Addspace OFW00124 User manual

Assembly Instructions - Please keep for future reference
Width - 77.0cm
1 Door 4 Drawer Sideboard
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Dimensions
Depth - 38.8cm
Height - 71.0cm
Rev C - 31.01.2017
041 xx 6632

Important - Please read these instructions fully before starting assembly
Safety and Care Advice
Check you have all the
components and tools listed on
pages 2 and 4.
Remove all fittings from the
plastic bags and seperate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Do not stand or put weight on
the product, this could cause
damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Parts of the assembly will be
easier with 2 people.
We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
Care and maintenance
Always lift furniture when
moving it (do not drag)
otherwise the joints may be
damaged.
From time to time check that
there are no loose screws on
this unit.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
1
Dust surfaces with a soft, dry,
lint free cloth.
More stubborn marks can be
removed using a damp
(not wet) cloth. Wipe the
surface dry immediately
using a soft lint free cloth.
Do not use detergants, abrasive
cleaning products or cleaning
products that contain ammonia,
solvents or silicone as these
may damage the surface finish.
To protect the furniture,
position the furniture out of
direct sunlight and away from
direct heat sources such as
radiators and fires.
Do not place the furniture in
excessively dry and humid
conditions.
Do not place hot or cold
objects on the surface, always
use protective mats to avoid
marking the furniture.
Clean spills up immediately
Dispose of all packaging
carefully and responsibly
when assembly complete.
Do Not dispose of packaging
until assembly complete.

Please check you have all the panels listed below
Components -Panels
Division (64.3x36.9cm)
Code - Code -
2
Important - Thick lines indicate finished edges
0321 0309
Backpanel (76.2x67.0cm)
Code - 0322
Drawer front x 4 (38.6x15.7cm)
Code - 0310
Top (77.0x38.8cm)
Drawer bottom x 4 (33.8x29.8cm)
Code -
2601
0319
Code -
Shelf (36.0x36.9cm)
Code - 8873
Left end (64.3x36.9cm) Right end (64.3x36.9cm)
Code - 0311
Bottom (77.0 x38.8cm)
Door (63.6x37.4cm)
0320
Code -
Code - 0307
Left drawer side x 4 (30x10cm)
Code -
Right drawer side x 4 (30x10cm)
Code -
622xx7002
Drawer back x 4 (32.7x10cm)
Code - 624xx7004
623xx7002

3
Components -Exploded View
0307
0309
0311
8873
0321
0319
0322
0320
622xx7002
4472
623xx7002
0310 2601
624xx7004
Drawers x4

70 80 90 100 110 120
010 20 30 40 50 60
mm
130 140 150 160 170
Ruler - Use this ruler to help correctly identify the screws
Please check you have all the fittings listed below
Components-Fittings
Note: The quantities below are the correct amount to complete the assembly, In some case more fittings
may be supplied than are required.
Tools required
4
Small Cross
Headed
Screwdriver
Tape Measure
Eye protection
(when using a
hammer)
Large cam x 10
Code 760001103
Metal dowel x 18
Code 760003004
Small cam x 8
Code 760003005
20mm bolt x 5
Code 700002006
ABC
D
G
JL
45mm screw x 6
Code 690001075
M
Wooden dowel x 6
Code 770001006
8mm screw x 16
Code 700003510
12mm screw x 4
Code 690001008
K
I
22mm screw x 5
Code 690001018
H
O
Hingeplate x 2
Code 653006000
Runner x 8
Code 760001040
N
E
Glide foot x 5
Code 720006001
F
9mm bolt x 8
Code 690001078
Large Cross
Headed
Screwdriver
Small Hammer Bradawl
Handle x 5
Code 640031118
P
Straight arm 26mm
hinge x 2
Code 652001128
Panel pin x 30
Code 760001012
Panel pin guide x 1
Code 684004501
RS
T
L Bracket x 1
Code 760001901
12mm Screw x 2
Code 690001099

Step 1
Assembly Instructions
5
Note: Insert metal
dowels as far as
shown by arrows.
Do not over tighten.
Note: Ensure cam
arrow points towards
the edge with hole.
A
Step 2
Fitting cams,dowels,
wooden dowels to left,
right hand end panels
B
Note: Insert metal
dowels as far as
shown by arrows.
Do not over tighten.
B
Fitting dowels to top
panel
B
B
x6
B
x2 x4
MA
x4
B
Use a hammer
to knock in
wooden dowels
into inner
holes.
M
M
0319
0321
0307

Step 3
Assembly Instructions
6
Fitting hingeplates to
left and right hand
end panels x2
J
J
Locate the pre-drilled
holes on the left and right
hand end panels. Fix
hingeplates in place by
tightening screws already
inserted in the hingeplate.
Step 4
x2
MA
x2
Note: Ensure cam
arrow points towards
the edge with hole.
A
Fitting cams,dowels,
wooden dowels to
divider.
0307
0309

7
Assembly Instructions
Step 5
a:Align the drawer
runner with the
finished edge of panel
the 2nd hole from
the front will then line up
with a pre-drilled hole,
secure the runner to the
panel using screws .
D
Attaching runners
to lh end and division.
Important:
We recommend you
do this on the packaging
the unit came in to
protect your floor.
b: Slide the drawer
runner forward to
secure screw .
The 2nd to last hole in
the runner will line up with
the pre-drilled holes in the
panel.
D
DD
Step a Step b
x16x8
D
N
N
N
N
N
Note: It is essential that
drawer runners are
attached correctly.
Ensure that the holes in
the runners are positioned
as shown.
Step 5a Now turn panel over divider
to attach metal dowels
Note: Insert metal
dowels as far as
shown by arrows.
Do not over tighten.
B
B
B
x2
0309
We suggest using the
cardboard packaging
to place under this
panel to prevent
damage to your floor.
0309
0321

Assembly Instructions
8
Step 6
Attach hinges and
handles to door
a: Insert hinges
into holes, ensure
the hinge is straight
(90 degree angle).
Important:
b: Before securing the
hinges , we recommend
you pre - mark the door
using a bradawl.
c: Secure hinges to
door using screws .
Secure handle to
door
using bolt .
G
0311
K
F
x4x2
OK
x1
G
O
O
O
x1
F
0311
0311
0311
O
O
K
K
K
K
F
G
Bradawl
90
Correct
98
Incorrect

0310
a: Insert dowels into
drawer front.
Note: Insert metal
dowels as far as
shown by arrows.
Do not over tighten.
9
Drawer assembly
B
Step 7
c: Insert wooden dowels
in drawer back
into holes in
left
right hand
drawer sides.
b: Insert small cams
into left
and right
drawer sides.
Note: Ensure cam arrow
points towards the edge
with hole.
C
C
a:
b:
c:
Left hand side
Right hand side
Left hand side
Right hand side
Drawer Back
Continued on next page.
622xx7002
624xx7004
623xx7002
622xx7002
623xx7002
622xx7002
623xx7002
623xx7002
624xx7004
622xx7002
Assembly Instructions
x8
B
C
x8
B
Drawer images
reduced in size
for illustration
purposes.

0310
10
Drawer assembly
Continued...
Assembly Instructions
Step 7- Continued
Turn cam 180 degrees
to lock
f: Secure handles to
drawer front
using bolt .
C
F
G
d:
f:
0310
Repeat on remaining
three drawers
e:
0310
0310
x4
GF
x4
G
F
d: Sit drawer bottom
into groove on drawer
front.
Ensure foil on the
drawer bottom is facing
upwards.
e:Locate grooves in
left and right drawer sides
around drawer bottom
and slide down locating
cams already inserted
in left and right
drawer sides onto
dowels in drawer front.
Turn cams 180 degrees
to lock.
2601
Foil surface facing upwards.
Plain chipboard surface
to underside.

Step 8
Assembly Instructions
11
8873
Fitting cams to the
shelf
Note: Ensure cam
arrow points towards
the edge with the hole.
A
A
x4
Turn cam 180 degrees
to lock
Connect right end
panel and divider
to shelf.
Step 9
Connect the dowels
already inserted in the
right hand end panel and
divider with the shelf
9681
0307
8873 0309
Finished edges to floor
Insert the metal dowels
located on panel
into the pre-drilled holes
in the ends and division
panels.
Tighten as shown below.
Turn cam 180 degrees
to lock
A
Connect previously
assembled pieces and
left end to top panel.
Step 10
0319
0307
0309
0321
0319
A

12
Assembly Instructions
Step 11
0307
0309
0321
Attach bottom panel.
Locate the wooden
dowels already located
in the end panels
and divisions
. Lower the bottom
panel so that the
wooden dowels line up
with the inside holes on
the bottom panel
Ensure that the dowels
are fully inside of the
pre-drilled holes before
using screw to secure
the bottom panel.
0307
0321
0309
0320
0320
L
x6
L
L
0320
Step 12
Lay the unit on
its front (2 people
may be required).
DIAG 1 DIAG 2 DIAG 3
XX
XX
YY
YY
XX
XX
YY
YY
XX
XX
YY
YY
Square up the unit.
IMPORTANT
Ensure a tape
measure is used
to square up unit!
Before securing the back
it is necessary to square
up the unit.
You can do this by
measuring between
XX - XX and YY - YY
ensuring these are the
same (DIAG 1).
If they are not (DIAG 2)
Apply slight pressure as
indicated (DIAG 3) until
they are the same.
XX
YY
Finished edges to floor
XX

13
Assembly Instructions
Step 13
P
R
Attach the back panel
to the unit.
Use the panel pin guide
when locating the panel
pins. This will hold the
panel pins vertical and
ensure the correct
distance from the edge.
R
x1
P
x30
Finished edges to floor
Plain chipboard surface
to this side.
Step 14
x5
I
x5
E
Attach feet to the
bottom panel.
Attach the glides to the
bottom panel with
screws .
stand the unit upright
(2 people may be
required).
0320
I
E
0320

Assembly Instructions
14
Step 15
a: b:
a: With help, slot door
hinges onto hinge
plates .
Ensure screw on hinge
slides into the slot
on hingeplate .
See Diagrams.
Hanging doors
b: Tighten screw shown
to lock hinges in
position. Repeat a and b
on remaining door.
See ‘Hinge adjustment’
page if the doors need
adjusting.
Please note diagrams
may not reflect the
hinge included in your
pack.
The principal of the hinge
fitting to the hingeplate
shown applies to all our
hinges.
B
Underside view
Ensure the underside of screw
B slides into slot on hingeplate.
Diagram 1
B
Hinge correctly attached to
hingeplate.
Diagram 2
J
O
O
J
O
O
JJ
0311

15
Assembly Instructions
Step 16
a: To move doors up
or down: loosen screws
shown and move doors
to suit.
Re-tighten screws.
Hinge adjustment
b: To move doors in or
out: loosen screw
shown and move doors
to suit.
Re-tighten screws.
c: To move doors left
or right: loosen or
tighten screw as shown.
Be careful not to fully
unscrew.
O
J
O
J
O
J

Assembly Instructions
16
Step 17
x8
H
For this step we
recommend you follow
the helpful hints page
on page 17.
REPEAT WITH 3 REMAINING DRAWERS.
H
H
2nd HOLE
H

Assembly Instructions
17
a: Pull sliding part of
drawer runners out
so they are fully
extended.
Locate drawers helpful
hints
b: Locate drawer onto
runners.
c: Locate screwdriver
into second threaded
hole in drawer runner .
d: Keeping screwdriver
in place push the drawer
in until the screwdriver
pushes against the
panel.
Remove the screwdriver.
e/f: Pull drawer out slowly
and line the front hole in the
drawer side with the 2nd
threaded hole in runner .
Holding runner and
drawer side together
insert bolts through the
drawer side and
into threaded hole in
runner .
Now repeat these
steps for the other
side of the drawer.
J
D
EF
AB
C
2nd Hole
2nd Hole
J
H
Step 17 - continued
N
N
N
N
N
N
N
N
H

18
Assembly Instructions
Step 18
We recommend that this
unit is fixed to a suitable
wall to prevent possible
overbalancing. We have
included a fixing bracket
for this. No fixing screws
are provided as they will
need to suit the wall
type, and the length of
screw will depend on
the distance from the
back of the unit to the
wall. Please ensure
fixings used are
appropriate to your wall
type. Locate the bracket
to the top panel or to the
end panel as close to
top as possible. We do
not specify exact
location for the bracket,
this is left to the
customer’s discretion.
Fixing to wall
Please take care when
drilling into the wall,
avoiding any pipes and
wires. Wear safety
goggles when drilling.
The use of residual
current device (RCD) is
recommended when
working with tools.If in
doubt consult a
qualified person.
Warning:
2 people to lift.
Lift with care.
With help move the
unit into position.
Warning:
S
x1
T
x2

Assembly Instructions
Congratulations! Your unit is complete.
Important Information
If you need help or have damaged or missing parts, call the Customer Helpline:
01709 534123 8am - 4.30pm (Monday toThursday)
8am - 2.30pm (Fridays)
Please have the following information to hand:
>> Unit Description
>> Product Code
>> Product Colour
>> Place of Purchase
>> Catalogue Ref. No.
>> Item Code
>> Assembly Instructions
You can also e-mail your requests to us at:
[e-mail]
Alternatively, you can write to us at: Customer Service Department, Addspace Furniture Limited,
Braithwell Way, Hellaby Industrial Estate, Hellaby, Rotherham, South Yorkshire, S66 8QY.
We do have an answer machine should you contact us out of office hours, so in addition to
the above information could you leave your name, address, daytime telephone number and
the nature of your call on the answerphone. All calls will be actioned asap.
(by contacting the customer service line your statutory rights are not affected)
