Addspace 033 7500 Series User manual

Product code
033 XX 7500
Assembly Instruction
610 00 7500
Issue: B
LOW ENTERTAINMENT UNIT
Product Dimensions
HHHxWWWxDDD
310x940x388mm
Tools Required
Help and Advice
Step by Step Assembly Instructions
Tape Measure
Cross Head Screwdriver
Hammer
Bradawl
CUSTOMER HELPLINE:
0845 0613967.
ASSEMBLY TIME:
1hr 30MINS
Approx.
IMPORTANT! PLEASE READ
Help and advice
Please have the following information: Unit Description, Product Code, Product Colour,
Place of Purchase, Catalogue Ref. No., Item Code, and have the assembly instructions close
to hand.
You can also e-mail your requests to us at: customer.help[email protected]o.uk
Simply contact us on CUSTOMER HELPLINE : 0845 0613967 Between 8am - 4.30pm
Monday to Thursday and 8am - 2.30p.m friday.
Alternatively Write to us at: Customer Service Department, Addspace Furniture Limited,
Braithwell Way, Hellaby Industrial Estate, Hellaby, Rotherham, South Yorkshire, S66 8 QY.
Do not throw away any of the packaging until you have checked
that you have all the component parts and fittings.
IMPORTANT! Before you start take a few moments to read
through this leaflet and then follow the step by step instructions.
Dear Customer,
In the unlikely event of you finding any parts either missing or faulty,
it will not be necessary to go to the trouble of returning the complete
item.
We do have an answer machine should you contact us out of office hours, so in addition to
the above information could you leave your name, address, daytime telephone number and
the nature of your call on the answerphone. All calls will be actioned asap.

COMPONENT PARTS LIST
DESCRIPTION SIZE QTY CODE
TOP 940x388x15 1 5729
PAGE 2
5731
BOTTOM 940x388x15 1 5730
LH END 230x370x15 1 5731
RH END 230x370x15 1 5732
DIVISION 230x370x15 1 5733
DRAWER FRONT 471x224x15 1 5734
DRAWER BOTTOM 426x296x3 1 4472
4472
BACK 471x256x3 1 5735
DRAWER SECTION
1@ 300 x 439 x 300x 90 mm
CODE : 625516605
5735
5732
5729
5730
5734
5733
760001103
CODEQTY 760003004 CODEQTY
690001018
CODEQTY
22mm
LARGE
68
aa bb
jj
CODEQTY
ff
cc
760003005
CODEQTY
2
CODEQTY
2
mm
690001021
25mm
CODEQTY
1
nn
644396000
720396000 510
690001008
CODEQTY 760001040
CODEQTY
690001078
CODEQTY
9mm
SMALL dd ee
gg
42
2684004501
CODEQTY
1
ii
690001075
CODEQTY
45mm
kk
6
760001012
CODEQTY
20
hh
010 20 30 40 50 60
mm
FITTINGS
THE SCREWPACK CONTAINS ITEMS WHICH MAY PROVE DANGEROUS TO CHILDREN ESPECIALLY THOSE UNDER
36 MONTHS. WE THEREFORE RECOMMEND CAUTION IS OBSERVED DURING THE ASSEMBLY OF YOUR UNIT.
IF THE UNIT CONTAINS SCREW COVERCAPS, WE SUGGEST THAT THESE ARE GLUED INTO POSITION.

STEP 1 PAGE 3
Fittings you will need in this step:
5729
LOCATE FITTINGS - CONTINUED...
(x6)
(x6)
bb
aa
ENSURE CAM ARROW
POINTS TOWARDS EDGE
WITH HOLE.
SCREW IN DOWEL
UNTIL TIGHTENED.
bb
Fittings you will need in this step:
aa
aa
ALIGN THE DRAWER
RUNNER WITH THE FRONT
OF PANELS 5732 AND 5733.
THE 2ND
HOLE FROM THE FRONT
WILL THEN LINE UP
WITH A PRE-DRILLED
HOLE. SECURE USING
SCREWS dd.
NOW SLIDE THE RUNNER
FORWARD TO SECURE
ANOTHER SCREW. THE 2ND
TO LAST HOLE IN THE
RUNNER SHOULD LINE UP
WITH THE HOLE IN THE
PANEL.
NOTE: DETAIL OF DRAWER
RUNNER POINTS TOWARDS
FRONT FINISHED EDGE
OF PANEL.
LOCATE FITTINGS - CONTINUED...
Fittings you will need in this step:
(x2)
5732
5733
bb
bb
bb
dd
ee
(x4)
dd
dd
dd
dd
dd
FRONT FINISHED EDGE
5731
5732
5733
aa
aa
aa
aa
FRONT FINISHED EDGE
5732
5733
bb
bb
IMPORTANT - NOTE: THICK LINES INDICATE FINISHED EDGES.

STEP 2 PAGE 4
MAKE DRAWER
STEP 3 ATTACH TOP TO ENDS AND DIVISION
(x2)(x2)
bb
cc
ENSURE CAM ARROW
POINTS TOWARDS EDGE
WITH HOLE.
SCREW IN DOWEL
UNTIL TIGHTENED.
SMALL
mm
mm
5734
mm
(x2)
nn
nn
(x1)
bb
bb
5734
STAGE 1
STAGE 4
STAGE 6
TURN CAM 180 DEGREES
TO LOCK.
4472
STAGE 5
INSERT CAMS IN
DRAWER SECTIONS
ONTO DOWELS IN
DRAWER FRONT
5734, THEN LOCK.
4472
5734
Fittings you will need in this step:
STAGE 3
TURN DRAWER SECTIONS
OVER, AND FOLD UP.
STAGE 2
cc
cc
INSERT CAMS IN
PANELS 5731,5732
AND 5733
ONTO DOWELS
IN PANEL 5729.
THEN LOCK.
TURN CAM 180 DEGREES
TO LOCK.
5731
5733
5732
5729
5733
5731
5732
5729
IMPORTANT! PLEASE NOTE AT THIS STEP YOU WILL HAVE TO DECIDE IF YOU WANT THE DRAWER
TO SIT ON THE LEFT HAND SIDE OR RIGHT HAND SIDE OF THE UNIT.
RIGHT HAND SIDE LEFT HAND SIDE
RIGHT HAND SIDE LEFT HAND SIDE

5729
STEP 4 PAGE 5
STEP 5
STEP 6 ATTACH 3mm BACK PANEL
TURN UNIT OVER SO THAT THE FINISHED EDGES ON TOP/BOTTOM ARE TO
THE FLOOR(2 PERSONS) AND SQUARE UNIT UP
ATTACH BOTTOM TO ENDS AND DIVISION
LOCATE SCREWS kk
THROUGH HOLES
IN BOTTOM 5730
AND SCREW INTO
HOLES IN ENDS
AND DIVISION.
kk
kk
(x6)
Fittings you will need in this step:
kk
kk
kk
kk
kk
kk
5730
BEFORE SECURING THE
BACK IT IS NECESSARY
TO SQUARE UP THE UNIT.
YOU CAN DO THIS BY
MEASURING BETWEEN
XX-XX AND YY-YY
ENSURING THESE ARE THE
SAME (DIAG 1). IF THEY
ARE NOT (DIAG 2) APPLY
SLIGHT PRESSURE AS
INDICATED (DIAG 3) UNTIL
THEY ARE THE SAME.
DIAG 1
DIAG 2
DIAG 3
XX
YY
XX
YY
YY
YY
XX
XX
YY
YY
XX
XX
YY
YY
MEASURE TO
EXTERNAL
CORNERS.
XX
IMPORTANT!
ENSURE A TAPE
MEASURE IS USED
TO SQUARE UP UNIT!
XX
hh
hh
ii
(x1) (x20)
Fittings you will need in this step:
USE THE NAIL GUIDE WHEN
LOCATING THE NAILS.
THIS WILL HOLD THE NAILS
VERTICAL AND ENSURE THE
CORRECT DISTANCE FROM
THE EDGE.
ii
hh
5732
5735
ALIGN BACK PANEL (5735)
SO THAT THERE IS A EQUAL
GAP FROM THE EDGE OF
END PANEL AND
DIV PANEL THEN
SECURE THIS IN PLACE.
5735
THE BACK PANEL IS TO BE
POSITIONED TO COVER THE
BACK OF THE DRAWER
SPACE.
IF YOU HAVE DECIDED TO HAVE A LEFT HAND
DRAWER THE BACK PANELNEEDS TO BE
POSITIONED ON THIS SIDE.

5729
5730
STEP 7 PAGE 6
STEP 8 LOCATE DRAWER
Fittings you will need in this step:
CONGRATULATIONS YOUR UNIT IS COMPLETE
jj
LOCATE FEET TOWARDS
THE CORNERS FOR MORE
STABILITY.MARK POSITION
WITH BRADAWL FIRST.
THEN SCREW IN TO PLACE.
ff
(x5) (x10)
ATTACH FEET
LIFT UNIT ONTO FEET( 2 PERSONS ) THEN
Fittings you will need in this step:
(x2)
PULL SLIDING PART OF
DRAWER RUNNERS (ee)
OUT SO THEY ARE FULLY
EXTENDED. THEN PLACE
THE COMPLETED
DRAWER UNIT ON TO
THE RUNNERS SO THAT
THE 2ND SMALL HOLE
FROM THE FRONT
OF THE RUNNER LINES
UP WITH THE HOLE IN
THE SIDES OF THE DRAWER
SECTION. YOU MAY
REQUIRE SOME HELP TO
DO THIS. THEN FROM THE
INSIDE OF THE DRAWER
SCREW (gg) THROUGH SO
THEY ARE AT TACHED.
gg
gg
gg
ENSURE YOU SECURE
THE FEET TO BOTTOM PANEL
THIS IS EDGED IN SILVER.
jj
ff
jj
ff
jj
jj
jj
jj
ff
jj
jj
ff
jj
ff
PLEASE NOTE:TO KEEP YOUR UNIT IN PERFECT CONDITION CLEAN ONLY WITH A SOFT DAMP CLOTH.DO NOT USE
ANY ABRASIVE CHEMICAL CLEANERS. DO NOT SUBJECT YOUR UNIT TO HEAT OR MOISTURE. I E BY
PLACING HOT OR DAMP CUPS ETC ON ANY OF THE SURFACES.
AFTERCARE INSTRUCTIONS, PLEASE READ.
WE RECOMMEND THAT THE UNIT IS LIFTED AND NOT DRAGGED.
