ADC ADView 2 9005BPSTO User manual

ADC® ADView® 2 Modular Diagnostic
Station
User Manual
2
2
TM

ADView 2 User Manual | 2
93-9005-00 rev 4
September 1, 2016

Changes
This manual is identified as item number: 93-9005-00. The most recent version is available for download from the
ADC website. Should you notice errors or omissions in this manual, please notify us at:
American Diagnostic Corporation
55 Commerce Drive
Hauppauge, NY 11788
Tel: 1.800.ADC.2670
1.631.273.9600
Fax: [phone]
Email: customerservi[email protected]
Web: www.adctoday.com
Copyright Information
All content in this manual is the property of American Diagnostic Corporation and is provided solely for purposes of
operation, maintenance or service of the ADView 2. This manual and the ADView 2 described herein are protected
under copyright law under which states they may not be copied, in whole or in part, without written consent of ADC.
The information in this manual is furnished for guidance only, is subject to change without notice, and should not be
construed as a commitment by ADC. ADC assumes no liability for errors or inaccuracies that may appear in this
manual.
© 2016 American Diagnostic Corporation. All rights reserved. ADC, the ADC logo, and ADView are registered
trademarks of American Diagnostic Corporation. All other trademarks are the property of their respective owners.

Welcome to the ADC® ADView® 2
Thank you for choosing the ADC® ADView® 2 Modular Diagnostic Station for accurate spot-checking of vital signs.
The ADView 2 is designed to be simple and efficient to use, and features:
•A contemporary, compact design
•An integrated handle for easy mobility
•Automatic BP checks
•Averaging of multiple BP readings
•Optional use of stethoscope for traditional auscultatory BP measurement
•A robust memory
•Connection options for EMR system integration
•Multiple options for pulse oximetry and temperature measurement
ADView 2 Description and Operation
The ADView 2 can perform automatic blood pressure, pulse oximetry and body temperature measurements for
clinical professionals. For measuring blood pressure, a blood pressure cuff is placed around the patient’s non-
dominant upper arm. The cuff is inflated automatically and blood pressure is determined by the oscillometric
method—which senses pressure waves in the artery when occluded by pressure in the cuff. Measurement of the
frequency of the pressure waves enables heart rate to also be measured. The pulse oximetry function non-invasively
measures the patient’s percent oxygen saturation of arterial hemoglobin using principles of plethysmography via an
SpO2 sensor placed on the patient’s finger. Temperature can be measured using an oral/axillary or a rectal
temperature probe containing a thermistor that generates a voltage based on changes in temperature. These
voltages are recorded by the temperature circuitry. The ADView 2 is a portable device, approximately 205 x 190 x 140
mm in size and weighs approximately 1440 g without battery. Control buttons allow the user to stop/start a BP
measurement, save a set of measurements to memory, change between BP modes, and return to the home screen.
There is also a selection knob that is used to scroll and select different device options. The backlit LCD display shows
the user device status and measurement information. The device uses a microprocessor with software, which is not
accessible to the user. The unit is powered by a single rechargeable lithium-ion battery at the rear of the device. Two
USB-A port connections can be used to connect, an optional printer, barcode scanner or Wi-Fi dongle. There is also
RJ11 Ethernet port for network connectivity, and a mini-USB port used to connect the device to a PC or laptop for
advanced device configuration.
Note: For purposes of this manual, the ADView 2 (Model 9005) may be referred to as “the ADView 2, or “the device.”

ADView 2 User Manual | 5
93-9005-00 rev 4
September 1, 2016
Table of Contents
Changes!...........................................................................!3
Copyright!Information!....................................................!3
Welcome!to!the!ADC®!ADView®!2!.................................!4!
ADView!2!Description!and!Operation!.............................!4
1. Safety!Considerations!........................!6!
Intended!Use!...................................................................!6
Indications!for!Use!..........................................................!6
User!Responsibility!.........................................................!6
Possible!Adverse!Reactions!.............................................!7
Icons,!Symbols!and!Abbreviations!..................................!9
Commonly!Used!Abbreviations!....................................!10
2. Setting!Up!the!ADView!2!..................!10!
Unpacking!the!Monitor!.................................................!10
Rear!Panel!Configuration!..............................................!11
Side/Temperature!Panel!Configuration!........................!12
Side/SpO2!Panel!Configuration!.....................................!12
Install!Batteries!.............................................................!13
Battery!Disposal!............................................................!13
Attach!Connections!to!the!Device!................................!14
Mounting!Options!.........................................................!14
System!Configuration!....................................................!14
3.!Getting!to!Know!the!ADView!2!............!15!
Measurement!Display!...................................................!15
Control!Panel!................................................................!18
Monitor!Setup!...............................................................!18
Visual!Alarms!................................................................!18
4.!Good!to!Know!Before!You!Begin!.........!19!
Power!Modes!................................................................!19
Documenting!Measurements!.......................................!19
Printing!..........................................................................!19
Saving!Measurements!...................................................!20
5. Using!ADView!2!for!BP!Measurement!21
Step!1:!Preparing!the!Patient!........................................!21
Step!2:!Select!Between!Adult!Vs!Pediatric!Mode!.........!21
Step!3:!Select!Measurement!Mode!..............................!22
Step!4:!How!to!Measure!BP!in!Each!Mode!...................!24
Step!5:!Record!Results!..................................................!25
Step!6:!Prepare!for!New!Patient!...................................!25
6. Using!ADView!2!for!Heart!Rate
Measurement!.........................................!25!
BP!Heart!Rate!Measurement!........................................!25
SpO2!Heart!Rate!Measurement!....................................!25
7.!Using!ADView!2!for!Pulse!Oximetry!....!26!
General!Principle!of!Operation:!....................................!26
System!Description:!......................................................!28
Taking!SpO2!Measurements:!.........................................!28
Special!Notes!for!Masimo!SET!SpO2!Module:!...............!28
Special!Notes!for!ChipOx!SpO2!module:!........................!30
8. Using!ADView!2!for!Temperature
Measurement!........................................!32!
Covidien!Filac!3000!Thermometry!Module!...................!32
Oral!Temperature!Taking!..............................................!32
Axillary!Temperature!Taking!.........................................!33
Rectal!Temperature!Taking!...........................................!33
Other!Temperature!Settings!.........................................!33
9. Using!ADView!2!EMR!and!Memory
Functions!...............................................!34!
Memory!Mode!..............................................................!34
EMR!Transmissions!.......................................................!35
10.!Taking!Care!of!Your!ADView!2!..........!36!
Cleaning!........................................................................!36
Preventative!Maintenance!............................................!37
Replacing!and!Disposal!of!the!Battery!..........................!37
Battery!Disposal!............................................................!37
Product!Disposal!...........................................................!37
Cuff!Disposal!.................................................................!37
Routine!Calibration!.......................................................!37
11.!Accessories!&!Replacement!Parts!.....!38!
Complete!Modules!(when!purchased!separately)!........!38
Mounting!Platforms!......................................................!38
Blood!Pressure!Cuffs!.....................................................!38
Power!Supplies!..............................................................!39
Temperature!Accessories!..............................................!39
SpO2!Accessories!..........................................................!39
Other!Accessories!.........................................................!39
12.!Status!Messages!&!Alarms!................!40!
Status!Messages!............................................................!40
Out!of!Range!Measurements!........................................!42
Service!Centers!.............................................................!43
13.!Frequently!Asked!Questions!.............!43!
14.!Technical!Information!......................!44!
EMC!Statement!.............................................................!44
Specifications,!General!..................................................!48
Specifications,!Blood!Pressure!Measurement!..............!48
Notes!on!Blood!Pressure!Data!......................................!49
Specifications!SP02!Sensor!............................................!49
Specifications!Temperature!Sensor!..............................!49
Limited!Warranty!..........................................................!50

ADView 2 User Manual | 6
93-9005-00 rev 4
September 1, 2016
1. Safety Considerations
Intended Use
The ADView 2 is a clinical-grade, automated blood pressure measurement device with optional temperature
and pulse oximetry modules for spot-check vital sign measurements in physician offices, long-term care
facilities, and low-acuity areas in hospitals. The ADView 2 can be used in combination with a clinical IT
network to transfer and store patient measurement data on an EMR system. !
Indications for Use
The ADView 2 is a non-invasive oscillometric spot-check vital signs device. The ADView 2 is capable of measuring
and displaying brachial systolic and diastolic blood pressure, heart rate, percent oxygenated hemoglobin (SpO2) and
body temperature on children 3 years of age to adults. This device is intended for use by a qualified clinician when it
is necessary to take a single or a series of vital signs measurements on a patient. The ADView 2 is only for
measurement, recording and display. It makes no specific diagnoses.
The ADView 2 is intended to be used on adult and pediatric patients using appropriately sized ADC ADView 2 blood
pressure cuffs.
User Responsibility
Your ADView 2 is designed to perform in conformity with the description thereof contained in this operation manual
and accompanying labels and inserts, when assembled, operated, maintained and repaired in accordance with the
instructions provided.
Further, the user of this device bears sole responsibility for any malfunction that results from improper use, faulty
maintenance, improper repair, damage or alteration by anyone other than ADC or authorized service personnel.
Use of ADView 2
Use only ADView 2 blood pressure cuffs supplied by ADC.
Observe the patient carefully during the measurement. Ensure pressure compatibility to all patients. If any
abnormality occurs, either in the unit or the patient, suspend the operation immediately and disconnect the BP cuff,
SpO2 sensor and thermometer (if applicable) from the patient.
Accuracy of any BP reading or oxygen saturation measurement may be affected by the position of the patient, their
physical condition and use outside of the operating instructions detailed in this guide. The interpretation of BP and
oxygen saturation measurements should only be made by a physician.
Safety and effectiveness when used with pregnant women, children under 3 years of age and neonates have not been
established.
Pulse Oximetry (SpO2)
ChipOx SpO2 Module: Use only pulse oximeter sensors supplied by ADC or original NellcorTM pulse oximeter sensors
supplied by Covidien® (except for forehead reflectance sensors).
Masimo® SpO2 Module: Use only original Masimo pulse oximeter sensors and cables.
Check the application site of the SpO2 sensor frequently to confirm proper positioning of the sensor and to check the
circulation and skin sensitivity of the patient.

ADView 2 User Manual | 7
93-9005-00 rev 4
September 1, 2016
Wireless Networking
When connecting this device to a wireless network, it is important to use only the hardware specified by ADC (see
Accessories section for details). Unsupported USB accessories, including unsupported wireless adapters, have been
intentionally disabled and will not function with this device.
Possible Adverse Reactions
In the area of the BP cuff or SpO2 sensor, allergic exanthema (symptomatic eruption) may result, including the
formation of urticaria (allergic reaction including raised edematous patches of skin or mucous membrane and
intense itching) caused by the fabric material of the cuff or sensor.
Following the application of the BP cuff, petechia formation (a minute reddish or purplish spot containing blood that
appears in the skin) or Rumpel-Leede phenomenon (multiple petechia) may appear on the arm, which may lead to
idiopathic-thrombocytopenia (spontaneous persistent decrease in the number of platelets, associated with
hemorrhagic conditions) or phlebitis (inflammation of a vein).
Warnings and Cautions
WARNING: Do not attach the cuff to a limb being used for IV infusions or any other intravascular access, therapy or
an arteriovenous (A-V) shunt. The cuff inflation can temporarily block blood flow, potentially causing harm to the
patient.
WARNING: Pressurization of the cuff can temporarily cause loss of functionality of SpO2 if simultaneously using
device on the same limb.
WARNING: Not designed for neonates.
WARNING: Do not apply the BP cuff to a limb being used for IV infusions as the cuff inflation can temporarily block
the infusion, causing harm to the patient.
WARNING: Check frequently by observing the limb that operation of the AUTOMATED SPHYGMOMANOMETER does
not result in prolonged impairment of the circulation of the patient.
WARNING: The cuff should not be applied over a wound as this can cause further injury.
WARNING: The cuff should not be placed on the arm on the side of a mastectomy. In the case of a double
mastectomy use the side of the least dominant arm.
WARNING: The ADView 2 is NOT defibrillator protected.
WARNING: Do not use in the presence of flammable anesthetics or other flammable substances in combination with
air, oxygen-enriched environments, or nitrous oxide.
WARNING: Do not use the device if it has failed its diagnostics self-test, or if it displays a greater than zero pressure
with no BP cuff attached or a value of oxygen saturation with no SpO2 sensor attached.
WARNING: Do not use if device is dropped and/or damaged. Have a qualified service representative check the unit
before using again.
WARNING: Do not remove unit covers. Doing so may cause electrical shock to the user. The device does not contain
any user serviceable components.
WARNING: Do not immerse the device in any fluid, place fluids on top, or attempt to clean the unit with any liquid
detergents, cleaning agents, or solvents. This may cause an electrical hazard. Refer to the cleaning section of this
guide for instructions on cleaning. If any of these situations apply, please contact ADC.
WARNING: Remove power before servicing device. Failure to remove power could cause electrical shock or death.
WARNING: A pulse oximeter should NOT be used as an apnea monitor.

ADView 2 User Manual | 8
93-9005-00 rev 4
September 1, 2016
WARNING: Pulse rate measurement is based on the optical detection of a peripheral flow pulse and therefore may
not detect certain arrhythmias. The pulse oximeter should not be used as a replacement or substitute for ECG-based
arrhythmia analysis.
WARNING: Do not use the device or any of its accessories during magnetic resonance imaging (MRI) scanning.
Induced current could potentially cause burns.
WARNING: Tissue damage can be caused by incorrect application or use of an SpO2 sensor, for example by wrapping
the sensor too tightly. Inspect the sensor site as directed in the sensor Directions for Use to ensure skin integrity and
correct positioning and adhesion of the sensor.
WARNING: Do not use high frequency surgical equipment with the ADView 2 as this may cause loss of stored data
WARNING: No modification of this equipment is allowed.
WARNING: Federal (U.S.) law restricts this device to sale by or on the order of a physician.
CAUTION: A compressed or kinked connection hose may cause continuous cuff pressure resulting in blood flow
interference and potentially harmful injury to the patient.
CAUTION:
Check calibration of this device annually.
CAUTION: Calibration should be done by a biomedical technician or other authorized personnel.
CAUTION: Never knowingly use a defective device.
CAUTION: Immediately replace parts that are broken, worn, missing, incomplete, damaged or contaminated.
CAUTION: Contact the nearest ADC-approved service center should repair or replacement become necessary. A list
of approved service centers appears in the guide or on our website at www.adctoday.com.
CAUTION: The reliability of the device depends upon conformance with the operation and service instructions, as
detailed in this manual.
CAUTION: Only replace battery with same type and model number.
CAUTION: To avoid the risk of electrical shock, this equipment must be only connected to supply mains with
protective earth.
CAUTION: Do not connect the device to equipment that does not meet EN60601-1. When the device is attached to a
patient, the device’s communication ports must only be connected to equipment that meets EN60601-1 standard.
CAUTION: Use only ADC-branded cuffs approved for use on the ADView 2 device.
CAUTION: Use only Masimo oximetry sensors for SpO2 measurements with the Masimo SpO2 module. Other oxygen
transducers (sensors) may cause improper performance.
CAUTION: Do not use damaged SpO2 or temperature sensors. Do not use an SpO2 sensor with exposed optical
components.
CAUTION: Do not immerse the SpO2 or temperature sensors in water, solvents, or cleaning solutions (the sensors and
connectors are not waterproof). Do not sterilize by irradiation, steam, or ethylene oxide. See the cleaning instructions
in the Sensor Directions for Use.
CAUTION: Do not use damaged patient cables. Do not immerse the patient cables in water, solvents, or cleaning
solutions (the patient cable connectors are not waterproof). Do not sterilize by irradiation, steam, or ethylene oxide.
See the cleaning instructions in the Patient Cable Directions for Use.
CAUTION: Do not position the device so that it is difficult to access and remove the power cord from the electrical
supply. The AC power cord is the means of disconnection to the supply mains.

ADView 2 User Manual | 9
93-9005-00 rev 4
September 1, 2016
Icons, Symbols and Abbreviations
Icons and Symbols
The following icons and symbols are used in this guide, on the ADView 2 equipment, and in packaging.
Warning message
Caution message
Manufacturer
Manufacture date
Authorized representative in the European Community
Catalog number
Serial number
Batch or lot code
Fragile, handle with care
Keep dry
Temperature limit
Humidity limitation
Consult instructions for use
Refer to instruction manual/booklet
Type B
Type BF applied part. Part is isolated from earth ground.
Indicates that the device contains materials which may be
hazardous to human health.
CE mark: Product meets the Medical Device Directive and is CE
marked to indicate conformance
SpO2 sensor. Type BF applied part
USB-A or USB-B
Warning: Federal (U.S.) law restricts this device to sale by or on
the order of a licensed health care practitioner.
Device includes RF transmitter.
Indicates the arm circumference which is appropriate for the cuff
Cuff index marker

ADView 2 User Manual | 10
93-9005-00 rev 4
September 1, 2016
Artery marker indicating proper placement – Arrow and symbol
should be placed over the brachial artery.
Cuff range indication
Device is not made with natural rubber latex
Device is not made with PVC
Class II equipment
IPX1!
Protection against vertically falling drops of water
Expiration date
Single use only
Commonly Used Abbreviations
BP Blood Pressure
BPM Beats Per Minute
EMR Electronic Medical Record system
K-sounds Korotkoff sounds
MAP Mean Arterial Pressure (Not available in the U.S.)
DIA Diastolic BP
NIBP Non-Invasive Blood Pressure
SpO2 Percent Oxygen Saturation of Arterial Blood (hemoglobin)
SYS Systolic BP
2. Setting Up the ADView 2
Your ADView 2 comes ready to use. The battery and any optional modules purchased were installed prior to shipping.
Unpacking the Monitor
As you unpack your ADView 2, check to make sure you have all the proper components.
Refer to the separate packing label stating which components you received based on the options you ordered with
your device.

ADView 2 User Manual | 11
93-9005-00 rev 4
September 1, 2016
Rear Panel Configuration
ADView 2 connections on the back of the device:
A. AC power cord
B. Wi-Fi USB dongle (optional)
C. Printer or barcode scanner USB cable (optional)
D. Ethernet cable (optional)
E. Mini USB cable to connect to PC or laptop

ADView 2 User Manual | 12
93-9005-00 rev 4
September 1, 2016
Side/Temperature Panel Configuration
Optional modules ordered at the time of original purchase are installed prior to shipping. Modules can also be
ordered later and installed in the field. To install the Covidien Filac™ temperature module, use the included Phillips
head screwdriver to remove the panel cover on the right side of the unit (the right side when the screen is facing the
user). Attach the module and fasten in place. Insert the probe/well assembly into the top of the module.
Side/SpO2 Panel Configuration
Optional modules ordered at the time of original purchase are installed prior to shipping. Modules can also be
ordered later and installed in the field. To install an SpO2 module, use the included Phillips head screwdriver to
remove the cover on the left side of the unit (the left side when the screen is facing the user). Attach the module and
fasten in place.
Filac

ADView 2 User Manual | 13
93-9005-00 rev 4
September 1, 2016
For ChipOx:
Attach the ChipOx SpO2 sensor to the connector on the module while the retention clip is held upwards. Once the
sensor/cable connector is inserted, push the clip downward over the connector to hold it securely in the module. For
easy insertion, ensure the cable plug is parallel to the device.
For Masimo:
Attach the Masimo extension cable to the connector on the module, making sure that the connectors lock together.
Then, attach the Masimo SpO2 sensor to the other end of the extension cable making sure that the retaining clip is in
place.
Install Batteries
The rechargeable lithium-ion battery is installed prior to shipping. Please allow 8 to 12 hours for charging before
using your unit. All segments of the Battery Symbol will be lit when the device is fully charged.
CAUTION: Fire, explosion and severe burn hazard. Replace only with ADC part number9005BAT.
If not installed in the device, the battery shall be kept away from heat, fire or other high temperature environments.
Keep the battery in a dry place stored at room temperature.
Do not disassemble, attempt to repair or use the battery for any other device or for any other purpose.
Do not place near any metal or use metal to shield the battery from physical damage as this may cause battery
overheating and/or a fire risk.
Do not short across the contacts of the battery or attempt to discharge the battery by shorting as a risk of fire or
explosion may result.
Do not expose or immerse the battery in water or attempt to clean with any cleaning agents. Only wipe battery with a
damp cloth if necessary.
Wash the affected area if electrolyte spills on skin or clothes. Leaking electrolyte may cause discomfort to the skin. If
it gets into the eyes, do not rob the eyes. Flush eyes immediately with water, and seek medical attention.
Battery Disposal
The ADView 2 has a lithium-ion battery that contains materials which may be hazardous to human health. Do
NOT dispose of battery in domestic waste! Instead, please dispose of in an environmentally responsible way, or
return the battery to ADC. A prepaid return label can be obtained. Please see our website for more information.

ADView 2 User Manual | 14
93-9005-00 rev 4
September 1, 2016
Attach Connections to the Device
After connecting the Power Cable, plug into an available AC power outlet to charge batteries.
Connect the BP cable, SpO2 sensor cable, and temperature sensor (if option is included) to the device.
Connect the barcode scanner and/or printer to the device if these options are included.
Use the Power Button on the left side of the ADView 2 to turn it on.
NOTE: The blue LED around the Selection Knob will be lit whenever the device is powered on.
Mounting Options
The ADView 2 is designed to be used on a tabletop or mounted to a wall or mobile stand. Your device may be
delivered with the appropriate mounting kit, depending on the configuration your facility ordered. Please see the
separate mounting hardware instructions.
System Configuration
The ADView 2 can be used out of the box with the factory settings.
Changes to the factory settings can be made using the Advanced Configuration Application, which can be accessed
by connecting the unit to a Windows computing device. This method can be used to customize certain default
settings, like choosing either BP or Spo2 as the pulse rate source. Advanced configuration can also be used by
qualified technicians to connect to a network or EMR system.
Please see the separate Advanced Configuration Application guide for more information.

ADView 2 User Manual | 15
93-9005-00 rev 4
September 1, 2016
3. Getting to Know the ADView 2
Measurement Display
Patient Identification and Date/Time Stamp
Patient ID
Memory Mode Information
Memory icon
Memory Delete icon
Connections to Ancillary Devices and Networks
Wi-Fi radio on (segments will illuminate in series)

ADView 2 User Manual | 16
93-9005-00 rev 4
September 1, 2016
Wi-Fi radio connected (segments will be illuminated continuously)
AC power connected
Printer connected and powered on
Barcode scanner connected and powered on
Error Alert Symbol
WARNING: User must take immediate action (see additional information in Section 12)
Battery Level Indicator
Battery symbol (all bars illuminated indicate a full charge)
Blood Pressure Measurement Mode Selection Icons
Manual Mode (for auscultatory readings)
Averaging Mode
Number of measurements taken in averaging mode
Maximum pressure setting for Manual Mode
Time before first measurement in minutes (Illuminates when Averaging Mode is selected)
Time between measurements in seconds (Illuminates when Averaging Mode is selected)
Blood Pressure Results (DIA and SYS)
DIA and mmHg: Diastolic blood pressure
SYS and mmHg: Systolic blood pressure
EMR Transmission Icons
EMR icon prompts the user to confirm whether or not to send measurement data as message to EMR
system. (Only shown if EMR connectivity has been set up via Configuration Application.)
Message icon (Indicates if EMR messaging is successful)
If successful, the icon will flash on and off with check mark.
If not successful, it will flash on and off with X.
Adult or Child Patient Selection
Press and hold toggle button for 4 seconds, until selection knob starts flashing. Release toggle button, and use the
selection knob to select the icon needed. Selected icon will blink after 1 second. Press the selection knob to confirm
the selection.
Adult BP Mode icon. This icon is illuminated when the Adult BP mode is selected. The ADView 2 will remain in the
selected patient mode until a new mode is set.

ADView 2 User Manual | 17
93-9005-00 rev 4
September 1, 2016
Pediatric BP Mode icon. This icon is illuminated when the Pediatric BP mode is selected. The ADView 2 will
remain in the selected patient mode until a new mode is set.
Heart Rate and MAP Measurements
Measured in BPM (beats per minute) is illuminated when a heart rate is shown in the heart rate display.
MAP Measured in mmHg. Illuminated when MAP functionality is enabled and a MAP value is shown. NOTE: This is a
factory setting. MAP is not available in the U.S.
Pulse Oximetry Measurement Display
Expressed in % of arterial oxyhemoglobin
Temperature Measurement Settings and Results Display
Body temperature in either Fahrenheit or Celsius (user selectable)
Cold Mode
Predictive Mode
Direct Mode
Human Thermometry Mode. Oral (arrow on right side of head), Axillary (arrow under arm), or Rectal (arrow
pointing to rectum).
Apply temp probe cover

Control Panel
Memory Button
Press this button to enter Memory Mode and to store, view or delete saved measurements.
Save Current Reading: A quick press gives the user an option to save the patients reading, suggested to be done after
each reading.
Access Previous Reading: A long press (holding the button down for 4 seconds) gives the user the option to access
the bank of prior readings. Please see Section 4 to read more about saving and accessing saved readings.
Toggle Mode Button
A quick press gives the user an option to switch between the three BP measurements modes:
Single Measurement, Averaging Measurement and Manual Mode.
A long press (holding the button down for four seconds) gives the user the option to switch between pediatric or
adult mode. More information on switching from adult to pediatric mode can be found in Section 5.
Selection Knob
This round knob rotates clockwise and counterclockwise and can be pressed in to select different options on the
ADView 2. This button can be used to change parameters and to set the intended parameter.
Start/Stop Button
Press this button to start or stop a BP measurement.
Home Button
Pressing this button returns you to the single measurement mode.
Monitor Setup
Press the power button to start Initial Power-up. The display will gradually illuminate over a 3-second period. If this is
the first time the device has been turned on since it left the factory or since the device was set to factory defaults, the
user will be prompted to set the time and date in the following format: MM.DD.YYYY HH:MM:SS. The “MM” portion
of the field will flash first, prompting you to set the month. Turn the Selection Knob to select the appropriate month
and then press the knob in. The next field, “DD,” will flash, prompting you to select the day, and so on, until you have
set “SS” for seconds.
After setting the date and time, the device is ready to use! It is possible to make additional configuration changes to
the ADView 2 using the Advanced Configuration Application.
Visual Alarms
When an error occurs, the Warning icon will blink, in addition to the relevant parameter experiencing the error.
93-9005-00 rev 4 ADView 2 User Manual | 18
September 1, 2016

ADView 2 User Manual | 19
93-9005-00 rev 4
September 1, 2016
Blood pressure error is displaced in the BP heart rate field.
Temperature error will displace in the lower right hand.
SpO2 error will displace in lower left side of the screen.
Battery symbol will flash if error is related to battery.
Depending on the out-of-range value, the display will indicate whether the value is out-of-range (hi) or out-of-range
(lo). If the out-of-range parameter is the systolic or diastolic pressure (or both), and MAP is enabled, MAP is not
displayed for that measurement. NOTE: MAP is not available in the U.S.
See Section 12, “Status Messages and Alarms,” for more details.
4.Good to Know Before You Begin
Power Modes
Initial Power-up occurs the first time the device is turned on after being received from the factory, after the device
has been reset to factory defaults or after the battery has been changed. See “Monitor Setup” for information about
Initial Power-up.
Nominal Power-up refers to every time the device is turned on after Initial Power-up. Simply press the power button
and the display will illuminate.
NOTE: The blue LED around the Selection Knob will be lit whenever the device is powered on.
Power-down occurs when you press the power button when the device is powered up. During power-down, all LCD
segments and icons illuminate for 1 second and then the entire display gradually darkens from normal brightness to
black and then one beep sounds. At this point, the device enters Sleep Mode, a low-power state, and is considered
off.
Automatic Power-down occurs when the device has not been used (i.e., no measurements taken or buttons pressed)
for 1 hour. The device will automatically execute the Power-down sequence and enter Sleep Mode.
Documenting Measurements
Before you start taking measurements, it’s important to document the patient ID per your facility’s procedures.
With a Barcode Scanner
If your ADView 2 is connected to a barcode scanner, you can scan your patient’s barcode ID and it will show at the top
left of your screen. Then, the patient ID will remain attached to all measurements taken, saved in memory, and/or
sent to your facility’s EMR.
Without a Barcode Scanner
If you don’t require a barcode scanner, all measurement results will be displayed on the main screen and can be
saved to the device’s memory, written down in a chart, printed out (with optional thermal printer) or captured in
another way that meets your facility’s documentation procedures.
Printing
The ADView 2 can be connected to an optional thermal printer to easily print out measurement results. See Section
11 for ordering information.

ADView 2 User Manual | 20
93-9005-00 rev 4
September 1, 2016
After connecting the optional thermal printer (see Section 2 and Section 3), ensure that the green LED on the top of
the printer is lit and unblinking before printing.
Reset Print
To print the information currently displayed on the ADView 2 screen, press the print button on the top of the printer
(see diagram above).
Saving Measurements
With EMR Connectivity
Technicians may have already connected the ADView 2 to your facility’s EMR system. If so, you can easily send
measurements directly to the EMR.
With the patient’s current measurements displayed on the screen, press the Memory button . The EMR icon
and Check Mark icon will begin flashing.
Press the Selection Knob to send the data to the EMR. If the measurements are delivered to the EMR successfully,
you will see the EMR Message icon and the Check Mark icon blink four times.
To store the displayed measurements in the device memory without sending to the EMR:
Press the Memory Button ,
While the EMR and Check Icons are flashing, turn the Selection Knob until the X icon is displayed and then press
the Selection Knob. The measurements will be saved to the device memory only.
Without EMR Connectivity
The ADView 2 does not have to be connected to an EMR system to save measurements. You can save them to the
device’s own memory. With the patient’s current measurements displayed on the screen:
Press the Memory button .
All of the measurement values on the screen, the Check icon and the Memory icon will flash on and off 2
times.
The display will then return to a blank screen/shows null values, but the Check Mark icon will flash 2 more times,
this verifies the measurements are successfully stored to the device’s memory.
Note: The ADView 2 does not autosave. The user must save the reading to memory after every reading.
To view results stored in memory, press the Memory Button for more than four seconds. You will see the
most recently saved measurements displayed on the screen, and can turn the Selection Knob counterclockwise to
see older measurements and then clockwise to see newer measurements.
