Addspace Helsinki OA580 User manual

Assembly Instructions - Please keep for future reference
Width - 64.7cm
1 Door Corner Robe
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Dimensions
Depth - 64.7cm
Height - 179.9cm
Rev B - 22/01/2016
001 xx 4057
MADE IN
GREAT BRITAIN

Important - Please read these instructions fully before starting assembly
Safety and Care Advice
Check you have all the
components and tools listed on
pages 2 and 3.
Remove all fittings from the
plastic bags and seperate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Do not stand or put weight on
the product, this could cause
damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Parts of the assembly will be
easier with 2 people.
We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
Care and maintenance
Always lift furniture when
moving it (do not drag)
otherwise the joints may be
damaged.
From time to time check that
there are no loose screws on
this unit.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
1
Dust surfaces with a soft, dry,
lint free cloth.
More stubborn marks can be
removed using a damp
(not wet) cloth. Wipe the
surface dry immediately
using a soft lint free cloth.
Do not use detergents, abrasive
cleaning products or cleaning
products that contain ammonia,
solvents or silicone as these
may damage the surface finish.
To protect the furniture,
position the furniture out of
direct sunlight and away from
direct heat sources such as
radiators and fires.
Do not place the furniture in
excessively dry and humid
conditions.
Do not place hot or cold
objects on the surface, always
use protective mats to avoid
marking the furniture.
Clean spills up immediately
Dispose of all packaging
carefully and responsibly
when assembly complete.
Do Not dispose of packaging
until assembly complete.

Please check you have all the panels listed below
Components -Panels
2
Important - Thick lines indicate finished edges
Top
(64.7x64.7cm)
9378
Left Back
(178.4x63.0cm)
9380
Plinth
(34.4x9.2cm)
9382
Door
(168.4x32.9cm)
9369
Hanging rail
(60.8cm Long)
740006000
Bottom x 2
(61.3x61.3cm)
9379
Right Back
(178.4x61.3cm)
9381
Left End
(178.4x39.5cm)
9383
Right End
(178.4x39.5cm)
9384

3
70 80 90 100 110 120
010 20 30 40 50 60
mm
130 140 150 160 170
Ruler - Use this ruler to help correctly identify the screws
Please check you have all the fittings listed below
Components - Fittings
Note: The quantities below are the correct amount to complete the assembly, In some case more
fittings may be supplied than are required.
Tools required
If you have damaged or missing components, call the
Customer Helpline: 01709 534123 Please turn to back page
for important information when contacting Customer Helpline.
Cross headed screwdriver
(medium & large )
Small Hammer
Tape Measure
Eye protection
(when using a
hammer)
Large cam x 36
Code 760001103
Metal dowel x 36
Code 760003004
13mm screw x 6
Code 760006002
ABC
E
DF
I
G
20mm bolt x 2
Code 700002006
H
J
Support bracket x 1
Code 760001901
K
Hingeplate x 3
Code 653004050
Hanging supports x 2
Code 680006003
Back connection x 2
Code 760004010
L
12mm screw x 10
Code 690001008
12mm screw x 2
Code 690001099
Handle x 1
Code 644004050
45 degree 26mm
hinge x 3
Code 652004050
Bradawl

Exploded View
4
9369
9380 9381
9383 9384
9378
9379
9379
9382

Step 2
Assembly Instructions
5
B
x12
B
Fitting dowels to back
panels.
B
A
Insert 12 metal dowels
into the right back
and left back
9381
9380
Note: Tighten metal
dowels up fully against
the panel.
Do not over-tighten.
A
x16
Step 1
Fitting cams into the
back panels.
Insert 16 metal cams
into the right back
and left back .
9381
9380
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
B
B
B
B
B
B
B
B
B
B
B
B
9381
9380
9381
9380

Assembly Instructions
6
Step 3
Attach hinges to the
door
A: Insert hinges
into holes, ensure
the hinge is straight
(90 degree angle).
B: Before securing the
hinges , we recommend
you pre - mark the doors
using a bradawl.
I
I
Bradawl
C: Secure hinges to
doors using screws .
I
F
I
x3
F
x6
9369
9369
9369
9369
F
F
F
F
F
F
A
B
C
D
90
Correct
I
I
I
D:
Fit 2 bolts through
the pre-drilled holes in
the door and
connect to the handle .
D
D
D
9369
D
x2
G
G
G
x1

Insert 8 dowels and
2 cams into the right
end panel 9384
Fitting dowels and
cams to the right end
panel.
B
A
Assembly Instructions
7
Step 4
K
x3
Hingeplates can also be
inserted into the right end.
Insert 3 hinge plates
into the left end panel
.
Ensure arrow on hingeplate
points towards nished
edge.
Insert 8 dowels and
2 cams into the left end
panel
K
9383
9383
Step 5
K
9383
Fitting hingeplates,
dowels and cams to
the left end panel.
B
B
B
B
B
B
B
B
B
BB
B
B
B
B
B
A
A
A
A
B
B
x8
A
A
x2
B
x8
A
x2
9384
K
K

Assembly Instructions
8
Step 6
Fitting cams to the
bottom panels.
A
x16
B
x8
Insert 8 cams into
bottom panel
Repeat on the second
bottom panel.
A
9379
Step 7
Fitting dowels to the
top panel.
Insert 8 metal dowels
into the top panel
B
9378
E
EE
EE
x4
Step 8
Fitting back connector
to the plinth.
Secure 2 back connectors
to the plinth panel
using 4 screws
Flush to edge
9382
9379
A
A
A
A
A
A
A
A
B
B
B
B
B
B
B
B
9378
9379
9382
E
x2
M
MM
M
x2
9382
E
Step 9
Connect the plinth to
one of the bottom
panels.
Connect the plinth
to one of the bottom
panel through the
back connector using
2 screws .
9382
9379
E

Assembly Instructions
9
Step 10
Connect the bottom
panels to the back
panel.
Connect the cams in the
bottom panels to
the dowels in the right
back panel
We recommend that you
build the unit on the
cardboard packaging to
slightly elevate the unit.
This will assist in later
stages of the build.
9379
9381
Step 11
Connect the bottom
panels and right back
to the left back panel.
Connect the cams in the
bottom panels
and the right back
to the dowels in the left
back panel
9379
9381
9380
9379
9379
9379
9379
9380
9381
9381

Assembly Instructions
10
Step 12
Connect the left and
right end panel to the
back and bottom
panels.
Connect the cams in the
bottom panels ,
the left back and
the right back to
the dowels in the left end
and right end
.
9379
9380
9381
9383
9384
Step 13
Connect the top panel
to the end and back
panels.
Connect the cams in the
left end , right end
, left back
and right back to
the dowels in the top
panel .
Stand the unit up once
this stage has been
complete - 2 people
required.
9383
9384 9380
9381
9378
9379
9379
9381
9381
9383
9384
9383
9384
9378
9380
9380

Assembly Instructions
11
Step 14
a: With help, slot door
hinges onto hinge plates.
Ensure screw on hinge
slides into the slot on
hingeplate.
See Diagrams 1, 2 and 3.
Hanging door
b: Tighten screw shown
to lock hinges in
position.
See ‘Hinge adjustment’
page if the door needs
adjusting.
The door can be fitted
to either side depending
on your preference.
A
B

Assembly Instructions
12
Step 15
a: To move door up
or down: loosen screws
shown and move door
to suit.
Re-tighten screws.
Hinge adjustment
b: To move door in or
out: loosen screw
shown and move doors
to suit.
Re-tighten screws.
c: To move door left
or right: loosen or
tighten screw as shown.
Be careful not to fully
unscrew.
A
B
C

Assembly Instructions
13
Step 16
After selecting which side
you would like the
hanging rail, secure the
bracket with 2 screws
. Secure the second
bracket on the opposite
panel.
Fitting the hanging rail
F
F
x4
J
J
x2
F
J
We recommend that this
unit is fixed to a suitable
wall to prevent possible
overbalancing. We have
included a fixing bracket
for this. No fixing screws
are provided as they will
need to suit the wall
type, and the length of
screw will depend on
the distance from the
back of the unit to the
wall. Please ensure
fixings used are
appropriate to your wall
type. Locate the bracket
to the top panel or to the
end panel as close to
top as possible. We do
not specify exact
location for the bracket,
this is left to the
customer’s discretion.
Fixing to wall
Please take care when
drilling into the wall,
avoiding any pipes and
wires. Wear safety
goggles when drilling.
The use of residual
current device (RCD) is
recommended when
working with tools.If in
doubt consult a
qualified person.
With help move the
unit into position.
Warning:
H
x1
C
x2

Assembly Instructions
Congratulations! Your unit is complete.
