ADEMCO Security System VISTA-15 Operating instructions

K3894V2 7/01
9,67$
9,67$&1
6HFXULW\6\VWHP

3URJUDPPLQJ*XLGH
•
•
••
•
•••
•
•
•
••
•
•
•
•••
*
®

– 2 –

–3 –
Local programming requires the use of a 2-line alpha keypad connected to the
keypad terminals on the control.
Field Function [ ] = Default Value Programmed Values Field Function [ ] = Default Value Programmed Values
SYSTEM SETUP (✱20 –✱30)
✱20 INSTALLER CODE | | |
Enter 4 digits, 0–9 [4 1 1 2]
✱21 QUICK ARM ENABLE [0] †
1 = enable: 0 = disable
✱22 RF SYSTEM [0] †
0 = none; 1 = 5800 (5881/5882)
4 = 5800 w/ RF Jam Detection
✱23 FORCED BYPASS [0] †
0 = none; 1 = bypass open zones
0 for UL installations.
✱24 RF HOUSE ID CODE [00] |
00 = disable all wireless keypad usage;
01–31 = using 5827, 5827BD, and 5804BD
✱25 WIRED ZONE EXPANSION [0] †
0 = none; 1 = 4219; 2 = 4229; 3 = 4204
✱26 CHIME BY ZONE [0] †
0 = no; 1 = yes (program zones to chime
on zone list 3)
✱27 X–10 HOUSE CODE [0]
0 = A, 1 = B, 2 = C, 3 = D, 4 = E, 5 = F,
6 = G, 7 = H, 8 = I, 9 = J, # + 10 = K, # + 11 = L,
# + 12 = M, # + 13 = N, # + 14 = O, # + 15 = P
✱28 PHONE MODULE ACCESS CODE [00] |
1st digit: enter 1–9; 2nd digit: enter # + 11 for ✱,
or # + 12 for #.
Entering "0" for either digit disables code.
✱29 OUTPUT TO LONG RANGE RADIO [0]
0 = disable; enable = Trouble code 1–9, B (# +11),
C (# + 12), D (# + 13), E (# + 14), or F (# + 15).
The 2nd digit of Trouble Dialer Report is
automatically entered from field ✱60. 0 for UL
installations.
✱30 HARDWIRE SHORT DETECTION [0] †
1 = enable; 0 = disable
ZONE SOUNDS AND TIMING (✱31 –✱39)
✱31 SINGLE ALARM SOUNDING/ZONE [0] †
1 = yes; 0 = no; 0 for UL installations.
✱32 FIRESOUNDERTIMEOUT [0] †
0 = timeout; 1 = no timeout
✱33 ALARM BELL TIMEOUT [1] †
0 = none; 1 = 4 min; 2 = 8 min; 3 = 12 min;
4 = 16 min; 1 (4 min.) minimum for UL.
✱34 EXIT DELAY (in seconds) [2] †
0 = 30 4 = 120
1 = 45 5 = 180
2 = 60 6 = 240
3 = 90
60 sec max for UL installations. Due to the Exit
Delay Restart feature, set for 30 seconds.
✱35 ENTRY DELAY 1 (zone type 01) [1] †
0 = 30; 1 = 45; 2 = 60; 3 = 90; 4 = 120;
5 = 180; 6 = 240. 45 sec max. for UL installations.
✱36 ENTRY DELAY 2 (zone type 02) [2] †
0 = 30; 1 = 45; 2 = 60; 3 = 90; 4 = 120;
5 = 180; 6 = 240. 45 sec max. for UL installations.
✱37 AUDIBLE EXIT WARNING [1] †
0 = no; 1 = yes
✱38 CONFIRMATION OF ARMING DING [0] †
0 = no; 1 = yes (wired keypads and RF);
2 = yes, RF only
✱39 POWER UP IN PREVIOUS STATE [1] †
0 = no; 1 = yes; 1 for UL installations.
†Entry of a number other than the one specified will give unpredictable results.

–4 –
DIALER PROGRAMMING (✱40 –✱52)
In fields ✱40, ✱41, ✱42, enter up to the number of digits shown. Do not fill unused spaces. Enter 0–9; # +11 for ✱; # +12 for
#; # +13 for a 2-second pause.
✱40 PABX ACCESS CODE | | | | |
Enter 6 digits. If fewer than 6 digits are entered, exit
by pressing ✱(and press 41, if entering next field).
To clear entries from field, press ✱40✱.
✱41 PRIMARY PHONE NO.
Enter up to 20 digits; do not fill unused spaces. If
fewer than 20 digits entered, exit by pressing ✱(and
press 42, if entering next field). To clear entries from
field, press ✱41✱.
✱42 SECONDARY PHONE NO.
Enter up to 20 digits; Do not fill unused spaces. If
fewer than 20 digits entered, exit by pressing ✱(and
press 43, if entering next field). To clear entries from
field, press ✱42✱.
✱43 PRIMARY SUBSCRIBER ACCOUNT NUMBER
| | |
[15 15 15 15]
✱44 SECONDARY SUBCRIBER ACCOUNT NUMBER
| | |
For fields ✱43 and ✱44:
Enter 0–9; # +11 for B; # +12 for C; # +13 for D;
# +14 for E; # +15 for F. Enter ✱as 4th digit, if 3+1
dialer reporting is to be used. If only 3 digits used,
exit by pressing ✱(and press next field).
To clear entries from field, press ✱43✱or ✱44✱.
Examples:
For Acct. 1234, enter: 1 | 2 | 3 | 4
For Acct. B234, enter: #+11| 2 | 3 | 4
✱45 PHONE SYSTEM SELECT [1] †
If Cent. Sta.
IS NOT
on a WATS line: 0 = Pulse Dial;
1 = Tone Dial; if Cent. Sta.
IS
on a WATS line: 2 = Pulse
Dial ; 3 = Tone Dial.
✱46 REPORT FORMAT [7] †[7]
†
Primary Secondary
0 = 3+1, 4+1 ADEMCO L/S STANDARD
1= 3+1, 4+1 RADIONICS STANDARD
2= 4+2 ADEMCO L/S STANDARD
3 = 4+2 RADIONICS STANDARD
6
or undefined = 4+2 ADEMCO EXPRESS
7
= ADEMCO CONTACT ID REPORTING
8
= 3+1, 4+1 ADEMCO L/S EXPANDED
9
= 3+1, 4+1 RADIONICS EXPANDED
✱47 SPLIT/DUAL REPORTING [0]
0 = Disable (Backup report only)
TO PRIMARY PHONE No. TO SECONDARY PHONE No.
1=Alarms,Restore,Cancel Others
2 = All except Open/Close, Test Open/Close, Test
3=Alarms,Restore,Cancel All
4 = All except Open/Close, Test All
5=All All
TO PRIMARY PHONE No. TO PAGING No. * (Secondary) †
6 = All except Open/Close Alarms, Open/Close, for users
5-25*, Troubles
7=Allreports Alarms,Troubles
8=Allreports Alarms,Open/Close,forusers
5-25*, Troubles
9 = All except Open/Close Open/Close for users
5-25*
*Will report users 5-16 and, if using wireless button-type
devices, will report the zone number of the arm or disarm
button (10-25). Open/Close for users 1-4 are not reported.
**See Installation Instructions for an explanation of the paging
format.
✱48 DIALER DLY (BURG/FIRE) (in sec) [10] | †
0 = no; 1 = 15; 2 = 30; 3 = 45; 4 = 60; Burg/Fire
5 = 120. 0 for UL installations.
✱49 PERIODIC TEST REPORT [0] †
0 = none; 1 = 24 hours; 2 = weekly; 3 = 30 days
(Enter Test Code in field ✱64.)
✱50 TEST REPORT OFFSET [2] †
  KRXU   KRXUV   KRXUV  
KRXUV 7LPH WR VW UHSRUW IURP SURJUDPPLQJ RU
GRZQORDGLQJ
✱51 SESCOA/RADIONICS SELECT [0] †
0 = Radionics (0 –9, B –F reporting); 1 = SESCOA
(0 –9 only reporting). Select 0 for all other formats.
✱52 CANCEL VERIFY [1]
0 = no; 1 = yes
†Entry of a number other than the one specified will give unpredictable results.

–5 –
✱56 / ✱58 ZONE ASSIGNMENT/ALARM REPORT CODES
This field is an interactive mode. Fill in the required data on the worksheet below (and on next page) and follow the programming procedure in
the installation manual. Zone Types are shown on page 6 of this manual.
ZONES ON CONTROL: See explanation of headings on next page →
ZONE ZONE ZONE ALARM RPT CODE INPUT
RESPONSE NO. TYPE (Hex) TYPE TIME
DESCRIPTION (Zn) (ZT) (RC) (In) (RT)
Wired Zone 1†0 1 [09] [01] [00] HW [1]
Wired Zone 2 0 2[01] [01] [00] HW [1]
Wired Zone 3 0 3[01] [01] [00] HW [1]
Wired Zone 4 04[03] [01] [00] HW [1]
Wired Zone 5 05[03] [01] [00] HW [1]
Wired Zone 6 06[03] [01] [00] HW [1]
†Zone 1 can be used as a 2-wire Fire zone.
Expansion Module Suprvsn 09[05] [01] [00] ——
Duress 9 2 ——[01] [00] ——
Keypad Panic (1 & ✱)95[00] [01] [00] ——
Keypad Panic (3 & #) 96[00] [01] [00] ——
Keypad Panic (✱& #) 99[07] [01] [00] ——
EXPANSION ZONES:
Assign zone numbers (Zn) 10–17 to 4219/4229 Auxiliary Wired Loops A–H, if used. [
ENTER FOR
RF zones can use zone numbers (Zn) 10–35 RF ONLY]
ZONE ZONE ZONE ALARM RPT CODE INPUT LEARNED
DESCRIPTION NO. TYPE (Hex) TYPE RF INPUT
(Zn) (ZT) (RC) (In) (L)
4219/4229 Loop A 1st Exp'n Zone 1 0 [00] [01] [00] [03] [1]
or RF Zones B1 1 [00] [01] [00] [03] [1]
C1 2 [00] [01] [00] [03] [1]
D1 3 [00] [01] [00] [03] [1]
E1 4 [00] [01] [00] [03] [1]
F1 5 [00] [01] [00] [03] [1]
G1 6 [00] [01] [00] [03] [1]
H1 7 [00] [01] [00] [03] [1]
RF Zones 1 8 [00] [01] [00] [03] [1]
1 9 [00] [01] [00]
[03] [1]
2 0 [00] [01] [00]
[03] [1]
2 1 [00] [01] [00]
[03] [1]
2 2 [00] [01] [00]
[03] [1]
2 3 [00] [01] [00]
[03] [1]
2 4 [00] [01] [00]
[03] [1]
2 5 [00] [01] [00]
[03] [1]
2 6 [00] [01] [00] [03] [1]
2 7 [00] [01] [00]
[03] [1]
2 8 [00] [01] [00]
[03] [1]
2 9 [00] [01] [00]
[03] [1]
3 0 [00] [01] [00]
[03] [1]
3 1 [00] [01] [00]
[03] [1]
3 2 [00] [01] [00]
[03] [1]
3 3 [00] [01] [00]
[03] [1]
3 4 [00] [01] [00]
[03] [1]
3 5 [00] [01] [00]
[03] [1]

–6 –
EXPLANATION OF ZONE ASSIGNMENT TABLE HEADINGS
Zn = ZONE NO. Zone Nos. are from 01 to 06, 09 to 35, 92, 95, 96, 99. Some are pre-assigned.
With Field
✱25 set for auxiliary wired loops (4219, or 4229), use Zone Nos. 10–17 for loops A–H.
With Field
✱22 set for RF (5800), use Zone Nos. 10-35.
ZT = ZONE
TYPE
00 = Not Used
01 = Entry/Exit #1
02 = Entry/Exit #2
03 = Perimeter
04 = Interior Follower
05 = Trouble Day/Alarm Night
06 = 24-Hr Silent
07 = 24-Hr Audible
08 = 24-Hr Aux
09 = Fire
10 = Interior w/Delay
12 = 24-Hour Monitor
20 = Arm–Stay
21 = Arm–Away
22 = Disarm
23 = No Alarm Response
24 = Silent Burglary
DEFAULT VALUES
Zn: 01 02 03 04
ZT: [09] [01] [01] (03)
Zn: 05 06 99
ZT: [03] [03] [07]
RC = ALARM REPORT CODE Two Hex Digits. For each Hex Digit, enter: 00–09 for 0–9, 10 for A, 11 for B, 12 for C, 13 for
D, 14 for E, 15 for F. If 00 is entered as the first digit, there will be no report for that zone.
For contact ID reporting, this is an enabling code only. Enter any hex digit (other than 00) in
the first pair of boxes. The second pair of boxes are ignored.
In = LOOP
INPUT TYPE HW: Hard Wire
AW: Aux Wire (4219 or 4229) Enter 2 for AW: Auxiliary wired
Enter 3 for RF: Supervised RF
Enter 4 for UR: Unsupervised RF
Enter 5 for BR: Button Type RF
Hardwire zone input
types are automatically
assigned.
RT = RESPONSE TIME 0 = 10mSec; 1 = 350mSec; 2 = 700mSec. Default Values for zones 01 –06 = 1 (350mSec)
L = LEARNED RF INPUT Used with 5800 RF Loop Input Devices. Record transmitter input number.
SYSTEM STATUS REPORT CODES (✱59 –✱68) †
TO PROGRAM SYSTEM STATUS & RESTORE
REPORT CODES (✱59–✱76, & ✱89):
With a 3+1 or 4+1 Standard Format: Enter a code in the
first
box: 1–9, 0, B, C, D, E, or F. Enter #+10 for 0, #+11 for B, #+12
for C, #+13 for D, #+14 for E, #+15 for F.
A 0 (
not
#+10) in the
first
box will disable a report.
A 0 (
not
#+10) in the
second
box will result in automatic
advance to the next field when programming.
With an Expanded or 4+2 Format: Enter codes in
both
boxes
(1st and 2nd digits) for 1–9, 0, or B–F, as described above.
A 0 (
not
#+10) in the
second
box will eliminate the expanded
message for that report.
A 0 (
not
#+10) in
both
boxes will disable the report.
With Ademco Contact ID Reporting: Enter any digit (other
than 0) in the
first
box, to enable zone to report (entries in the
second
boxes will be ignored).
A 0 (
not
#+10) in the
first
box will disable the report.
Examples:
For Code
3(single digit), enter: 3 | 0
For Code
3 2 (two digits), enter: 3 | 2
For Code
B 2 (Hexadecimal), enter: #+11 | 2
✱59 EXIT ERROR REPORT CODE [0]
✱60 TROUBLE REPORT CODE [00] |
✱61 BYPASS REPORT CODE [00] |
✱62 AC LOSS REPORT CODE
[00] |
✱63 LOW BAT REPORT CODE [00] |
✱64 TEST REPORT CODE [00] |
✱65 OPEN REPORT CODE [0] †
✱66 ARM AWAY/STAY RPT CODE [00] ††
AWAY STAY
†2nd digit is automatically sent as the 2nd digit of the
zone alarm report code programmed in ✱56, if expanded
or 4+2 reporting is selected.
†† 2nd digit is automatically sent as the user number if
expanded or 4+2 reporting is selected.
✱67 RF XMTR LOW BAT REPORT CODE [00] |
✱68 CANCEL REPORT CODE [00] |

–7 –
RESTORE REPORT CODES (✱70 –✱76) †
✱70 ALARM RESTORE RPT CODE [0]
2nd digit is automatically sent as the 2nd digit of
the zone alarm report code programmed in ✱56,
if expanded or 4+2 reporting is selected.
✱71 TROUBLE RESTORE RPT CODE [00] |
✱72 BYPASS RESTORE RPT CODE [00] |
✱73 AC RESTORE RPT CODE [00] |
✱74 LOW BAT RESTORE RPT CODE [00] |
✱75 RF XMTR LO BAT RST RPT CODE [00] |
✱76 TEST RESTORE RPT CODE [00] |
DAYLIGHT SAVING TIME (✱77 –✱78) DYNAMIC SIGNALING (✱79)
✱77 DAYLIGHT SAVING TIME [4,10] | †
START/END MONTH
0 = Disabled; 1 = Jan; 2 = Feb; 3 = Mar….
10 = Oct; 11 = Nov; 12 = Dec.
(Enter 0-9); #+10 = 10; #+11 = 11; #+12 = 12
✱78 DAYLIGHT SAVING TIME [1,5] | †
START/END WEEKEND
0 = Disabled; 1 = First; 2 = Second; 3 = Third;
4 = Fourth; 5 = Last; 6 = Next to Last;
7 = Third to Last
1st Entry 2nd Entry
✱79 DYNAMIC SIGNALING [0] †[0]
†
DS Delay DS Priority
D S Delay; 0-15 times a 15-sec delay
1 = 15 secs; 2 = 30 secs; 3 = 45 secs;
4 = 60 secs…etc.
0 = No delay. (Reports are sent to both
the Primary Phone No. and LRR).
For UL installations, set for 0 = No delay
D S Priority; 0 = Send message to Primary
Phone No. first;
1 = Send message to LRR first.
†Entry of a number other than the one specified will give unpredictable results.
OUTPUT AND SYSTEM SETUP (✱80 –✱93)
✱80 OUTPUT RELAYS AND
POWERLINE CARRIER
DEVICES
✱81 ZONE LISTS FOR OUTPUT
DEVICES
Program only if
Relays and/or
Powerline Carrier
devices are to be
used. See page 9.
✱82 CUSTOM ALPHA EDITING (Also entered from field
✱56)
See procedure in instructions.
✱84 AUTO STAY ARMING [0]
0 = no; 1 = yes
✱85 CROSS ZONE TIMER (in seconds) [0]
0 = 30
1 = 45
2 = 60
3 = 90
4 = 120
5 = 180
6 = 240
NOTE: This field (✱85) and Zone List 04 are not to be
used in UL installations.
✱87 ALARM PAGER DELAY TIME [3]
0 = none
1 = 1 minute
2 = 2 minutes
3 = 3 minutes
✱88 PAGER CHARACTERS(16 digits as user decides)
| | | | | | | | | | | | | | | |
(See field ✴41 for programming instructions)
✱89 EVENT LOG 80% FULL RPT CODE [00] |
✱90 EVENT LOGGING [3]
0 = None; 1 = Alarm/Alarm Restore;
2 = Trouble/Trouble Restore; 4 = Bypass/Bypass
Restore; 8 = Open/Close.
Example:
To select “Alarm/Alarm Restore”and
“Open/Close,”enter 9 (1 + 8); to select all, enter #+15.
Note: System messages are logged when any
non-zero selection is made.
✱91 OPTION SELECTION (AAV) [8]
0 = None;
4 = AAV;
8 = Enable Exit Delay Restart;
12 = Both enabled.
0 for UL installations.
✱92 PHONE LINE MONITOR ENABLE [0]
0 = Not used
1 = Keypad display when line is faulted
2 = Keypad display plus keypad trouble sound
3 = Same as “2,”plus Device #2 STARTS. If armed,
external sounder activates also.
Note: Device #2 must either be programmed to be
STOPPED in field ✱80 or STOPPED by
Code + # + 8 + 2.
✱93 SWINGER SUPPRESSION [0]
0 = Unlimited; 1 - 15 = Number of Alarms
(0 - 9; #+10 = 10; #+11 = 11; #+12 = 12;
#+13 = 13; #+14 = 14; #+15 = 15)
0 for UL installations.

–8 –
DOWNLOAD INFORMATION (✱94, ✱95)
✱94 DOWNLOAD PHONE NO.
| | | | | | | | | |
| | | | | | | | | |
Enter up to 20 digits, 0–9; #+11 for ✱; #+12 for #;
# + 13 for a pause. Do not fill unused spaces. If fewer
than 16 digits entered, exit field by pressing ✱(and
press 95, if entering next field). To clear entries from
field, press ✱94✱.
Note: In UL installations, downloading may only be
performed if a technician is at the site.
✱95 RING DET COUNT FOR DWNLDING [0]
0 = Disable Station Initiated Download; 1–14 =
number of rings (1–9, # +10 =10, # +11 =11,
# +12 =12, # +13 =13, # +14 =14); 15 = answering
machine defeat (# +15 =15)
Note: Do not enter 0 if using 4285/4286 Voice
Module.
✱96 INITIALIZES DOWNLOAD ID, SUBSCRIBER
ACCOUNT NO. FOR INITIAL DOWNLOAD: No
data entry required.
✱97 SETS ALL PROGRAM FIELDS TO DEFAULT
VALUES: No data entry required.
EXITS (✱98, ✱99)
✱98 Exits programming mode and
prevents
re-entry
by: Installer Code + 8+ 0 + 0. If ✱98 is used to
exit programming mode, system must be
powered down. Then power up, and press ✱and
# within 50 seconds of power-up.
✱99 Exits programming mode and
allows
re-entry by:
Installer Code + 8 + 0 + 0 or: Power-up, then
press ✱and # within 50 seconds of power-up.

–9 –
OUTPUT RELAYS/POWERLINE CARRIER DEVICES WORKSHEET FOR ✱80 and ✱81.
Applicable only if Relays and/or Powerline Carrier devices are to be used.
✱80 OUTPUT DEVICES –This is an Interactive Menu mode. Fill in the required data on the worksheet below and follow the
programming procedure in the installation manual as you enter the data in response to the displays and prompts that
appear in sequence.
Notes:
1. For Relays, field ✱25 must be programmed for a 4229 (Relays 01 and 02),
OR
for a 4204 (Relays 01 to 04).
2. For Powerline Carrier devices, field ✱27 must be programmed with a House Code.
3. Tampers of expansion units cannot be used to operate devices.
START
= either or both-STOP = either or both-
DEVICE
NUMBER ACTION (A)
ZONE
EVENT LIST
(EV) (ZL)
ZONE TYPE
SYST OP'N
(ZT)
RESTORE OF
ZONE LIST
(ZL)
ZONE TYPE
/SYST OP'N
(ZT) X-10
SELECT
OUTPUT RELAY
OR P.L.C.D.* 01
OUTPUT RELAY
OR P.L.C.D.* 02
OUTPUT RELAY
OR P.L.C.D.* 03
OUTPUT RELAY
OR P.L.C.D.* 04
* P.L.C.D. = Powerline Carrier device (X-10).
Where:
X-10 SELECT = Powerline Carrier Enter 1 if Powerline Carrier device is being used; enter 0 if relay is being used.
device
A = DEVICE ACTION 0 = No Response; 1 = Close for 2 sec; 2 = Close and stay closed; 3 = Pulse on
and off.
EV = EVENT 0 = Not used; 1 = Alarm; 2 = Fault; 3 = Trouble.
Z L = ZONE LIST 1, 2, or 3 (from Field ✱81) or 0 = Not Used.
"START" ZONE LIST: Upon alarm, fault, or trouble of ANY zone on this list,
device action will START.
"STOP" RESTORE of ZONE LIST: Upon restore of ALL zones on this list,
device action will STOP. It need not be
same list as used for START.
NOTE: Do not use input type "BR" transmitters in a zone list to STOP a relay
action, since these transmitters do not send restores.
ZT = ZONE TYPE/SYSTEM OPERATION
Choices for Zone Types are:
00 = Not Used 06 = 24-Hr Silent
01 = Entry/Exit #1 07 = 24-Hr Audible
02 = Entry/Exit #2 08 = 24-Hr Aux
03 = Perimeter 09 = Fire
04 = Interior Follower 10 = Interior w/Delay
05 = Trouble Day/Alarm Night 24 = Silent Burglary
Note:
Any
zone in "ZT" going into
alarm, fault, or trouble will
actuate relay.
Any
zone of that type that
restores will stop relay action.
Choices for System Operation are:
20 = Arming–Stay 39 = Any Fire Alarm
21 = Arming–Away 40 = Bypassing
22 = Disarming (Code + OFF) 41 = AC Power Failure
31 = End of Exit Time 42 = System Battery Low
32 = Start of Entry Time 43 = Communication
Failure
33 = Any Burglary Alarm 52 = Kissoff
36 = At Bell Timeout** 58 = Duress
38 = Chime
** Or at Disarming, whichever occurs first.
Note: In normal operation mode:
Code + # + 7 + N Key Entry
starts Device N.
Code + # + 8 + N Key Entry
stops Device N.

–10 –
✱81 ZONE LISTS FOR OUTPUT DEVICES (01 - 03); Cross Zones (04); and Night-Stay Zones (05). This is an interactive
mode. Fill in the required data on the worksheet below and follow the procedure in the installation manual as you
enter the data in response to the displays and prompts that appear in sequence.
Note:
Record desired zone numbers below. More or fewer boxes than shown may be needed, since any list may
include
any
or
all
of system's zone numbers.
Zone List 01: Started or stopped by zone numbers (enter 00 to end entries).
, , , , , , , , , ...etc.
Zone List 02: Started or stopped by zone numbers (enter 00 to end entries).
, , , , , , , , , ...etc.
Zone List 03: Started or stopped by zone numbers AND/OR assignment of Chime zones (enter 00 to end entries).
, , , , , , , , , ...etc.
Zone List 04: Cross Zone list: An alarm will occur if the system is armed and two or more of these active burglary
zones (Entry/Exit 1 or 2, Interior Follower, Perimeter, Trouble Day/Alarm, Night, or Interior w/ Delay) remain faulted
after Cross Zone time has expired, and this mode is enabled.
, , , , , , , , , ...etc.
NOTE: This Zone List 04 is not to used in UL installations.
Zone List 05: Night Stay Zones: These interior zones (Interior Follower or Interior w/ delay) will be armed when
arming the system in the Night-Stay mode.
, , , , , , , , , ...etc.
NOTE: Zone 92, DURESS, must not be programmed into any Zone List.

–11 –
SPECIAL MESSAGES
OC = OPEN CIRCUIT (no communication between console and control).
EE or ENTRY ERROR = ERROR (invalid field number entered; re-enter valid field number).
After powering up, "AC, dI"(disabled) or "Busy Standby" and "NOT READY" will be displayed after approximately 4 seconds.
This will revert to READY in approximately. 1 minute, which allows PIRS, etc. to stabilize.
To bypass this delay, press: # + 0.
If E4 or E8 appears, more zones than the expansion units can handle have been programmed. Correct the programming and
then completely de-power and re-power the control to clear this indication and remove the disable indication.
TO ENTER PROGRAMMING MODE:
1. POWER UP, then press ✱and # both at once, within 50 seconds of powering up.
OR
2. Initially, key: Installer Code (4 + 1 + 1 + 2) plus 8 + 0 + 0.
OR
3. If different Installer Code is programmed, key: New Installer Code + 8 + 0 + 0.
(If ✱98 was used to exit previously, method 1 above must be used to enter the program mode again.)
TO EXIT PROGRAMMING MODE:
✱98 Exits programming mode and
prevents
re-entry by keying Installer Code + 8 + 0 + 0. If ✱98 is used to exit
programming mode, system must be powered down, and method 1 above used to enter the programming mode.
✱99 Exits programming mode and
allows
re-entry by keying Installer Code + 8 + 0 + 0; or by powering up, then pressing
✱and # within 50 seconds of power-up.

–12 –
ALPHA VOCABULARY LIST
)RU (QWHULQJ =RQH 'HVFULSWRUV
000 (Word Space)
A
•001 AIR
•002 ALARM
004 ALLEY
005 AMBUSH
•006 AREA
•007 APARTMENT
•009 ATTIC
010 AUDIO
B
•012 BABY
•013 BACK
•014 BAR
•016 BASEMENT
•017 BATHROOM
•018 BED
•019 BEDROOM
020 BELL
•021 BLOWER
•022 BOILER
023 BOTTOM
025 BREAK
•026 BUILDING
C
028 CABINET
•029 CALL
030 CAMERA
031 CAR
033 CASH
034 CCTV
035 CEILING
036 CELLAR
•037 CENTRAL
038 CIRCUIT
•040 CLOSED
•046 COMPUTER
047 CONTACT
D
•048 DAUGHTERS
049 DELAYED
•050 DEN
051 DESK
•052 DETECTOR
•053 DINING
054 DISCRIMINATOR
055 DISPLAY
•057 DOOR
•059 DOWN
•060 DOWNSTAIRS
061 DRAWER
•062 DRIVEWAY
•064 DUCT
E
•065 EAST
066 ELECTRIC
067 EMERGENCY
068 ENTRY
•069 EQUIPMENT
•071 EXIT
072 EXTERIOR
F
•073 FACTORY
075 FAMILY
•076 FATHERS
•077 FENCE
•079 FIRE
•080 FLOOR
081 FLOW
082 FOIL
•083 FOYER
084 FREEZER
•085 FRONT
G
•089 GARAGE
•090 GAS
091 GATE
•092 GLASS
093 GUEST
094 GUN
H
•095 HALL
•096 HEAT
098 HOLDUP
099 HOUSE
I
100 INFRARED
•101 INSIDE
102 INTERIOR
103 INTRUSION
J
104 JEWELRY
K
•105 KITCHEN
L
•106 LAUNDRY
•107 LEFT
108 LEVEL
•109 LIBRARY
•110 LIGHT
111 LINE
•113 LIVING
•114 LOADING
115 LOCK
116 LOOP
117 LOW
•118 LOWER
M
•119 MACHINE
121 MAIDS
122 MAIN
•123 MASTER
•125 MEDICAL
126 MEDICINE
128 MONEY
129 MONITOR
•130 MOTHERS
•131 MOTION
132 MOTOR
N
•134 NORTH
135 NURSERY
O
•136 OFFICE
•138 OPEN
139 OPENING
•140 OUTSIDE
142 OVERHEAD
P
143 PAINTING
•144 PANIC
145 PASSIVE
•146 PATIO
147 PERIMETER
•148 PHONE
150 POINT
151 POLICE
152 POOL
•153 POWER
R
155 RADIO
•156 REAR
157 RECREATION
159 REFRIGERATION
160 RF
•161 RIGHT
•162 ROOM
163 ROOF
S
164 SAFE
165 SCREEN
166 SENSOR
•167 SERVICE
•168 SHED
169 SHOCK
•170 SHOP
171 SHORT
•173 SIDE
174 SKYLIGHT
175 SLIDING
•176 SMOKE
•178 SONS
•179 SOUTH
180 SPRINKLER
•182 STATION
184 STORE
•185 STORAGE
186 STORY
190 SUPERVISED
191 SUPERVISION
192 SWIMMING
193 SWITCH
T
194 TAMPER
196 TELCO
197 TELEPHONE
•199 TEMPERATURE
200 THERMOSTAT
•201 TOOL
202 TRANSMITTER
U
•205 UP
•206 UPPER
•207 UPSTAIRS
•208 UTILITY
V
209 VALVE
210 VAULT
212 VOLTAGE
W
213 WALL
214 WAREHOUSE
•216 WEST
•217 WINDOW
•219 WING
220 WIRELESS
X
222 XMITTER
Y
223 YARD
Z
224 ZONE (No.)
•225 ZONE
•226 0
•227 1
•228 1ST
•229 2
•230 2ND
•231 3
•232 3RD
•233 4
•234 4TH
•235 5
•236 5TH
•237 6
•238 6TH
•239 7
•240 7TH
•241 8
•242 8TH
•243 9
•244 9TH
245 Custom Word #1
________________
246 Custom Word #2
________________
247 Custom Word #3
________________
248 Custom Word #4
________________
249 Custom Word #5
________________
250 Custom Word #6
________________
251 Custom Word #7
________________
252 Custom Word #8
________________
253 Custom Word #9
________________
254 Custom Word #10
________________
NOTE: Bulleted (•) words in boldface type are those that are also available for use by the 4285/4286
VIP Module. If you are using a phone module, and words other than these are selected for alpha descriptors,
the phone module will not provide annunciation of those words.
CHARACTER (ASCII) CHART
)RU $GGLQJ &XVWRP :RUGV
32 (space)
33 !
34 “
35 #
36 $
37 %
38 &
39 '
40 (
41 )
42 *
43 +
44 ,
45 –
46 .
47 /
48 0
49 1
50 2
51 3
52 4
53 5
54 6
55 7
56 8
57 9
58 :
59 ;
60 <
61 =
62 >
63 ?
64 @
65 A
66 B
67 C
68 D
69 E
70 F
71 G
72 H
73 I
74 J
75 K
76 L
77 M
78 N
79 O
80 P
81 Q
82 R
83 S
84 T
85 U
86 V
87 W
88 X
89 Y
90 Z

–13 –
ENROLLED TRANSMITTERS
ZONE
No.
ZONE
TYPE
ZONE
INPUT
TYPE
SERIAL No. (If applicable)
Stick Serial No. Label from Transmitter
Here
LOOP
No. DEVICE LOCATION

–14 –
ENROLLED TRANSMITTERS (cont'd)
ZONE
No.
ZONE
TYPE
ZONE
INPUT
TYPE
SERIAL No. (If applicable)
Stick Serial No. Label from Transmitter
Here
LOOP
No.
DEVICE LOCATION

–15 –
AUX. POWER
OUTPUT
10.5-13.8VDC
600mA MAX.
(500mA MAX.
FOR UL
INSTALLATIONS)
INTERRUPTS
FOR 4-WIRE
FIRE ALARM
RESET. ALL
CIRCUITS ARE
POWER
LIMITED.
NOTE:
KEYPAD(S)
CURRENT
AND ALL OTHER
DEVICES
DRAWING
POWER FROM
TERMS 4 & 5
MUST BE
INCLUDED IN
AUX CURRENT
DRAIN
CALCULATIONS.
OPTIONAL
FOR UP TO 30 ADDITIONAL ZONES
(ONE FROM EITHER OR BOTH GROUPS)
ADEMCO 5881* Type
RF RECEIVER
WIRELESS ZONES
5881L: UP TO 8
5881M: UP TO 16
5881H: UP TO 30
* 5882 IN CANADA
ADEMCO 4219
WIRED EXPANSION MODULE
(8 ADD'L EOLR WIRED ZONES)
-OR-
ADEMCO 4229
WIRED EXPANSION/RELAY MODULE
(8 ADD'L EOLR WIRED ZONES PLUS 2
OUTPUT RELAYS)
-OR-
ADEMCO 4204 RELAY MODULE
(4 OUTPUT RELAYS)
BLK
RED
GRN
YEL
12345678910 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25
EARTH
GROUND
SEE
INSTRUCTIONS
FOR PROPER
GROUNDING
TELEPHONE WIRING
(VIA RJ31X* JACK AND DIRECT
CONNECT CORD)
*CA38A IN CANADA
DOC LOAD NO.: 3
REMOTE KEYPADS
USE 6148 OR 6160
KEYPADS. LOCAL
PROGRAMMING MUST
BE DONE WITH A 6160
CONNECTED TO KEYPAD
TERMINALS, BUT NEED
NOT REMAIN IN THE
SYSTEM.
BLACK: KEYPAD GROUND (–) RETURN RED: KEYPAD PWR (+) GREEN: DATA IN FROM KEYPAD YELLOW: KEYPAD DATA OUT
REMOTE
KEYPAD
}
WARNING: TO PREVENT RISK OF
SHOCK, DISCONNECT TELEPHONE LINE
AT TELCO JACK BEFORE SERVICING
THIS UNIT.
BATTERY
12V, 4AH
–
+
–
+
CONNECTOR
TABS
PLUG-IN TRANSFORMER
16.5VAC, 25VA (e.g. ADEMCO
No. 1321, USE No. 1321CN IN
CANADA)
TO 110VAC
UNSWITCHED
OUTLET (24HR)
–
+
BLK
RED
GRN
YEL
TO TERM 4
TO TERM 5
TO TERM 6
TO TERM 7
BLK
RED
GRN
YEL AND/OR
SET RECEIVER’S
DIP SWITCH FOR
DEVICE ADDRESS
OF “0”.
SEE
INSTRUCTIONS.
THIS EQUIPMENT SHOULD BE INSTALLED IN
ACCORDANCE WITH THE NATIONAL FIRE PRO-
TECTION ASSOCIATION’S STANDARD 72, CHAP-
TER 2 (NATIONAL FIRE PROTECTION ASSOC.,
BATTERYMARCH PARK, QUINCY, MA 02269).
PRINTED INFORMATION DESCRIBING PROPER
INSTALLATION, OPERATION, TESTING, MAINTE-
NANCE, EVACUATION PLANNING AND REPAIR
SERVICE IS TO BE PROVIDED WITH THIS
EQUIPMENT.
RING
(GRAY) TIP
(GREEN) RING
(RED)
INCOMING
PHONE LINE
HANDSET
BLACK
RED
–+
2000
OHMS
EOLR
2000
OHMS
EOLR
ZONE 1
ZONE 2
HI LO HI LO
2000
OHMS
EOLR
2000
OHMS
EOLR
ZONE 3 ZONE 4
HI LO HI LO
2000
OHMS
EOLR
2000
OHMS
EOLR
ZONE 5 ZONE 6
HI LO HI LO
• MAXIMUM LOOP RESISTANCE: (EACH ZONE) 300 OHMS
(PLUS EOLR)
• RESPONSE, ZONES 1-6: 10, 350, OR 700 MSEC
(PROGRAMMABLE)
VISTA-15/VISTA-15CN SUMMARY OF CONNECTIONS
USE UL LISTED
LIMITED ENERGY
CABLE FOR ALL
CONNECTIONS
BATTERY FUSE
FOR REPLACEMENT,
USE SAME VALUE
(e.g. ADEMCO No. 90-12)
9-PIN CONNECTOR
USED FOR 4300
TRANSFORMER
CONNECTIONS (FOR
OPTIONAL POWER LINE
CARRIER DEVICES)
SEE INSTRUCTIONS.
123456789
USE 4142TR CABLE
USE 4300 TRANSFORMER INTERFACE
IN PLACE OF 1321 WHEN POWER LINE
CARRIER DEVICES ARE BEING USED
(SEE INSTRUCTIONS FOR
CONNECTIONS)
TIP
(BROWN)
}
}
OPTIONAL:
5800TM
TRANSMITTER MODULE (20mA)
(for 5827BD
Wireless Bidirectional Console)
AND/OR
4285/4286 VOICE MODULE (160mA)
AND/OR
LONG RANGE RADIO
MAY ALSO BE CONNECTED. SEE
INSTRUCTIONS ACCOMPANYING
THOSE DEVICES.
THIS DEVICE COMPLIES WITH PART 15 OF FCC RULES.
OPERATION IS SUBJECT TO THE FOLLOWING TWO
CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL
INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT
ANY
INTERFERENCE RECEIVED, INCLUDING INTERFERENCE
THAT MAY CAUSE UNDESIRED OPERATION.
COMPLIES WITH FCC RULES, PART 68.
FCC REGISTRATION NO. AC398U-68192-AL-E
RINGER EQUIVALENCE: 0.7B.
WEEKLY TESTING IS REQUIRED TO ENSURE
PROPER OPERATION OF THIS SYSTEM.
3A
ALARM OUTPUT
10.5-13.8VDC, 2A MAX. (600mA MAX. FOR UL
USAGE, INCLUDING AUX POWER)
STEADY FOR BURGLARY/PANIC, TEMPORAL PULSE
SOUNDING FOR FIRE (e.g. USE ADEMCO No. 702
SIREN, OR 12V BELL). SEE INSTRUCTIONS.
CONNECT 2k RESISTOR ACROSS LAST
SOUNDING DEVICE FOR BELL SUPERVISION
CAN BE USED FOR 2-WIRE SMOKE DETECTORS
SET UNIT’S
DIP SWITCH
FOR DEVICE
ADDRESS
OF “1”.
SEE
INSTRUCTIONS.
FOR COMPLETE INFORMATION
SEE INSTRUCTIONS ACCOMPANYING
VISTA-15 CONTROL (K3892)
SMOKE
ZONES 2–7
*
CHARGING
VOLTAGE
13.8VDC MAX.
CHARGING
CURRENT
600mA MAX.
24 HR BATTERY STANDBY REQUIRED FOR FIRE
INSTALLATIONS. USE 12V, 17.2AH BATTERY
FOR 500mA AUX POWER. SEE INSTRUCTIONS.
NORMALLY
NEED NOT BE
REPLACED FOR AT
LEAST 3 YRS.
TO DETERMINE TOTAL
STANDBY LOAD ON
BATTERY, ADD 100mA TO
TOTAL OF AUX. POWER CUT RED JUMPER
FOR BELL SUPERVISION
FOR CONNECTION OF
OPTIONAL 4285/4286 VOICE MODULE
TO PHONE TERMINALS, SEE
INSTRUCTIONS.
}
NOT USED
BATTERY STANDBY TIME FOR EMERGENCY
BURGLARY MUST BE AT LEAST 4 HOURS.
SEALED LEAD ACID TYPE
BATTERY
AUX PWR
OUTPUT
TERMS
+
-
TO HI SIDE OF SELECTED ZONE
TO LO SIDE OF SELECTED ZONE
+
-
-
+
EOL
POWER
SUPER-
VISION
RELAY
MODULE
A77-716B
5
4
4-WIRE SMOKE
OR COMBUSTION
DETECTOR
2000
OHMS
EOLR
HEAT
DETECTOR
+
RED
BLK
–
* IF PROGRAMMED FOR FIRE
VIOLET
ECP Compatible
V15_V15CN-SOC-V1

165 Eileen Way, Syosset, New York 11791
Copyright ©2000 PITTWAY CORPORATION
¬.9V
K3894V2 7/01 (See Instructions K3892V2)
