ACV 381300-24 User manual

9. Plug hazard light switch and
Passenger Airbag switch
Place OEM panel
Reinstall everything
in reverse order
All installation work must be performed by a qualied professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
Double-DIN Kit
Installation Manual
• Toyota Auris 01/2013-> Typ (E15UT / E15UTN / HE15U)
part-no.: 381300-24
colour: piano-black
Compatible with these navigation devices
Double DIN Navigation
Kit Content
(1) Facia Plate
(2) Mounting bracket right
(3) Mounting bracket left
(4) Flat Headed Screw
1
2
4
3
4

1. Toyota Auris OEM dash board
2. Remove plastic clips at left
and right side beside climate
control unit
4. Remove 4 screws of OEM head unit
3. Remove panel by pulling it towards
your direction (see arrows)
Unplug hazard light switch
and Passenger Airbag switch
carefully
5. Remove OEM head unit
by pulling it towards your
direction (see arrows)
6. Attach mounting frames to
Double DIN head unit
7. Connect all required circuit points
place Double DIN head unit
and x it with 4 screws (see arrows)
8 . Place facia plate over
Double DIN head unit
