Addspace 051 0510 Series User manual

Assembly Instructions - Please keep for future reference
Width - 98cm
Occasional table
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Dimensions
Depth - 49cm
Height - 33.5cm
Rev A - 03.06.10
051 xx 0510

Important - Please read these instructions fully before starting assembly
Safety and Care Advice
Check you have all the
components and tools listed on
pages 2 and 4.
Remove all fittings from the
plastic bags and seperate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Do not stand or put weight on
the product, this could cause
damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Parts of the assembly will be
easier with 2 people.
We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
Care and maintenance
Always lift furniture when
moving it (do not drag)
otherwise the joints may be
damaged.
From time to time check that
there are no loose screws on
this unit.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
1
Dust surfaces with a soft, dry,
lint free cloth.
More stubborn marks can be
removed using a damp
(not wet) cloth. Wipe the
surface dry immediately
using a soft lint free cloth.
Do not use detergants, abrasive
cleaning products or cleaning
products that contain ammonia,
solvents or silicone as these
may damage the surface finish.
To protect the furniture,
position the furniture out of
direct sunlight and away from
direct heat sources such as
radiators and fires.
Do not place the furniture in
excessively dry and humid
conditions.
Do not place hot or cold
objects on the surface, always
use protective mats to avoid
marking the furniture.
Clean spills up immediately
Dispose of all packaging
carefully and responsibly
when assembly complete.
Do Not dispose of packaging
until assembly complete.

Please check you have all the panels listed below
Components -Panels
2
Important - Thick lines indicate finished edges
Rail x 2 (32x10.2cm)
Code - 7611
Bottom (93x41.4cm)
Top (98x49cm)
7555 7556
Code -
Code -
End panel x 2 (32x41.4cm)
Code - 7558
Rail x 2 (32x10.2cm)
Code - 7557
Plinth (93x7.5cm)
7559
Code -

3
Components -Exploded View
Important - Thick lines indicate finished edges
7557
7555
7556
7558
7558
7559
7611
7557
7611

70 80 90 100 110 120
0 10 20 30 40 50 60
mm
130 140 150 160 170
Ruler - Use this ruler to help correctly identify the screws
Please check you have all the fittings listed below
Components-Fittings
Note: The quantities below are the correct amount to complete the assembly, In some case more fittings
may be supplied than are required.
Tools required
If you have damaged or missing components, call the
Customer Helpline: 01709 534123 Please turn to back page
for important information when contacting Customer Helpline.
4
Cross headed screwdrivers
(small & large )
Small Hammer
Tape Measure
Eye protection
(when using a
hammer)
Large cam x 22 - Code 760001103 Metal dowel x 22 - Code 760003004
A B M
Wooden dowel x 2
Code 770001006

Step 1
Assembly Instructions
5
Fittings you will need for this step:
B
B
(x8)
Note: Insert metal
dowels as far as
shown by arrows.
Do not over tighten.
B
Fittings you will need for this step:
A
(x4)
Fittings you will need for this step:
Fitting dowels to top
panel
Fitting cams to
bottom panel
Step 2
Step 3
Fitting cams to end
panels
Large
7555
B
A
Note: Ensure cam
arrow points towards
the edge with hole.
A
B
B
B
B
B
B
B
7556
7558 x2
A
A
A
A
A
Note: Ensure cam
arrow points towards
the edge with hole.
A
A
(x12)
Large
A
A
A
A

Step 4
Assembly Instructions
6
Fittings you will need for this step:
B
(x6)
Note: Insert metal
dowels as far as
shown by arrows.
Do not over tighten.
B
Fittings you will need for this step:
Fittings you will need for this step:
Fitting dowels to end
panels
Step 5
Step 6
Fitting cams to rails
B
A
(x4)
Large
7557 x2
7558 x2
B
B
B
7611 x2
A
A
Note: Ensure cam
arrow points towards
the edge with hole.
A
7557 x2 7611 x2
Note: Insert metal
dowels as far as
shown by arrows.
Do not over tighten.
B
Fitting dowels to rails
B
B
B
B
B
B
(x8)

Step 7
Assembly Instructions
7
Fittings you will need for this step:
Fittings you will need for this step:
Step 8
Fitting cams to
plinth
7559
M
(x2)
A
Note: Ensure cam
arrow points towards
the edge with hole.
A
A
(x2)
Large
7559
Use a hammer to
knock in wooden dowels
.
M
M
M
M
Fitting wooden dowels
to plinth
A

8
Assembly Instructions
Step 9
Attach plinth to end
panel
Step 10
7558
7558
7556
7559
Turn cam 180 degrees
to lock
A
Attach end panel to
bottom panel
Locate dowels in
end panel into
cams in bottom
.
Then lock.
B
7556
7558
A
Turn cam 180 degrees
to lock
A
Locate cams in
plinth onto
dowels in end panel
. Ensure wooden
dowel already inserted
into plinth goes
into hole in end panel
.
Then lock.
You will require someone
to hold the plinth until
the next step.
A
7558
7559
B
M
7559
7558
Warning: 2 people
required.

9
Assembly Instructions
Step 11
Step 12
Locate rails to end
panels
Turn cam 180 degrees
to lock
A
Locate dowels in
end panel into
cams in bottom
and plinth .
B
7556
7558
A
7559
7558
7556
Attach end to bottom
and plinth panels
7559
Ensure wooden
dowel already inserted
into plinth goes
into hole in end panel
.
Then lock.
7558
7559
M
Turn cam 180 degrees
to lock
A
Locate dowels in
rails and
into cams in ends
.
Ensure the four cams
are tightened.
B
7558
7557
A
7611
7611
7557
7558
7558
Ensure spare cams
are to this end.

10
Assembly Instructions
Step 13
Turn cam 180 degrees
to lock
A
Turn unit so it is
positioned as shown
to attach top panel to
ends and rails
Locate dowels in
top panel into
cams in ends
and rails and
.
Then lock.
B
7558
7555
A
7557
7611
7558
7558
7611
7611
7557
7557
7555
Note: Please turn over for
important information.
Ensure all eight cams
are tightened.
You will need to use
a small screwdriver
to tighten cams.
7558
7558
Step 14
Turn unit over so
it is positioned as
shown then locate
rails to end panels
Locate dowels in
rails and
into cams in ends
.
B
7558
7557
A
7611
7611
7557
Ensure the four cams
are tightened.
Ensure spare cams
are to this end.

11
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please have the following information: Unit Description, Product Code, Product Colour,
Place of Purchase, Catalogue Ref. No., Item Code, and have the assembly instructions close
to hand.
You can also e-mail your requests to us at: [e-mail]
Simply contact us on CUSTOMER HELPLINE : 01709 534123 Between 8am - 4.30pm
Monday to Thursday and 8am - 2.30p.m friday. Your statutory rights are not affected.
Alternatively Write to us at: Customer Service Department, Addspace Furniture Limited,
Braithwell Way, Hellaby Industrial Estate, Hellaby, Rotherham, South Yorkshire, S66 8QY.
We do have an answer machine should you contact us out of office hours, so in addition to
the above information could you leave your name, address, daytime telephone number and
the nature of your call on the answerphone. All calls will be actioned asap.
Important Information
Congratulations! Your unit is complete
