ACV 381170-08 User manual

1
2
3
Double DIN Set contents
• (1) Metal Frame
• (2) Install Kit
• (3) Mounting Frame
• (4) Facia Plate
4
© 12/2008 ALL RIGHTS RESERVED. Technical changes possible. No liability for misprints.
Compatible with these double DIN devices
Double DIN Navigation
Installation Manual
Double DIN Kit
standard: 381170-08
• Mazda CX-7 2009->
Installation Manual Double DIN Kit
9. Connect all required circuit points
and push the double DIN head
unit in the metal frame until it
snaps in.
Place facia plate
Install everything in reverse order
to nish installation
Mount the metal brackets to
double DIN head unit.
The position of the copper
coloured holder can be adjusted
to your needs for perfect t.
(see sample)
(sample photo) (sample photo)

1. Mazda CX-7 OEM dashboard 5. Unplug cable from panel
Remove panel
6. Remove screws ( see arrows )
7. Remove OEM head unit
8. Remove hazard light switch from
OEM panel
Mount hazard light switch to
facia plate
2. Unclip side panels at let
and right side
3. Remove screws
4. Pull panel towards your direction
Installation Manual Double DIN Kit Installation Manual Double DIN Kit
