1.0. Introduction The ACM1252U-Z6 is an NFC reader module with an FFC connector
developed based on the 13.56 MHz contactless technology. This NFC
Reader Module supports all three NFC modes, namely card
reader/writer, card emulation, and peer-to-peer communication.
The ACM1252U-Z6 supports ISO 14443 Type A and B cards,
MIFARE®, FeliCa, and ISO 18092–compliant NFC tags. It also
supports other NFC devices with an access speed of up to 424 Kbps
and a proximity operating distance of up to 30 mm (depending on tag
type used).
It is PC/SC-compliant for interoperability across different applications
and platforms, and provides high-speed communication ability for
contactless cards and NFC tags/devices. Post-deployment firmware upgrade is also supported,
eliminating the need for additional hardware modification.

ACM1252U-Z6 – User Manual [e-mail]
Version 1.00 www.acs.com.hk
Page 4 of 7
2.0. PIN Assignment
2.1. LED Configuration
There is a bi-color LED (Red and Green) on the ACM1252U-Z6 to display and control its operation
status.
Figure 1: LED Configuration
2.1.1. LED for Power status
The default LED settings when the power is on are Red and Green and then slow flashing Green.
These LEDs cannot be controlled.
2.1.2. LED for smart card operation status
To control the LEDs’ output and checking their behavior for smart card operation status, please refer
to the ACM1252U-Z6 Reference Manual. The manual will discuss how PC/SC APDU commands were
implemented for the contactless interface and device peripherals of the ACM1252U-Z6.
2.1.3. Default LED Behaviors
To control the LEDs’ output and check the LED’s behavior, you may refer to the ACM1252U-Z6
Reference Manual.

ACM1252U-Z6 – User Manual [e-mail]
Version 1.00 www.acs.com.hk
Page 5 of 7
2.2. Connect ACM1252U-Z6 to another device via USB
A USB port is available to connect the ACM1252U-Z6 to another peripheral or device.
To do this:
1. Connect socket (J2) via FFC cable (6 Pins, 0.5mm Pitch) to another peripheral device (see
Figure 2).
Pin Test Point Description
1,2 TP1 USB VBUS (5V)
3 TP2 USB D-
4 TP3 USB D+
5 TP4 USB GND
6 Connect to GND with 0ohm Resistor (R7)
Figure 2: ACM1252U-Z6 USB Configuration
6
5
4
3
2
1

ACM1252U-Z6 – User Manual [e-mail]
Version 1.00 www.acs.com.hk
Page 6 of 7
3.0.Minimum Distances from Conductive Materials
The table below illustrates the recommended minimum distances of the ACM1252U-Z6 from
conductive materials.
.
Location Minimum Distance
Sides 15 mm
Side (with connector) 5 mm
Top and Bottom 30 mm
Table 1: Recommended Minimum Distances from Conductive Materials

ACM1252U-Z6 – User Manual [e-mail]
Version 1.00 www.acs.com.hk
Page 7 of 7
Appendix A. Connector Specification
Figure 3: ACM1252U-Z6 USB Connector Specification
Note: The connector shown in Figure 3 is attached to the PCB.
