Addspace 011 7027 Series User manual

Product code
011XX 7027
Assembly Instruction
610 00 7027
Issue: B
Help and advice
Tools Required Help and Advice
Dear Customer,
In the unlikely event of you finding any parts either missing or faulty, it will not be
necessary to go to the trouble of returning the complete item.
Please include the following information: Unit Description, Product Code, Product Colour,
Place of Purchase, Catalogue Ref. No., Item Code.
Do not throw away any of the packaging until you have checked that you have all the
component parts and fittings.
THE SCREWPACK CONTAINS ITEMS WHICH MAY PROVE DANGEROUS TO CHILDREN
ESPECIALLY THOSE UNDER 36 MONTHS.WE THEREFORE RECOMMEND CAUTION IS
OBSERVED DURING THE ASSEMBLY OF YOUR UNIT. IF THE UNIT CONTAINS SCREW
COVERCAPS, WE SUGGEST THAT THESE ARE GLUED INTO POSITION.
You can also e-mail your requests to us at: customer[email protected]o.uk
Alternatively contact us on 01709 534123 and leave your name, address, daytime telephone
number and the nature of your call on the answerphone. All calls will be actioned asap.
Before you start take a few moments to read through this leaflet and then follow the step
by step instructions.
TALL BOOKCASE
Step by Step Assembly Instructions
Product Dimensions
HHHxWWWxDDD
1784x668x290mm
Tape Measure
Cross Head Screwdriver
Hammer
Simply Write to us at: Customer Service Department, Addspace Furniture Limited,
Braithwell Way, Hellaby Industrial Estate, Hellaby, Rotherham, S.Yorks, S66 8QY.
CUSTOMER HELPLINE:
01709 534123.
ASSEMBLY TIME: 1hr Approx.

5620
COMPONENT PARTS LIST
DESCRIPTION SIZE QTY CODE
LH END 1784x280x15 1 5703
RH END 1784x280x15 1 5704
TOP 668x290x15 1 5619
SHELF 634x278x15 3 5635
PLINTH 634x70x15 1 5637
BACK PANEL 1724x660x3 1 5695
FITTINGS
PAGE 2
760001103
CODE QTY 760003004
CODE QTY
4 4
aa bb
5703
5704
5695
5635
5619
SHELF 634x280x15 2 5620
5637
cc
690001075
CODE QTY
45mm
8
5635
760001012
CODE QTY 684004501
CODE QTY
60 1
ii
hh
770001006
CODE QTY
4
ee
681003001
CODE QTY
12
dd
ll mm
760001901
CODE QTY CODE QTY
690001099
12mm
1 2
5620
5635
0 10 20 30 40 50 60
mm

LOCATE FITTINGS - CONTINUED...
STEP 1 PAGE 3
LOCATE FITTINGS - NOTE:THICK LINES INDICATE FINISHED EDGES.
Fittings you will need in this step:
Fittings you will need in this step:
(x4)
bb
bb
ENSURE CAM ARROW
POINTS TOWARDS EDGE
WITH HOLE.
SCREW IN DOWEL
UNTIL TIGHTENED.
aa
bb
bb
5619
bb
bb
aa
(x4)
aa aa aa
aa
LOCATE SHELF AND PLINTH TO LH AND RH END
5703
5704
STEP 2
cc
Fittings you will need in this step:
cc
(x8)
cc
cc
5637
LOCATE TOP TO LH AND RH END
STEP 3
ee
ee
ee
ee
(x4)
5637
5703
5704
5620
cc
NOW LOCATE SCREW
cc THROUGH HOLES
IN PANEL 5703 AND
5704 AND SCREW
INTO HOLES IN
PANELS 5620 x 2.
LOCATE WOODEN ee
DOWELS ALREADY
INSERTED INTO 5637
INTO HOLES IN
PANELS 5703 AND
5704.
5619
cc
INSERT DOWELS
IN PANELS 5619
INTO CAMS IN PANELS
5703 AND 5704.
THEN LOCK.
TURN CAM 180 DEGREES
TO LOCK.
RAW FACE
cc
cc
cc
5620
5704
5703

5704
5703
STEP 4 PAGE 4
STEP 6 LOCATE SHELVES AND OVERBALANCE BRACKET
STEP 5 ATTACH 3mm BACK PANEL
SQUARE UNIT UP
Fittings you will need in this step:
CONGRATULATIONS YOUR UNIT IS COMPLETE
PLEASE NOTE:TO KEEP YOUR UNIT IN PERFECT CONDITION CLEAN ONLY WITH A SOFT DAMP CLOTH.DO NOT USE
ANY ABRASIVE CHEMICAL CLEANERS. DO NOT SUBJECT YOUR UNIT TO HEAT OR MOISTURE.I E BY
PLACING HOT OR DAMP CUPS ETC ON ANY OF THE SURFACES.
LIFT UNIT UP
5619
STEP 9
BEFORE SECURING THE
BACK IT IS NECESSARY
TO SQUARE UP THE UNIT.
YOU CAN DO THIS BY
MEASURING BETWEEN
XX-XX AND YY-YY
ENSURING THESE ARE THE
SAME (DIAG 1). IF THEY
ARE NOT (DIAG 2) APPLY
SLIGHT PRESSURE AS
INDICATED (DIAG 3) UNTIL
THEY ARE THE SAME.
DIAG 1
DIAG 2
DIAG 3
XX
XX
YY
YY
XX
XX
YY
YY
XX
XX
YY
YY
YY
YY
XX
XX
MEASURE TO
EXTERNAL
CORNERS.
IMPORTANT!
ENSURE A TAPE
MEASURE IS USED
TO SQUARE UP UNIT!
hh
ii
(x1)
ii
hh
5704
ALIGN BACK PANEL (5695)
SO THAT THERE IS A EQUAL
GAP FROM THE EDGE OF
END PANELS (5703 AND
5704) THEN
SECURE THIS IN PLACE.
USE THE NAIL GUIDE WHEN
LOCATING THE NAILS.
THIS WILL HOLD THE NAILS
VERTICAL AND ENSURE THE
CORRECT DISTANCE FROM
THE EDGE.
5695
(x60)
DECIDE AT WHAT HEIGHT
YOU REQUIRE YOUR
SHELVES THEN
PUSH IN SHELF STUDS
IN TO END L/H (5703) AND
R/H(5704).
THEN LOCATE SHELVES.
dd
dd
(x12)
We recommend that this
unit is fixed to a suitable
wall to prevent possible
overbalancing.We have
included a fixing bracket for
this. No fixing screws are
provided as they will need
to suit the wall type, and
the length of screw will
depend on the distance
from the back of the unit to
the wall. Please ensure
fixings used are appropriate
to your wall type.
Please take care when
drilling into the wall,
avoiding any pipes or wires.
If in doubt consult a
qualified person.
mm
ll
(x1) (x2)
5620
5704
5620
hh
5695
5635
5635
5635
5703
5704
WE RECOMMEND THAT THE UNIT IS LIFTED AND NOT DRAGGED.
