Adaptive AlphaEclipse 2500 Instruction sheet

4Open the sign labeled with SERIAL ADDRESS = 2.
Using the communications conduit opening, run the Serial I/O cable between the two signs.
AlphaEclipse 2500/2600/3500 Signs
Multiple Master Configuration
http://www.adaptivedisplays.com/support/eclipse
2Open the sign with SERIAL ADDRESS = 1.
Locate the 30-foot Serial I/O cable in the lower left side of the sign.
Serial I/O cable
READ THIS FIRST
1Locate the SERIAL ADDRESS label on the back of each sign.
The SERIAL ADDRESS number will increase by one for each sign (1, 2, 3, and so on):
1 2 3
3Run the Serial I/O cable out through the sign’s communications conduit opening.
Then close the sign.
Communications conduit opening
Power wires
NOTE: Do not route the Serial I/O
cable in the same conduit
as the power wires.
5Connect the signs as shown on the next page.
6Repeat steps 3, 4, and 5 for each remaining sign.
Connect the signs as shown below:
SHIELD
RS485 + (Black)
SERIAL I/O
CUSTOMER
CONNECTION
SERIAL I/O
(on Controller Board)
SERIAL I/O
(on Controller Board)
SERIAL I/O
(on Controller Board)
SERIAL I/O
(on Controller Board)
SERIAL I/O
CUSTOMER
CONNECTION
SERIAL I/O
CUSTOMER
CONNECTION
RS485 - (Red)
Controller Board
Communications
Conduit
Opening
Communications
Conduit
Opening
Turbo Extender Board
SHIELD
RS485 + (Black)
RS485 - (Red)
Controller Board
Turbo Extender Board
Communications
Conduit
Opening
SHIELD
RS485 + (Black)
RS485 - (Red)
Controller Board
Turbo Extender Board
SERIAL I/O
CUSTOMER
CONNECTION
Communications
Conduit
Opening
SHIELD
RS485 + (Black)
RS485 - (Red)
Controller Board
Turbo Extender Board
1
2
3
4
If a sign does not have a SERIAL I/O
Customer Connection terminal block,
then use the SERIAL I/O terminal block
on the Controller board.
© Copyright 2003-2004 Adaptive Micro Systems LLC. All rights reserved.
Adaptive Micro Systems • 7840 North 86th Street • Milwaukee, WI 53224 USA • 414-357-2020 • 414-357-2029 (fax) • http://www.adaptivedisplays.com
The following are trademarks of Adaptive Micro Systems: Adaptive, Alpha, AlphaNet plus, AlphaEclipse, AlphaPremiere, AlphaTicker, AlphaVision, AlphaVision InfoTracker, Automode, BetaBrite, BetaBrite Director, BetaBrite Messaging
Software, Big Dot, PPD, Smart Alec, Solar, TimeNet
The distinctive trade dress of this product is a trademark claimed by Adaptive Micro Systems LLC.
Due to continuing product innovation, specifications in this manual are subject to change without notice.
September 20, 2004 9811-7012
