable into
any of the power supplies listed below:
• A computer
• A USB wall-charger with an output of 5 volts and 1 amp
• A DC car-charger with an output of 5 volts and 1 amp
• It takes about 1-2 hours to fully charge the battery from
empty. Try not to let the battery completely run out before
charging. Charge the battery as needed, but it is best not to
charge more than once a week.
• Battery percentage can be viewed via the Acaia apps.
* Note: Using a “fast-charging” charging block or charging hub (a charging block/hub delivering
over 5v at 1A) could damage your Acaia scale’s circuit board.
Turn on the Acaia
scale.
Make sure the scale
is in weighing mode
and the unit is set to
‘gram’, then tap the
‘T’ button rapidly.
Keep tapping the ‘T’
button until ‘CAL’ is
shown on the
display.
Place a weight
(100 g/500 g/1000 g)
on the scale and wait
until the display
shows ‘_End_’.
Calibration is now
complete!
Product Care Information
Turn on scale Tap T button See CAL display Place a weight
Battery charge
Calibration
5

In the Weighing Mode, the scale will only display
weight, in either grams or ounces.
In the Dual Display Mode, the scale displays [ 0:00 0.0 ]
with a timer (left) and weight (right).
• There are two different weighing units in Weighing Mode: gram and ounce. A dot will
appear in the upper right of the LED display and the scale will read 0.000 when weighing
in ounces.
• The LED display shows [ 0.0 ] when the scale is measuring in grams.
• The LED display shows [ 0.000 ] when the scale is measuring in ounces.
• The readability is 0.1 g or 0.002 oz. For high resolution mode, the readability is 0.01 g or
0.0005 oz.
• There are two different weighing units in Dual Display Mode: gram and ounce.
• When the scale is measuring in grams, the LED display shows [ 0:00 0.0 ].
• When the scale is measuring in ounces, the LED display shows [ 0:00 0.00 ].
• If the weight exceeds 2000.00 grams, the scale will display [ _ _ _ _ ].
• The maximum time that can be displayed is 9 minutes and 59 seconds. When the
limit is reached, the timer still goes up to until 999 minutes and 59 seconds. It can be
observed through our iOS/Android App.
Mode Introduction
Mode 1 - Weighing Mode
Mode 2 - Dual Display Mode
Action Operation
Tare Weight Tap Tare button
Switch Mode Long press Power button
Action Operation
Start/Stop/Reset Timer Tap Power button
Tare Weight Tap Tare button
Switch Mode Press and hold Power button
6
Note
To change the weighing unit to either gram or ounce, please see Default Unit Setting in the
Conguration section (p. 12).

• The LED display shows [0:00 0.0] with the timer on the left and the weight on the right
in grams.
• The LED display shows [0:00 0.000] with the timer on the left and the weight on the
right in ounces.
• The timer displays from [0:00] to [9:59] and then stops.
Mode 3 - Timer Starts with Flow Mode ( ) - Droplet
Mode Description
Display
Action Operation
Start/Stop/Reset Timer The timer will start when ow is detected
Tare Weight Tap Tare button
Reset Mode Double tap Tare button
Stop Timer The timer will stop when ow is no longer detected
Switch Mode Press and hold Power button
When the scale detects the ow of espresso, the timer
starts. The timer will stop when the ow stops.
*Please note: The ow detection mode is designed to
detect the slow trickle of a shot of espresso. The timer
may not trigger when attempting to pour from a kettle.
7
• The timer starts when the ow of espresso is detected.
• When the espresso ow stops, the timer stops.
The droplet icon indicates that you
are in Timer Starts With Flow Mode.
Tare the weight manually.
Placing a container on the scale will
display its weight.
The timer starts when the ow of
espresso is detected.
1
3
2
4

Action Operation
Start/Stop/Reset Timer The timer will start when ow is detected
Tare Weight Tare function operates when the weight exceeds 2 grams
Reset Mode Double tap Tare button
Stop Timer The timer will stop when ow is no longer detected
Switch Mode Press and hold Power button
Mode 4 - Auto Tare Timer Starts with Flow Mode ( ) -
Droplet and Square
• The LED display shows [0:00 0.0] with the timer on the left and the weight on the right
in grams.
• The LED display shows [0:00 0.000] with the timer on the left and the weight on the
right in ounces.
• The timer displays from [0:00] to [9:59] and then stops.
Display
Mode Description
This mode is designed for baristas who would like to
measure the time of the shot starting from the rst few
drops of espresso. When a stable weight is detected,
the scale will perform the auto-tare operation. After the
scale detects the espresso ow, the timer starts. The
timer will stop when the espresso ow stops.
8
This mode is designed to measure
the time of the shot starting from the
rst few drops of espresso.
The scale will perform the auto-tare
function.
Place a stable weight on the scale.
When the scale detects the espresso
ow, the timer will start.
1
3
2
4
• The auto-tare function operates when a stable weight is placed on the scale.
• The timer will start automatically when the ow of espresso is detected.

Mode 5 - Auto-Tare Auto-Start Timer Mode ( ) -
Triangle and Square
9
This mode is for baristas to measure the total time of
a shot including the pre-infusion time. After a stable
weight such as a cup is placed on the weighing pan,
the scale performs auto-tare and starts the timer.
• The LED display shows [0:00 0.0] with the timer on the left and the weight on the right
in grams.
• The LED display shows [0:00 0.000] with the timer on the left and the weight on the
right in ounces.
• The timer displays from [0:00] to [9:59] and then stops.
Mode Description
Display
Action Operation
Start/Stop/Reset Timer The timer will start when a stable weight is placed on the scale
Tare Weight Tare function starts when a stable weight is placed on the scale
Reset Mode Double tap Tare button
Stop Timer The timer will stop when ow is no longer detected
Switch Mode Press and hold Power button
• The scale performs auto-tare once a stable weight is detected, then the timer starts.
• The timer stops when the espresso ow stops.
This mode is for baristas who
would like to measure the total time
of a shot, including pre-infusion
time.
Measure the total time of a shot
including the pre-infusion time.
After a stable weight such as a cup is
placed on the weighing pan, the scale
performs auto-tare and starts the timer.
When the espresso ow stops the
timer stops.
1
3
2
4

Mode 6 - Auto-Tare Mode ( ) - Square
10
Action Operation
Tare Weight Tare function is performed when a stable weight is placed
on the scale
Reset Mode Double tap Tare button
• The LED display shows [0.0] with the weight in grams.
• The LED display shows [0.000] with the weight in ounces.
Display
In this mode, the scale will only perform auto-tare without
automatically starting the timer. Put the cup on the scale
and auto-tare will be performed. Pull the shot of espresso
as usual. When the cup is removed from the scale, the
display ashes the nal beverage weight and also shows
In this mode the scale will only per-
form auto-tare without automatically
starting the timer.
Put the cup on the scale and
auto-tare will be performed.
Place a stable weight on the scale.
The weight resets after 30 seconds.
1
3
2
4
the tare weight of the cup. The weight resets after 30 seconds (to change this reset time,
see the Conguration section to edit the [ Auto_rES ] setting).
Mode Description
• The scale performs auto-tare once a stable weight is detected.
• The weight resets after 30 seconds

Note:
1. In all three Auto Start Modes (Timer Starts With Flow Mode, Auto-Tare Timer Starts With Flow
Mode and Auto-Tare Auto-Start Timer Mode), the timer will stop when the espresso ow stops.
2. In all Auto Start Modes, if you do not operate the scale for 30 seconds, it will reset timer and
perform tare operation.
3. In all Auto Start Modes, the timer will stop when a negative weight (i.e., removal of cup) is
detected.
4. The scale will also display a previous stable weight that captures the coffee weight of the shot
when you unload the cup.
11

1. Press and hold Power button while the LED display shows [ :ACAIA ] and then
changes to [ SEt ].
2. Tap T button to enter Settings. The rst setting is [ SLEEP ].
3. Please refer to the following table for key operations
Conguration
Enter settings
Settings Menu
Action Operation
Next Setting Tap Tare button
Previous Setting Tap Power button
Enter Setting Press and hold Tare button
Toggle Options Tap Tare button
Save Option Press and hold Tare button
Exit Settings and Return to Modes Tap Power button
Setting Display Sub-Menu Options Default
Sleep Timer SLEEP 5, 10 ,20, 30, 60, Off 5
Zero Tracking trAcE 0.5 d, 1 d, 2 d, 3 d, Off 1 d
Key Sound bEEP On, Off On
Zero Range O.rAnGE 2, 100 100
Weighing Filter Filt 2, 4, 6, 8, 16, 32, 64, 128 16
Default Weighing Unit Unit Gram, Ounce Gram
Weighing Mode NodE_1 On, Off On
Dual Display Mode NodE_2 On, Off On
Timer Starts with Flow Mode NodE_3 On, Off On
Auto-Tare Timer Starts with Flow Mode NodE_4 On, Off On
Auto-Tare Auto-Start Timer Mode NodE_5 On, Off On
Auto-Tare Mode NodE_6 On, Off On
Bluetooth On/Off bt_SEt On, Off On
Battery Saving bAttSvE 30, 90, 180, Off 90
Pre-infusion Timeout PrE_inFu 10, 30, 60, 120 60
Auto-Start Sensitivity SEnSE 0.1 g, 0.2 g, Off Off
Auto-Reset Auto_rES Off, 10, 30 30
Reset to Default rESEt.dNo, Yes
12

Sleep Timer Setting [ SLEEP ]
1. Sleep Timer settings can also be congured in the Acaia apps.
2. The number indicates the amount of time before the scale automatically powers off. For example,
when 10 is selected, the scale powers off after 10 minutes of being idle if the scale is disconnected
from all mobile devices.
Zero Tracking Setting [ trAcE ]
1. Zero Tracking is a function for automatically maintaining the zero indication within certain limits.
2. OFF: It is not recommended to turn off Zero Tracking because the zero indication can drift easily
as the room temperature changes.
3. 0.5 d~3 d: For example, for standard resolution each division is 0.1 g, 3 d = 0.3 g. When Zero
Tracking is set to be 3 d, any initial weight between +/- 0.3 g on the weighing pan will be zeroed out
gradually.
4. 2 d is recommended in general for the Acaia Lunar.
Key Sound Setting [ bEEP ]
1. Key Sound settings can also be congured in the Acaia apps.
2. Set the Key Sound function to on/off to enable/disable the beeping sound.
Zero Range Setting [ 0.rAnGE ]
1. The Zero Range setting determines the range for which the tare button executes zero operation
instead of tare operation.
2. When Zero Range is set to 2, the range for zero-setting will be 2% of the capacity, i.e., +/- 40 g
for Acaia Lunar. By pressing the tare button, any weight within +/- 40 g is zeroed out by zero opera-
tion while any weight that lies outside the range is tared out by tare operation.
3. If Zero Range is set to 100, the range for zero-setting will be 100% of the capacity, i.e., +/- 2 kg
for Acaia Lunar. Therefore, instead of tare operation, zero operation would be executed in this set-
ting whenever tare button is pressed.
Notice: The difference between zero operation and tare operation is that zero operation would sim-
ply ignore the weight and display as 0 while tare operation would deduct the weight from the weigh-
ing result. However, zero operation does not increase the scale capacity.
Weighing Filter Setting [ Filt ]
1. The Weighing Filter Setting determines the speed at which the load receptor responds to weight
and determines the weighing value. The larger the number, the more stable but slower the weighing
result will be. The number shown on the LED display indicates the current lter setting.
2. Press tare button to change the parameter.
Default Unit Setting [ Unit ]
1. The Default Weighing Unit is set to grams if [ 9] is selected and ounce if [ o2 ] is selected.
Weighing Resolution Setting [ rESoL ]
1. The default Weighing Resolution is set to [ dEFAUL ]: the division is 0.1 g/0.002 oz.
2. Tap tare button to switch the Weighing Resolution between [ dEFAUL ] and [ hiGh ].
3. When the Weighing Resolution is set to high, division will be 0.01 g/0.0005 oz. The default display
will show [ 0.00 ] when the scale is set to grams, and [ 0.0000 ] for ounces in Weighing Mode.
Note: After setting Weighing Resolution to high, the default display will show [ 0:00 0.00 ] with timer
in Dual Display Mode and Auto Start Modes.
13

Weighing Only Mode Setting [ NoDE_1 ]
1. The default Weighing Only Mode Setting is set to ON, which means this mode is enabled.
• ON: The Weighing Mode is enabled.
• OFF: The Weighing Mode is disabled.
Dual Display Mode Setting [ NodE_2 ]
1. By default, the Dual Display Mode Setting is set to ON, which means this mode is enabled.
• ON: The Dual Display Mode is enabled.
• OFF: The Dual Display Mode is disabled.
Timer Starts with Flow Mode Setting [ NodE_3 ]
1. By default, the Timer Starts with Flow Mode with Droplet Setting is set to ON, which means this
mode is enabled.
• ON: The Timer Starts with Flow Mode with Droplet is enabled.
• OFF: The Timer Starts with Flow Mode with Droplet is disabled.
Auto-Tare Timer Starts with Flow Mode Setting [ NodE_4 ]
1. The default Auto-Tare Timer Starts with Flow Mode with Droplet and Square Setting is set to
ON, which means this mode is enabled.
• ON: The Auto-Tare Timer Starts with Flow Mode with Droplet and Square is enabled.
• OFF: The Auto-Tare Timer Starts with Flow Mode with Droplet and Square is disabled.
Auto-Tare Auto-Start Timer Mode Setting [ NodE_5 ]
1. The default Auto-Tare Auto-Start Timer Mode with Triangle and Square Setting is set to ON,
which means this mode is enabled.
• ON: The Auto-Tare Auto-Start Timer Mode with Triangle and Square is enabled.
• OFF: The Auto-Tare Auto-Start Timer Mode with Triangle and Square is disabled.
Auto-Tare Mode Setting [ NodE_6 ]
1. The default Auto-Tare Mode with Square is set to ON, which means this mode is enabled.
• ON: The Auto-Tare Mode with Square is enabled.
• OFF: The Auto-Tare Mode with Square is disabled.
Bluetooth Setup Setting [ bt_SEt ]
1. OFF: Bluetooth is disabled. The scale does not allow any Bluetooth connection.
2. ON: Bluetooth is enabled. The scale allows Bluetooth connection. The user may connect the
scale with Acaia apps.
Battery Saving [ bAttSAvE ]
1. Save up to 20% of your battery by dimming the display after some time. It will return to its origi-
nal brightness when the scale detects objects on it.
2. The number indicates the amount of time before the scale enters battery saving mode.
3. Tap the tare button to toggle through the options.
Pre-Infusion Time Out [ PrE_inFu ]
1. Determines when the scale times out in all three of the Auto-Start modes. This is most useful
for long pre-infusion times and resolves the timeout that sometimes happens for slow pre-infusion
times.
2. The number indicates the time in seconds it will take for the scale to reset if no espresso ow or
weight is detected.
14

Auto-Start Sensitivity [ SEnSE ]
1. Minimum weight is decreased for more sensitivity. This is ideal for slower espresso shots in the
droplet icon modes. Stability depends on environmental noise. The previous rmware started the
timer at ~0.6 g into an espresso shot.
2. The number indicates the sensitivity of ow detection in the droplet icon modes. Smaller value
indicates higher sensitivity, but is recommended only for stable working environments.
Auto-Reset [ Auto_rES ]
1. After a cup is removed, the timer will automatically reset. This gives you options on how long to
wait for the reset. This setting enables the user to pull successive shots of espresso quickly in the
three Auto-Start modes.
2. The number indicates the timeout value of timer reset after a cup is removed.
Reset To Default Setting [ rESEt.d]
1. Select [ YES ] to reset all settings to default value.
2. Press and hold tare button for 1 second until [ SLEEP ] is shown on the LED to reset all settings
to default.
15

Appendix
Buttons
Function Example
Power
Button
Turn on Press and hold for 0.5 seconds to turn on
the scale.
Turn off Double-tap to turn off the scale.
Switch Mode While the scale is turned on, press and hold
for one second to switch modes.
Start/Stop/Reset Timer Tap to start/stop/reset timer.
Back While in Settings Menu, tap to go back to
Modes.
Tare
Button
Tare Tap to perform tare operation.
Tare and reset timer While in Auto Start Modes, double tap to
zero weight and reset timer.
Switch option While in Settings, tap to advance through
sub-menus. While in sub-menus, tap to
toggle options.
Conrm While in Settings, press and hold for two
seconds to conrm the option selected in a
sub menu.
Enter Calibration Mode While in Weighing Mode, rapidly tap to
enter Calibration Mode.
16

Battery Charge/Charge Error
The orange indicator on the upper left turns on when the battery is charging and turns off
when the battery is fully charged. The indicator starts ashing or does not appear when the
USB cable malfunctions.
Tare Operation/Bluetooth Connected
The orange indicator on the lower left turns on when the Tare button is pressed.
Ounce Indicator
The orange indicator on the upper right turns on when the weighing unit is in ounces.
Timer Starts with Flow Droplet
When the scale detects the ow of espresso, the timer starts. The timer will stop when the
ow stops.
*Please note: The ow detection mode is designed to detect the ow of espresso. The timer
may not trigger when attempting to pour from a kettle.
Timer Starts with Tare Triangle
The scale performs auto-tare and simultaneously starts the timer when a stable weight is
placed on the weighing pan.
Auto-tare Operation Square
The scale performs auto-tare when a stable weight is placed on the weighing pan.
LED Indicators
Ounce Indicator
Timer Starts with Tare
Battery Charge
Timer Starts with Flow
Auto-tare Operation
Tare Operation
Bluetooth Connected
17

Error Code Description
100 Access Code Error, unrecognized access code.
101 EEPROM error, unable to access memory. Please contact Acaia support.
102 AD error, unable to access weighing signal. Please contact Acaia support.
303 Unable to nd acceptable starting Zero point, most likely due to loadcell
damage caused by excessive force or drop. Please contact Acaia support.
Over load: the weight is over the maximum capacity.
Under load: the weight is under the minimum capacity.
304 Calibration error. Calibration cannot proceed when environmental noises are
too strong. Please calibrate in a stable environment free of wind, vibration, etc.
904 Password error (the default password is 0000)
_H2O Water in the power button
H2O_ Water in the tare button
_H2O_ Water in the power button and tare button
Error Codes
Display Code Description
UPdAtE
The scale is in update mode.
Note: If you want to leave update mode, please connect the scale’s USB to a
power source.
Other
18

Specications
Model AL001 / AL006
Product Weight 265 g ± 5 g
Product Dimensions W: 105 mm L: 105 mm H: 15 mm
Maximum Capacity 2000 g / 70.55 oz
Minimum Weight 0.1 g
Measuring Units g / oz
Readability 0.1 g
Repeatability 0.1 g
Linearity 1 d (d = 0.1 g)
Indication Limit 2060 g / 72.66 oz
Power Supply 5 V / 500 mA
Battery Lithium-ion rechargeable 3.7 V 1100 mAh
Battery Life Up to 27 hours
Display LED
Material Aluminum, Acrylic
Connectivity Bluetooth 4.0
Warranty 2 Years
Inside the Package Acaia Lunar Coffee Scale (Black / Silver) x 1
Heat Resistant Pad (Black) x 1
Micro USB Charging Cable x 1
Acaia Calibration Weight 100 g x 1
19

Copyright
This user manual is protected by copyright. All rights reserved. No part of this manual may be reproduced,
processed, duplicated or published in any form by photocopying, microlming, reprinting or any other
method, in particular electronic means, without the written consent of Acaia.
© Acaia, California, 2020.
