Compatible with Double-DIN devices:
Double-DIN Navigation
Installation Manual
Double DIN Kit
anthracite: 381178-29-1
black: 381178-29-2
• Kia Rio 2011->
Double DIN Set contents
• (1) Facia Plate
• (2) Cover*
*(for models withoutengine start/stop button)
• (3) Mounting bracket (L)
• (4) Mounting bracket (R)
• (5) at headed screw
• (6) Clip
9. Mount metal brackets to
double DIN Navigation
10. Attach Clips to new
facia plate
11. Connect all required circuit
points of double DIN head unit
Fix double DIN head unit with
4 screws
Re-install everything in reverse
order to nish installation

2
3
1
2
Installation Manual Double DIN Kit
1. Unclip OEM panel (see arrows)
2. Remove panel
4. Remove hazard light switch
5. Remove air vents
6. Remove passenger air bag switch
7. Models with start/stop:
Remove start / stop button
Mount start / stop button
to new facia plate
Models without start/stop
Attach cover to facia plate
8. Mount
- hazard light switch
- air vents (left / right)
- passenger air bag switch
to new facia place
3. These parts need to be removed
from OEM panel:
- hazard light switch (1)
- air vents (left / right) (2)
- passenger air bag switch (3)
