ADC PROSCOPE 671 User manual

Assembly Instructions for PROSCOPETM Teaching Stethosco es
(Models #671 and #661)
TO ASSEMBLE
A. Attach “Y” tubi g to each set of the bi aurals (660-05) as show i the illustratio .
B. Attach free e d of each “Y” tubi g to the double pair e d of the “Y” co ector (#611-20).
C. Co ect o e e d of the straight tubi g (#671-05TBK) to si gle e d of the “Y” co ector.
D. Co ect remai i g e d of the straight tubi g to stem of chestpiece (#660-01 or #670-01).
Make sure all tubi g co ectio s are firm.
A
A
B
B
C
D

PROSCOPETM Teaching Stethosco es
(Models #671 and #661)
Re lacement Parts Included
Part Number Descri tion Qty.
660-01 PROSCOPETM Nurse Chestpiece 1*
670-01 PROSCOPETM Dual Head Chestpiece 1*
611-20 “Y” Co ector 1
671-05TBK PVC Tubi g, Straight, 10”, Black 1
660-05T PVC “Y” tubi g, 22” 2
660-05 Bi aurals 2
*NOTE: PROSCOPETM Model #671 i cludes the 670-01 chestpiece o ly
PROSCOPETM Model #661 i cludes the 660-01 chestpiece o ly
!
Attention, see
instructions for use.
ADC
55 Commerce Drive
Hauppauge, NY 11788
ADC (UK) Ltd.
Unit 6, PO14 1TH
United Kingdom
tel: [phone]
1-800-232-2670
fax: [phone]
www.adctoday.com
email: [e-mail]
EC REP
IB p/n 345-00 - rev 4 Printed in the U.S.A.
