Spec Sheet
FlexWave™ WMX 3000
WiMAX Single-sector Base Station
The FlexWave™WMX 3000 delivers industry leading WiMAX technology into a single-sector
“stackable” form factor. For service providers seeking entry into the WiMAX market or those
expanding coverage of an existing network, the FlexWave WMX 3000 is an economical and
elegant solution. Its space-saving design allows operators a carrier-grade platform from which to
launch premium voice, multimedia and data services.
The FlexWave WMX 3000 operates seamlessly within a heterogeneous network by synchronizing
with other FlexWave WMX base stations in the same cell. The system offers a broad range of
deployment options including operation as a single-sector base station or operation within a
multi-sector cell site configured through WaveCenter EMS Pro provisioning. Fully compliant with
the IEEE 802.16-2004 standard, FlexWave WMX 3000 supports fixed and nomadic WiMAX
applications and seamlessly integrates into a network consisting of mobile 802.16e-2005
WiMAX.
Features
• Comprehensive 1U indoor unit
• Split design compatible with all FlexWave WMX outdoor radios
• Per-subscriber link management
• Stackable design supporting pay-as-you-grow business model
• Seamless co-location with multi-sector base stations for expanded network coverage

9/07•103693AEFlexWave™WMX 3000
2
www.adc.com • [phone] • 1-800-366-3891
FlexWave™ WMX 3000
WiMAX Single-sector Base Station
Typical Applications
• Lastmile,carrierdeploymentssupportingsmall
initial roll outs, growing to support hundreds
of subscribers
• Convergedfixed-mobileserviceoffering
including multi-user, multi-application, and
multi-service simultaneously
• ScalableVoIPservicewithper-flowQoSand
dynamic link adjustment
• Wirelessapplicationsdesiredbyindoor
consumersofWiMAXincludingDSLbypass
and extended Wi-Fi coverage
• FixedWiMAXserviceevolvingtosupport
mobile subscribers
• Bandwidthhungryvideoanddataapplications
requiring low latency and predictable
performance
The FlexWave™WMX 3000 operates in licensed and license-exempt bands under virtually all wireless
conditionsincludingLOS,OLOS,andNLOS,givingprovidersaversatileplatformformaximizing
WiMAX revenue opportunities. The FlexWave WMX 3000 is an effective wireless access point for
hundreds of simultaneously active subscriber units serving both outdoor and indoor applications.
TheFlexWaveWMX3000usesasplitIDU/ODUdesignwiththe1Urackmountableindoorunit
performing IP networking, backhaul and radio control functions. The outdoor unit consists of a
spectrum-specific radio and antenna connecting to the indoor unit via coax cable carrying power,
timing, and control signals.

9/07•103693AEFlexWave™WMX 3000
3
www.adc.com • [phone] • 1-800-366-3891
FlexWave™ WMX 3000
WiMAX Single-sector Base Station
Specifications
RADIO AND SYSTEM SPECIFICATIONS
Compliance: IEEE802.16-2004(3.5T1,3.5T2),ETSIHiperMAN
Duplexing Mode, PHY: TDD,OFDM256FFT
Frequency: 3.3 – 3.4 GHz, 3.4 – 3.6 GHz, 5.725 – 5.925 GHz
Future: 3.6 – 3.8 GHz, 5.15 – 5.35 GHZ, 5.475
– 5.725 GHz
Channel Bandwidth: 1.75 MHz, 3 Mhz, 3.5 MHz, 5.0 Mhz, 5.5 MHz,
and 7.0 MHz,
Step Size: 250 KHz
Radio Output Power: 17 dBm, 20 dBm, 30 dBm options
Receiver Sensitivity: -95.1 dBm
Modulation: BPSK,QPSK,16QAM,64QAM
Forward Error Correction: Convolution coding 1/2, 2/3, 3/4
IP NETWORKING FEATURES/OPTIONS
IP Version: IPV4(RFC791)
Bridging Mode: IEEE 802.3d
Routing: RIPV2,OSPF(future)
VLANs: IEEE802.1P/Q
SECURITY/ENCRYPTION
Authentication: X.509 based authentication
Encryption: 3DES, AES CCM 128, 1024
MULTI-SERVICE/MULTI-USER SUPPORT
Traffic Classification:
MACDA/SA,802.1P/Q,IPSA/DA,IPProtection,IPTOS,
TCP/UDP Port
Scheduling/QoS: UGS,rtPS,nrtPS,BE,CIR,MIR
Max # Sectors: single
Active Connected Subscriber Units: 512 per sector
Uni-directional Service Flows: up to 7168 per sector
PHYSICAL INTERFACES
RF Sectors, IF Port: 1xIFPortforconnectiontoBSR
   (Type-F,Female,75Ohm)
Backhaul: 1x10/100BT(RJ45)
Management: RS-232(DB9)
External clock, Synchronization: 10MHzClock(BNC)/1HzSync(BNC)
MANAGEMENT
Remote Management and Monitoring: WaveCenterEMSPro,CLI(Telnet),SNMP
Local Management and Monitoring: CLI(RS232)
Provisioning: CentralizedusingWaveCenterEMSPro(SNMP)
SNMP: MIBII(RFC1213),EnterpriseMIB;
    SNMPV2,IEEE802.16fMIB
MECHANICAL
Indoor Unit Dimensions (W*H*D)/weight: 42.0 x 4.2 x 27.0 cm / 16.5" x 1.65" x 10.6"/5.5 kg
(12 lbs.)
Outdoor Unit (W*H*D)/weight: 29.8 x 7.0 x 29.8 cm / 11.75" x 2.75" x 11.75"/4.5 kg
(10 lbs.)
IDU-ODU Distance: up to 250 m
ELECTRICAL
Input DC Voltage: DC40–60V
Input AC Voltage: 85VAC–265VAC
Max Power Consumption: 70 W
ENVIRONMENTAL Indoor Outdoor
Weather Protection: na IP65/NEMA-4
Operation Temperature: 0° to 40° C - 35° to 60° C
Humidity: 10 - 90%, non-condensing 0 - 95%, non-condensing
RoHS Compliance: yes yes
