ADF Web HD67738-IP-A1 User manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server /
BAC
net
Slave
Document code: MN67738_ENG Revision 1. Page 1 of 3
User Manual
Revision 1.
English
IEC 61850 Server / BACnet Slave - Converter
(Order Code: HD67738-IP-A1 , HD67738-MSTP-A1)
For Website information:
www.adfweb.com?Product=HD67738
For Price information:
www.adfweb.com?Price=HD67738-IP-A1
www.adfweb.com?Price=HD67738-MSTP-A1
Benefits and Main Features:
Very easy to configure
Triple Electrical isolation
Temperature range: -4 °C/+85°C (-4 °F/+185°F)
For other IEC 6185 products see also the following link:
Converter IEC 61850 Server to
www.adfweb.com?Product=HD67B82 ( ROFINET Master)
www.adfweb.com?Product=HD6762 (S7comm)
www.adfweb.com?Product=HD67733 (Modbus Master)
www.adfweb.com?Product=HD67734 (Modbus Slave)
www.adfweb.com?Product=HD67735 (Modbus TC Master)
www.adfweb.com?Product=HD67736 (Modbus TC Slave)
www.adfweb.com?Product=HD67737 (BACnet Master)
www.adfweb.com?Product=HD67739 (CAN)
www.adfweb.com?Product=HD6774 (CANopen)
www.adfweb.com?Product=HD67741 (DeviceNet Master)
www.adfweb.com?Product=HD67743 (EtherNet/I Master)
www.adfweb.com?Product=HD67744 (EtherNet/I Slave)
www.adfweb.com?Product=HD67745 (J1939)
www.adfweb.com?Product=HD67746 (KNX)
www.adfweb.com?Product=HD67747 (MQTT)
www.adfweb.com?Product=HD67748 (NMEA0183)
www.adfweb.com?Product=HD67749 (NMEA2000)
www.adfweb.com?Product=HD6775 ( ROFIBUS Master)
www.adfweb.com?Product=HD67751 ( ROFIBUS Slave)
www.adfweb.com?Product=HD67752 ( ROFINET Slave)
www.adfweb.com?Product=HD67753 (SNM Manager)
www.adfweb.com?Product=HD67754 (SNM Agent)
www.adfweb.com?Product=HD67755 (Serial)
www.adfweb.com?Product=HD67756 (Ethernet)
www.adfweb.com?Product=HD67765 (EnOcean)
Do you have your customer protocol? Then go to:
www.adfweb.com?Product=HD67 3
Do you need to choose a device? Do you want help?
www.adfweb.com?Cmd=helpme
U
ser Manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server /
BAC
net
Slave
Document code: MN67738_ENG Revision 1. Page 2 of 3
INDEX:
Page
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 7
CONFIGURATION 7
POWER SUPPLY 8
FUNCTION MODES 9
LEDS 1
ETHERNET 11
RS485 (FOR BACNET MS/TP) 12
USE OF COMPOSITOR SW67738 13
NEW CONFIGURATION / OPEN CONFIGURATION 14
SOFTWARE OPTIONS 15
SET COMMUNICATION 17
IEC 6185 ACCESS 21
SET BACNET ACCESS 22
TLS KNOWN CERTIFICATE 24
BACNET EDE FILE 24
UPDATE DEVICE 25
MECHANICAL DIMENSIONS 27
ORDERING INFORMATIONS 28
ACCESSORIES 28
DISCLAIMER 29
OTHER REGULATIONS AND STANDARDS 29
WARRANTIES AND TECHNICAL SUPPORT 3
RETURN POLICY 3
U DATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
REVISION LIST:
WARNING:
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belong to their respective
owners.
Revision Date Author Chapter Description
1. 18/ 9/2 2 Ff All First Release

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server /
BAC
net
Slave
Document code: MN67738_ENG Revision 1. Page 3 of 3
SECURITY ALERT:
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and
safety regulation are required for each individual application. The same applies also when using accessories.
I NTENDED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q UALIFIED ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job.
R ESIDUAL R ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage.
CE CONFORMITY
The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server /
BAC
net
Slave
Document code: MN67738_ENG Revision 1. Page 4 of 3
EXAM LES OF CONNECTION:

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server /
BAC
net
Slave
Document code: MN67738_ENG Revision 1. Page 5 of 3
CONNECTION SCHEME:
Figure 1a: Connection scheme for HD67738 IP A1

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server /
BAC
net
Slave
Document code: MN67738_ENG Revision 1. Page 6 of 3
Figure 1b: Connection scheme for HD67738 MSTP A1

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server /
BAC
net
Slave
Document code: MN67738_ENG Revision 1. Page 7 of 3
CHARACTERISTICS:
The HD67738-xxx-A1 are IEC 6185 / BACnet - Converters.
It allows for the following characteristics:
Triple isolation between RS232/RS485/RS422 - Power Supply, RS232/RS485/RS422 - Ethernet, Ethernet - Power Supply;
Two-directional information between IEC 6185 bus and BACnet bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -4 °C / 85°C [-4 °F / +185°F].
CONFIGURATION:
You need Compositor SW67738 software on your PC in order to perform the following:
Define the parameters of IEC 6185 line;
Define the parameters of BACnet line;
Define IEC 6185 variables that contains the data written by the BACnet Master;
Define IEC 6185 variables that contains the data to make available to the BACnet Master;
Define BACnet objects accessible by the external BACnet Master;
Export the EDE file for configuration of BACnet Master;
Update the device.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server /
BAC
net
Slave
Document code: MN67738_ENG Revision 1. Page 8 of 3
OWER SU LY:
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 24V DC:
Device Consumption [W/VA]
HD67738-X-A1 3.5
HD67738-X-A1
Caution:
Do n
ot reverse the polarity power

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server /
BAC
net
Slave
Document code: MN67738_ENG Revision 1. Page 9 of 3
FUNCTION MODES:
The device has got two function modes depending on the position of the ‘Dip1 of Dip-Switch A’:
The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
The second, with ‘Dip1 of Dip-Switch A’ at “ON” position, is used for uploading the Project and/or Firmware.
For the operations to follow for the updating, see ‘UPDATE DEVICE’ section.
According to the functioning mode, the LEDs will have specific functions, see ‘LEDS’ section.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server /
BAC
net
Slave
Document code: MN67738_ENG Revision 1. Page 1 of 3
LEDS:
The device has got six LEDs that are used to give information about the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: ON [supply voltage ]
(green)
ON: Device powered
OFF: Device not powered
ON: Device powered
OFF: Device not powered
2: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: BACnet communication
(green) It blinks when a BACnet request is received Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
4: IEC 6185 communication
(green) It blinks when a IEC 6185 request is received Blinks quickly: Boot state Blinks very slowly (~0.5Hz): update in progress
5: Ethernet1 Tx (green) Blinks when is transmitting Ethernet frames Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
6: Ethernet2 Tx (green) Blinks when is transmitting Ethernet frames Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server /
BAC
net
Slave
Document code: MN67738_ENG Revision 1. Page 11 of 3
ETHERNET:
IEC 6185 connection, BACnet/IP connection and the updating of the converters must be made using Connector3 and/or Connector4 of the
HD67738-XXX-A1 with at least a Category 5E cable. The maximum length of the cable should not exceed 1 m. The cable has to conform to
the T568 norms relative to connections in cat.5 up to 1 Mbps. To connect the device to an Hub/Switch is recommended the use of a
straight cable, to connect the device to a PC/PLC/other is recommended the use of a cross cable.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server /
BAC
net
Slave
Document code: MN67738_ENG Revision 1. Page 12 of 3
RS485 (for BACnet MS/T ):
For terminating the RS485 line with a 12 Ω resistor it is necessary to put ON dip 1, like in figure.
The maximum length of the cable should be 12 m (4 feet).
Here some codes of cables:
Belden: p/n 8132 - 2x 28AWG stranded twisted pairs conductor + foil shield + braid shield;
Belden p/n 82842 - 2x 24AWG stranded twisted pairs conductor + foil shield + braid shield;
Tasker: p/n C521 - 1x 24AWG twisted pair conductor + foil shield + braid shield;
Tasker: p/n C522 - 2x 24AWG twisted pairs conductor + foil shield + braid shield.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server /
BAC
net
Slave
Document code: MN67738_ENG Revision 1. Page 13 of 3
USE OF COM OSITOR SW67738:
To configure the Converter, use the available software that runs with Windows called SW67738. It is downloadable on the site
www.adfweb.com and its operation is described in this document. (This manual is referenced to the last version of the software present on
our web site). The software works with MSWindows (XP, Vista, Seven, 8, 1 ; 32/64bit).
When launching the SW67738, the window below appears (Fig. 2).
Note:
It is necessary to have installed .Net Framework 4.
F
igure 2: Main window for SW67738

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server /
BAC
net
Slave
Document code: MN67738_ENG Revision 1. Page 14 of 3
NEW CONFIGURATION / O EN CONFIGURATION:
The “New Configuration” button creates the folder which contains the entire device’s configuration.
A device’s configuration can also be imported or exported:
To clone the configurations of a programmable “IEC 6185 Server / BACnet Slave -
Converter” in order to configure another device in the same manner, it is necessary to
maintain the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Configuration”.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server /
BAC
net
Slave
Document code: MN67738_ENG Revision 1. Page 15 of 3
SOFTWARE O TIONS:
By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the
compositor.
In the section “Language” it is possible to change the language of the
software.
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb.com website.
Checking the option “Check Software Update at Start of rogram”, the
SW67738 checks automatically if there are updatings when it is launched.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server /
BAC
net
Slave
Document code: MN67738_ENG Revision 1. Page 16 of 3
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in
the different sections of the software.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server /
BAC
net
Slave
Document code: MN67738_ENG Revision 1. Page 17 of 3
SET COMMUNICATION:
By Pressing the “Set Communication” button from the main window for SW67738
(Fig. 2) the window “Set Communication” appears (Fig. 3).
The window is divided in different sections in order to define the different
parameters of the converter:
IEC 6185 Server
TLS (Transport Layer Security) Server
BACnet Slave
NTP (Network Time Protocol)
Figure 3a: “Set Communication” window

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server /
BAC
net
Slave
Document code: MN67738_ENG Revision 1. Page 18 of 3
Figure 3b: “Set Communication  IEC 61850
Server” window
Figure 3c: “Set Communication

TLS” window
IEC 61850 S ERVER :
This section is used to define the main parameters of IEC 6185 line. The means of
the fields are:
In the field “ ort” the port used for IEC 6185 communication is defined;
If the field “ assword” the password used for accessing to IEC 6185
variables is defined.
TLS (T RANS ORT L AYER S ECURITY ) S ERVER
This section is used to define the main parameters of TLS protocol. The means of
the fields are:
If the field “Enable TLS” is checked, the TLS protocol for secure connection
is enabled;
In the field “Key” the key for the authentication is defined;
In the field “Key assword” the password for decrypting the key is defined;
In the field “Server Certificate” the certificate for the server is defined;
In the field “Root Certificate” the root of the server is defined;
If the field “Enable Only Known Certificates” is checked, the converter will
accept just connection from known Clients (defined in the section “TLS
Known Certificate”).

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server /
BAC
net
Slave
Document code: MN67738_ENG Revision 1. Page 19 of 3
Figure 3d: “Set Communication  BACnet Slave”
window
BAC NET S LAVE :
This section is used to define the main parameters of BACnet line. It is possible to
select the type of BACnet to use from:
BACnet/IP (it uses Ethernet);
BACnet MS/TP (it uses RS485).
If selected “BACnet/IP” the means of the fields for “BACnet” are:
In the fields “I ADDRESS” the IP address of BACnet/IP side of the
converter is defined;
In the fields “SUBNET Mask” the SubNet Mask of BACnet/IP side of the
converter is defined;
In the fields “GATEWAY” the default gateway of the network is defined. This
feature can be enabled or disabled pressing the Check Box field. This feature
is used for going out of the net;
In the field “ ort” the port used for BACnet communication is defined. The
default port used for BACnet communication is 478 8, but is possible to
insert any value;
In the field "BACnet Device Name" the name of BACnet/IP side of the
converter is defined;
In the field “Device Identifier” the device instance of BACnet/IP side of the
converter is defined;
If the field “BACnet description up to 32 chars” is checked, the
description of the BACnet objects can be up to 32 chars.
If selected “BACnet MS/TP” the means of the fields for “BACnet” are:
In the field “Baudrate” the baudrate of BACnet MS/TP side of the converter
is defined;
In the field “ arity” the parity of BACnet MS/TP side of the converter is
defined;
In the field “BACnet Device Name” the name of BACnet MS/TP side of the
converter is defined;

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server /
BAC
net
Slave
Document code: MN67738_ENG Revision 1. Page 2 of 3
Figure 3e: “Set Communication  NTP” window
In the field “MAC Address” the MAC of BACnet MS/TP side of the converter is
defined;
The field “Max Masters” specifies the highest allowable address for master
nodes. The value shall be less than or equal to 127;
The field “Max Info Frames” specifies the maximum number of information
frames the node may send before it must pass the token;
In the field “Device Istance” it is possible to assign a number to the
BACnet node (used for the Device Istance);
In the field “Network” the BACnet MS/TP network number is defined;
If the field “BACnet description up to 32 chars” is checked, the
description of the BACnet objects can be up to 32 chars.
NT :
This section is used to define the general parameters of NTP. The means of the
fields are:
In the field “Server URL” the URL or the IP Address of the NTP Server is
defined;
In the field “ oll Time (seconds)” the polling time for the time
synchronization is defined.
