ActionTec ECB7250 KIT User manual

MoCA Network Adapters
©2020 Actiontec Electronics, Inc.
Actiontec, Creative Solutions for the Digital Life, and the Actiontec logo are
registered trademarks or trademarks of Actiontec Electronics, Inc., in the U.S.
or other countries. All other names are properties of their respective owners.
Product photo may differ from actual product. However, functionality remains
as stated above. Specifications are subject to change without notice.
This Quick Start Guide will walk you through the easy
steps to connect your MoCA Network Adapters.
Quick Start Guide
(2) MoCA Network
Adapters
(2) Ethernet Cables
(2) Power Adapters (2) Coaxial Cables
(2) Coaxial Splitters
Package Contents:
ECB7250 KIT
Congratulations! You’ve successfully connected
your device to the Internet.
Additional MoCA Network Adapters may be purchased
and connected to other devices needing an Ethernet
connection and that are near a coaxial port.
Tech Support
For registration or access to user manuals, wall-mount
templates, software updates, etc. visit our webpage:
www.screenbeam.com/products/screenbeam-ecb7250 (External, 5V DC, 2A
made by APD,
Model #WB-10E05FU)
PN 0530-0857-000

Step 1: Connect to your Modem/Router Step 2: Connect to your Device
Get one MoCA Network Adapter.
Locate the device or access point (laptop, etc.) that
needs to connect to the Internet. Connect one Ethernet
Cable from the Network Adapter to the Device.
Connect one Splitter to the Coax Cable coming from
the Coax Outlet on the wall.
Connect one Coax Cable from the Splitter to the Coax
In port on the Network Adapter.
Connect one Power Adapter to the Network Adapter
and to a Power Outlet.
Wait until the Power light on the front of the adapter
is GREEN.
IMPORTANT! If the Coax LED on the Network Adapter
is already GREEN, you may have MoCA built in to your
modem/router. Check the device you just connected. If
it is connected to the Internet, you’re done*. If the device
does not connect to the Internet, return to Step 1.
* You may use the 2nd adapter with another device or access point.
Get one MoCA Network Adapter.
Connect one Ethernet Cable from the Network
Adapter to the Modem/Router.
Connect one Splitter to the Coax Cable coming from
the Coax Outlet on the wall.
Connect one Coax Cable from the Splitter to the Coax
In port on the Network Adapter.
Note: If you have a TV or set top box near your modem/router,
connect a coax cable from the splitter to the TV or set top box.
Connect the second Power Adapter to the Network
Adapter and to a Power Outlet.
Wait until the Power light on the front of the adapter
is GREEN.
When the Coax LED is GREEN on both adapters, your
adapters are working.
aa
b
c
d
e
f
g
TV
Ethernet
Power
Power
Coax
Coax In
MPS
a
ge
ef
g
f
b
d
d
c
c
MoCA Network
Adapter2
Laptop or other
access point
Power
Outlet
Splitter
Coax LEDPower LED Power
Adapter
Ethernet Cable
Coax Outlet
TV Ethernet Port of
Modem / Router
Power
Outlet
MoCA Network
Adapter1
Power
Adapter
Coax LEDPower LED
Ethernet Cable
Splitter
Coax Outlet
Coaxial wiring behind the wall
Ethernet
Power
Power
Coax
Coax In
MPS
b
a
ECB7250 ECB7250
b
c
ad
e
f
g
