ADC Diagnostix 752M User manual

®
AMERICAN DIAGNOSTIC CORPORATION
AMERICAN DIAGNOSTIC CORPORATION
55 Commerce Dr ve
Hauppauge, NY 11788
Customer Service: 1-800-ADC-2670
Voice: 1-631-273-9600
Fax: [phone]
email: [email protected]
http://www.adctoday.com
NEW YORK • LONDON • TOKYO
©2015 ADC®IB p/n: 9352B-00 - rev 6
To Regi ter Your Product,
vi it u at
www.adctoday.com
and follow the link
• Mobile Aneroid
Assembly
Instructions
• Schematic
• Parts List for
Mobile Stand
• Wall Aneroid
Mounting
Instructions
DiagnostixTM
752M, 750W Aneroids
®
Wall Mount ng
Instruct ons for the
D agnost xTM 750W
Tool Needed
• Medium phillips head screwdriver
• Hammer
• Drill with 3/16” drill bit
Direction
1. osition manometer (with attached wall bracket) on wall
at desired location and rotate gauge to right side to
permit access to left side mounting holes on bracket.
Make pencil marks on wall through the mounting holes.
Holding bracket firmly in place, rotate gauge to left side
to permit access to right side mounting holes. Make
pencil marks on wall through the mounting holes.
Recommended height is near the eye level of the
intended users.
2. At each of the four pencil marks, drill a 3/16” hole
approximately 7/8” deep. Use a masonry type bit if
drilling through ceramic tile.
3. Gently tap the 4 screw anchors into the holes until they
are flush with the wall.
4. osition the manometer and bracket over the screw
holes and screw bracket into wall first on one side, then
the other using the procedure outlined in step one to
gain access to each of the four mounting holes. Take
care not to over tighten screws.
5. Attach 8 foot length of coiled tubing to air inlet at bottom
of manometer.
Insert “male” luer connector on free end of coiled tubing
to “female” luer connector on bladder tubing. Wrap cuff
around bulb and store in mounting bracket/storage
compartment behind gauge.
Note: If the mounting hardware supplied is not suitable for the
application, select hardware of adequate si e and type to secure
the instrument firmly to the wall.
Important: The instrument is designed to permit wall mounting
without having to first remove the bracket from the instrument.
If the instrument is removed from the bracket for mounting or
service, we recommend applying removable loctite®to the
bracket hardware to prevent the instrument from working loose.
Locktite can be obtained from most hardware stores.
Main Unit
Wall Bracket
CAUTION: En ure that the unit i ecurely mounted
prior to u e to avoid damage to the in trument
and/or potential injury.
®

Schemat c Parts L st
Assembly Instruct ons for the
D agnost xTM 752M
1. With base on its side
connect upright outer pole
to base using the long hex
bolt. Tighten with the large
hex key provided. Tighten
hardware as securely as
possible. (Note: To prevent
loosening, hardware must
be tightened securely and
periodically checked).
(Figure 1).
2. Slide stainless steel inner
pole inside outer pole with
open end up.
(Figure 2).
3. Loosen the hex bolt on col-
lar of cuff storage basket
with small hex key provid-
ed. lace cuff storage bas-
ket on top of stainless
steel inner pole making
sure the pole goes com-
pletely inside collar and
tighten hex bolt with key.
(Figure 3).
4. Attach manometer
bracket to cuff storage
basket using the short
hex bolt and washers
as shown. Tighten
securely with large
hex key. (Figure 4).
Included Tools
Large Hex
Key
Small Hex
Key
5. Adjust height of manometer by loosening knob and rais-
ing or lowering inner pole until gauge is at desired
height. Tighten knob by hand.
6. Connect coiled tubing to gauge inlet. (Note: The coiled
tubing may be difficult to connect, moisten with soapy
water if necessary). Refer to booklet entitled DIAGNOS-
TIX™Aneroids ocket, alm, Clock Type booklet
(9350N-00) for instructions on operating the unit.
Connect outer pole to base
assembly. Note: Tighten large
hex bolt securely by applying
as much force to hex key as
possible.
Large Hex Bolt
2
Slide inner pole inside
outer pole.
3
Insert pole into bottom of cuff
storage basket and tighten hex
bolt on side of the basket with
small hex key.
4
Attach manometer bracket to
cuff storage basket.
Cuff storage
basket Short Hex
Bolt
1
9B
4
5
6
7
8
9
9A
9C
9C
6A
1
2
3
3A
Ref # Item # De cription
1 972 101 Long Hex Bolt and Washer (1)
2 972 080 Base
3 972 106 Casters (5)
3A 972 106 1 Single Caster
4 972 107 Outer Pole
5 972 108 Knob
6 972 109 Spring
6A 972 107A Gasket
7 972 110 Inner Pole
8 972 111 Tightening Device
9 972 112 Cuff Storage Basket
9A 752 113 Manometer Bracket
9B 752 114
Short Hex Bolt & Washer
9C 752 115 Manometer Bracket Hardware
Mobile Stand A embly for the 752M
