ADF Web HD67B17-B2 User manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
J1939
Document code: MN67B17_ENG Revision 1.000 age 1 of 30
User Manual
Revision 1.000
English
OPC UA Client / J1939 - Converter
(Order Code: HD67B17-B2)
for Website information:
http://www.adfweb.com/? roduct=HD67B17
for rice information:
http://www.adfweb.com/? rice=HD67B17-B2
Benefits and Main Features:
Triple electrical isolation
ower Supply 18…35V DC and 8…24 V AC
Temperature range: -40°C/+85°C (-40°F/+185°F)
For others O C UA Client devices, see also the following links:
OPC UA Client from/to …
www.adfweb.com? roduct=HD67B08 ( erial)
www.adfweb.com? roduct=HD67B09 (Modbus lave)
www.adfweb.com? roduct=HD67B10 (Modbus TCP lave)
www.adfweb.com? roduct=HD67B11 (BACnet)
www.adfweb.com? roduct=HD67B12 (CAN)
www.adfweb.com? roduct=HD67B13 (CANopen)
www.adfweb.com? roduct=HD67B14 (DeviceNet lave)
www.adfweb.com? roduct=HD67B15 (DMX)
www.adfweb.com? roduct=HD67B16 (EtherNet/IP lave)
www.adfweb.com? roduct=HD67B18 (KNX)
www.adfweb.com? roduct=HD67B19 (MQTT)
www.adfweb.com? roduct=HD67B20 (NMEA0183)
www.adfweb.com? roduct=HD67B21 (NMEA2000)
www.adfweb.com? roduct=HD67B22 (PROFINET)
www.adfweb.com? roduct=HD67B23 ( NMP Agent)
Do you have an your customer protocol?
See the following links:
www.adfweb.com? roduct=HD67003
Do you need to choose a device? do you want help?
Ask it to the following link:
www.adfweb.com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
J1939
Document code: MN67B17_ENG Revision 1.000 age 2 of 30
INDEX:
age
INDEX 2
U DATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAM LE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 6
CONFIGURATION 6
OWER SU LY 7
FUNCTION MODES 8
LEDS 9
CAN 10
ETHERNET 11
USE OF COM OSITOR SW67B17 12
NEW ROJECT / O EN ROJECT 13
SOFTWARE O TIONS 14
SET COMMUNICATION 16
O C UA ACCESS 17
RECEIVE FRAMES 23
SEND FRAMES 24
U DATE DEVICE 25
MECHANICAL DIMENSIONS 27
ORDERING INFORMATIONS 28
ACCESSORIES 28
DISCLAIMER 29
OTHER REGULATIONS AND STANDARDS 29
WARRANTIES AND TECHNICAL SU ORT 30
RETURN OLICY 30
Pagina 2 di 30
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
REVI ION LI T:
Revision Date Author Chapter Description
1.000 13/03/2019 Tf All First release version
WARNING:
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARK :
All trademarks mentioned in this document belong to their respective
owners.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
J1939
Document code: MN67B17_ENG Revision 1.000 age 3 of 30
ECURITY ALERT:
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and
safety regulation are required for each individual application. The same applies also when using accessories.
I NTENDED U E
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q UALIFIED P ER ONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job.
R E IDUAL R I K
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage.
CE CONFORMITY
The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
J1939
Document code: MN67B17_ENG Revision 1.000 age 4 of 30
EXAMPLE OF CONNECTION:

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
J1939
Document code: MN67B17_ENG Revision 1.000 age 5 of 30
Figure
1
: Connection
scheme
for HD67
B1
7
-
B2
CONNECTION CHEME:

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
J1939
Document code: MN67B17_ENG Revision 1.000 age 6 of 30
CHARACTERI TIC :
The HD67B17-B2 is a O C UA Client / J1939 converter.
It allows the following characteristics:
Up to 1500 bytes in reading and 1500 bytes in writing;
Two-directional information between J1939 and O C UA;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67B17 software on your C in order to perform the following:
Define the parameter of O C UA;
Define the parameter of J1939 line;
Define the list of O C UA servers connected to the converter;
Define the list of J1939 messages in reception and transmission;
Update the device.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
J1939
Document code: MN67B17_ENG Revision 1.000 age 7 of 30
POWER UPPLY:
The devices can be powered between a wide range of tensions. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
HD67B17-B2 8V 24V 12V 35V
Consumption at 24V DC:
Device W/VA
HD67B17-B2 4
Caution: Not reverse the polarity power
HD67B17-B2

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
J1939
Document code: MN67B17_ENG Revision 1.000 age 8 of 30
FUNCTION MODE :
The device has got two functions mode depending of the position of the Dip1 of ‘Dip-Switch A’:
The first, with Dip1 in Off position (factory setting), is used for the normal working of the device.
The second, with Dip1 in On position, is used for upload the roject/Firmware.
For the operations to follow for the updating (see ‘U DATE DEVICE’ section).
According to the functioning mode, the LEDs will have specifics functions (see ‘LEDS’ section).

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
J1939
Document code: MN67B17_ENG Revision 1.000 age 9 of 30
LED :
The device has got five LEDs that are used to give information of the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
2: O C UA comm. (yellow) Flashing: O C UA response
OFF: No O C UA response
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: J1939 comm. (yellow) Flashing: J1939 communication
OFF: No J1939 communication
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
4: Error state (yellow) ON: At least one O C UA Server is disconnected
OFF: all O C UA Servers are connected
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
5: Link Ethernet (green) ON: Ethernet cable connected
OFF: Ethernet cable disconnected
ON: Ethernet cable connected
OFF: Ethernet cable disconnected

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
J1939
Document code: MN67B17_ENG Revision 1.000 age 10 of 30
CAN:
For terminating the CAN line with a 120Ω resistor it is necessary that the Dip1 of ‘Dip-Switch A’ is at ON position.
Cable characteristics:
DC parameter: Impedance 70 Ohm/m
AC parameters: Impedance 120 Ohm/m
Delay 5 ns/m
Length Baud Rate [bps] Length MAX [m]
10 K 5000
20 K 2500
50 K 1000
100 K 650
125 K 500
250 K 250
500 K 100
800 K 50
1000 K 25

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
J1939
Document code: MN67B17_ENG Revision 1.000 age 11 of 30
ETHERNET:
The Ethernet connection must be made using Connector3 of HD67B17-B2 with at least a Category 5E cable. The maximum length of the
cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the
device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a C/ LC/other is recommended the use of a
cross cable.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
J1939
Document code: MN67B17_ENG Revision 1.000 age 12 of 30
U E OF COMPO ITOR W67B17:
To configure the Converter, use the available software that runs with Windows called SW67B17. It is downloadable on the site
www.adfweb.com and its operation is described in this document. (This manual is referenced to the last version of the software present on
our web site). The software works with MSWindows (X , Vista, Seven, 8, 10; 32/64bit).
When launching the SW67B17, the window below appears (Fig. 2).
Note:
It is necessary to have installed .Net Framework 4.
Figure 2: Main window for SW67B1
7

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
J1939
Document code: MN67B17_ENG Revision 1.000 age 13 of 30
NEW CONFIGURATION / OPEN CONFIGURATION:
The “New Configuration” button creates the folder which contains the entire device’s configuration.
A device’s configuration can also be imported or exported:
To clone the configurations of a programmable “O C UA Client / J1939 - Converter” in
order to configure another device in the same manner, it is necessary to maintain the
folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Configuration”.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
J1939
Document code: MN67B17_ENG Revision 1.000 age 14 of 30
OFTWARE OPTION :
By pressing the “ ettings” ( ) button there is the possibility to change the
language of the software and check the updatings for the compositor.
In the section “Language” it is possible to change the language of the
software.
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb.com website.
Checking the option “Check oftware Update at tart of Program”, the
SW67B17 check automatically if there are updatings when it is launched.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
J1939
Document code: MN67B17_ENG Revision 1.000 age 15 of 30
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in
the different sections of the software.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
J1939
Document code: MN67B17_ENG Revision 1.000 age 16 of 30
ET COMMUNICATION:
This section define the fundamental communication parameters of two buses, O C UA and
J1939.
By ressing the “ et Communication” button from the main window for SW67B17 (Fig. 2)
the window “Set Communication” appears (Fig. 3).
The means of the fields for “O C UA Client” are:
In the field “IP Address” the I address for O C UA side of the converter is defined;
In the field “ ubNet Mask” the SubNet Mask for O C UA side of the converter is
defined;
In the field “Gateway” the default gateway of the net is defined. This feature can be
enabled or disabled pressing the Check Box field. This feature is used for going out
of the net;
In the field “DN ” the I Address of the DNS server is defined. This feature can be
enabled or disabled pressing the Check Box field.
The means of the fields for “J1939” are:
In the field “Baudrate” the data rate of J1939 is defined;
In the field “TimeOut Data” a time is defined. When a J1939 message is not
received in this time, the data on MQTT side are set to 0xFF;
If the field “Enable Peer to Peer” is checked, the gateway will mask the Source
Address of the J1939 messages received.
In the field “ID Device J1939” the ID of J1939 side of the converter is defined.
The means of the fields for “NT (Network Time rotocol)” are:
In the field “ erver URL” the URL or the I Address of the NT Server is defined;
In the field “Poll Time (seconds)” the polling time for the time synchronization is
defined.
Figure 3: “Set Communication” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
J1939
Document code: MN67B17_ENG Revision 1.000 age 17 of 30
Figure 4: “O C UA Client Access” window
OPC UA ACCE :
By ressing the “OPC UA Client Access” button from the main window for SW67B17 (Fig. 2) the window “O C UA Client Access” appears
(Fig. 4).
This section is used to define the list of the O C UA Servers to read/write with the O C UA Client.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
J1939
Document code: MN67B17_ENG Revision 1.000 age 18 of 30
Figure 5: “Add O C UA Server” Figure 6: “Modify O C UA Server”
By clicking on “Add”, it is possible to add a new O C UA Server inserting its characteristics (Server Address, Authorization, Security Type…).
The window “Add O C UA Server” appears (Fig. 5). By clicking on “Modify”, it is possible to change these characteristics for the selected
Server. The window “Modify O C UA Server” appears (Fig. 6).

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
J1939
Document code: MN67B17_ENG Revision 1.000 age 19 of 30
Figure 7: “Scan Server O C UA” window
By clicking on “ can”, it is possible to get the list of available variables from the selected Server. The window “Scan Server O C UA” appears
(Fig. 7).
The means of the checkboxes inside the table are:
If the field “Read” is checked, the variable can be read;
If the field “Write” is checked, the variable can be written.
Note:
For each variable, it is possible to uncheck these fields and the variable will not be used in read/write.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA Client /
J1939
Document code: MN67B17_ENG Revision 1.000 age 20 of 30
Figure 8: “Variables in Read” section
After the scan, the selected variables will appear in “Variables in Read” and/or “Variables in Write” sections, in the lower part of the window
“O C UA Client Access” (Fig. 4).
The “Variables in Read” section is used to define the O C UA variables to make available on J1939 side (Fig. 8).
The means of the fields are:
If the field “Enable” is checked, the O C UA variable is enabled;
In the field “Display name” the name of the O C UA variable is defined;
In the field “Node Type ” the type of the O C UA node, which includes the variable, is defined;
In the field “Node ID” the name of the O C UA node, which includes the variable, is defined;
In the field “Var Type” the data format of the O C UA variable is defined;
In the field “Name pace Index” the Name Space Index of the node, which includes the variable, is defined;
In the field “Time (ms)” the delay in ms between two readings of the variable is defined;
In the field “Position” the starting byte of the internal memory arrays where saving the value is defined;
In the field “Mnemonic” a description of the variable is defined.
